Unidrive SP Panel Mounted
0.37kW – 132kW
200V 1ph/200V 3ph/400V/575V/690V
High Performance AC & Servo Drive
Unidrive SP Panel Mount is a high performance drive module for system integration and stand alone applications.
Applications
Due to the inherent performance and flexibility of Unidrive SP, potential areas for its application are limitless, the drives’ intelligence and dynamic response allow it to be applied in the most demanding applications.
Benefits
Onboard programmable intelligence and generous connectivity allows the removal of external programmable logic and motion controllers, reducing costs and the cabinet size. Unidrive SP features 5 analogue I/O and 7 digital I/O as standard;
Drive option module slots future proof your investment, it also means you only fit the functionality you need, reducing costs and removing complexity. Unidrive SP Sizes 1 to 6 benefit from 3 option slots with the ultra compact Size 0 featuring 2 slots;
Available option modules include advanced automation controllers, world-standard fieldbus connectivity options and a comprehensive range of digital and analogue I/O interfaces and feedback devices;
Optional Internal Brake Resistors for Unidrive SP Sizes 0, 1 & 2 reduce your space requirement;
The built in EMC filter is suitable for most applications and can be easily removed where required. Optional external footprint EMC Filters are available where more rigourous standards must be met;
Safe Torque Off reduces system costs in machine safety designs;
IP54 through panel mount capability allows convenient heat dissipation and reduces cabinet size;
Operation with global power supplies 200V, 400V, 575V & 690V.
|
|
|
|
|
|
MELSERVO - Servo technology that does more
Servo Amplifiers: MR-J3-A, MR-J3-B und MR-J3-T
Mitsubishi offer a wide range of Servo amplifiers to meet the demands of all types of applications. From standard digital pulse and analogue controlled amplifier through to dedicated SSCNET bus type amplifiers, there is a product for all circumstances.
• Realtime-Auto-Tuning
• Adaptive vibration suppression control function to suppress machine resonance frequency
• Advanced vibration suppression control for compensation of motion overshoot
• Compact and flexible design
• Communication via USB, RS-422
• Automatic servo motor recognition
• Torque-, speed- and position control mode is possible by using pulstrain/ analog input signals (MR-J3-A)
• High precision synchronisation of servo axes via „Plug-and-Play“ Motion network SSCNET III (MR-J3-B)
• Integrated positioning functions with CC-Link network (MR-J3-T)
• 6 different motor types
• Absolute detection system with 262144 Pulse/Rev. encoder as standard
• HF-SP/ HF-JP motor series have IP67 protection as standard enhancing their ability to withstand environmental hazards
Servo Motors: HF-KP/ HF-MP/ HC-RP/ HF-SP/ HF-JP/ HA-LP
Mitsubishi Servo Motors are made to high standards and offer a wide range of power, speed and inertia ratings providing a motor for all applications. Ranging from 50W through to 55kW and with specialist type motors available (flat “pancake”motors) the new motors of the MR-J3 series complete the line-up of products offered by Mitsubishi Electric.
|
|
|
|
|
|
DIGITAX ST SERVO DRIVE - 1.1 to 8 A
Servomotor control
- Three versions :
DIGITAX ST-BASE
DIGITAX ST-INDEXER
DIGITAX ST-PLUS
- Main supply :
Single or three phases 230V : 1.1 up to 4.7 A
Three Phases 400V : 1.5 up to 8 A
DIGITAX ST drives satisfy the requirements of the modern automation environments in the world of Servo Process application drive systems. They offer users maximum ease of use.
DIGITAX ST drives allow transient cycles with an exceptional dynamic response. They can handle very high peak torques, up to 300% of Tn.
The universal encoder input can be used to control incremental, SinCos, Hiperface, EnDAT and SSI encoders. DIGITAX ST’s embedded intelligence saves on having an external automated management system, while simplifying the installation.
Commissioning is quick and easy, with a choice of parameter-setting mode via a removable keypad, a Smartcard, or a CTSoft software.
The CTscope software, a 4-channel real-time oscilloscope, can be used to display, analyse and save application data.
Standard application programs, that can be integrated in the drives, are available: position control, cam, indexing, synchronisation between axes.
Option modules provide connectivity to all standard industry fieldbuses: EtherCAT, Ethernet IP, Ethernet TCP/IP, SERCOS, CANopen, Profibus, DeviceNet, Interbus.
|
|
Together with BSH servo motors, Lexium 05 servo drives are compact and dynamic servo drives for machines with various power ranges and diverse supply voltages.
Lexium 05 servo drives:
100…120 V single phase, from 0.4 to 1.4 kW
200…240 V single phase, from 0.75 to 2.5 kW
200…240 V 3-phase, from 0.75 to 3.2 kW
380…480 V 3-phase, from 1.4 to 6 kW
BSH servo motor:
Nominal torque: from 0.5 to 36 Nm
Nominal speed: from 1500 to 8000 rpm
|
|
AC Servo DrivesConfigure Product Selector Documents 3D Models
Our AC servo drives are designed to compliment our wide range of rotary and linear three phase brushless servomotors and offer the broadest connectivity available in the global marketplace today. These drives bring you advanced control technology along with compact packaging and simplified commissioning.
Standard models are available from 300 watts to 58 kW continuous with input voltage ranges from 20 VDC to 480 VAC
|
|
Digital servo controller for three-phase synchronous servo motors with permanent magnets.
- Compact devices for mounting in control cabinets
- Integrated safety technology
- Comprehensive technical functions
- High dynamics and quality of control
- Choice of field bus interfaces: Profibus DP, CANopen, EtherCAT
- Analog and digital inputs and outputs
- Integrated mains filter and ballast circuit
- Direct connection to 230 V or 3 x 400/480 V
|
|
|
|
|
|
As the technology of microprocessor unit becomes more advanced and much further, the development and cost effectivity of permanent magnet manufacturing technology for servo motor and high power and high performance semiconductor power devices is improved continuously. Therefore, AC servo motor and AC servo control system have become the basic techniques for accomplishing automation control technology in current industry field.
Delta servo system is an omnibearing integrated servo system which is based on Delta's strength in industrial and electronic technology and developed for different customers' requirements of various application machine tools. All ASDA series servo drives are provided with a superior digital signal processor (DSP) which represents a high-speed performance of the control circuit loop. Besides, the other features of Delta ASDA series, including gain tuning, smooth motor operation and software analysis / monitor function, also provide high-speed and high-precision motion control for a wide range of industrial automation applications.
|
|
Servo/Motion
MELSERVO - Servo technology that does more
Mitsubishi Electric offers a variety of Servo and Motion system products providing solutions for applications as simple as a single axis point-to-point system through to fully synchonised 96 axis systems.
With both standard pulse type output modules and SSCNET bus modules specific application needs are easy to meet.
The Super Series of Servo motors and amplifiers takes Mitsubishi Motion Control to new levels of precision with a wide range of motors (all fitted with a standard 131,072 absolute encoder) and wide amplifier range (up to 55kW).
All Mitsubishi Servo and Motion system hardware is complimented by a range of software packages allowing easy programming and set-up of the units.
|
|
MELSERVO - Servo technology that does more
Servo Amplifiers: MR-J2S-A, MR-J2S-B und MR-J2S-CL
Mitsubishi offer a wide range of Servo amplifiers to meet the demands of all types of applications. From standard digital pulse and analogue controlled amplifier through to dedicated SSCNET bus type amplifiers, there is a product for all circumstances.
• Real-time autotuning
• Compact design
• Communications capability with RS232/RS485
• Automatic motor type recognition
• Multiple operation mudes (MR-J2S-A)
• Built-in positioning control (MR-J2S-CL)
• 4 different motor types available
Servo Motors: HC-KFS/ HC-MFS/ HC-SFS/ HC-RFS
Mitsubishi Servo Motors are made to high standards and offer a wide range of power, speed and inertia ratings providing a motor for all applications. Ranging from 50W through to 55kW and with specialist type motors available (flat “pancake”motors) the new Super Series Servo Motors complete the line-up of products offered by Mitsubishi Electric.
|
|
Shortest cycle time – highest throughput
Better product quality
Less machine wear
Shortest initial set-up time
Lowest lifecycle cost
|
|
AC Servo Motors
Today machines require servo systems that can fully utilise the machin's potential. In response to this Yaskawa has released the Sigma Series, the servo drive product, which completely realises our concept of "compact, quick and simple"
|
|
| ... products without technical information |
| |
The new series of servo motors SM2A with integrated motor can be easily programmed through EVER's windows PC based user friendly development environment called ATOMIC.
The SM2A series are constructed with a high protection degree of IP65 and are equipped with reliable connectors. Other features are: AC power supply, fieldbus CANbus or serial RS232/485, optoisolated inputs and outputs, an encoder for the closed loop control of torque, velocity and position (optional), The motor section is made of magnetic Low Loss material and has a holding torque from 3,4 to 12,5 Nm.
|
|
# Peripheral operation, minimized installation needs
# Versions for operation at 24VDC and 48VDC
# Compact and powerful design
# Versions with CANopen interface acc. to CiA DSP 402 V2.0
# Versions with incremental output 1024/rev. RS422 A-,B-,Z-signal
# Dynamic speed control and positioning
# To combine with planetary gear GPK45/55 (1-, 2-stages; up to i=49:1)
# Parking brake available
# High protection class IP54 (IP65 as an option)
# Maintenance free and robust
# Customer specific design
|
|
IndraDyn A is the new generation of asynchronous motors in the 1 to 100 KW power range, available in four axis heights (100, 130, 160 and 180), with options like high-resolution, single-turn or multi-turn absolute encoders and a brake. The air and liquid-cooled motors provide significant advantages for service and preventive maintenance due to their integrated modular construction. For example, exchanging a cooling fan is possible in a few minutes with the appropriate safety measures, even when the motor is running. This provides substantial advantages when used in decentrally-powered printing machinery, machine tools, plastics machinery and general automation.
MAD Series – Air-Cooled Asynchronous Servo Motors
With modern development and production processes, a significant performance increase can be achieved in contrast to previous models. Unparalleled performance: Drive and fan motors offer an IP65 protection rating
|
|
MSK Series
This series offers complete scalability, with performance options for standard and more challenging applications. The compact construction with increased torque density provides a costomer-orriented range of size and performance.
|
|
ASM series asynchronous servomotors:
• robust squirrel-cage rotor
• field weakening range to 8000 rpm with constant output
• integrated PTC
• terminal box
• shaft with feather key
• vibration severity grade N to DIN ISO 2373 (optionally grade R possible)
• outstanding value for money
|
|
The LSH Servomotor - the power pack
Nominal torque 0,2 Nm up to 20 Nm
Based on the new winding technology, the so-called concentrated winding, the new LSH generation of motors improves power density by between 30% and 70% relative to conventional technologies. For the user that means as much as a 100% improvement in dynamics, and more compact installation combined with smooth running.
The LST-Servomotor - the versatile one
Nominal torque 0,1 Nm up to 24 Nm
Featuring conventional winding technology, the LST motor combines all the advantages of a 6-pole synchronous servomotor.
* Well suited to speeds up to 9000 rpm. Special windings are possible on request.
* High overload capacity even at standstill based on efficient heat distribution in the stator packet.
* Increased rotor moment of inertia for torque adaptation.
|
|
MAD Series – Air-Cooled Asynchronous Servo Motors
With modern development and production processes, a significant performance increase can be achieved in contrast to previous models. Unparalleled performance: Drive and fan motors offer an IP65 protection rating
MAF Series – Liquid-Cooled Asynchronous Servo Motors
The MAF series with liquid cooling provides high sustained performance in a compact package. Robust and maintainable. The quick-release coupler with integrated leakage protection can be disconnected under full coolant pressure. The encoder systems are accessible from the outside and simplify on-site service.
|
|
MSK Series
This series offers complete scalability, with performance options for standard and more challenging applications. The compact construction with increased torque density provides a costomer-orriented range of size and performance.
|
|
|
|
