Kemro UserID - the intelligent identification method
This innovative module for a quick and simple user identification makes an enormous increase in machine and plant productivity possible.
The Kemro UserID product line offers an optimal and comprehensive solution in this regard. With this solution, both the cumbersome user registration with names and passwords, as well as the extensive efforts needed for the maintenance and administration of user data, are no longer necessary at the machine level.
Kemro UserID not only registers names and access rights; with it one can also define a large variety of settings for each operator, such as the preferred language of the visualisation screens. This means that every user will immediately have the accustomed visualisation environment and preferred language at his disposal.
|
|
The TURCK identification system is a so-called RFID system (Radio Frequency IDentification).
Data are exchanged by electromagnetic waves.
The system operates wear-free and non-contact and is insensitive to temperature fluctuations (high temperature data carriers), dirt as well as water and oils.
Furthermore, it has a very long service life.
The system is comprised of:
- a mobile data carrier
- a read/write head
- a processor unit (interface module)
|
|
The RF identification system for production control.
- DTS125: Industrially compatible identification system in 125 kHz technology.
- Coding of workpiece carriers in routing conveyors.
- Quick and easy set-up: Plug and play.
- Read/write head requiring little space due to narrow design.
- Compact and at a low cost: Antenna and evaluation in one housing.
Innovation in production control
The constant increase of the degree of automation in modern production plants is increasingly supported by identification systems. Their tasks include for example the control or release of production steps or the assignment of information about each product.
|
|
|
|
|
|
Access control is installed on millions of doors worldwide each year. A significant proportion utilise high integrity cards or biometrics to prevent compromise to their system yet few have any measure to prevent a person following (tailgating) a cardholder.
Using IRISYS unique thermal imaging technology, the IRS 2100 Tailgate Detector offers a significant increase in security for controlled doors, helping prevent unauthorised access, countering walk-in theft or enforcing the requirement for all employees to use their card for roll-call, audit and safety purposes. By catering for multiple cardholders and simultaneous entry and exit it allows normal use of the controlled door.
The unit is self contained, can interface with most access control systems and the resulting tailgate alarm output can be used to trigger an alarm, sound a local buzzer and activate a CCTV system.
Applications:
Airports, Ports & Rail Terminals
Defence Establishments
Banks and Building Societies
Cash Centres
Data Centres
High Security Manufacturing Plants
Pharmaceutical Companies
R&D Centres
Public and Private Buildings and Complexes
|
|
|
Capacitive fingerprint biometric reader connectable to OMNIA controllers (memorizes 1900 fingerprints with one second response time). Surface or wall mounted versions.
|
|
Balluff provides a range of RFID systems to track work in progress and provide feedback on in-process testing. Computer-assisted manufacturing, modern warehouse systems, flexible assembly lines, plus logistics and distribution systems benefit from Balluff BIS RFID systems.
Balluff has developed a complete line of easy to use read-only systems that interface directly into a PLC through discrete inputs or an RS-232 interface. These systems offer data reliability and environmental ruggedness not found in bar code systems. Read-only systems are ideal when product data are stored centrally in a control system and referenced by a code contained on RFID tags located on products, parts, or pallets.
|
|
|
|
|
|
Active RFID System FC-406:
Applications
. Mine worker tracking security system
. Hospital Intelligent management
. School security system
. Intelligent residential area management
. Prison security management
. Asset tracking and management
. Entry management
Features:
Low power consumption design,battery life 1-3years
Able to replace battery
IP67 water-proof level
Two call buttons
Anti-collision design
Two-color LED display
Speaker inside Tags
Range between tag and reader over 100 meters
RFID system is composed of three parts:
Tag: Each tag has a single ID code.
Reader: The device for reading or writing the tag information. It has two
kinds of reader: Fixed reader and handheld reader.
Antenna: To transfer the signal between the reader and the tag.
The reader provide the standard RS-232 interface and USB interface, The interface rate is 19200bps(8N1).
Specification:
Tags
Frequency :433.92MHz,868MHz,915MHz
RF data rate :19.2kbit/s
Modulation:FSK
Dimension: 65mm*42mm*14mm
Housing: ABS
Memory:read/wirte, 1k bytes
Storage Temperature: -30C--+70C
Reader
Frequency :433.92MHz,868MHz,915MHz
RF data rate :19.2kbit/s
Modulation:FSK
Dimension: 85mm*55mm*25mm
Housing: ABS
Storage Temperature: -30C--+70C
|
|
FINGERKEY
Access control unit with Pin and Prox reader integrated
Technical specifications
Memory capacity 800 templates / 1600 fingerprints
Verification mode 1:1 or 1:N
Identification modes Finger-prints only, PIN + finger-prints, PIN only
Sensor Optical
Risoluzione 500 DPI
Output1 relay 3A/12VDC
Output2 Wiegand 16/34
Power supply 12 Vdc
Electrical input 150 mA
Identification speed <= 2 second
Wrong identification ratio <= 1 %
Wrong authorization ratio <= 0.0001 %
Signals 3 LED’s, keypad keybacklight, buzzer
Dimensioni 166 x 90 x 31.6 mm
|
|
GSL 1000 is a modern and competitive high-security electronic lock designed to be perfectly adapted to the specific requirements of the customers in banking, retail and secure storage.
GSL 1000 can be used as a stand-alone unit, as a lock using one-time codes or as part of a network. It offers a powerful management software to manage and control the fleet of locks.
GSL 1000 is approved by ECB-S and A2P (Grade A and B) and by Vds (class II and III).
|
|
EASYBKA
Vandal-proof access control unit with blue backlite keypad, suitable for external applications (resinate electronics) controls up to 500 users using 4 fi gure codes.
vandal-proof
backlite
2 output relays 5A
2 two-colour warning LED + buzzer
optical tamper
selectable thermal heating
zama housing with 1 m cable
|
|
COMPASS access control system
A MODEL FOR EVERY NEED.
> Multiple application possibility thanks to the broad range of cards managed (up to 6000) in standalone mode.
> The wide range of components and accessories makes it possible to create a product to measure for every need.
SMART TECHNOLOGY.
> Parameter variations are made without interrupting operation of the system.
SAFE USE.
> Identification of the cards is carried out in an environment which is separate from the reading one, thereby guaranteeing the system's inaccessibility even if the card reader is tampered with.
|
|
|
|
|
|
Stand Alone Touchplate Card Reader
The 26SA standalone access control unit provides an effective and inexpensive solution to access control requirements without the need for secondary controllers, software or expensive cable runs when interfaced with a CPEAPE auto gate. A "touch" of the card on the stainless steel face plate allows the 26SA to read the card and grant access to the parking facility.
DESCRIPTION
Self Contained
3500 Card Capacity
Touch Card Slotless Reader
No Control Panels or Secondary Electronics
Easy To Install
Low Power Consumption
Non-Volatile Memory
Timed Anti-Passback (1750 Card Maximum)
SPECIFICATIONS
The 26SA card access control unit utilizes state-of the art electronics in providing a unit that is both inexpensive and fully programmable. The patented slotless reader is protected from weather and vandalism. Simply place the card on the stainless steel touch plate and the card is read instantly and without error. A green light indicates that access has been granted.
Power Requirements:
The 26SA operates from 8 to 24 volts, AC or DC, and consumes less than 200 milliamps.
Outputs:
Latch SPDT Contact, 115V AC or 28V DC, 3A Maximum.
Alarm Shunt SPDT Contact, 115V AC or 28V DC, 2A Maximum.
Tamper SPDT Contact, 115V AC, 2A Maximum (Optional).
Environment:
Ambient Temperature -40C to 70C.
Humidity 0% to 90% relative humidity (Non-condensing).
Operational:
Memory E2PROM (non-volatile).
Because the ENTRACOMP 26SA has non-volatile memory, reprogramming after a power loss is a thing of the past. Validating and voiding of cards as well as other programming functions are easily accomplished from outside the housing using a few cards.
Card Capacity 3500 Cards.
Up to three facility code codes simultaneously.
Programmable latch/alarm shunt timer from 1 to 30 sec.
Size:
The 26SA card access control unit easily surface mounts to a single gang masonry wall, post or almost any surface.
117 mm (4.6") High x 102 mm (4") Wide x 57 mm (2.25") Deep.
|
|
The MRMAG and MRMAGINOX readers of magnetic cards read the card information is coded onto track 2 in accordance with the ISO standards and is in CLOCK and DATA and CLS (the latter only for MRMAG) protocols.
MRMAG uses the MW30 converter, supplied with the reader, the signals are converted in the Wiegand 30 bit format compatible with all the Prastel access control units and with all the systems that accept this data format.
|
|
Control Boards
The Control Board is the central processing unit that handles information being passed from a host device (PLC, Computer, I/O Device) onto a Balogh RFID Tag. All Balogh Control interfaces have been designed for the specific bus architecture it functions on. This means no gateway devices, no passthroughs, and no special software.
|
|
For decades SICK has offered a large number of solutions in the field of identification for almost any problem. Now the product portfolio has been expanded by a new technology: Radio Frequency Identification.
Logistics, curier express parcel services, automobile manufacture - RFID can be utilized to identify pallets, ensure smooth transport of totes or match the content to the right transport box.
RFID allows identification, even with difficult environmental conditions, without visual contact between reader and object to be identified. This allows a reliable and fast detection. Identifying faster means commissioning faster - commissioning faster means higher efficiency and therefore real cost reduction.
SICK as a complete supplier for Auto Ident applications opens up a great variety of application possibilities with RFID and barcode.
|
|
|
Omron's Radio Frequency Identification (RFID) systems act as portable databases allowing information to be accessed and modified at any point on the production line providing a non-contact, non-line of sight method of automatically gathering, inspecting and distributing production data.
|
|
|
Datalogic can offer the market one of the most complete ranges of radio frequency identification devices, and includes read-only and read-and-write systems, both active and passive. These identification solutions are suitable for anything from harsh industrial applications to clean rooms, and include RFID offerings ranging from 125 KHz to 13.56 MHz and Network Interface Modules.
|
|
Our resourcefulnesses `identification ID allow a sure and fast identification of parts. The head D `writing/reading (SLK) offers a connection by various interfaces: multi-poles, bus -I, drank Profibus-DP,...
The mobile supports of data (MDT) have a nonvolatile EEPROM (a safeguard by pile N `is not necessary) with a capacity going until 8k bits of memory. Moreover, the data carriers can not only be gone up on the top of the pallet part holders, but also in lower part see being integrated completely in the pallets part holders.
The ID allow a dynamic transmission of the data until a speed of transport reaching 20 m/min.
|
|
Our resourcefulnesses `identification ID allow a sure and fast identification of parts. The head D `writing/reading (SLK) offers a connection by various interfaces: multi-poles, bus -I, drank Profibus-DP,...
The mobile supports of data (MDT) have a nonvolatile EEPROM (a safeguard by pile N `is not necessary) with a capacity going until 8k bits of memory. Moreover, the data carriers can not only be gone up on the top of the pallet part holders, but also in lower part see being integrated completely in the pallets part holders.
The ID allow a dynamic transmission of the data until a speed of transport reaching 20 m/min.
|
|
