Compressed air filtration
Sizes Available: Miniature Series 1/8", 1/4" NPT, Compact Series 1/4", 3/8", 1/2" NPT, Large Series 1", 1-1/2" NPT
General purpose professional filter removes water, dirt and dust from the air line.
Manual and Automatic drain types available. The automatic drain operates only when flow change occurs.
Bowl available in transparent polycarbonate or metal zinc die cast.
Filter Element size: Miniature: 5, 25, 100 micron, Compact: 5, 25, 50 micron, Large: 5, 50 micron |
|
Cube 100 Regulator
Max. primary pressure: 12 bar/170 psi
Temperature range: 0-60 °C
Pressure gauge specifications connection: G 1/4"
Outlet pressure range: 0-10 bar
Weight: 1235 g
Material: Housing: Aluminium
Top cover: Glassreinfoced polyamid
Other parts: Nitril rubber - Brass
Cube 100 Regulator is a single-acting selfrelieving piston regulator. The regulator is inlet pressure compensated. The regulator is designed for use with compressed atmosphaeric air. |
|
Parker’s large capacity coded professional filter vessels have been designed specifically for our coalescing elements and incorporate large sump capacities and generous exit cavities for maximum performance with low differential pressures.
With flow capacities to 22,828m3/h and pressure to 16 barg and optional materials of construction, most compressor specification source filtration requirements can be met.
Features
Porting up to DN200 flange
Flows to 22,828m3/h
Large sump capacity
Easy element replacement |
|
The FRL range is a complete line of components for the treatment of the compressed-air.
PROFESSIONAL FILTER: Thread from 1/8 to 1". Filtration Grade from 5µm to 50µm. Maximum Pressure 15 bar.
REGULATOR: Thread from 1/8 to 1". Regulation Range from 0-2 to 0-12 bar. Max. Pressure 15 bar.
FILTER DRIVER: Thread from 1/8 to 1''. Regulation Range from 0-2 to 0-12 bar. Filtration Grade from 5µm to 50µm. Max. Presssure 15 bar.
Condensate Exhaust System: Semi automatic - Manual or Automatic to vacuum-operated.
QUICK EXHAUST REGULATOR: Thread 1/8-1/4. Regulation Range from 0-2 to 0-12 bar. Max. Pressure 15 bar.
LUBRICATING: Thread from 1/8 to 1''. Max. Pressure 15 bar. Oil Loading System: Manual or Automatic to vaccum-operated.
SHOT OFF COCK: Thread from 1/8 to 1''. Max Pressure 15 bar. Drive System Manual, Pneumatic, Electropneumatic.
SOFT START VALVE: Thread from 1/8 to 1''. Max. Inlet Pressure 3-10 bar. Drive Sytem Electropneumatic.
FR-L, V-FR-L, F-R-L, V-R-L, F-L are available. |
|
C3
of plastic, modular design
5 and 20 µm, G1/4 - G1
outlet 0 - 8 bar, max. 8500 l/min
|
|
Assembled Combinations
Sizes Available: Miniature Series 1/8", 1/4" NPT and Compact Series 1/4", 3/8", 1/2" NPT
An assortment of professional filter, regulator, and lubricator combinations available. |
|
Supply only "compressed air".
For compressed air, always use clean air chat does not contain corrosive gas.
Be sure to use non lubricated, filtrated dry air (équivalent to Class 1, 3, 2 - ISO 8571-3).
With a thorough understanding of compressed air characteristics, design a pneumatic circuit.
%u25A0 Where instantaneous stop holding at emergency stop is required, the same function as in the mechanical or hydraulic or electrical units cannot be expected.
%u25A0 There arise pop-up, jet-out and leaking phenomena caused by compressibility and expansibility, which are air characteristics.
Prior to use, always ensure that the product withstands the operating environ ment.
%u25A0 The product cannot be used in corrosive gas, chemical liquid solvent, water, water vapor (steam) and ozone atmosphčre. When a product is exposed to water droplets, oil or metallic powder, such as spatters and chips, be sure to protect it.
%u25A0 No product can be used in the explosive gas atmosphčre.
Always pay extra attention to the electric circuit during emergency stop, and professional cylinder opération, etc. during power failure.
Attach a "industrial pressure switch" and "residual pressure discharge cock" to the compressed air inlet of the equi pment.
|
|
Professional filters, Regulators, and Lubricators (FRLs)
27 Modular Series Assemblies and Accessories
Filter, Regulator, Lubricator, trio (pictured)
- traditional trio design
- gauge packaged uninstalled for installation on either side
- bowl guard supplied standard
- filter, regulator, and lubricator options available
27 Series combo units offer pre-assembled units for fast installations. The integral filter/regulator offers space saving design. Duo and trio assemblies utilize the modular vise system to ease installation.
Other Filters, Regulators, and Lubricator Products offered by Coilhose Pneumatics:
Economy Regulators
Pre-Set In-Line Manufacturers of pressure regulators
Adjustable In-Line Pressure Regulators
In-Line Series F, R, Ls
Miniature Series F (also in Coalescing), R, Ls
Miniature Pro Line F, R, L, Assemblies and Accessories
25 Series F, R, L, A and A
26 Series F (also in C), R, L, A and A
27 Series Modular Series F(also in C), R, L, A and A
Heavy Duty Series F (also in C), R, L, A and Accessories
General Purpose Series F (also in C), R, L, A and A
Dessiccant Suppliers of air dryers
Mechanical Condensate drains
Solid State Automatic Drain
Manufacturer of pressure gauges
Vacuum and Hydraulic Gauges
|
|
Max. primary pressure: Transparant bowl 12 Bar/170 PSI
Metal bowl 18 Bar/255 PSI
Temperature: 0-60° C
Water separation capacity: min 90 %
Effective bowl volume: Professional filter: 20 cc
Lubricating: 45 cc
Material: Housing: Zinc
Transparent bowl: Polycarbonate
Metal bowl: Zinc
Filterelement: Plastic
Top cover: Glassreinforced Polyamid
Diaghragm: Chloroprenerubber with nylon reinforcement
Other parts: Brass, nitrile rubbe
|
|
Max. primary pressure: Metal bowl 18 Bar/255 PSI
Temperature: 0-60 oC
Water separation capacity: min 90 %
Effective bowl volume: Professional filter 45 cc
Lubricator 120 cc
Material: Housing: Zinc
Metal bowl: Zinc
Filterelement: Plastic
Top cover: Glassreinforced polyamid
Diaghragm: Chloroprenerubber with nylon reinforcement
Other parts: Brass, nitrile rubber |
|
Balston Stainless Steel Professional filters protect your equipment and delicate instruments from the dirt, water and oil usually found in compressed air and other gases. These filters will remove contaminants at a very high efficiency - up to 99.99% for 0.1 micron particles and droplets. Liquid releases from the manufacturer of filter cartridge to an automatic drain as rapidly as it enters the filter.
This allows the filter to continue removing liquids for an unlimited time without loss of efficiency or flow capacity. Select 1/4” to 1” line filters are constructed of 304 stainless steel and are designed to hold up to the harshest environments. |
|
P-2000 Series High Performance Professional filters for Compressed air & Gas
(35 to 15,000 scfm)
State-of-the-art filtration media, CAD engineered designs and ISO 9001 manufacturing practices combine to produce the P-2000 Series of compressed air filter products. The result is a product unmatched in value-Long element life, high contaminant removal efficiencies and low differential pressure drop at a system price you can afford.
Contaminants in your compressed air and gas system dramatically increase your operating cost. Dirt, moisture, oil, hydrocarbons, gases and bacteria aggressively attack, corrode and erode your piping system, controls, instruments and tools. Maintenance and repair costs escalate dramatically. P-2000 Series filters remove these harmful contaminants from your system utilizing the follow features:
Pleated filtration media used in both coalescing prefilters and particulate afterfilters, offering 6 to 9 times the surface area found in "wrapped" or "depth-style" elements.
Coalescer liquid removal efficiency of 0.001 ppmw based on 20 ppmw challenge. Removes liquid aerosols down to 0.01 micron.
Particulate filters have a 100% absolute removal rating down to 0.9 micron.
Single element, aluminum housing design 35 to 1,200 scfm.
|
|
Supplier of air treatment system: professional filter, regulator, lubricating
- A modular, compact range for all types of pneumatic circuits
- Quick mounting and connection on installation: filter, regulator and lubricator functions in a "single unit"
- Lightweight and robust for direct professional fitting on rigid conduits
Accessories: Softstarter cut-off cocks, padlockable manual isolating valves, bypass modules.
|
|
After compressing the air, the concentration of particles and moisture increases. This creates an abrasive mixture that can cause extensive damage.
Instruments and tools can malfunction, spray painting and breathing air can be rendered unusable, maintenance costs will increase and products will be spoiled.
The range of Atlas Copco's DD - PD - DDp and QD industrial filters, when used in the correct combinations, will provide high quality air from 9 to 7200 l/s at nominal working conditions.
|
|
After compressing the air, the concentration of particles and moisture increases. This creates an abrasive mixture that can cause extensive damage.
Instruments and tools can malfunction, spray painting and breathing air can be rendered unusable, maintenance costs will increase and products will be spoiled.
The range of Atlas Copco's DD - PD - DDp and QD professional filters, when used in the correct combinations, will provide high quality air from 9 to 7200 l/s at nominal working conditions.
DD range:
Coalescing and particulate filters for general purpose protection, removing liquid water and oil aerosol to 0.1 mg/m (0.1 ppm) and particles down to 1 micron.
DDp range:
Particulate filters for dust protection, removing particles down to 1 micron.
PD range:
High efficiency coalescing and particulate filters, removing liquid water, oil aerosol to 0.01 mg/m (0.01 ppm) and particles down to 0.01 micron.
QD range:
Active carbon filter for removal of oil vapours and hydrocarbon odours with a maximum remaining oil content of 0.003 mg/m (0.003 ppm) to be installed after a PD filter.
|
|
FRL's - Delta 901 Series Premium Professional filters
The Numatics Delta Series%u2122 offers premium filtration for applications which require high flows. The standard aluminum end caps on every element, premium manual industrial drain, professional seals made of Viton®, and available 3 micron internal pleated prefilter sets the Delta Series%u2122 apart from other competitors.
Features:
Inner core - Prevents element from collapsing in backflow conditions
Optional internal pleated prefilter - 3.0 micron media protects the fine borosilicate fibers from large particles, extending the life of the coalescing media
Inner media wrap - Allows crossflow of gas which initiates the coalescing process
Media - Three coalescing media choices for best performance. Proprietary glass fiber blend combines low differential pressures and high efficiencies with maximum holding capacity (3 micron particulate and adsorbing grade also available)
Outer media wrap - Allows crossflow of gas and improves performance
Metal professional retainers - Supports the media both inside and outside during pressure spikes or high differential pressures
Drain layer - Large pore fibers allow the large coalesced liquids to drain to the bottom of the bowl
End caps - Aluminum end caps provide sturdiness and durability. The design of the bottom caps make inserting a new filter element easy. |
|
HOLYSUN offers 5 grades of Compressed air filtering as following:
1). Divider filter (HF9)
For bulk liquid removal plus a 3 micron coalescer (5ppm w/w maximum remaining oil content)
Two-stage filtration
2). Air line professional filter (HF7)
For removal of liquid water and oil; Removes solid particles to 1 micron (1.0 ppm w/w maximum remaining oil content)
Corrosion resistant inner and outer cores
3). High efficiency oil removal filter (HF5)
For coalescing fine water and oil aerosols; Removes solid particles to 0.01 micron (0.01 ppm w/w maximum remaining oil content)
Corrosion resistant inner and outer cores
Outer coated, closed cell foam sleeve
4). Ultra high efficiency oil removal filter (HF3)
For coalescing ultra-fine oil aerosols; Removes solid particles to 0.01 micron (0.001 ppm w/w maximum remaining oil content)
Corrosion resistant inner and outer cores
Two stage filtration
Outer coated, closed cell foam sleeve
5). Oil vapor removal filter (HF1)
For removal of oil and hydrocarbon vapors normally absorbable by activated carbon; Removes solid particles to 0.01 micron (0.003 ppm w/w maximum remaining oil content)
Corrosion resistant inner and outer cores
Two stage filtration
Multiple layers of fine media prevent particle migration
Outer coated, closed cell foam sleeve prevents fiber migration
Designed life is 1000 hours under rated conditions. |
|
High efficiency professional filter / regulator air set for the highest quality compressed air for instrument and control systems.
- Eliminates problems due to poor air quality.
- 100% water removal at line temperature.
- Solid particulate removal to 0.01 micron.
- Oil aerosol removal to 0.01 mg/m3 |
|
airfit comfort (G3/8 - G1/2 - G3/4)
Operating comfort at the highest level. Down to the smallest detail.
That was the main challenge for HOERBIGER-ORIGA in the development of a new G1/2 series. The result is called airfit comfort - and it lives up to its name.
Advantages:
optimum price/performance ratio
high operating reliability
fast bowl change with bayonet professional fitting
direct wall-mounting possible
connects to G3/4 air lines using special adapter
corrosion resistant through high quality surface treatment of the zinc die-cast housing
modular design for easy interlock between components
comprehensive range of accessories
all environmentally relevant materials are identified |
|
FRL's - 50 Series
High flow capacity FRL line - Professional filters, Regulators and Lubricators.
Features:
High Flow
High Pressure
T Handle Adjustment Regulator
Pilot Regulators to 2-1/2 NPT
Rugged Design
Metal Bowls with Sight Glass
1/4 to 1-1/2 NPT Size Range
Assemblies Available
FRL's - FlexiBlok FRL 14/22/32/42 Series
The Numatics 14, 22, 32, and 42 Series FlexiBlok¨ line is a series of high performance air preparation products. Introduced in 1997, the FlexiBlok¨ line is made from sturdy but light weight aluminum; perfect for applications such as robotic arms which cannot afford extra weight and less expensive to ship than zinc. The block head design with integrated mounting holes eliminates costly mounting plates and adapters, making the product easier to use and install. Private labeling is easy thanks to the special templates which snap securely in the front and back of the heads. These templates can be customized with names and/or logos; perfect for OEM applications.
The 14,22,32 series conforms to ISO 1179-1 and 228-1 requirements.
The 42 series will soon also conform to these requirements. |
|
After compressing the air, the concentration of particles and moisture increases. This creates an abrasive mixture that can cause extensive damage.
Instruments and tools can malfunction, spray painting and breathing air can be rendered unusable, maintenance costs will increase and products will be spoiled.
The range of Atlas Copco's DD - PD - DDp and QD industrial filters, when used in the correct combinations, will provide high quality air from 9 to 7200 l/s at nominal working conditions. |
|
Features:
- Integrated monitoring of the useful lifetime of the professional filter element to automatically indicate the optimal time of element change
- Easily readable, informative display
- Potential free contact for relaying a fault signal to a control centre
- Condensate discharge at the rear through elbow supplier of connector, ideal for installation close to a wall |
|
The network professional filters are one of the most important part for the protection of your air treatment equipment and the filtration of oil vapor and residual dust contained in compressed air.
By using network filters, a total quality is guaranteed from the beginning of compressed air production. You don’t need specific protection for your downstream production equipment
|
|
After compressing the air, the concentration of particles and moisture increases. This creates an abrasive mixture that can cause extensive damage.
Instruments and tools can malfunction, spray painting and breathing air can be rendered unusable, maintenance costs will increase and products will be spoiled.
The range of Atlas Copco's DD - PD - DDp and QD professional filters, when used in the correct combinations, will provide high quality air from 9 to 7200 l/s at nominal working conditions. |
|
| The professional filters Atlas Copco stop the particles (dust, vapors of oil, water droplets) harmful with the network of compressed air and the processes. Clogging indicator or differential pressure gauge, float drainer or electronics, audible alarm in the event of disassembling under pressure make them practical and sure. |
|
A range extended for the air conditioning:
Complete unit FRL, governor automatically-controlled, industrial filters, membrane drier, pressurization progressive, gate valve. Flow from 150 to 10.500 possible Nl/min.
Many accessories for all applications
|
|
|
