vent-captor - Insertion type Air Flow Switch for gaseous media
Compact Air Flow Switch for AC/DC Applications
Adjustable Set-Point between 1 m/s and 10 m/s
For general applications
Compact Air Flow Switch for DC Applications
High accuracy Set-Point adjustable between 0.5 m/s and 20 m/s
For critical Applications
Easy installation with Special Flange (supplied), or optional pipe adaptor
|
|
Delta Controls' flow meters are proven in a broad range of air and gas management applications, including:
-Blow-by gas measurement in engine test beds
-Nuclear, biogas, pharmaceutical, industrial process gas and pollution monitoring
To support both existing and new customers with a high level of meter performance and minimal long-term cost of ownership, Delta offers an extensive recalibration service. Utilising the in-house flow laboratory, quick turnarounds can be achieved to minimise customer downtime.
Delta also offers an ATEX approved, vane operated flow switch, ideally suited to ducted air system applications in hazardous environments.
|
|
FQS Flow Switch is for use on liquid lines such as water, ethylene glycol or any non-corrosive fluid in chillers, pumps, condensers, boilers, industrial equipment, etc.
One model for pipe connections from 1 to 6 in.
Flow and pipe diameter determines use of 1, 2 or 3 paddles.
|
|
Air Logic switches interface from pressure signals to electrical systems. The snap-action electrical switch provides a positive and reliable response. The switch operation is based on the actuation of a precision snap-acting switch acting against a diaphragm.
The switches are single pole, double throw for normally open, normally closed and common terminals, which are available from 0.1 to 25 AMP, 15 AMP standard. For low current applications, gold contact switches are available.
Maximum pressure is 100 PSI. Adjustment ranges from 0.5 to 100 PSI. Special actuating and releasing pressures are available on request.
The switches include Miniature Switches, Subminiature Switches, Low Differential Switches and Solid State Switches.
|
|
Air Logic switches interface from vacuum signals to electrical systems. The snap-action electrical switch provides a positive and reliable response. The switch operation is based on the actuation of a precision snap-acting switch acting against a diaphragm.
Maximum vacuum of 29.9" Hg. Adjustment ranges from 1" to 28" Hg. Special actuating and releasing vacuum are available on request.
|
|
AKS 38 is an electro-mechanical float switch designed to provide a reliable, electro-mechanical response to liquid level changes.
The simple and basic design ensures long lifetime performance and reliable operation for many applications.
AKS 38 can control liquid level in vessels and accumulators or can be used as a low/high level safety alarm.
|
|
LL SERIES REFRIGERANT FLOAT SWITCHES
This float controlled, magnetically actuated, mechanically operated, HERMETICALLY SEALED switch assembly can maintain close control of liquid level. The rugged construction makes it relatively insensitive to disturbances of the refrigeration system or vibration of the attached pipelines. The electrical switch, which is fused, and the operating mechanism are encapsulated within a transparent housing, which HERMETICALLY SEALS the moving parts and switch from ambient conditions and yet allows observation of the switching motion for determination of the liquid level. Type LLC, LLSC, LLAC are U.L. Listed for outdoor service. Types LLX, LLXS, or LLAX are not fused.
|
|
|
|
|
|
EE55 Series
Air Velocity Switch for HVAC Applications
The EE55 air velocity switch is designed for standard HVAC applications with a switching threshold between 2 and 20 m/s.
EE55 consists of an interchangeable sensing probe and a relay unit suitable for panel mounting. The electronics integrated in the sensing probe allow a cable length up to 10 m to the relays unit and ensure high immunity to electromagnetic perturbations.
Low angular dependence and an extension tube allows cost-effective, easy positioning of the sensing probe in ducts with diameter between 50 and 630 mm.
EE56 Series
Air Velocity Switch for lowest Velocities
EE56 air velocity switch is designed for special laminar flow and HVAC applications with a switching threshold between 0.2 and 2 m/s.
EE56 consists of an interchangeable sensing probe and a relay unit suitable for panel mounting. The electronics integrated in the sensing probe allow a cable length up to 10 m to the relays unit and ensure high immunity to electromagnetic perturbations.
Low angular dependence and an extension tube allows cost-effective, easy positioning of the sensing probe in ducts with diameter between 50 and 630 mm. For smooth plant start-up there is the possibility to set the delay time between 20 and 100 s.
|
|
|
|
