Alphanumeric displays are available in a range of sizes from 12.7 to 57 mm character height in single and 13.6 mm dual digit options plus a siingle digit monolithic version.Ideal for low cost text displays, 14 & 16 segment configurations can be supplied and the dual digit 13.6 mm alpha display is also offered with inbuilt driver IC.Typical applications include transportation and point of sale information.
|
|
When you focus on the process, you're focused on productivity & efficiency. Our highly visible, Alpha 4000 series NEMA 12 displays, ensure continued productivity & safety throughout your production facility. From your desktop PC, your PLC or HMI system you can relay real time production data and manage quality assurance during the process.
Download brochure Alpha 4000 IP55 (182Ko)
Don't risk production coming to a screeching halt.
Our 4000 Series NEMA 12 provides maximum protection against windblown dust and splashing water aroundany of your industrial processes.
|
|
Example:
MONOCOLOUR OUTDOOR DISPLAY ED 40
Technology LEDs
Number of lines 1 to 4 lignes
Brightness Outdoor
Brightness adjustment Yes
Colour Red (option Amber ou Green)
Operating modes 18 modes
Character set 12 types
Built-in animations Yes (100)
Programming mode TC3 programming keyboard or Software
Interface communication RS232, RS485, Ethernet (option)
Temperature probe Yes
Type of case Aluminium, IP 54 RAL 5004
Operating temperature range -10° to +45°C
Power supply 230 VAC / 50-60 Hz
Mounting support Wall mount support Included
TECHNICAL SPECIFICATIONS
Pixel diameter 5 mm
Nombre de LEDs par pixel 1
Microprocessor 16 bits
Message capacity 128 kb
Angle viewing +/- 30°
Front face Polycarbonate
Baud rate de 2400 à 38400 Bauds
|
|
TYPE: LCD-COG-module LCD-DATA:FSTN-mode transflective / positiv graphic
BACKLIGHT: LED edge amber CONTROLLER: SSD1815 ; FEATURES: COG module with special shaped glass + special shaped FPC ; REFERENCE NO. 123 ; TYPE: LCD-module LCD-DATA:FFSTN-mode transmisive / negative
alphanumeric + segment BACKLIGHT: bicolor LED red and yellow-green
CONTROLLER: KS0066 FEATURES: LCD + Backlight + tact switches +
customers circuitry REFERENCE NO. 090
|
|
|
Edwards Message Centers and Edwards lamp annunciators have proven themselves as the standard of reliability for commercial and institutional applications.
|
|
Series S102/SX102
Digital displays for panel mounting
Numeric and alphanumeric displays
4-, 5-, 6-, 8- or 14-digit LED display
Character height: numeric 14 and 25 mm, alphanumeric 18 and 30 mm
Interfaces: Profibus, Modbus, serial, parallel, analog
Comfortable setting of operation modes and parameters via menu
Bright red LED displays
Reduced mounting depth
Addressable
|
|
At airports and car-parks, production lines and inside buildings, ANKA® large displays by Wöhrle are essential everywhere for rapid and direct information.
Not only do they display text and figures in sizes configurable by the user. Icons and graphics can be displayed clearly, and in many colours too, thanks to the dot matrix LED displays. This considerably increases the attention-getting value.
ANKA® large display units are housed in solid enclosures of protection type IP 65.
The modular and flexible system design provides a number of different expansion options:
- LED large displays, single colour (red, green, yellow, or mixed configuration)
- character height 50 mm, up to 15 lines, up to 40 characters per line.
- LED large display units, multi-colour (red, green, orange). Character heights can be altered:
• at 120 mm character height : one line display 3-20 characters per line
• at 50 mm character height these values are doubled.
|
|
New Series SX502
Alphanumeric large size displays
Multifunctional text display
Standard fixed text memory
Character heights 33 and 50 mm, switchable to 66/75
or 100/120 mm respectively
Red or multi-color LED (switchable between red/green/orange)
Extremely bright SuperBright LEDs for outdoor use
2, 4, or 8 lines with 20 or 40 characters per line
Interfaces Profibus, Modbus. serial, Ethernet TCP/IP, further interfaces
Different kinds of presentation: marquis text, paging, blinking etc.
Protection type IP54 and IP65
Presentation types can vary within a line
Convenient control with an optimized and ergonomic
command set
Optional proportional lettering
Setup menu for setting parameters and operating modes
Degree of protection IP54 and IP65
Equipment packages for outdoor applications
Unit versions readable from one or both sides
Downloadable/uploadable fonts and character sets
|
|
- Product designed and produced by Topway ourselves.
- Character (Alpha Numeric) display.
- Characters x Line (5x8 format):
8 x 1, 8 x 2, 16 x 1, 16 x2, 20 x 2, 20x4, 24 x 2, 40 x2
- LCD Mode: STN-Blue, Grey, YG, FSTN-Pos. Neg. as option
- LCD Controller: KS0066 or Equivalent
- We have full product line with different module size, display model, 3v/5v power supply as options.
|
|
* STN Character Display Modules in the size 8x1 to 40x2.
* STN Graphic Display in the sizes of 1,5" to 2,0" in 262K or Full Color with Backlight LED and Transmissive Display mode.
* STN Graphic Display in the sizes of 1,5" to 2,0" in 262K or Full Color with Backlight LED and Transmissive Display mode.
|
|
