Resistance meter, electrometer, picoammeter, low current meter, micro-ohmmeter, current source.
Picoammeters
- Model 428-PROG Programmable Current Amplifier
The Model 428-PROG Programmable Current Amplifier converts fast, small currents to a voltage, which can be easily digitized or displayed by an oscilloscope, waveform analyzer, or data acquisitionsystem. It uses a sophisticated "feedback current" circuit to achieve both fast rise times and sub-picoamp noise. The gain of the Model 428-PROG is adjustable in decade increments from 103V/A to 1011V/A, with selectable rise times from 2μs to 300ms.
- Model 6485 5-1/2 digit Picoammeter with 10fA Resolution
- Model 6487 Picoammeter/Voltage Source
|
|
Flexible output options make this meter the right choice for many applications. With display scaling
the user can display engineering units from a linear DC input. Using the relay output users can set alarms or shut down the process.
• 14.2mm character high visibility LED display.
• 1/8 DIN (96mmX48mm) bezel.
• Simple user programming.
• Display scaleable to show engineering units.
• Programme lock out facility.
• AC and DC powered models available.
• Analogue re transmission option.
• Dual relay output option for alarms or ON/OFF control.
• RS485 communications option.
• CE approval (UL and cUL pending).
|
|
Appropriate equipment for indication and supervision of alternate current, the PRU adds protection, security and trustworthiness. With alarm superior and inferior ideal for protection of loads is monitored and generally. It owns parameter of time-lag for alarm action. Access to the parameters protected by password.
Dimensions: 48x96x95mm;
Approximate weight: 360g;
Feeding: 110/220Vca, 50-60Hz;
Exit to relay 5A;
External or direct TC/5A until 25A.
|
|
|
|
|
|
clamp on meter is a combination power analyzer, power quality logger, and clamp meter, and is ideal for monitoring electronic loads.
With the bright color power meter display to analyze the harmonic spectrum, a low-pass filter to remove high frequency noise, and a high EMC immunity design, the Fluke 345 power analyzer is ideal for troubleshooting power quality on switching loads. Additionally, the Hall Effect clamp meter design makes measurement of dc current possible without the need to break the circuit with the power meter. The internal memory of the power analyzer enables long-term power quality logging for analysis of trends or intermittent problems.
Applications
Setup and troubleshoot variable frequency drives and UPS systems - Verify correct operation by measuring key power quality parameters
Harmonics measurements - Uncover harmonic issues that can damage or disrupt critical equipment
Inrush capture - Check start-up current where spurious resets or nuisance circuit breaker tripping occurs
Load studies - Verify electrical system capacity before adding loads
|
|
Product ID: CA-60
AC/ DC mA Current Clamp-on Transducer
1. This miniature clamp meter features two Hall effect sensors
2. For use with any multimeter with 200mV or/and 2V ranges
for direct readout input impedance of least 1M ohm.
3. High conversion factor for low DC and AC mA measurement.
4. With the small jaw size it can fit into tight space in circuit panel
or wire bundle to take the reading
5. The high frequency response at 20 kHz is useful for
waveform monitoring on an oscilloscope.
6. Zero adjustment is made easy by just pushing the ZERO button.
7. It is best for locating small signal, industrial control,
battery leakage,and automotive usage
|
|
Current must always be measured in our power test systems, of course, but that's just the beginning. Amperage is an important measurement in hundreds of other data acquisitoin applications, too.
We understand that, so we provide more than one choice of current clamp, and also, convenient flexible current sensors (aka Rogowski coils). DEWETRON current sensors output voltage, so they can be used directly with our medium gain voltage input connections. Every current sensor has a phase shift, and this can be offset using the standard sensor database included with DEWESoft! Yes, we thought of that.
|
|
With its unique 100mm jaw opening, the Seaward Type L Plus large jaw current clamp meter is designed for the measurement of current in large diameter conductors and fuses.
With the ability to operate in the most difficult circumstances the instrument is capable of use on porcelain fuse carriers in distribution systems.
|
|
511 Clamp-On Meters
The Clamp-On Meter Model 511 is a general purpose professional clamp-on meter that measures up to the toughest standards. It is built into a rugged mechanical case and is designed using quality polycarbonate materials. This meter offers a complete set of measurement ranges and is in compliance with international safety and quality standards to ensure a professional and reliable measuring tool. The Model 511 is auto-ranging and provides the best measurement range and resolution for troubleshooting. It has a high resolution 40A range.
The Model 511 measures AC Amps, AC Volts, DC Volts, Ohms, Continuity (with beeper), Frequency (from V or A) and has a Diode Test function.
The Model 511 is sized for a comfortable, one-handed operation. This model is average sensing and designed for traditional average responding electrical systems. The jaw opening for the Model 511 is 1.575" (40mm).
|
|
To ensure impeccable measurement quality, the F15 gives measurements in RMS, whether or not the current is deformed or sinusoidal. In addition, it offers DC measurement with fully automatic zero adjustment.
# AC (RMS) intensity: 0.2-400 and 700A (2 cal.)
# DC 400 and DC 1,400A intensity (2 cal.)
# accuracy: 2.5%+/-2ct *
# AC & DC voltage: 400 and 600V (5 cal.)
# accuracy: 1.5%+/-2pt *
# RMS
# auto AC/DC and auto-range (with manual selection possible)
# bandwidth: 45Hz-450Hz
# resistance: 0.5-400Ω to 4MΩ (5 cal.)
# audible continuity test: R < 40Ω
# frequency 1.00Hz to 4kHz (3 cal.)
# functions: automatic DC zero, memory, max/min and automatic stop
# adaptor calibre (ADP) 0-4,000mV, acc. 0.1%+/-15ct
# clamping: 1 cable ø42mm, 2 cables ø25mm, 2 bars 50 x 5mm
# electrical safety: IEC 1010 & IEC1010-2-032 600V Cat III-2
# dimensions: 254 x 97 x 46mm - weight: 600g
|
|
Easily monitor leak current fluctuations
Wide bandwidth, 5 Hz to 15 kHz (Waveform output)
High-sensitivity with a full scale of 10 mA (resolution:10 µA)
High-accuracy at ±1 %
True RMS measurement
Analyzer functions, for filtering and output signals
|
|
Clamp-on current probes or "current clamps" enable the user to measure currents without breaking the electric circuit. Current clamps are designed with jaws that can be opened, placed around the conductor and clamped closed to form a magnetic loop around the conductor.
Current clamps offer a safe, cost-effective, simple and accurate way to take current measurements.
|
|
| ... products without technical information |
| |
