Description:
LOW NOISE AMPLIFIER Performance Data
Frequency: 50.0 - 1000.0 MHz
Gain: 21.0 dB Min (Flatness 1.0)
Noise Figure: 3.5 dB Max
P1dB: 12 Min
VSWR: 2.0 Input Max, 2.0 Output Max
Power Supply: 12.0 Volts DC 100.0 mA
Operating Temperature: -30.0 - 70.0 ?C
|
|
|
AR's microwave amplifiers are just as tough and dependable as our RF amplifiers, and they are backed by the same "Competitive Edge" warranty, the best and most comprehensive warranty in the industry. Our microwave amplifiers offer the hard-to-find combinations of power and bandwidth in frequency increments and power output you need for today's test applications.
|
|
RF broadband power amplifiers rated at or above 10W continuous output are supplied by Credence Technologies, Inc.
Our RF Power amplifiers have fixed gain, low distortion with excellent stability over a wide range of VSWR.
|
|
|
|
|
|
The Giga-tronics Microwave Power Amplifier offers linear high-power amplification across multi-octive bands. It is ideal for testing in EMC, wireless communications applications and Defense EW systems. The GT-1000A with 2 GHz to 20 GHz and GT-1050A with 2 GHz to 50 GHz frequency range allows broadband testing without band switching or swapping narrow band amplifiers resulting in faster and more accurate testing.
The amplifiers can be used in wireless communications and component testing wherever a highly linear amplifier is needed. These microwave power amplifiers with excellent pulse fidelity are ideal for many Aerospace and Defense applications, including EW, ECM, ECCM, radar and satellite system signal simulation and testing. The Giga-tronics Microwave Power Amplifier is an ideal ATE system building block for boosting test signals to overcome cable and connector loss whenever long cable runs are needed in assembly bays, environmental test chambers or field locations.
The amplifiers can be paired with Giga-tronics Microwave Signal Generators 2400C series and 2500B series, increasing the overall output power while preserving the synthesizer's fast switching speed, modulation, and high signal fidelity.
|
|
The SM2325-53LD is a 2300-2500 MHz* LDMOS amplifier designed for multiple wireless communications and RF heating applications in medical devices.
Features
- Mis-Match Protected
- Single Power Supply
- Temperature Compensation
Options
- Forward/Reverse Power
Detection
- Logic On/Off Control
- Heatsink
|
|
Sensor signal amplifier MTI04CS/ MTI04CQ
With the MTI04CS/CQ, MAZeT now presents the second-generation multi-channel transimpedance amplifier. The MTI04CS/CQ now offers the ability to adapt the compensation of the transimpedance amplifier) to the input capacitance of the sensors, such as photodiodes. This is done digitally in two stages, 5 and 80pF.
Programming of the transimpedance gain is carried out via three input pins to any of eight levels; and takes effect for all channels simultaneously.
Additional technical characteristics
- Switchable frequency response compensation for input photodiodes (< 5pF and < 80pF)
- Good synchronization of the amplification and the temperature coefficients by the transfer function
- Settable power-save mode
- Supply voltage from 2.7 to 5.5V
- Extended temperature range from -40 to +125°C
IC Types
* MTI04CD – ‘naked’ chip (die)
* MTI04CS – 16-pin SOP16 package
* MTI04CQ – 16-pin QSOP16 package
|
|
The LDS line of linear and digital switching amplifiers offer energy efficient and robust operation for power requirements up to 280 kVA.
Power Amplifier Features
Modular power amplifiers from 8 to 280 kVA use fast switching IGBT technology and deliver excellent distortion at low power level
High efficiency maximizes the performance capabilities of the shaker and reduces operating costs
Peak current rating of 3-sigma meets ISO standards
Amplifier Controller Software coordinates power amplifier and shaker controller Operation
A range of safety features protects operators, test specimens, and the vibration test system
Low cost, single-phase linear power amplifiers for permanent magnet shakers
|
|
ADI's high gain limiting amp ICs are optimized for SFP/SFF/GBIC datacom and telecom optical transceiver modules and provide the receiver functions of quantization and Loss of Signal Detection as well as SFF-8472 compliant average power measurement. Applications include 1x2x4x Fibre Channel, 10GBASE-LX4, multi-rate SONET/SDH OC3 to OC48 FEC and GbE. ADI's high gain limiting amps feature: low power; excellent sensitivity and jitter performance.
|
|
|
|
|
|
Dual-Band (2.4-2.5) GHz & (4.9-6) GHz WLAN Low-Noise Amplifier
Avago Technologies’ ALM-2812 is a dual-band LNA designed for WLAN applications in the (2.4 - 2.5)GHz and (4.9-6)GHz frequency ranges. The LNA uses Avago Technologies’ proprietary GaAs Enhancement-mode pHEMT process to achieve high-frequency wideband operation with very low noise figures.
The ALM-2812 has two individual LNAs housed in a 3mm x 3mm package, each one switcheable using a single CMOS-compatible pin. All matching components are inside the module. Only one external low frequency bypass capacitor is required for proper operation, making it suitable for use in ultra-miniature WLAN cards and access points.
Features
- Advanced GaAs E-pHEMT
- Low Noise: 0.8dB Typ for 2.4 - 2.5 GHz
- Low Noise: 1.4dB Typ for 4.9 - 6 GHz
- Wide Supply Voltage: 2 to 3.6V
- 50 Ohm matched Input & Output
- High Input P1dB and IIP3
- Power Shutdown Function
- RoHS Compliant
- Small Footprint: 3x3mm2
- Low Profile: 1.1mm max.
- Minimal External Components
|
|
|
|
|
|
|
Delivering low noise, high performance, and a small footprint, the CS3301A/02A seismic amplifiers are designed for use with geophone and hydrophone sensors. These highly integrated, programmable gain differential amplifiers are engineered for precise low frequency, high dynamic range measurements. Based on Cirrus Logic’s patented Multipath™ amplifier architecture, these powerful amplifiers provide unrivaled noise and drift performance. Low-power consumption combined with outstanding THD performance makes them ideal for today’s seismic applications. Chopper stabilized and designed for use with geophone sensors, the CS3301A delivers impressive low noise, low drift performance down to 0.1 Hz. The high input impedance of the CS3302A makes it well suited for use with hydrophone sensors, while still delivering outstanding noise and drift performance. With an extensive feature set and available in a 24-pin SSOP package, these amplifiers provide an outstanding price/performance combination for seismic applications.
|
|
The KA741 series are general purpose operational amplifiers. It is intended for a wide range of analog applications. The high gain and wide range of operating voltage provide superior performance in intergrator, summing amplifier, and general feedback applications
Features
- Short circuit protection
- Excellent temperature stability
- Internal frequency compensation
- High Input voltage range
- Null of offset
|
|
General description :
Intersil op amps are designed to meet today's increasing complexities for communication, video, and imaging applications. This high speed analog portfolio delivers low power, superior drive, and slew rate performance at full bandwidths, making them the perfect choice for video and high speed data transmission, A/D buffering, and high frequency filtering. The complete line of Intersil op amps, buffers, comparators, and transistor arrays covers the DC to GHz frequency range and includes special features like output disable, output limiting, and programmable gain functions.
|
|
Maxim offers the widest selection of operational amplifiers (op amps) and comparators for audio and video applications, battery and power management, and signal conditioning.
|
|
|
The MCP6031 operational amplifier (op amp) has a gain bandwidth of 10 kHz with a low typical operating current of 900 nA and an offset voltage that is less than 150 uV. The MCP6031 uses Microchip's advanced CMOS technology, which provides low bias current, high-speed operation, high open-loop gain and rail-to-rail input and output swing. The MCP6031 operates with a single supply voltage that can be as low as 1.8V, while drawing less than 1 uA of quiescent current. The MCP6031 is available in standard 8-lead SOIC, MSOP, SOT-23 and 2x3 DFN packages.
|
|
|
The VIP50 vertically integrated PNP (VIP) process technology is optimized to perform well at 3.3V and 5V supply levels, enabling direct interfacing with advanced analog-to-digital converters while maintaining a very high signal-to-noise level. The products span a 0.9V to 12V supply voltage range that covers both standard DC single-supply voltage standards and +5V/-5V split supplies common in precision amplifier applications and battery chemistries such as Li-Ion and NiCAD.
|
|
Op Amps - Audio-Video Amps - Comparators - Compandors:
ON Semiconductor offers operational amplifiers, audio amplifiers, video amplifiers, transconductance amplifiers, compandors, and comparators.
|
|
The ZL40120 is a low power, quad, current feedback operational amplifier offering high performance at a low cost. The device provides a very high output current drive capability of 65 mA while requiring only 3.3 mA of static supply current per channel. This feature makes the ZL40120 the ideal choice where a high density of high speed devices is required.
The 280 MHz Av=+1 V/V small signal bandwidth and 1100 V/µs slew rate make the device an excellent solution for component video applications such as driving RGB signals down significant cable lengths.
Other applications which may take advantage of the ZL40120 dynamic performance features and matched amplifiers include low cost high order active filters and twisted pair driver/receivers.
|
|
|
Analog Devices' amplifiers are the number one selling brand of amplifiers in the world today. Nobody sets more performance standards for next generation designs, with the widest portfolio of leading-edge products. Designers who want dependable, reliable parts that enable the highest performance from their design, come here for the ultimate source in high-speed, precision, rf, broadband, instrumentation, and other amplifiers.
|
|
|
The CMOS operational amplifier family, CS3001/02/11/12, is designed to achieve optimum performance while reducing component count and bill of materials (BOM) costs. This innovative single and dual op amp family builds on Cirrus Logic's patented Multipath™ amplifier technology to deliver both low noise and low drift. System noise is reduced by 10x and system drift by 4x compared to competing components.
|
|
Linear Technology manufactures a broad line of high performance operational amplifiers (op amps) each one designed for the unexpected. Fully specified over temperature, look to Linear for signal conditioning solutions when performance matters. Amplifier product families include high speed amplifiers, precision amplifiers, low noise amplifiers, and micropower amplifiers as well as special function amplifiers such as current sense, programmable gain and differentail high speed analog to digital converter (ADC) drivers.
|
|
|
TI's 1394 integrated products combine both 1394 Phy and link layers into a single device. Our OHCI family is available in both 1394a and 1394b for PCI and PCI Express hosts. Our 1394 Consumer Electronics family provides a single chip to meet the needs of moving MPEG Transport Streams over 1394 with the power of DTCP encryption.
|
|
Control Modes Torque
Command Interface UV externally commutated torque commands
Current limit
Feedback None
Configuration Potentiometers
DIP switch
Solderless component header (preconfigured option)
I/O Digital inputs: reset, enable, motor overtemperature
Digital outputs: amp OK, normal, current limited
Analog monitor: actual current (U and V)
Internal Edge Filter Optional - append F to model number
Dimensions 191 x 176 x 69 mm (7.5 x 6.9 x 2.7 in)
|
|
|
The MMG3012NT1 is a General Purpose Amplifier that is internally input matched and internally output matched. It is designed for a broad range of Class A, small–signal, high linearity, general purpose applications. It is suitable for applications with frequencies from 0 to 6000 MHz such as Cellular, PCS, BWA, WLL, PHS, CATV, VHF, UHF, UMTS and general small–signal RF.
|
|
RF power transistors are used whenever an electromagnetic signal needs to be amplified and transmitted from an antenna.
Today ST offers a broad range portfolio, from LDMOS transistors for cellular intrastructure and private mobile radio to DMOS for industrial applications and TV broadcast.
A broad package range, from SMD plastic to standard gold ceramic, gives customers great flexibility.
|
|
|
RF Amplifiers backed by Worldwide Support and Service and a 3-Year Warranty. dc to 1000 MHz. 1 to 50,000 Watts. Linear, broadband and VSWR tolerant, with a wide range of uses and exceptional endurance even in the most difficult test scenarios, the AR RF/Microwave Instrumentation RF amplifier is the industry standard for benchmark performance.
|
|
Features
* 0.15 um MHEMT Technology
* Frequency Range; 30 KHz to > 40 GHz
* 235 O Transimpedance
* Average Input Eq. Noise: 15 pA / √ Hz
* Single Supply Operation: +5V @ 27 mA
* Chip Size: 0.85 x 0.85 mm
Typical Applications
* OC768 Fiber-Optic System
|
|
Vitesse’s high-performance transimpedance amplifiers (TIAs) support a wide variety of optical communication network protocols, including 1 GbE and 10 GbE, SONET/SDH, Fibre Channel, and InfiniBand. Available in a variety of data rates and differential transimpedances, these devices feature a linear current monitor to add diagnostic capabilities and to simplify optical alignment during the manufacturing process.
Wide Range of Support
- Ideal for the low-power requirements of SFF, SFP, SFP+, XFP, and other applications
- Available in a variety of data rates and differential transimpedance levels
- Support for both bare die and TO-46 packages
- Means for adjusting bandwidth to meet multiple GbE, Fibre Channel, and Infiniband standards (VSC7977-01)
|
|
When test needs call for higher power and higher frequency, consider our "T" Series microwave amplifier line- 0.8 to 45 GHz, 10 to 16,000 watts CW and Pulse. These amplifiers provide coverage for a wider range of high-power microwave test applications than any other brand of microwave amplifier on the market and are incredibly feature-rich.
They also offer an advanced design and highest quality construction of any TWT amplifier on the market.
|
|
General description :
The number and variety of video products on the market continue to expand. Even with the expansion of HDTV and high resolution RGB signals, the most common point-to-point connection for a video signal is analog. Intersil video ICs provide many solutions for moving these signals around. Whether it is transmitting RGB down CAT-5 or switching 32 security video feeds, Intersil has a solution. From high performance video amplifiers to differential line equalizers, Intersil's family of video products can address any portion of the analog signal chain.
|
|
|
MSK offers a broad range of high performance video amplifier products. These amplifiers have high voltage capability, very high slew rates and, in some cases, high output current for use in Piezo Electric drives, electrostatic or electro-magnetic deflection and CRT cathode drives.
|
|
|
|
