Universal Electronic Ammeter
Digital ammeter is used to measure the AC current that goes the meter on its ring
circuit. It also can be used in other working condition that is on the purpose of
current measuring. The max value of the instantaneous conveyanoc current should
not ezceed 5A. The transforming rate of the can be set from 1/5A to 5000/5 with the
panel pushbutton. When the power sutting over, the class value set can be kept in
the meter and the meter can be working on this condition. The working power supply
input terminals(1-2) and the measuring signal connection terminals (3-4)are on the
back board of the meter and the display screen is on the font panel
Setting Of Current Transformer Ratio:
1. Press the key and then display screen will indicate the current value.
2. Press the ADD key (upwelling) or press the DOWN key (down welling) and
select the needed rate.
3. After select the rate, when press the set key, the display screen will be dark for
one time and the rate will be kept in the meter automatically.
4. Attention: When press the button, the time must exceed 3 minutes or the
operation will be of no effect.
Warning:
• A switch or circuit breaker must be connected between the network and the
auxiliary supply input of device
• Connected switch or circuit breaker must be in close proximity to the device
• Connected switch or circuit breaker must be marked as the disconnecting
device for the equipment
• The type of used fuse must be FF type and the current of the used fuse must
be 1A
|
|
Resistance meter, electrometer, picoammeter, low current meter, micro-ohmmeter, current source.
Picoammeters
- Model 428-PROG Programmable Current Amplifier
The Model 428-PROG Programmable Current Amplifier converts fast, small currents to a voltage, which can be easily digitized or displayed by an oscilloscope, waveform analyzer, or data acquisitionsystem. It uses a sophisticated "feedback current" circuit to achieve both fast rise times and sub-picoamp noise. The gain of the Model 428-PROG is adjustable in decade increments from 103V/A to 1011V/A, with selectable rise times from 2μs to 300ms.
- Model 6485 5-1/2 digit Picoammeter with 10fA Resolution
- Model 6487 Picoammeter/Voltage Source
|
|
Flexible output options make this meter the right choice for many applications. With display scaling
the user can display engineering units from a linear DC input. Using the relay output users can set alarms or shut down the process.
• 14.2mm character high visibility LED display.
• 1/8 DIN (96mmX48mm) bezel.
• Simple user programming.
• Display scaleable to show engineering units.
• Programme lock out facility.
• AC and DC powered models available.
• Analogue re transmission option.
• Dual relay output option for alarms or ON/OFF control.
• RS485 communications option.
• CE approval (UL and cUL pending).
|
|
|
|
|
|
clamp on meter is a combination power analyzer, power quality logger, and clamp meter, and is ideal for monitoring electronic loads.
With the bright color power meter display to analyze the harmonic spectrum, a low-pass filter to remove high frequency noise, and a high EMC immunity design, the Fluke 345 power analyzer is ideal for troubleshooting power quality on switching loads. Additionally, the Hall Effect clamp meter design makes measurement of dc current possible without the need to break the circuit with the power meter. The internal memory of the power analyzer enables long-term power quality logging for analysis of trends or intermittent problems.
Applications
Setup and troubleshoot variable frequency drives and UPS systems - Verify correct operation by measuring key power quality parameters
Harmonics measurements - Uncover harmonic issues that can damage or disrupt critical equipment
Inrush capture - Check start-up current where spurious resets or nuisance circuit breaker tripping occurs
Load studies - Verify electrical system capacity before adding loads
|
|
Product ID: CA-60
AC/ DC mA Current Clamp-on Transducer
1. This miniature clamp meter features two Hall effect sensors
2. For use with any multimeter with 200mV or/and 2V ranges
for direct readout input impedance of least 1M ohm.
3. High conversion factor for low DC and AC mA measurement.
4. With the small jaw size it can fit into tight space in circuit panel
or wire bundle to take the reading
5. The high frequency response at 20 kHz is useful for
waveform monitoring on an oscilloscope.
6. Zero adjustment is made easy by just pushing the ZERO button.
7. It is best for locating small signal, industrial control,
battery leakage,and automotive usage
|
|
With its unique 100mm jaw opening, the Seaward Type L Plus large jaw current clamp meter is designed for the measurement of current in large diameter conductors and fuses.
With the ability to operate in the most difficult circumstances the instrument is capable of use on porcelain fuse carriers in distribution systems.
|
|
511 Clamp-On Meters
The Clamp-On Meter Model 511 is a general purpose professional clamp-on meter that measures up to the toughest standards. It is built into a rugged mechanical case and is designed using quality polycarbonate materials. This meter offers a complete set of measurement ranges and is in compliance with international safety and quality standards to ensure a professional and reliable measuring tool. The Model 511 is auto-ranging and provides the best measurement range and resolution for troubleshooting. It has a high resolution 40A range.
The Model 511 measures AC Amps, AC Volts, DC Volts, Ohms, Continuity (with beeper), Frequency (from V or A) and has a Diode Test function.
The Model 511 is sized for a comfortable, one-handed operation. This model is average sensing and designed for traditional average responding electrical systems. The jaw opening for the Model 511 is 1.575" (40mm).
|
|
Easily monitor leak current fluctuations
Wide bandwidth, 5 Hz to 15 kHz (Waveform output)
High-sensitivity with a full scale of 10 mA (resolution:10 µA)
High-accuracy at ±1 %
True RMS measurement
Analyzer functions, for filtering and output signals
|
|
Clamp-on current probes or "current clamps" enable the user to measure currents without breaking the electric circuit. Current clamps are designed with jaws that can be opened, placed around the conductor and clamped closed to form a magnetic loop around the conductor.
Current clamps offer a safe, cost-effective, simple and accurate way to take current measurements.
|
|
|
High quality analogue instruments designed to measure an extensive range of electrical and electronic parameters. This comprehensive range offers DIN instruments, ANSI switchboard meters, panel indicators, sealed and ruggedised instruments, and complementary selector switches for line to line and line to neutral readings. Instruments are precision engineered and robust in design, ensuring accurate measurement and display in the most demanding of environments. All instruments are available in a range of styles, sizes and specifications to meet the exacting needs of industry.
|
|
|
|
|
|
Features
• For measurement of AC currents and voltages
• Good read-out survey on larger distance
• Exchangeable dial
• Resistance to mechanical vibrations
• Protective cover for terminals
Regulations and Standards
Terminal Protection
Safety Precautions
Our meters and indicator/controllers comply with the regulations of the European
Guidelines 73/23/EWG and 89/336/EVG. This is confirmed bby the compliance with the following standards:
IEC/EN 61010-1/A2.VDE 0411-1/A1(Safety Regulations)
IEC 60 051/EN 60 051/DIN EN 60051 (Meters with cale Display)
EN 50 081-2:1993 EMC (Emitted Interference, Industries)
EN 50 082-2:1995 EMC (Emitted Resistance, Industries)
Given below are the most important regulations for the fabrication and the required properties of electrical meters.
TERMINAL PROTECTION
Full sized polycarbonate back cover to provide protection against accidental contact (hand and fingers) acc. to VDE 0410,
SAFETY PRECAUTIONS
1. Instruments with damaged bezels or window glasses must be disconnected from the mains.
2. The back cover must be snapped into place after connector wires have been clamped for protection against
accidental contact.
3. Scales may only be replaced under voltage-free conditions.
4. Bezels and window glasses may only be replaced under voltage-free conditions.
|
|
