Market Segments
* Perimeter fencing
* Traffic management
* Parking areas
BL 229 versatile rising barrier advantages
Aesthetics
* smooth design
Technologies
* new mechanism
* new user-friendly control board
Performance
* fast, harmonious & silent movements
* intrinsic automatic opening mode (no crank, no accumulator)
Universal
* mechanism & casing : fit for all arm lengths and accessories
* programmable opening speeds for toll or perimeter fencing use
|
|
|
|
|
|
QIK: THE NEW DITEC BARRIER
Qik barrier has been launched, boasting newly designed shapes and uncompromising security.
Soft profiles, rounded edges, high performance and total installation flexibility.
Newly designed and technically advanced, Qik is the ideal solution to ensure total security access in medium to high transit environments such as: hotels, banks, shopping centres as well as blocks of flats, companies and camp sites, which always require access control to car parking areas, thus ensuring their use only by authorised people.
Safe and reliable
Smart, yet practical and safe, Qik has been designed to last.
The painted pickled metallic sheet metal will not deteriorate with time, even in extreme weather conditions, and gives Qik a clean look.
Clean lines and attention to details in a heavy duty solution
The single block pressure die-cast aluminium reduction unit ensures an easier installation, a longer life and a cleaner look.
The gear motor bronze reduction gears are subject to less wear and tear, thus ensuring a higher number of operations, up to 1.000.000, to be achieved.
Qik: DITEC solution to access control problems
|
|
|
|
|
|
FLEX-18 Barrier Gate (New G89)
High-speed automatic rising barrier especially designed for access control in public and private parking lots as well as industrial sites. The Flex-18 barrier has been developed to ensure an economical vehicle access control for lanes up to 5.5m (18 Feet), while providing dependable efficient control and safe every day use.
Description:
Housing made of folded and welded 10-gauge steel sheet.
Removable upper hood. Upper hood fixed by two latches designed to resist vandalism.
Lateral door side mounted for easy access to mechanism.
Extruded aluminum arm.
Electromechanical assembly including:
120VAC single-phase motor.
Lubricated speed reduction gearbox with worm screw.
Balance achieved by built-in extension spring. No external counterweights.
Crankshaft-rod device ensuring smooth, progressive operation.
Mechanical locking of barrier arm in extreme positions (Closed/Open), with rubber bumpers.
Easily reversible main shaft.
Easily adjustable limit switches with mechanical and controller overrun protection.
Barrier arm shaft mounted on two pillow blocks with welded arm support.
Shaft configuration allows easy barrier model inversion from left to right.
Built-in heater.
Easily removable 10 or 26 IO PLC logic control to ensure automatic closing of the barrier either by detector and loop or by push button. Opening of the barrier by push button, card reader or other optional controls. The 26 IO controller provides for connection of up to three optional loop detectors.
Barrier anchoring by means of expanding bolts or threaded rods, thus allowing easy alignment with road-way (anchoring means available as option, to be defined depending on the type of ground). Fits over existing G89E bolt patterns.
Seam welded cabinet is constructed from 10 gauge galvanized steel with polyester powdered finish for superior corrosion resistance.
Dimensions: Approximately 42" Height x 15" Wide x 15" Deep
Technical Characteristics:
Shaft output left or right, to be specified with order.
Standard power supply 120V AC single phase ( ±8%).
Frequency 50-60HZ.
Reversing Motor 1/3 HP - 1625 RPM.
Operating time 2 -4 seconds depending on arm length.
Worm screw type life lubricated gearbox.
Compression springs available in 1 to 3 spring configurations depending on arm length.
Programmable logic controller with LCD display, allows for uploading of logic changes.
Run timer, safety edge timer, auto close timer (jumper enabled).
Operating Temp. - 35° to +70° C.(-31° to 150°F)
Net weight from 90 to 96 Kg (200-215Lbs), (arm included) depending on arm length.
|
|
BARRIER TO MOBILE CHAIN PILOMAT® CHAIN
PILOMAT® CHAIN is a sturdy barrier to mobile chain in order to delimit steps carrai and wide areas of parking till 20 m.
They Electronic incorporated with motor double quantity to 24V centers that she allows of
to raise chains till 60 kg of weight.
She is equipped of impact sensor
in order to guarantee the maximum emergency of operation.
She advises herself to add the guide to earth for
control of the chain when lowland.
Possibility to connect a card of recharges and batteries tempone
|
|
AUTOMATIC BARRIER:
PILOMAT BARRIER
Automatic barrier with survey system obstacle to encoder magnetic with reversal of the movement. In the respect of relative norm EN 60335-2-103 to the automatic barriers, PILOMAT BARRIER inverts its movement also during last the 5 centimeters of race.
Incorporated PARK centers them electronic 24V.
Second time opening 3.
Body in aluminum and steel. Slowing down in opening and closing.
The confection comprises the slab to bury, the telescopic auction from 4 meters and the adhesive ones for the auction.
Simplified installation: without necessity of regulating the motivatings force of balance or the positioning of the finecorsa.
Manual release with personalized key.
Possibility to connect a card of recharges and backup batteries (180 cycles)
|
|
|
A Came patent which is widely applied in demarcating private and public parking for single or multiple spaces. High in technology content, it is uniquely designed and perfectly integrable even in particular architectural settings and historical town centers.
|
|
A new concept of automatic barrier
Designed for a range of large openings up to 7,6 m / 24.9 ft, the new Gard barriers are the ideal solution for control of roads and parking areas for industrial and public use. The Gard series is available in the 110V/230V A.C. motor and the 24V D.C. motor versions.
|
|
Road barriers
• A MODEL FOR EVERY NEED.
> Possibility of closing passages up to 8 m.
• SMART TECHNOLOGY.
> Electronic adjustment of the limit switches.
> The new position of the control panel makes it possible to operate in a vertical position.
• SAFE USE.
> The barrier features a very stout structure to guarantee greater protection from vandal attacks and constant reliability in use.
• SIMPLER INSTALLATION.
> The blinker and the support for the photocells are integrated in the frame (optional), the lights are integrated in the boom (optional).
> Cabling is simplifi ed by means of the ducting for housing the cables themselves.
|
|
Rising barrier Miami/Hospital & Clinic
* Great reliability and robustness : 5 million cycles guaranteed
* High speed performance : up to 15 vehicles / minute
* Modular up to 6m
* Automatic opening in case of lack of voltage
* Adapted for all control access systems
* Man-trap system
* Wild range of options and accessories (boom type PROTECTA, removable boom, ultrasonic sensor, traffic lights)
|
|
Rising barrier Boston/Bridge & tunnel
* Great reliability and robustness : 2.5 million cycles guaranteed
* Modular up to 8m
* Anti corrosion casing
* Wild range of options and accessories (traffic lights, signaletic panels, boom skirt)
* Adapted for all control access systems
|
|
|
|
|
|
MAG-12 Small Profile Gate
General purpose automatic rising barrier designed for vehicle access control in public and private parking lots as well as industrial sites. The MAG-12 barrier gate has been developed to provide low cost control in lanes up to 3.65m (12 ').
Description:
Seam welded cabinet is constructed from 10 gauge galvanized steel with polyester powdered finish for superior corrosion resistance.
Lateral door side mounted for easy access to mechanism.
Supports 3 - 3.6m (10-12') pine gate arms up to 4.5Kg( 10Lbs) or 10' Titan Flex arm.
Electromechanical assembly including:
120VAC single-phase motor.
Lubricated speed reduction gearbox with worm screw.
Easily adjustable limit switches with controller overrun protection.
Shaft configuration allows easy barrier model inversion from left to right.
Built-in 250W strip heater.
Easily removable 10 IO PLC logic control to ensure automatic closing of the barrier either by detector and loop or by push button. Opening of the barrier by push button, card reader or wireless remote. Controller provides for connection of two optional loop detectors.
Barrier anchoring by means of expanding bolts or threaded rods, thus allowing easy alignment with road-way.
Dimensions: 100cmHx33cmWx26cmD (40'x13'x10').
Technical Characteristics:
Flange connection left or right, to be specified with order.
Standard power supply 120V AC single phase ( ±8%).
Frequency 50-60HZ.
Reversing Motor 1/3 HP - 1625 RPM.
Operating time 2-4 seconds depending on arm length.
Worm screw type life lubricated gearbox.
Programmable logic controller with LCD display, allows for uploading of logic changes.
Run timer, safety edge input and onboard memory vend.
Operating Temp. - 35° to +70° C.(-31° to 150°F).
Net weight without arm: 61 Kg (135Lbs).
|
|
|
|
|
|
A protection being integrated in the environment
APPLICATIONS:
Forest accesses
Pedestrian precincts
Parks and gardens
Historic sites
Villas of character
The CHAINOSOL, chains heavy retractable, is intended for the prohibition or the control of the motor vehicle traffic, in mediums where esthetics must be taken into account. Indeed, its two boxes are designed to receive a preparing making it possible to integrate them in any site (example: preparing of the type hones).
This product is an answer adapted to the users who wish to control the passage of cars in a nonhostile environment.
The CHAINOSOL requires only travaus of civil engineering light. The chain, firmly anchored on both sides passage in its boxes, is in low position contained in a gutter, releasing thus completely the passage.
The CHAINOSOL comprises a simple and robust mechanics, and its automatism makes it possible to easily control it to your systems.
The CHAINOSOL makes it possible to constitute hoppers of safety associated with a management by badge readers, controllers biometric, readers of number plates...
|
|
Barriers series "EURO" and Special
The raising barriers of our series EURO are intended for the access control on sites where the robustness is the paramount element.
Only or associated, the barriers EURO can automate overpasses than 10 meters.
Their peripheral equipments allow them the integration of
Badge readers, remote controls, digicodes, readers biometric...
Cameras
Interphonie
Control with complementary stoppings (retractable gates, terminals, motorized harrows, plates of stopping,...)
The barrier EURO comprises a control simple and robust, its automatism also enables him to be easily controlled to your systems.
Its communicating interface makes it possible to you to reach remote maintenance and the telecontrol in order to still increase the safety of the exploitation.
The barrier makes it possible to constitute hoppers of safety associated with a management by badge readers, controllers biometric, readers of number plates...
|
|
