BEUMER's packaging products for palletized loads include various types of shrink wrap and stretch wrapping systems as well as advanced technologies for stretch hood systems. Numerous process engineering and design patents testify to BEUMER's continuous development of innovative technologies.
|
|
KEOPS
AUTOMATIC TURNTABLE STRETCH WRAPPER.
Main Modules:
Turntable: roller conveyor placed onto this. It incorporates cutting and sealing group.
Vertical column: support and guide for roll of film. Control cabinet and touch-screen interface for user are integrated within.
Characteristics:
- Electronic pre-stretch intelligent system.
- No tails of film. Continuous control for film tension.
- Sealing system integrated on the turning table.
- Compact size, easy placing on reduced spaces.
- Separate column which allows 4 different possible configurations.
- Counter plate heat sealing device.
- Fully equipped with frequency inverters to ensure accurate and smooth operations.
- Double roping once wrapping cycle is over Wrapping of base pallet.
- Full colour touch-screen interface for main adjustment.
- Control cabinet within main column.
|
|
Artemis 50 automatic
Automatic machine for horizontal packaging round products with stretchfilm.
APPLICATIONS:
Packaging and protection of round products such as hose rolls, wire rolls, wheels and rings.
ADVANTAGES:
It wraps the product by its thickness and in its entire perimeter instead of wrapping by width leaving the inner space of the product free to put other products inside.
It saves stretchfilm because it uses less quantity of consumable for wrapping the thickness instead of the width.
|
|
Atis 50
Automatic orbital wrapping machine
Designed to wrap mouldings, aluminium profiles, tubs, blinds, shelves, … Automatic wrapping machine ready to set up in automatic production lines or high productions.
|
|
|
|
|
|
NEW pallet-wrapper that functions electrically (compressed air is not required) and is equipped with an exclusive cut and clamp device PAT so that it works fully automatic.
The wrapping cycle starts and ends at the top of the pallet; this uniquely different approach to attaching and cutting the stretch-film provides the following advantages:
- Selectable top banding capability
- the load is stabilized early in the wrap cycle
- the ending film tail is placedat the top of the load
- Easier, faster and safer positioning of the load on the turntable
MAIN FEATURES:
- Working functions and operations controlled by a PLC, with touch-screen Operator Interface
- Selection among three (3) different types of wrapping : automatic / semi-automatic / top banding
- Photo-eye for the automatic load height detection
- Separate setting of the top and bottom wraps, from 1 to 12 revolutions;
- Variable turntable speed control with a soft start acceleration and a final revolution deceleration with positive stop alignment
- Film tension control
- Brooken film/run-out of film detection with automatic machine reset
- Film carriage with an adjustable speed motor and driving through a belt/pulley with Anti-Fall Device.
Pre-stretch film carriage (max film width of 500 mm) with a 200% fixe ratio (1 mt = 3 mt), powered by a variable speed motor, with a fully electronic dynamic dancer corner compensation
Visit our website for all the pallet-wrappers of the ECOSPIR LINE.
Machines manufactured according to CE rules
|
|
|
Stretch cold extension machine with extensible film as far as a tubular coil, a model with one or more coils. The cover fitting is suitable for every type of product because there are not flames or warm air. This plant links the thermoretractiles qualities concerning the pallets seal, the protection against some atmospheric agents (water and dust) and the practical use of the extensible film. This machine is available in four models, according to the customers needs.
|
|
As an addition to the wide range of semiautomatic machines for wrapping pallets, Comarme has produced RONDA 100, a fully automatic machine which wraps and stabilises palletised loads with stretch film. RONDA 100 can be placed at the exit of a palletiser or installed in an existing pallets conveyor line.
It spaces, binds and cuts the film and sends the pallet onto a motor-driven roller assembly. It is especially suitable for medium/high production loads.
|
|
WM4
is a wrapping machine with double rotating arm , equipped with 2 film distribution heads and one single seaming device which comes above the palett .During the wrapping cycle , only the film is in contact with the load .
The capacity of this machine can reach 150 P/H for standard load and 100 P/H in 5 sides wrapping process.
This 5 sides process , different from the top-sheet process save around 20% to 30% of film.
INTERNATIONAL PATENT
|
|
WRAPPING MACHINE TOSA 120
AUTOMATIC PALLET STRETCH WRAPPING MACHINE WITH ROTATING ARM
While the pallet lies on the conveyor, the wrapping cycle is carried out by a rotating arm holding a film-roll. A steady and compact packing is guaranteed for all sorts ot palletized products by a multilayer wrapping made with stretch film. It is particularly suitable for light and unsteady charges. This machine can be installed on any existing packing line and it perfectly meets high production needs.
|
|
Fully Automatic Stretch Wrapper
Special customer benefit:
• Very little space required due to modular construction
• Variable speeds guarantee that all types of product will be optimally
wrapped
• Machine signals and malfunctions are shown on the clear text display
• The Cyklop Power-Eco-Stretch system ensures an optimal film
pre-stretch of 0-360% - precise and reproducible
• Diverse product sizes represent no problem in the product flow. Due
to the option moveable film takeover the permanently changing
product sizes also represent no problems.
|
|
1525CN Automatic :
- Wraps up to 40 loads per hour
- Heavy duty construction
- Pre-stretches fi lm up to 300%
- Installs over existing conveyor or can beprovided with conveyor
- Positive, non-slip V-belt rotation driveFavori
- Allen-Bradley PLC with operator interface
- Octo-Thread carriage allows easy fi lm threading
- Strain gauge fi lm delivery control
- 3-1/2" dia. conveyor rollers on 3-3/4" centers (1500CN model)
|
|
|
|
|
|
WRAPPING MACHINE TOSA 125E
AUTOMATIC PALLET STRETCH WRAPPING MACHINE WITH ROTATING RING
EQUIPPED WITH WATERTIGHT TOP SHEET DISPENSER
This machine, with rotating film-roll, allows to obtain a steady and compact packing of all sorts of palletized load by a differentiated wrapping on products of sundry nature. An overall packing (five sides) is guaranteed for all sorts of palletized products by the waterproof top sheet dispenser integrated in the machine. Such a wrapping provides an excellent protection against the action of the weather. The possibility of carrying out different wrapping cycles is the main feature of this machine. The wrapping program, in addition to the complete cycle, allows to carry out a downward cycle only, an upward cycle only, a wrapping of the top or the bottom of the pallet only and a waterproof cycle. This machine can be installed on any existing packing line and it perfectly meets high production needs. It is complete with top pneumatic presser, powered pre-stretch assembly, film hooking and cutting unit, film sealing unit, boundary safety-guards, control board with PLC and different adjusting and control units.
|
|
Octopus 303 Automatic :
- Wraps up to 60 loads per hour
- Heavy duty construction
- Pre-stretches film up to 300%
- Rotary ring design increases film savings
- Installs over existing conveyor or can beprovided with conveyor
- Allen-Bradley PLC control
- Octo-Thread carriage allowseasy film threading
|
|
Octopus 808 Automatic
- Wraps up to 120 loads per hour
- Heavy duty construction
- Pre-stretches film up to 300%
- Cut and heat seal design increases film savings
- Installs over existing conveyor or can be provided with conveyor
- Allen-Bradley PLC
- Banding and split wrap capabilities
- Optional Pak-Air carriage for load ventilation requirements
- Octo-Thread carriage allows easy film threading
- Strain gauge film delivery control
- Optional integral top sheet dispenser
|
|
|
THE TOPSHEET DISPENSER IS ADAPTED FOR ALL THE PWM MACHINES AS ARM OR TURNTABLE FOR SPLASHPROOF WRAPPING.
|
|
WRAPPING MACHINE "TOSA 095"
AUTOMATIC PALLET STRETCH WRAPPING MACHINE - TURN-TABLE WITH POWER ROLLERS CONVEYOR.
A steady and compact packing is guaranteed for all sorts of palletized products with a multilayer wrapping made with stretch film. This machine can be installed on any existing packing line and it perfectly meets low production needs.
|
|
ECOSPIRLINE: wide range of fully-automatic pallet-wrapping lines, from the simplest (infeed conveyor - pallet-wrapper - outfeed conveyor) up to the most complete and accessorized ones, both standardarized or customized.
Machines manufactured according to CE rules
|
|
FULLY - AUTOMATIC STRETCH WRAPPING MASCHINE - WAH 4
Fully-Automatic Stretch Wrapping Machine with Rotating Arm
Machine Description:
- Fully automatic stretch wrapping machine with rotating arm
- Capacity up to 80 pallets / hour
Options:
- Roller conveyor
- Top film coating
- Special sizes 1800 mm x 1800 mm
- Hold-down device
|
|
SATURN S6 HIGH PRODUCTION
. Automatic Envolvedora of ring for palletized loads.
. Production 60-90 palets/hour.
. Double desbobinador mall pillow.
. System rammer.
. Dispenser from film it leaves superior of the load.
|
|
SATURN S8 DOUBLE PRODUCTION
. Automatic Envolvedora of ring for palletized loads.
. Production 90-150 palets/hour.
. Double desbobinador mall pillow.
. System rammer.
. Dispenser from film it leaves superior of the load.
|
|
SATURN S4 AVERAGE PRODUCTION
. Automatic Envolvedora of ring for palletized loads.
. PRODUCTION 30-60 palets/hour.
. Desbobinador of film.
. System rammer.
. Dispenser from film it leaves superior of the load.
|
|
Horizontal stretch-wrapping machines mod. RING, with rotating ring and automatic hook-up and cutting film, for horizontal wrapping of panels, doors, pipes, bars, bobbins and all long products.
The Range include several models with ring sizes from mm. 400 to mm. 1500 mm. 2000 on request) in two series :
- S = semiautomatic machines for small production, with free conveyor and foot-switch for start
- A =automatic machines for medium and high production, with motorized conveyor, stabilizer press and photocell, for their insertion in automatic lines
|
|
|
|
|
|
- Penguin Horizontal Ring Wrapper is a well proven machine for packing lengthy products, using LLDPE stretch cling film, helically wrapped around the surface as the objects placed over the feed conveyor move towards the delivery conveyor.
- Even 6 meter long objects, like precision - finished metallic shafts/tubes, rigid PVC pipes, aluminium and other sections, doors, bundles of cloth etc can be packed easily.
- Can be supplied for any length and cross section of any product-single/ bundle
- Variable speeds for conveyors and ring wrapper
- Completely automatic cycle of operation - including holding the film initially and cutting the film finally
- Overlap of film can be varied as desired
- One stroke lubrication and very low maintenance requirements
- Easy operation with the state-of-the-art Programmable Logic Controller (PLC)
- Penguin RING WRAPPER is suitable for Industries manufacturing, even 6 meter-long Shafts, Pipes & Extrusions in Aluminium or other metals or P.V.C., which cannot be easily wrapped with protective wrappers manually due to their heavy weight & very lengthy nature. Using low installed power of 2 kW, this machine can stretch wrap the above items of various sizes in width & diameter, weighing even up to 200 / 300 Kgs. The type & size of Conveyor will depend on the nature & size of the product being stretch wrapped.
- For economical consumption of the stretch film, the inbuilt pre-stretch unit stretches the LLDPE stretchable cling film mechanically before wrapping over the "products". As the "products" are simultaneously moved over the feed / delivery conveyors, we get uniformly overlapped/ helically wound wrapping of the stretch film all over the surface of the "products". This gives the "products" necessary protection from dust & moisture and ensures longer storage life at a much cheaper packing cost.
- This machine can be easily integrated in to conveyor lines to save considerable labour & time. When larger quantities of above products are required to be packed, or when new expansion projects are implemented, industries like above can install this machine and save enormously in packing cost, in labour cost, in time taken for packing, etc., and this machine will pay back its cost very soon.
|
|
Fully automatic horizontal wrapping machine enables the protection and the stabilization of long-shaped products with important cross sections.
Stretch film width : 250 or 500 mm.
OPTIONS :
- 300% power pre-stretch
- Welding tail group instead of standard film cutting.
- Programming according to needs.
- motorized conveyor
- Automatic top sheet dispenser
|
|
|
|
|
|
Meypack FW 100 Series
- Economical transport packaging due to minimized film consumption
- Product bundling without heat
- Easy opening system available
- Capacity of up to 12 bundles/min.
Functions
- Turning upright stacking and grouping of lying and standing products, easy format change-overs.
- Film pre-stretching according to product requirements, the bundle strength can be adapted by easy modification of the film pre-stretch.
- Wrapping unit reliable wrapping process.
Meypack FW 200 Series
- Economical transport packaging due to minimized film consumption
- Product bundling without heat
- Only one film width for all bundle formats
- Easy opening system available
- Continuously running wrapping process
- Capacity of up to 60 bundles/min.
Functions
- Bundle separation turning upright, stacking and grouping of lying and standing products, up to 300 single products per minute.
- Film pre-stretching according to product requirements, the bundle strength can be adapted by easy modification of the film pre-stretch.
- Cutting system continuously operating cutting system, thermal cut with knifeedge.
|
|
The Lan-ringer® wraps products that won't fit on a turntable, require banding, compression or extra packing for shipment. The Lan-ringer® has a proven record of success in many industries.
Lantech offers a wide variety of options to meet your specific requirements. Each application is evaluated to provide the right solution to your needs.
Controls
- PLC Allen Bradley MicroLogix 1500
- HMI / Touchscreen Allen Bradley PanelView 600+ Monochrome
- Logic Lan-Logix™ powered by RS Logix 500
Film Delivery System
- Power Roller-Stretch® 150% Standard;100-300% Available
- Wrapping Force Adjustable
- Film Capacity 10" Roll Diameter; 20" Film Width
- Film Break Detection Standard
Standard Options
- Power-Thru® Conveyor
- Product Stabilizers
- Accumulation Conveyor
|
|
|
|
|
|
PALLET PACKING MACHINE - Model Classic
The Penguin Stretch Wrapping Machine is a fully automatic machine for wrapping pallets using stretch cling film.
- This machine is used in many countries for wrapping pallets with pre-stretched cling film. It ensures stable and moisture-proof wrapping of pallets at minimum cost. Optimum wrapping of pallets using wide range of film material is made possible by the state-of-the-art "Powered Pre-Stretch Unit " which can stretch the film up to 300% (One meter long becomes 4 meters long). Powered Pre-Stretch unit has a seperate motor to stretch the film.
- This simple and sturdy machine can operate continuously under severe industrial environment. The machine can be easily operated by unskilled workers in the packing line as the cycle of operation is completely automated.
- Stretch wrapped Pallet of yarn cones. The picture shows 432 cones of 2 kg each stacked on a pallet of size 44" x 44". The cones are stacked in 12 layers of 36 cones per layer. Ten such pallets can be stuffed in one 20 feet container
Features
- Fully Automatic Machine.
- Heavy duty turn table for all industrial applications.
- Sturdy mast and machined guide ways for guiding the stretch unit.
- Compact stretch unit with change gears to vary stretch percentage.
- Suitable for a wide range of stretch film material.
- Modular in construction
|
|
WM1
is a wrapping machine with rotating arm , equipped with 1 film distribution head and one single seaming device which comes beside the palett .
The capacity of this machine can reach 80P/H for standard load .
|
|
|
|
