For Industrial Computing, Lanner offers a variety of backplane choices for Full/Half-sized SBCs to fulfill diverse requirements. Integrated with suitable chassis and power supply units, this product line can satisfy a wide variety of computing requirements in different situations.
http://www.lannerinc.com
|
|
VMEbus
- Conforming with VITA 1-1994
- J1, J2 and J1/J2 backplane
- Manual or automatic daisy chain
VME64 Extension
- Conforming with VITA 1-1994 VME standards, VITA 1.1-1997 VME64 Extension standards, VITA 38 System Management for VME
- Termination, passive
- Electronic automatic daisy chain (EDC)
- Outstanding high-frequency noise suppression and very high MTBF due to ceramic capacitors
CompactPCI bus
- For durable industrial application
- CompactPCI is an adaptation of the Peripheral Component Interconnect (PCI) specification, version 2.1
- Power supply selectable with screw connections, ATX-PSU-connector, connector type M
- Clock signal less running times with optimum skew
ATCA Backplane
- Conformity with PICMG 3.0 ATCA Core Specification (ATCA= Advanced Telecom Computing Architecture)
- Full Mesh and Dual Star Topology
- 4 Ports per Link
- Slots for 2 redundancy Shelf Management Controller
- Connector for fan unit integrated
|
|
Elma offers the widest selection of cPCI, VME and VME64x in the industry.
Backplanes in various industry-standard architectures and custom design services. Signal integrity services are also available.
Products:
AdvancedTCA
CompactPCI
CPSB (PICMG 2.16)
MicroTCA
PXI
VXI
VME / VME64x
VPX (VITA 46)
VXS (VITA 41)
|
|
|
|
|
|
PICMG 1.3@Industrial Backplane
Model PBPE-06V
Vertrical 6-slot [PCI-E x1 (4),PCI-E x16 (1)]PICMG 1.3 Backplane
Fit for 2U chassis
Four USB ports
Dual SATA port
24-pin ESP12V power connector
Model PBPE-14AD64
14-slot [PCI-E x4 (1), PCI-E x8 (1), PCI-X (8),PCI (3)] PICMG 1.3 Backplane
Fit for 4U chassis
Dedicated to ROBO-8920VG2
Four PCI-X buses support eight PCI-X expansion slots
ModelPBPE-19AG64
19-slot [PCI-E x8 (1), PCI-E x4 (1),PCI-X (16)]
Fit for 4U up chassis
Dedicated to ROBO-8920VG2
Four PCI-X buses support 16 PCI-X expansion slots
PICMG 1.2@Industrial Backplane
Model PBP-14PD64
14-slot (4xPCI-X) 64-bit PICMG 1.2 backplane
PICMG 1.2
Four PCI-X buses
1 SHB, 2 PCI-X, 3 PCI-X, 3 PCI-X and 4 PCI-X
Fit for 4U chassis
283(L) x 317(W) mm;11.14"(L) x 12.48"(W)
Model PBP-06V564
Vertical 6-slot (2xPCI-X, 3xPCI) 64-bit PICMG 1.2 backplane
Fit for 2U chassis
ATX power connector support
321.94(L) x 83(W) mm;12.67"(L) x 3.27"(W)
ModelPBP-06P564
6-slot (2xPCI-X, 3xPCI) 64-bit PICMG 1.2 backplane
Fit for 6-slot node chassis
ATX and aux power connectors support
310(L) x 140.2(W) mm;12.2"(L) x 5.52"(W)
PICMG 1.0@Industrial Backplane
Model ACTI-14P4
14-slot (4xPCI) Active PICMG Backplane
2.4 mm PCB thickness
ATX power connector support
Fit for 14-slot chassis
317(L) x 257(W) mm;12.48"(L) x 10.12"(W)
Model PBP-19AI
19-slot (18xPCI) active PICMG backplane
Suitable for advanced CTI application
ATX power connector support
415.4(L) x 265.2(W) mm;16.35"(L) x 10.44"(W)
Model PBP-19P4
19-slot (4xPCI) PICMG Backplane
Fit for any 20-slot chassis
ATX power connector support
Sufficient ISA slots for CTI application
415.4(L) x 265.2(W) mm;16.35"(L) x 10.44"(W)
Model PBP-02V1X
Vertical 2-slot (1xPCI) PICMG backplane
Fit for 1U chassis
ATX power connector support
327.9(L) x 33.7(W) mm;12.91"(L) x 1.33"(W)
|
|
Mini-ITX Motherboards
Mini-ITX is the new compact standard motherboard form factor which is mechanically compatible with ATX motherboards. Kontron offers Embedded Mini-ITX motherboards with long life and many industrial features.
|
|
JRex 3.5" SBC
Embedded SBCs - in 3.5" (JRex). Serving as the best scaleable off-the-shelf-board solution - with up to Pentium M performance. Offering patented JFLEX IO, PC/104 and PCI/104-only expansions.
JRex boards are a family that allows full accessory reuse - as all interfaces remain unchanged electronically and mechanically.
Easiest up/downgrade at minimum risc - from VIA Eden to Pentium M and back again.
|
|
|
|
|
|
Micro-ATX single board computer with LGA775 socket supporting Core 2 Duo CPU, SATA II, GbE LAN, USB, PCI-E and CompactFlash socket
Features
* Supports Intel Conroe Core 2 Duo LGA775 CPUs, FSB 533/800/1066MHz
* Intel Q965 + ICH8R Chipset
* Four DIMMs up to 8 GB Dual Channel DDR2 533/667/800 MHz SDRAM
* Intel GMA 3000 2D/3D graphics accelerator
* Dual gigabit LAN with PXE support
* 1 PCI-E X16, 1 PCI-E X1, 2 PCI
* 4 COM, 6 USB 2.0, 4 SATA 300/150, CF
Form Factor
Micro-ATX
Platform
Supports Intel Conroe Core 2 Duo with VT, Pentium D 900 sequence, Pentium 4 with HT, FSB 533/667/800 MHz, LGA775
Intel Q965 +ICH8R chipset
AMI Flash BIOS
Processor Built-in Cache Memory
System Memory
DDR2 533/667/800 MHz SDRAM
8GB Max Capacity
240-pin DIMM x4
Storage Interface
IDE x1, Serial ATA II x4
CompactFlash I/II x1
Networking
10/100/1000 Mbps
RJ45 x2
Display
Intel(R) GMA 3000 2D/3D graphics media accelerator
Supports up to 224MB Video Memory
Audio
Realtek ALC260/262 HD audio codec, NS LM4950 amplifier
Mic-in, Line-in, Line-out
I/O Interface
FDD Header x 1
RS-232 x3, RS-232/422/485 x1 (all serial headers+5/12V support)
1 Parallel Port
6 USB(v2.0)
8 x TTL input , 8 x TTL output
PS/2
PS/2
Cooling
Heatsink & Fan
Expansion
PCI Express (x16) x 1, PCI Express (x1) x 1, PCI x 2, Mini-PCI slot x 1
Environmental Parameters
0~60C ambient operating temp.
neg 20~70C ambient storage temp.
0~90% ambient operating humidity
Physical Dimensions
243.84 mm x 243.84 mm (9.6 x 9.6)
Power
DC +3.3V/+5V/+12V/+5Vsb
ATX support
Compliance
CE, RoHS
|
|
|
Advantech is a global leader in plug-in I/O card design and manufacturing, providing a full range of industrial data acquisition (DAQ) and control products which are widely used in industrial and laboratory applications such as: monitoring, motion control, data acquisition, and automated testing. There are six major categories - CompactPCI, PCI-bus, ISA-bus, USB-bus, PC/104 modules, and Motion Control I/O products. With rich wiring terminals and extensive software support, Advantech provides reliable, efficient, and cost-saving industrial solutions. Moreover, Advantechs DAQ products could simply be bundled with versatile industrial PC chassis, backplanes, CPU modules, flat panel monitors and embedded automation computers.
|
|
Embedded Motherboards
Kontron motherboards are the ideal solution for embedded applications. As the options for embedded computing continue to expand, identifying the right choice becomes more complicated and can be very confusing. In applications where longevity and risk avoidance must be optimized, Kontron's experience in a variety of markets can lead customers to the solution that meets their needs and meets critical programming and cost objectives.
|
|
|
|
|
|
|
Protech Systems Co., Ltd., the leading provider of industrial computers, is releasing the PMB-601LF, an RoHS compliant LGA 775 ATX industrial motherboard supporting the latest Intel Core 2 Duo, Intel Celeron D, Intel Pentium D and Intel Pentium 4 processors with up to 1066MHz FSB. It is one of the first industrial motherboard solutions on the market offering the potent Intel Core 2 Duo/Intel Q965 chipset (ICH8R controller hub) combination. The PMB-601LF offers excellent power management, great I/O bandwidth with two PCI Express x16 slots, Intel High Definition Audio and an integrated 32-bit 3D graphics engine based on Intel Graphics Media Accelerator 3000 (Intel GMA 3000) architecture with DirectX 9.0, Shader Model 3.0, and 256 MB of video memory. The PMB-601LF delivers the high performance, low power consumption and efficient thermal design in a rugged solution developers need to support a range of embedded applications such as gaming, medical and industrial imaging, multimedia systems, digital image storage servers, application servers, automation and more.
|
|
Protech's New Mini-ITX Intel Core Duo CPU Industrial Motherboard
ITX industrial motherboard supporting the latest Intel Core Duo processors to deliver an optimum combination of performance, multitasking flexibility and fanless, low-power operation for a wide range of embedded and industrial applications.
The PMB-531LF incorporates the Intel 945GM Express chipset with Intel Graphics Media Accelerator (GMA) 950 to provide extreme graphics performance and takes advantage of the Intel Serial Digital Video Output (SDVO) specification on the PCI Express x16 slot for comprehensive video output connectivity to LVDS, TV-out and VGA displays through Advanced Digital Display 2 (ADD2) cards.
|
|
Industrial Motherboards
Avalue's industrial motherboards / mainboards come standard with an Extended Service Package that includes product life cycle management. PCB/ Assembly/ BIOS revision control, high quality design and manufacture, and legacy form factor/ device support that further ensure customers a lower cost of system ownership.
Product Range:
|
|
Avalue Unveils High-Performance, High-Secure Gaming Platform, ACP-GM45
Features
- Supports 45nm Intel FC-PGA/BGA Socket-P Core 2 Duo CPU
- Intel GM45 / ICH9-M Chipset
- Two SODIMMs up to 4GB DDR2 667/800 SDRAM
- Intel Graphics Accelerator 4500MHD
- Dual View, 2-CH LVDS, Dual VGA
- 7.1-CH Audio, 6W Amplifier, Dual Gbe
- 1CF, 1 PCI, 8 USB, 4 SATA, 3 COM, 2 CC Talk
- 32 Isolated DI, 32 Darlington DO
- Battery Backup 512KB x 2 SRAM
- JAMMA Interface
|
|
Structured around a processor, heart 32bits x86 at
133 MHz of ZF Micro devices and STM.
Dedicated to the industrial or military embeded applications.
Personnalisable according to the application.
Especially conceived to answer the constraints of an environment severe (temperature, vibrations, shocks and CEM).
|
|
Embedded Motherboards
Kontron motherboards are the ideal solution for embedded applications. As the options for embedded computing continue to expand, identifying the right choice becomes more complicated and can be very confusing. In applications where longevity and risk avoidance must be optimized, Kontron's experience in a variety of markets can lead customers to the solution that meets their needs and meets critical programming and cost objectives.
|
|
RX965QV
Intel Core 2 Quad LGA 775 Micro ATX Motherboard with Onboard LVDS, 6 SATAII RAID, 3 PCI
- Intel Core 2 Quad/ Core 2 Duo/ Pentium D LGA 775 Socket with 533/800/1066 MHz FSB
- Intel Q965 Chipset
- Four DIMMs up to 8 GB Dual Channel DDR2 Non ECC
- Intel Graphics Media Accelerator 3000
- Onboard LVDS connector
- Realtek ALC888 support 8 CH HD Audio, SPDIF header
- Dual Gbit LAN: Intel 82566DM and Intel 82573L
- 1 PCIe x16, 3 PCI
- 6 SATAII (3.0 Gb/s) RAID, 4 COM, 10 USB
- Support TPM 1.2, optional iAMT
- Micro ATX Form Factor (9.6" x 9.6")
- RoHS Compliant
- Microsoft Windows Vista ready
|
|
RX815ELT-LF
Intel Pentium III Micro ATX Motherboard
* Intel Pentium III / Celeron PGA 370 Socket with 66/100/133 MHz FSB
* Intel 82815E GMCH Chipset
* Three DIMMs up to 512 MB SDRAM Non ECC Memory
* Integrated Intel 3D with Direct AGP, DVO
* ADI AD1885 AC'97 support 2 CH Audio
* Intel 82562ET 10/100Mbps LAN
* 1 AGP, 3 PCI , 1 CNR (Optional)
* 2 COM, 4 USB
* Micro ATX Form Factor (9.6" x 8.6")
* RoHS Compliant
Please contact us if you need customization for industrial motherboards, barebone, systems or panel PC.
|
|
|
|
|
|
RX35Q
Intel Core 2 Quad LGA 775 Micro ATX (mATX) Motherboard with TPM, 2 IEEE 1394, 5 SATAII, PCIe x16
- Intel LGA 775 Core 2 Quad/ Core 2 Duo CPU with 800/1066/1333 MHz FSB
- Intel Q35 Chipset
- Four DIMMs up to 8 GB Dual Channel DDR2 Non ECC
- Intel Graphics Media Accelerator 3100
- DVI Output through PCIe x16 with ADD2 card
- Realtek ALC888 support 8 CH HD Audio, SPDIF header
- Intel 82566DC Gbit LAN
- 1 PCIe x16, 1 PCIe x1, 2 PCI
- 5 SATAII, 2 IEEE 1394, 2 COM, 10 USB
- Support TPM 1.2
- Micro ATX Form Factor (9.6" x 9.6")
- RoHS Compliant
- Microsoft Windows Vista ready
The RX35Q Micro ATX industrial motherboard covers many key requirements of embedded computing designs including:
Enhanced Graphics: Intel GMA3100 supports 3-D enhancements enable greater flexibility and scalability. Low-power consumption, noise reduction.
Upgraded Manageability: The Intel Q35 chipset implements Active Management Technology (IAMT) which provides around-the-clock availability to remotely monitor networked embedded systems. Note: Revision is required for acquiring IAMT function.
Superior Data protection and security: Optional TPM function for drive encryption, digital authentication, and hardened file protection.
Applications
This is an optimized solution for imperious demands for data transaction security applications and the multitasking/multi-devices environments, such as:
Point-of-Sale Terminals
Testing Equipment
Digital Signage
Kiosk PC
ATM
This board will also be fully FCC and UL certified in a Systium chassis to form a barebone system or a complete industrial PC.
|
|
|
|
|
|
BCM's industrial graded Mini ITX motherboard is 6.7 x 6.7 square inches. It's small but it has everything you need designed on the board to support various applications for various industries. The socket type is ranged from mPGA 478, Socket M and Socket P to support Intel processers from Celeron, Pentium to the latest Mobile Core 2 Duo CPU. The chipset is ranged from Intel 852GM to the latest 965GME chipsets. Fan or fanless operation, or BIOS revision is available via customization services.
BCM's Mini ITX Features:
1. Long life cycle: designed for 24/7 and at least 3-5 years operation
2. Strict Revision Control
3. RoHS and CE, FCC certified
4. Flexible requirements
5. Local R&D engineering support
6. Strict Quality Control
7. Local logistical support
Check out our latest best selling Mini ITX motherboard:
MX965GME
Intel Mobile Core 2 Duo Socket P Mobile Mini ITX Motherboard features HDMI, DVI, LVDS, TV-out
* Intel Mobile Core2 Duo/ Pentium Dual-Core/ Celeron 5xx Socket P 533/667/800 MHz FSB
* Intel GME965 GMCH Chipset
* Two DIMMs up to 4 GB DDR2 533/667MHz System Memory
* Intel GMA X3100 GFX Engine; DVMT 4.0 up to 256MB memory, CRT, Dual CH 18/24-bit LVDS, TV-out, DVI, HDMI Output
* Dual Gbit Ethernet
* Realtek ALC888 8 CH HD Audio, SPDIF
* 1 PCIe x4, 1 PCI, 1 Mini PCIe, CF
* 2 SATAII (3.0 Gb/s), 8 USB, 2 COM
* Support TPM 1.2 (Infineon SLB 9635)
* Mini ITX Form Factor (6.7 x 6.7 inch)
* RoHS Compliant
* Microsoft Windows Vista ready
Applications
BCM MX965GME Mini ITX is optimized for various applications, such as:
* Gaming
* Digital Signage
* Information Kiosk
* Interactive POS
* Medical Diagnostic System
|
|
IN915GVE
Intel Pentium 4 Micro ATX Motherboard
* Intel Pentium 4 Prescott/ Pentium 4 (65nm)/ Celeron D LGA775 Socket with 533/800 MHz FSB
* Intel 82915GV GMCH Chipset
* Two DIMMs up to 2 GB Dual Channel DDR2 Non ECC Memory
* Intel Graphics Media Accelerator 900
* Realtek ALC655 support 6 CH Audio
* Realtek RTL8100C 10/100Mbps LAN
* 1 PCIe x16, 3 PCI
* 4 SATA, 2 COM, 8 USB
* Micro ATX Form Factor (9.6" x 9..6")
* RoHS Compliant
Please contact us if you need customization for industrial motherboards, barebone, systems or panel PC.
|
|
|
|
