Market Segments
* Perimeter fencing
* Traffic management
* Parking areas
BL 229 versatile rising barrier advantages
Aesthetics
* smooth design
Technologies
* new mechanism
* new user-friendly control board
Performance
* fast, harmonious & silent movements
* intrinsic automatic opening mode (no crank, no accumulator)
Universal
* mechanism & casing : fit for all arm lengths and accessories
* programmable opening speeds for toll or perimeter fencing use
|
|
|
|
|
|
QIK: THE NEW DITEC BARRIER
Qik barrier has been launched, boasting newly designed shapes and uncompromising security.
Soft profiles, rounded edges, high performance and total installation flexibility.
Newly designed and technically advanced, Qik is the ideal solution to ensure total security access in medium to high transit environments such as: hotels, banks, shopping centres as well as blocks of flats, companies and camp sites, which always require access control to car parking areas, thus ensuring their use only by authorised people.
Safe and reliable
Smart, yet practical and safe, Qik has been designed to last.
The painted pickled metallic sheet metal will not deteriorate with time, even in extreme weather conditions, and gives Qik a clean look.
Clean lines and attention to details in a heavy duty solution
The single block pressure die-cast aluminium reduction unit ensures an easier installation, a longer life and a cleaner look.
The gear motor bronze reduction gears are subject to less wear and tear, thus ensuring a higher number of operations, up to 1.000.000, to be achieved.
Qik: DITEC solution to access control problems
|
|
|
|
|
|
FLEX-18 Barrier Gate (New G89)
High-speed automatic rising barrier especially designed for access control in public and private parking lots as well as industrial sites. The Flex-18 barrier has been developed to ensure an economical vehicle access control for lanes up to 5.5m (18 Feet), while providing dependable efficient control and safe every day use.
Description:
Housing made of folded and welded 10-gauge steel sheet.
Removable upper hood. Upper hood fixed by two latches designed to resist vandalism.
Lateral door side mounted for easy access to mechanism.
Extruded aluminum arm.
Electromechanical assembly including:
120VAC single-phase motor.
Lubricated speed reduction gearbox with worm screw.
Balance achieved by built-in extension spring. No external counterweights.
Crankshaft-rod device ensuring smooth, progressive operation.
Mechanical locking of barrier arm in extreme positions (Closed/Open), with rubber bumpers.
Easily reversible main shaft.
Easily adjustable limit switches with mechanical and controller overrun protection.
Barrier arm shaft mounted on two pillow blocks with welded arm support.
Shaft configuration allows easy barrier model inversion from left to right.
Built-in heater.
Easily removable 10 or 26 IO PLC logic control to ensure automatic closing of the barrier either by detector and loop or by push button. Opening of the barrier by push button, card reader or other optional controls. The 26 IO controller provides for connection of up to three optional loop detectors.
Barrier anchoring by means of expanding bolts or threaded rods, thus allowing easy alignment with road-way (anchoring means available as option, to be defined depending on the type of ground). Fits over existing G89E bolt patterns.
Seam welded cabinet is constructed from 10 gauge galvanized steel with polyester powdered finish for superior corrosion resistance.
Dimensions: Approximately 42" Height x 15" Wide x 15" Deep
Technical Characteristics:
Shaft output left or right, to be specified with order.
Standard power supply 120V AC single phase ( ±8%).
Frequency 50-60HZ.
Reversing Motor 1/3 HP - 1625 RPM.
Operating time 2 -4 seconds depending on arm length.
Worm screw type life lubricated gearbox.
Compression springs available in 1 to 3 spring configurations depending on arm length.
Programmable logic controller with LCD display, allows for uploading of logic changes.
Run timer, safety edge timer, auto close timer (jumper enabled).
Operating Temp. - 35° to +70° C.(-31° to 150°F)
Net weight from 90 to 96 Kg (200-215Lbs), (arm included) depending on arm length.
|
|
BARRIER TO MOBILE CHAIN PILOMAT® CHAIN
PILOMAT® CHAIN is a sturdy barrier to mobile chain in order to delimit steps carrai and wide areas of parking till 20 m.
They Electronic incorporated with motor double quantity to 24V centers that she allows of
to raise chains till 60 kg of weight.
She is equipped of impact sensor
in order to guarantee the maximum emergency of operation.
She advises herself to add the guide to earth for
control of the chain when lowland.
Possibility to connect a card of recharges and batteries tempone
|
|
AUTOMATIC BARRIER:
PILOMAT BARRIER
Automatic barrier with survey system obstacle to encoder magnetic with reversal of the movement. In the respect of relative norm EN 60335-2-103 to the automatic barriers, PILOMAT BARRIER inverts its movement also during last the 5 centimeters of race.
Incorporated PARK centers them electronic 24V.
Second time opening 3.
Body in aluminum and steel. Slowing down in opening and closing.
The confection comprises the slab to bury, the telescopic auction from 4 meters and the adhesive ones for the auction.
Simplified installation: without necessity of regulating the motivatings force of balance or the positioning of the finecorsa.
Manual release with personalized key.
Possibility to connect a card of recharges and backup batteries (180 cycles)
|
|
Base to bury for lodging Parky® AR580.
Characteristics
of the base Rubber from king cycling.
Agglomerated of grain mixture of rubber (SBR) and from poliuretanico binder.
Lowest emissions of CO2 during the production process.
Elevated technical qualities and performances.
High resistance to the usury and the atmospheric agents (ices and beams UV).
Drenante ability.
Weight max 50 Kg. (± 5%).
Density max 1 Kg. /dmc.
I use: parking on private area sluice to
public transit.
I pack in cardboard characterizes them
|
|
MANUAL SALVAPARCHEGGIO PILOMAT PARKY AR 580
Device for the protection of the parking, motor vehicle on private area sluice to the public transit.
Construction in elettro-galvanized steel tubes.
Cap of protection on the foot of implantation in steel elettro-galvanized realized in POLYAMIDE (NYLON) loaded with glass fiber "FIBER GLASS", resistant material many - new and searched design - rounded off forms.
Block automatic rifle to the manual return in vertical position.
Possibility of closing also in lowered position.
Certifyd product TÜV.
Anticorrosion treatment elettro-galvanizing
System of closing Cylinder European profile
Dowels to expansion (if the installation place uses allows some it)
|
|
MANUAL SALVAPARCHEGGIO PILOMAT PARKY AR 600
Device for the protection of the parking, motor vehicle on private area sluice to the public transit.
Construction in elettro-galvanized steel tubes.
Cap of protection on the foot of implantation in steel elettro-galvanized realized in POLYAMIDE (NYLON) loaded with glass fiber "FIBER GLASS", resistant material many - new and searched design - rounded off forms.
Block automatic rifle to the manual return in vertical position.
Possibility of closing also in lowered position.
Certifyd product TÜV.
Anticorrosion treatment elettro-galvanizing
System of closing Cylinder European profile
Dowels to expansion (if the installation place uses allows some it)
|
|
|
|
|
|
PILOMAT® PARK
BARRIER SALVAPARCHEGGIO AUTOALIMENTATA
PILOMAT® PARK is a sturdy barrier saves autoalimentata parking (not feeding 220V:) for the safeguard of the single place car.
The installation of Pilomat® Park is much easy and fast one as it is solo to fix to the ground with six dowels to expansion and is quickly working.
Pilomat® Park incorporates 5 alkaline batteries formed D (easy sostituibili) that of it they allow the operation for beyond two years.
In order to carry out the Pilomat® raising Park it uses the released energy from the passage of the vehicle.
Pilomat® Park is equipped with: N 6 dowels to expansion N 1 dima of manual positioning n1 of installation N 2 emitters radius of commando to three push-buttons (in order to command till max 3 N Pilomat® Park with an only emitter).
Pilomat® Park, with the exception of other competitive products, beyond to being autoalimentato has the characteristic important of having the molleggiata barrier of block in order to prevent the breach in case of accidental impact.
|
|
|
A Came patent which is widely applied in demarcating private and public parking for single or multiple spaces. High in technology content, it is uniquely designed and perfectly integrable even in particular architectural settings and historical town centers.
|
|
A new concept of automatic barrier
Designed for a range of large openings up to 7,6 m / 24.9 ft, the new Gard barriers are the ideal solution for control of roads and parking areas for industrial and public use. The Gard series is available in the 110V/230V A.C. motor and the 24V D.C. motor versions.
|
|
Road barriers
• A MODEL FOR EVERY NEED.
> Possibility of closing passages up to 8 m.
• SMART TECHNOLOGY.
> Electronic adjustment of the limit switches.
> The new position of the control panel makes it possible to operate in a vertical position.
• SAFE USE.
> The barrier features a very stout structure to guarantee greater protection from vandal attacks and constant reliability in use.
• SIMPLER INSTALLATION.
> The blinker and the support for the photocells are integrated in the frame (optional), the lights are integrated in the boom (optional).
> Cabling is simplifi ed by means of the ducting for housing the cables themselves.
|
|
|
|
|
|
RLG-46 Long Arm Industrial Barrier
The rising barrier type RLG46 with electric control, has been specially designed to control access of vehicles to large areas. Its precise balance, achieved by means of an integrated compression spring, permits a span of up to a maximum of 14m46ft.
DESCRIPTION
Housing made of heavy gauge steel sheet of 3 mm thickness, welded and shaped, with a framework of steel profiles welded into a strong section.
Removable upper hood, locked from inside.
Lateral doors with safety locks, ensuring easy access to the internal mechanism.
Boom made of extruded aluminum tubing, white enameled with red reflecting stripes. The boom is composed of three sleeves of decreasing diameter with an end sealing cap.
Bracing wires and adjustable stretchers in stainless steel. The number of wires varies from 2 to 4,according to the length of the boom.
Electro-mechanical assembly comprising:
120V motor,
life-lubricated speed reduction gearbox, ratio of reduction: 100/1,
gearbox driven by pulley and V-belt, allowing to adapt the operating speed in accordance with the length of the boom,
crankshaft/rod device ensuring progressive, shock less movements as well as mechanical locking of the boom in extreme positions,
safe passage is assured by an adjustable safety friction torque, regulated by Ferodo disks and self adjusting device for wear taking up,
llimit switches activated by adjustable cams.
Balance of the boom achieved by means of compression spring, eliminating all risk of accident to people, thanks to the limited number of movable parts to which the general public have access.
Electrical control board type PLC on a printed circuit remote controlled by a 3-push button box (open - stop - closed) supplied with the barrier.
Built-in heater for low temperature locations.
Emergency crank for manual operation in the event of power failure, with safety circuit breaker cutting the electrical power supply, providing the crank has not been removed from the barrier.
Adjustable tip-support.
Embedded framework composed of a fixing template with threaded rods and fixing claws.
|
|
|
|
|
|
MANUALLY OPERATED RISING BARRIER MG19
The MG19 has been developed for use in locations that require barriers up to 18 feet in length but do not have any provisions for electrical supply. The MG19 utilizes cast iron counterweights to balance the gate to the point where it can be easily opened with one hand. Locking rings may be fitted with pad or combination locks to secure the arm in either the raised or closed position.
POSSIBLE OPTIONS
Standard tip support for arm length over 15 Feet.
Lockable tip support.
Octagonal "STOP" sign in one or two directions.
CHARACTERISTICS
Net weight: of a 6m-arm barrier: 146 Kg.
Arm length: min. 2m-6.5ft., max. 7m-19ft.
Overall dimensions: see below.
DESCRIPTION
Vertical posts made of tubular steel with bracket for mounting.
Barrier arm made of round tubular aluminum
Arm is white with red reflecting stripes on both sides.
Pivot assembly made of flat steel profiles, mounted on steel rotating shaft with arm fixing brackets.
Sliding cast iron counterweights for adjustable arm balancing whatever the arm length
Padlock fixing points for locking arm in closed or open position.
Tip support for arm length of 5,01m (16 Feet) and longer (optional for arm up to 5m).
|
|
Bar Barrier
Dimensions: 2.5m x 1m
A low-level pedestrian bar barrier complete with hook fastening and fixed metal feet.
|
|
An innovative Came idea to reserve one's parking space, in any setting, whether residential, industrial or collective. It allows you to open and close the barrier directly from the car using a remote control.
Application contexts:
Apartment blocks
Workplace
Technology:
24V operator
|
|
|
|
|
|
MAG-12 Small Profile Gate
General purpose automatic rising barrier designed for vehicle access control in public and private parking lots as well as industrial sites. The MAG-12 barrier gate has been developed to provide low cost control in lanes up to 3.65m (12 ').
Description:
Seam welded cabinet is constructed from 10 gauge galvanized steel with polyester powdered finish for superior corrosion resistance.
Lateral door side mounted for easy access to mechanism.
Supports 3 - 3.6m (10-12') pine gate arms up to 4.5Kg( 10Lbs) or 10' Titan Flex arm.
Electromechanical assembly including:
120VAC single-phase motor.
Lubricated speed reduction gearbox with worm screw.
Easily adjustable limit switches with controller overrun protection.
Shaft configuration allows easy barrier model inversion from left to right.
Built-in 250W strip heater.
Easily removable 10 IO PLC logic control to ensure automatic closing of the barrier either by detector and loop or by push button. Opening of the barrier by push button, card reader or wireless remote. Controller provides for connection of two optional loop detectors.
Barrier anchoring by means of expanding bolts or threaded rods, thus allowing easy alignment with road-way.
Dimensions: 100cmHx33cmWx26cmD (40'x13'x10').
Technical Characteristics:
Flange connection left or right, to be specified with order.
Standard power supply 120V AC single phase ( ±8%).
Frequency 50-60HZ.
Reversing Motor 1/3 HP - 1625 RPM.
Operating time 2-4 seconds depending on arm length.
Worm screw type life lubricated gearbox.
Programmable logic controller with LCD display, allows for uploading of logic changes.
Run timer, safety edge input and onboard memory vend.
Operating Temp. - 35° to +70° C.(-31° to 150°F).
Net weight without arm: 61 Kg (135Lbs).
|
|
|
|
|
|
A protection being integrated in the environment
APPLICATIONS:
Forest accesses
Pedestrian precincts
Parks and gardens
Historic sites
Villas of character
The CHAINOSOL, chains heavy retractable, is intended for the prohibition or the control of the motor vehicle traffic, in mediums where esthetics must be taken into account. Indeed, its two boxes are designed to receive a preparing making it possible to integrate them in any site (example: preparing of the type hones).
This product is an answer adapted to the users who wish to control the passage of cars in a nonhostile environment.
The CHAINOSOL requires only travaus of civil engineering light. The chain, firmly anchored on both sides passage in its boxes, is in low position contained in a gutter, releasing thus completely the passage.
The CHAINOSOL comprises a simple and robust mechanics, and its automatism makes it possible to easily control it to your systems.
The CHAINOSOL makes it possible to constitute hoppers of safety associated with a management by badge readers, controllers biometric, readers of number plates...
|
|
Barriers series "EURO" and Special
The raising barriers of our series EURO are intended for the access control on sites where the robustness is the paramount element.
Only or associated, the barriers EURO can automate overpasses than 10 meters.
Their peripheral equipments allow them the integration of
Badge readers, remote controls, digicodes, readers biometric...
Cameras
Interphonie
Control with complementary stoppings (retractable gates, terminals, motorized harrows, plates of stopping,...)
The barrier EURO comprises a control simple and robust, its automatism also enables him to be easily controlled to your systems.
Its communicating interface makes it possible to you to reach remote maintenance and the telecontrol in order to still increase the safety of the exploitation.
The barrier makes it possible to constitute hoppers of safety associated with a management by badge readers, controllers biometric, readers of number plates...
|
|
Rising barrier Boston/Bridge & tunnel
* Great reliability and robustness : 2.5 million cycles guaranteed
* Modular up to 8m
* Anti corrosion casing
* Wild range of options and accessories (traffic lights, signaletic panels, boom skirt)
* Adapted for all control access systems
|
|
Rising barrier Miami/Hospital & Clinic
* Great reliability and robustness : 5 million cycles guaranteed
* High speed performance : up to 15 vehicles / minute
* Modular up to 6m
* Automatic opening in case of lack of voltage
* Adapted for all control access systems
* Man-trap system
* Wild range of options and accessories (boom type PROTECTA, removable boom, ultrasonic sensor, traffic lights)
|
|
The raising barriers of our series EURO are intended for the access control on sites where the robustness is the paramount element.
Only or associated, the barriers EURO can automate overpasses than 10 meters.
Their peripheral equipments allow them the integration of:
- Badge readers, remote controls, digicodes, readers biometric...
- Cameras
- Interphonie
- Control with complementary stoppings (retractable gates, terminals, motorized harrows, plates of stopping,...)
|
|
Rising barrier Tollgate / Motorway
* The reference for the motorway environments : 20 000 cycles / day
* Great reliability and robustness : 10 million cycles guaranteed
* High speed performance : up to 50 vehicles / minute
* Modular up to 3.5m
* Removable boom
* Wild range of options and accessories (boom type PROTECTA, ultrasonic sensor, traffic lights, colors according to RAL)
|
|
Rising barrier Peapark/High capacity car park
* The reference for the paid carparks environment : 20 000 cycles / day
* Great reliability and robustness : 10 million cycles guaranteed
* High speed performance : up to 50 vehicles / minute
* Modular up to 3.5m
* Delivered with articulated and removable boom
* Wild range of options and accessories (ultrasonic sensor, traffic lights, colors according to RAL )
|
|
Rising barrier Manual/Industry tertiary
* Great robustness
* Balanced boom
* Positive locking pin for high and low positions
* Up to 8 meters
* Wild range of options and accessories
|
|
| ... products without technical information |
| |
|
|
