Model 6 Basket Strainer and Bag Filters
Model 6 strainer/filter housings are made in 3 sizes and 3 pressure ratings, and can serve as basket strainers (for particle retention down to 74 micron size) or as bag filters (for particle retention down to 1 micron size). In all cases, covers are easily removed without special tools, and the basket or bag is easily cleaned or replaced.
Features
- Low pressure drops
- Permanently piped housings
- Covers are O-ring sealed
- Carbon steel, or stainless steel (304 or 316) construction for housings
- All housings are electropolished to resist adhesion of dirt and scale
- Easy to clean!
- Adjustable-height legs, standard
- O-ring seals: Buna N, EPR, Viton®, Teflon® • ASME code stamp available
- Three pressure ratings: 150, 210 or 300 psi
- Duplex units are available
- Can provide 3.4 square feet of basket or bag surface area without need for ASME code construction
- Three basket depths: 12, 18, or 30 inches (nominal)
- Special alloys
|
|
These high-capacity filters and strainers require no flow interruption for servicing
- For use with filter bags for filtering to as fine as one micron, or with perforated strainer baskets
- From 2 to 10 Model 8 housings are mounted in parallel to inlet and outlet manifolds
- Each unit has inlet and outlet valves, gage ports, and a drain port, to permit servicing one at a time
- These are completely packaged free- standing systems in carbon steel and stainless steel
|
|
PUMP-PROT ECTING BAS KET ST RAINERS
Polypropylene build, no metal parts and low head loss make them ideal for installation on a pump suction port, providing protection from suspended solids, filaments, algae, etc. The strainer can be easily removed by unscrewing the lid without the need for tools.
max. operating pressure 7 bar
For chemical sector, water treatment plants, fish farming, the galvanising, tanning, textile, paper and printing
industries and a host of other applications.
Available in five different connection sizes: 1”, 11/2”, 2”, 21/2”, 3”
|
|
|
Viking Lid-Ease® strainers protect pumps and systems from foreign materials. Available in stainless steel, cast iron, ductile iron and aluminum, all with stainless steel baskets, they are suitable for almost all process fluids. Basket mesh options range from 140 to 4780 micons. Ports range from 0.75- to 8-inch, in tapped, grooved and flanged models. The breech lock lid allows easy basket removal for cleaning, and low pressure drop minimizes impact on pump system NPSHa. Magnetic inserts available for trapping ferrous particles.
|
|
97FB-CI: Cast Iron, Simplex, Basket Strainers
Description:
Series 97FB-CI Cast Iron, Simplex, Basket Strainers feature an angle-designed basket, cast iron body with flanged connections, stainless steel screen, bolted retainer cap (Model 97FB-CIB) or clamped retainer cap (Model 97FB-CIC) and cast-iron blow-off plug. Sizes 8 to 12 in. (200 to 300mm) have a side drain facing outlet of the strainer. Model 97FB-CIB - Maximum Pressure (non-shock): 200psi (14 bar) @ 150°F (66°C) WOG, 125psi (9 bar) @ 353°F (178°C) WSP. Model 97FB-CIC - Maximum Pressure (non-shock): 50psi (3 bar) @ 150°F (66°C) WOG.
|
|
FEATURES
- Quick open cover
- Straight through flow
design
- Low pressure loss
- Convoluted-basket
design
- Hand removable basket
- Threaded drain
- O-ring cover seal
- Perforated or mesh
stainless steel baskets
standard
OPTIONS
- Basket perforations from
1/32" to 1/2"
- Basket mesh 20 or 40
- Monel baskets
- Vent valves
- Drain valves
- 1/4" NPT taps
- Pressure differential
gauge and switch
connections
|
|
Simplex Plastic Basket Strainers
1/2" to 8" - PVC, Corzan® CPVC and Eastar®
Duplex Plastic Basket Strainers
1/2" - 4" - PVC, Corzan® CPVC and Eastar®
Duplex Plastic Basket Strainers
6" - 8" - PVC & Corzan® CPVC
Plastic Y-Strainers
1/2" to 4"- PVC - Clear PVC and Corzan® CPVC
Y Strainers - Clear PVC
1/2" to 2"
|
|
Streamline-Duplex-System
- The technical advantage of single streamline systems
- Double volume compared to single system
- Single cover lid with eye bolts
- Filtration efficiency up to 98 %
- Compact Design
- Ready to connect
- Adjustable mounting legs
Specifications
Max. Flow-rate: 80 m³/h
Filter area: 1
Volume housing: 60 Liter
Weight housing: appr. 110 Kg
Installation height: appr. 180 cm
|
|
Simplex Plastic Basket Strainers
1/2" to 8" - PVC, Corzan® CPVC and Eastar®
Duplex Plastic Basket Strainers
1/2" - 4" - PVC, Corzan® CPVC and Eastar®
Duplex Plastic Basket Strainers
6" - 8" - PVC & Corzan® CPVC
Plastic Y-Strainers
1/2" to 4"- PVC - Clear PVC and Corzan® CPVC
Y Strainers - Clear PVC
1/2" to 2"
|
|
Basket Strainers
Used to filter any fluid in industrial pipes.
The basket strainer is basically used to protect equipment such as:
- Pumps;
- Flow meters;
- Spraying systems;
- Cooling towers and other.
Basket strainers do not require any tool for maintenance. They have a very simple, strong construction. The cover is sealed with an o-ring, which ensures perfect sealing with minimum grip.
This strainer range meets the needs of most industrial segments:
- Chemical;
- Petrochemical;
- Pharmaceutical;
- Food;
- Hydroelectric;
- Thermoelectric;
- Pulp and paper, etc.
|
|
