Battery charger/Power supply – type DCP2 (12V)
The DCP2 can be applied as a battery charger or a stabilised network component as a universal DC voltage supply. Battery chargers offer the possibility of parallel operation.
Features include:
- Easy installation - DIN-rail mounting
- Automatic recovery from overload conditions
- 5-10A types
- Switch mode power technology
- Extremely low ripple <100mV
The DCP2 battery charger is applied to charge and to maintain the full-charge condition of closed or gastight 12V Pb batteries. In parallel operation with a battery and other consumers, the nominal power for the consumers is given until interruption from the battery, e.g. for recharging/maintenance reasons.
|
|
|
|
|
|
Desk-Top Fast-Charger, Ni-Cd/Ni-MH battery packs for ITE and Medical Applications
GlobTek Inc. is introducing our new family of External Switchmode Constant Current Split-Charge, two states: fast charge with charge termination and trickle charge end module. Fast Charge, 1C, Main Termination is achieved by Negative Delta Voltage or Delta Temperature Cut-Off and failsafe back-up: maximum temperature cut-off and 4-5 hours timer. Two Visual indicators are provided: Power-On and Charging using distinctive patterns to indicate the current charger status. This family is available in low profile 94V0 Polycarbonate plastic, no vents cases, size: 118L x 60W x 33H (mm), SMT/Through-Hole Components Single-Platform Design, has integral multi-fold heatsink thermal conduction cooling. Single Output, current regulated, are available up to 60W power, with outputs ranging from 1 cell to 48V battery configurations; accepts Universal Input: 90-264 VAC 47-63Hz, has Class B EMI Filter, meets Safety Agency Requirements: UL60950 and UL2601, CE Compliant. Modified and Custom Designs are also available.
|
|
Intelligent Battery Chargers
The IC Series Intelligent Battery chargers offer an ideal way of charging any type of lead acid battery safely and reliably.
The rugged fully protected unit (IP67) can be used in a variety of applications including on trucks, off road vehicles, fire vehicles, boats, caravans and in depots and workshops.
|
|
Switched mode, automatic battery chargers for wall mount or chassis mount, cooled by fan or air circulation, customer specific charging curves programmable, pre-programmed for the most common battery types (selectable)
- Mains voltage operation from 85...264V (wide range input)
- High efficiency and power factor through switching mode technology
- Powers from 150W to 1200W
- Charging voltages: 12V, 24V, 36V, 48V
- Programmable after customer's specifications
|
|
Switching battery charger:
The E61020541 battery charger is built using switching technology in order to offer small size and weight added to high efficiency.
High efficiency means less dissipated heat and more device service time. The small weight, less than 1700g, improves its immunity to vibrations and shocks during transportation and operating using.
The battery charger works in current mode up to the end of charge voltage; at this point it begins to operate in voltage mode.
|
|
Battery chargers
Zentro-Elektrik supplies the ZATxxxx range of primary switched mode power-supply units and battery chargers with outputs from 50W to 30kW, complete with temperature-controlled fans and various configuration possibilities.
|
|
The intermediate battery charger range: Chargetec C300 and C400 series
The Chargetec C300 and C400 series of battery trip units provide a more comprehensive array of functions and alarms than those offered in the Economy range. This includes a microprocessor based, temperature compensated, and current limited charger with a wider range of alarms, including high volts, low volts, AC mains fail, and low battery voltage cut-off via the battery isolation MCB. The battery load test facility is now automatic. The standing load capability is increased over the economy trip unit to150watts. The metering is also increased over the economy trip unit to include a voltmeter, a charge / discharge ammeter and LED’s to indicate the alarm condition.
- Charger size: 300mA to 4A.
- Voltage range: 24, 30, 50 & 110v DC.
- Battery size: 5 or 8Ah (VRLA).
|
|
* AC input range selected by switch
* Short circuit, over load, over voltage, over temperature protection
* Battery under/over voltage and polarity protection
* Fixed switching frequency at 25KHz
* 3 colour LED loading indicator
|
|
battery charger: 5A - 8A:
The battery charger allows the optimising of the system to charger and maintain the accumulator battery, ensuring its efficiency and life in time.
Innovation and improvement are the base of the philosophy which determined the study and realisation of a line of «battery charger», with such characteristics as to meet with the most different requirements and uses.
|
|
Using our Spec by DOGA industrial battery charger, make your Cordless tools more productive and durable. Make economy increasing the life time of your batteries and manage the recycling.
- Suitable with any cordless tools’ batteries from 1,2 to 24 volts
- Charge Management with impulsions controlled by Microprocessor,
optimizing the battery life (up to 3000 cycles) and autonomy (no memory effect).
- Automatic trickle charge mode when the cycle charge is achieved
(Delta peak achieved)
- Recognition of defective batteries through current charging analysis
- NG signal when charging time last over 100 mn
- Battery temperature monitoring (automatic switch-off when overheat)
- Auditive signal on Battery default (short circuit, internal damage...)
- Optical display of charging level
- Individual power supply for each cell of charging reducing maintenance cost.
|
|
|
|
|
|
Medical in-line charger meets stringent requirements and IP68
In order to meet the requirements of hospital and care environments, Engelking Elektronik has developed an innovative 12W charger unit which is able to withstand the ingress of water and other liquids to IP68+ as found in automatic washing units. The unit's robust housing can withstand the weight of such items as a 250kg hospital bed without damage. This is hardly surprising as the charger electronics are completely molded in polyurethane making it almost indestructible.
The charger's output is fitted with a 2.5m spiral cable made of polyurethane which is impervious as well as having excellent long-term retraction qualities. The mains side is fitted as standard with a short water resistant (EPR) cable and splash-proof European 2-pin contour plug thus meeting the requirements of class 2 for hospital applications, needing no earth connection.
The in-line design of this charging unit means that the strain on the wall socket is reduced and the unit cannot easily fall onto the floor or patient.
Having a wide range input of 90-240VAC, double pole fusing the standard product is designed for charging 24V lead acid batteries but custom variations are available on request.
|
|
|
GUTOR's DC supply systems (battery chargers) consists of a thyristor- controlled 6-puls/12puls rectifier. The systems are available with or without batteries. The DC supply systems can be modified for different voltages (24 - 220 VDC) and output ratings (25 - 1200A). Our customers can also select from a range of optional features.
|
|
Battery Chargers (Single Phase)
- Microprocessor Controlled DC Power Suppy
- Operation according to constant voltage and current principle
- Adjustable Boost and Nominal Charge Voltage
- Adjustable Output Current
- High Voltage Protection
- Over Current Protection
- Short Circuit Protection
- Over Temperature Protection
- Input Filter
- Low DC Voltage Protection (LVD)- Optional
- Alphanumerical LCD Display and Control Panel
- Parallel Connection Availability- Optional
- Dry Contact Alarms- Optional
- Small Footprints, Compact Size
- Control Panel
|
|
Battery Charger
AEC DC Power Supply & Battery Charger has been designed to provide a variety of DC power equipment to meet your specific requirements. The equipment includes insulating transformer, bridge rectifier, filter and control circuit to provide a standard DC output power. AEC thyristor control solid state circuit of charger and power supply offer compact design, high efficiency, easy operation and trouble free service. Our standard products cover a complete range of output rating from 15A~800A. Other ratings are handled by request.
|
|
Type: Linear
AC Voltage: 230V~240V
Output Current: 160mA
Output Voltage: 4.2V
Charging Indication: LED Lights
|
|
Features:
- Patents
- Standard/ Din Rail Mount (Option)
- Output Modify Range:3V~200VDC
- Automatic output protection,
- No replacement fuse
- Compact-Economical
- Water & Dust Proof
- 2 years Warranty
- Reverse Polarity Protection
- Charger type exposition download
- RoHS Report
- ISO 9001:2000 TUV Certification
- Part Number Rule
- Split rail, Series, and Parallel, Redundant use, and Remote sensor connection circuit
|
|
2A 12Vdc / 1A 24Vdc
- Supply voltage: 230Vac ±10%
- Supply frequency: 47 ÷ 63Hz
- Temperature range: operating: -10°C ÷ +50°C / storage: -25°C ÷ +85°C
- Voltage output: 13,8Vdc ±7% (12Vdc) / 27,6Vdc ±7% (24Vdc)
- Max charge current: 2A (12Vdc) / 1,2A (24Vdc)
- Mechanical data: dimension 90x70x60mm, weight 130g, IP20
- Other Specifics: Switching technology, PTC protection for polarity inversion, supply green led, charging curve limited in voltage and current
|
|
|
|
|
|
Designed primarily for marine applications, Xantrex XC Battery Chargers are versatile enough to be used in a wide variety of conditions and locations. Available in both 12 and 24 volt models, XC Chargers provide longer battery life by independently controlling each battery bank and eliminating the problem of under- or overcharging batteries.
Multi-bank chargers designed to provide the ultimate in battery care
Xantrex XC Battery Chargers are designed to provide longer battery life by independently controlling the charge profile for each battery bank. The XC is the first “smart” charger that can charge up to 3 different battery chemistries simultaneously. This unique multiplex design means that boaters can choose the optimal battery type for each application on their boat without concern about battery damage from either under- or overcharging.
Available in both 12 and 24 volt models, XC Chargers are unmatched for reliability. In addition to meeting global safety and emission standards, XC Chargers feature a unique drip-proof design and fuseless reverse polarity protection to ensure trouble-free charging.
Designed primarily for marine applications, XC Chargers are versatile enough to be used in a wide variety of conditions and locations. Auto-ranging AC input voltage capability (100-260VAC) makes travelling abroad and handling poor quality power a breeze. The easy-to-read digital display is invertable to accommodate either horizontal or vertical installations, and can be detached and mounted wherever needed. An optional intelligent shunt provides a simple “fuel gauge” capability
that displays amp-hours consumed from a selected battery bank.
|
|
BC10 IQv Series Battery Charger
Universal Battery Charger
IQv Series
The innovative IQv Series battery charger digitally communicates with every IQv Series lithium-ion or nickel cadmium battery, regardless of voltage, to identify its chemistry, voltage, and conditon - and then optimize the charging cycle. The unique Renew feature counters memory effect to extend the usable life of the battery.
|
|
Install Mastervolt battery chargers and rest assured that your on board batteries are always quickly and completely charged, even when you have limited supply or are moored in marinas with low shore power.
Mastervolt's three-step charging method guarantees optimum efficiency. Your batteries will perform better and last much longer.
|
|
RP1100C Series
100 Watts, Dual Stage Lead Acid Battery Charger, IEC320 3 Pin Input Connector, Screw Terminal Outpu
ED1048 Series 3 Stage Lead Acid Battery Charger, IEC320 3 Pin Input Connector, Flying Lead Output
|
|
Curtis switch-mode portable chargers allow for easy high-frequency charging of electric vehicle batteries at any outlet. Safely recover deeply discharged batteries and protect them from overcharging. Users can program the charger profile optimum for a specific battery. Microprocessor control and switch-mode operation allow for faster charging of all types of lead-acid batteries. Curtis chargers are lightweight and compact.
Model 1620
Portable. Switch-mode. Ideal for order pickers, walkies, pallet trucks, reach trucks, scrubbers, stackers, sweepers, and tugs.
- Model numbers:
1620FS-120/24/20-001
1620FS-230/24/20-001
- Cooling: Fan
- Sealing: IP 54 electronics, IP 54 fan
- Input Voltage:
120 VAC (1620FS-120/24/20-001)
230 VAC (1620FS-230/24/20-001)
- Output Voltage: 24 VDC
- Output Current: 20A, max.
- CE approved versions.
|
|
High Efficiency Means
Lower Operating Costs
Curtis switch-mode portable chargers allow for easy high-frequency charging of electric vehicle batteries at any outlet. Safely recover deeply discharged batteries and protect them from overcharging. Users can program the charger profile optimum for a specific battery. Microprocessor control and switch-mode operation allow for faster charging of all types of lead-acid batteries. Curtis chargers are lightweight and compact.
Model 1604FV
Portable. Switch-mode. For opportunity charging of micro-walkies and walkies/pallet trucks.
- Model number: 1604FV-AVS/24/08-001
- Cooling: Fan
- Sealing: IP 30 electronics, IP 30 fan
- Input Voltage: 105-264 VAC
- Output Voltage: 24 VDC
- Output Current: 8A, max.
- UL & CE approved versions.
|
|
On-board Battery Chargers for 24 V
These high frequency battery chargers use an efficient 3-stage charge curve designed to efficiently charge a vehicle battery whatever the status of its residual charge. For curve please click here.
Connected permanently to the battery and motor speed controller, the unit allows “opportunity” charging while the machine is not in use. Driving may be inhibited when vehicle is on charge using the integral relay in series with the vehicle key switch.
|
|
|
The new Lifetech series covers single phase and three phase chargers, 24 V to 80 V. It has been developed to meet the needs for a cost effective and efficient charger for standard applications with flooded and VRLA motive power batteries, type Hawker perfect plus and Hawker evolution. These multicapacity chargers offer key features in corporating the costsaving benefits of the HF technology. The design is optimised in terms of weight and size. The high value polymer ABS flame retardant enclosure reflects the innovative energy converting technology.
|
|
Hawker provides a wide range of advanced charging systems for all traction battery applications. All chargers are equipped with microprocessors to control the charging process. Tough powder paint coatings and electrolyte resistant membrane keypads are, of course, standard, as is full CE conformity.
LED displays provide an at-a-glance view of the state of charge.
|
|
Combis (Inverter/Charger)
The Dakar Combi, an all-in-one power centre, is the ideal inverter for use in the solar market. Its use in a system is displayed above. The Mastervolt Mass Combi is increasingly playing a leading role in carefully designed marine electrical systems, allowing owners to get the most value for their money.
A professional inverter and advanced battery charger in one compact device, the Mass Combi employs high-frequency technology for the most vital functions. Batteries are always charged to 100% and last longer, and the 230V power supply is perfectly reliable. You won't have to worry about the quality of shore power in any port - things will always work with the Mass Combi. The Dakar Combi comes in a compact package and is the ideal inverter for use in remote locations and for solar applications.
|
|
Perfect for battery maintenance and charging, the Sunboard semi-rigid solar battery charger can easily be mounted on garden house, chalet and caravan rooftops to maintain your 12 V battery system.
The Sunboard is lightweight and unbreakable (it does not contain glass) - it is therefore shock resistant and easy to handle and install.
The Sunboard range is available in 7, 14 and 27 Watt models
|
|
Perfect for battery maintenance and charging, the Sunslick flexible solar battery charger has been specifically designed for marine & yachting applications. The Sunslick can be mounted on curved surfaces such as hatch covers, boat decks and vehicle roofs, or it can be tied to sail covers, dinghies and canvas awnings.
The Flexcell modules will continue to produce electricity even in shadow and cloudy conditions which is especially useful in marine applications where sail shadow can be a problem.
The Sunslick is waterproof and lightweight.
The Sunslick range is available in 7, 14 and 27 Watt models..
|
|
|
The Sunpack is a lightweight solar charger which is compact and rollable. The Sunpack is your ideal companion for all outdoor activities such as, camping, trekking, mountain climbing, etc. All activities where mobility is key! It enables you to recharge your portable electronic devices such as, mobile & satellite phones, PDA's, GPS', MP3 players, and digital cameras. Easily transportable, it is also easy to use thanks to its universal cigarette lighter connector.
|
|
