The BEx explosion proof beacons and status lamps are available as 5, 10, 15 and 21 Joule Xenon beacons or as the revolutionary multi-function L.E.D version. All units are suitable for hazardous area Zones 1, 2, 21 & 22.
Features:
- All units are available in EEx d and EEx de versions
- ATEX, GOST-R, IECEx approved (Xenon version only)
- Dual M20 cable gland entries
- Large termination areas
- Ratchet adjustable mounting brackets
The BEx range also includes:
- 117dB(A) and 123dB(A) alarm sounders
- 15 & 25W loudspeakers (100V, 70V line & 16R, 8R)
- 'Appello' speech and tone voice annunciation models
- Audio-visual combination units (can be operated from a single power source or separately)
|
|
|
|
|
|
Hazardous areas often require the use of optical signals for warning or information purposes. The EExII strobe light dSLB21 offers both of these signalling features. It is designed for continuous operation. If the supply voltage is turned on, the Strobe Light dSLB21 is activated. The device is available in several versions with various levels of operating voltage and flash energy and various signalling colours. The stable, glass-fibre reinforced polyester (GRP) housing is made to the IP66 degree of protection and may be used indoors or outdoors. The II 2 G EEx de IIC T6 protection class enables the unlimited use of the signalling device in all hazardous areas, zones 1 and 2. The flameproof enclosure and the "increased safety" type of protection of the terminal room guarantee hazardous area protection. The upper part of the flameproof enclosure, which contains the flash electronic and the mounted flash tube, consists of a transparent Makrolon-cap. An inner cap lends colour to the light. The housing consists completely of GRP. Thus the device is protected against corrosion, and fulfills the requirements of contact safety class II. An equipotentiel bonding is not required. All outer fastening parts are manufactured
in noncorrosive materials.
|
|
|
|
|
|
|
Hazardous areas often require the use of optical signals for warning or information purposes. The EExII rotating beacon dSLD 21 offers both of these signalling features. It is designed for continuous operation. If the supply voltage is turned on, the rotating beacon dSLD 21 is activated.The device is available in several versions with various levels of operating voltage and and various signallingcolours. The stable, glass-fibre reinforced polyester (GRP) housing is made to the IP66 degree of protection and may be used indoors or outdoors. The II 2 G EEx de IIC T6 protection class enables the unlimited use of the signalling device in all hazardous areas, zones 1 and 2. The flameproof enclosure and the "increased safety" type of protection of the terminal room guarantee hazardous area protection. The upper part of the flameproof enclosure, which contains the electronic and the mounted halogen lamp, consists of a transparent Makroloncap. An inner cap lends colour to the light. The housing consists completely of GRP. Thus the device is protected against corrosion, and fulfills the requirements of contact safety class II. An equipotentiel bonding is not required. All outer fastening parts are manufactured in non corrosive materials.
|
|
The IS-mC1 combined alarm sounder & L.E.D. beacon has been designed for installation in intrinsically safe environments (Zone 0). The IS-mini range also includes stand alone intrinsically safe alarm sounders and L.E.D. beacons and is definitely the most effective method of signalling in Zone 0.
Features:
- Zone 0, 1 & 2
- EEx ia IIC T4 (Tamb.-40 to +60°C)
- Maximum 100dB(A) output
- 49 alarm tones, 3 alarm stages
- Array of 6 high intensity L.E.D's
- Sealed to IP65
- ATEX, FM, IECEx
|
|
IS-L101L L.E.D Beacon
► Zone 0, 1 & 2 Intrinsically safe
► Ex ia IIC T4 (Tamb.-40 to +60°C)
► Alarm accept function (with IS-A105N)
► Can be combined with the IS-A105N alarm
► Sealed to IP66
► ATEX, FM, IECEx
|
|
ActiveLine is designed to indicate various operating states of machines and systems. The possible signalling colours green, yellow, red, blue and white are all shown in one single light element. Each colour can be preset to continuous light, blink light or flash light. The light is generated by use of lightemitting diodes. The model with sounder can also generate a penetrating signalling tone, with four adjustable sound levels.
The plastic housing, the stable foot and the sounder housing are made of impact-resistant thermoplastic. The cap consists of im-pact-resistant polycarbonate, and the stand-tube is made of aluminium.
|
|
The PEW/PES dome shape LED signal light provides increased visibility and years of maintenance-free operation.
* Size: 82mm diameter.
* Available in 24V AC/DC, 100V AC and 200V AC versions.
* Dome is visible from top and sides.
* PEW-B type includes single-tone intermittent alarm with adjustable volume to 85dB at 1m.
* Colors available: red, amber, green and blue.
* Flashing function available in three different flash rates: 60 fpm, 120 fpm, 180 fpm.
* NPN open collector compatible.
* PEW: Meets IP54
PES: Meets IP23 (IP55 with optional rubber gasket SZ-210).
|
|
The NE series dome shape LED signal light provides increased visibility and years of maintenance-free operation.
* Size: 57mm diameter.
* Available in 24V DC (No polarity).
* Colors available in red, amber, green, blue and clear/white.
* Water and dust-tight IP65 construction.
* Dome is visible from top and sides.
* NPN/PNP open collector compatible.
* Terminal block allows easy wiring.
|
|
The RKE/RHE series LED revolving warning light provides increased visibility and long service life with high power LED.
* Size: 100mm diameter.
* Available in 12V DC, 24V DC, 100V AC and 200V AC versions.
* Colors available: red, amber, green and blue.
* RKEB/RHEB series has an integral alarm (high-pitch tone 90dB at 1m).
* No bulb replacement needed with long service life LED, perfect for "hard-to service" locations.
* Dome is made of heat and shock resistant polycarbonate resin.
* IP23 (IP55 with optional rubber gasket SZ-200A).
|
|
The RFV series is a combination of LED rotating beacon light and MP3 programmable sound unit
* Available in 24V DC, 100V AC and 220V AC
* Volume is adjustable from 0 to 95dB (at 1m)
* Colors available: red and amber
* Units are shipped completely pre-wired and pre-assembled
* Voice message or sound data is field-programmable with SD card (SD card
is sold separately)
* Total recording time of 64 seconds (64kbit/s) can be divided up to 4
channels by bit input or 15 channels by binary input
Available by Special Order
* PNP open collector transistor type
|
|
The Spectra range has been designed to offer a complete visual signalling solution for industrial, marine and general applications.
The High output LED multifunction beacon is available in two sizes and allows to choose from a total of 9 user selectable operation modes:
- 4 rotating configurations
- 4 flashing configurations
- Steady mode for status applications
E2S’s wide range of beacons also includes :
- Halogen rotating beacon
- 5J Xenon strobe beacon
- Synchronised Xenon strobe beacon
- Multi-flash-frequency Xenon strobe beacon
- Halogen flashing / status beacon
- Filament lamp flashing / status beacon.
- Different sizes and a range of accessories including wall brackets and pole mounts are available.
|
|
The KHE Series is a multi-feature LED beacon with three selectable light patterns for diverse use. The clear lens makes it easier to see the light in bright ambient conditions.
* Size: 100mm diameter.
* Available in 24V DC (no polarity)
* Dome is visible from top and sides.
* Colors available: red, amber, green and blue.
* Lighting patterns available: simulated rotation, strobing and flashing
* Super bright LEDs provide long service life, maintenance-free operation.
* IP23 (IP65 with SZ-200A optional rubber gasket)
|
|
|
|
|
|
|
Hazardous areas often require the use of optical signals for warning or information purposes. The EExII rotating beacon dSLD 21 offers both of these signalling features. It is designed for continuous operation. If the supply voltage is turned on, the rotating beacon dSLD 21 is activated.The device is available in several versions with various levels of operating voltage and and various signallingcolours. The stable, glass-fibre reinforced polyester (GRP) housing is made to the IP66 degree of protection and may be used indoors or outdoors. The II 2 G EEx de IIC T6 protection class enables the unlimited use of the signalling device in all hazardous areas, zones 1 and 2. The flameproof enclosure and the "increased safety" type of protection of the terminal room guarantee hazardous area protection. The upper part of the flameproof enclosure, which contains the electronic and the mounted halogen lamp, consists of a transparent Makroloncap. An inner cap lends colour to the light. The housing consists completely of GRP. Thus the device is protected against corrosion, and fulfills the requirements of contact safety class II. An equipotentiel bonding is not required. All outer fastening parts are manufactured in non corrosive materials.
|
|
|
|
|
|
New DA135 Intrinsically Safe LED Beacon from RTK Instruments
RTK Instruments has developed a new range of LED Beacons, which provide powerful visual alarm signals in both hazardous and safe areas. The DA135 is ATEX certified for use in Zone 0, 1 or 2 hazardous areas and is available in five super-bright colours. The ruggedised and encapsulated enclosure makes this an ideal choice for the harsh environments found offshore and in the chemical and petrochemical industry.
The standard unit has a unique method of allowing the user to change the flash rate between single, double or triple flash by triggering control inputs. Customers can then use the same unit to indicate different site problems. A dual colour version is also available where each colour can be triggered separately from the control inputs
The DA135 can be operated alone or in conjunction with an intrinsically safe Sounder and Pushbutton to create a fully featured single point Alarm Annunciator.
RTK Instruments is a leading supplier of safe and hazardous area alarm, display and interface products and can provide specific application advice, as well as product recommendations and installation assistance.
|
|
|
|
|
|
New DA135 Intrinsically Safe LED Beacon from RTK Instruments
RTK Instruments has developed a new range of LED Beacons, which provide powerful visual alarm signals in both hazardous and safe areas. The DA135 is ATEX certified for use in Zone 0, 1 or 2 hazardous areas and is available in five super-bright colours. The ruggedised and encapsulated enclosure makes this an ideal choice for the harsh environments found offshore and in the chemical and petrochemical industry.
The standard unit has a unique method of allowing the user to change the flash rate between single, double or triple flash by triggering control inputs. Customers can then use the same unit to indicate different site problems. A dual colour version is also available where each colour can be triggered separately from the control inputs
The DA135 can be operated alone or in conjunction with an intrinsically safe Sounder and Pushbutton to create a fully featured single point Alarm Annunciator.
RTK Instruments is a leading supplier of safe and hazardous area alarm, display and interface products and can provide specific application advice, as well as product recommendations and installation assistance.
|
|
Federal Signal Model 371 incandescent warning lights have a powerful sealed beam lamp that rotates 360º within a glass or polycarbonate dome. Power is delivered to the Commander's rotating lamp by a unique collector ring. The lamp itself is mounted in a pivoting yoke. This allows the lamp beam angle to be adjusted through 90 degrees from horizontal to vertical. Changing the beam angle allows the user to create unique light patterns and/or direct the light for better visibility.
- Available in 120VAC
- Five dome colors
- Pivoting lamp yoke
- Surface mount and integrated 1- inch pipe mount
- Type 4X, IP66 enclosure
- UL and cUL Listed, CSA Certified
|
|
|
APS Resource is a recognized leader in providing lasting and economical solutions to safeguard loading dock personnel and warehouses against accidents and damage from poor lighting or poor communication between truck driver and dock workers. APS offers dock lights in many sizes and variations to meet your needs. Our line of safety products has been developed to solve multiple safety concerns at your facility.
|
|
Lightings
Explosion-Proof fluorescent luminaires EEx d IIC.
Explosion-Proof floodlights EE x de IIB.
Explosion-Proof lighting fixture Ex d IIC.
Explosion proof Indicating lights; incandescent lights, rotating lights, flashing lights.
Explosion proof traffic lights EEx d IIC.
|
|
|
|
|
|
Excellent light intensity and high life duration
The new 782 Ex LED beacons stand out from the competition with their modern design and extraordinary brightness. The fluted dome generates an optimal light dispersion. The LEDs in the colour of the dome produce an extremely colour-intense light effect.
Thanks to their low current consumption, these beacons also generate savings in operating costs for users. Due to the innovative LED technology, the beacon has an extremely long life duration of up to 50,000 hours and is maintenance-free. Screwing open the housing to replace the light source is now a thing of the past.
Best temperature class thanks to LEDs
Even in continuous operation the beacons keep a cool head. The cool surface offers even the most ignitable of gases and dusts no reason to explode: With T6 or T 80°C, the device complies with the requirements of the highest temperature classes in Ex areas.
Permanent or rotating light
In addition to the light intensive permanent light variant, a wear-free 782 Ex LED revolving beacon is also available. The rotating beacon is wear-free thanks to the absence of any moving components. Instead, the LEDs are triggered in sequence, generating a strikingly intense signal with a rotating light effect.
Wide range of applications
The new 782 Ex beacons from WERMA can provide signalling in gas or dust explosion hazardous areas. With just one device, the user can cover the zones 1 and 2 as well as 21 and 22.
The robust aluminium and glass housing has a diameter of 195 millimetres and a height of 305 mm. It has a flame-proof enclosure “d” and is equipped with an “e” connection area, making it easy to connect.
|
|
Flashguard LED Beacons
Flashguard weatherproof xenon beacons are ideal visual indicators in a variety of applications.
- Compact, ultra modern sleek appearance
- Long life LED design
- Ease of installation with first-fix option on standard models
- Weatherproof to IP67
- White, high quality polycarbonate housing
- Vandal-resistant safety locking mechanism
- Flashing or static indicators
Overview
Flashguard weatherproof LED beacons are ideal visual indicators in a variety of applications.
All Flashguard LED beacons are low current and have an exceptionally long life compared to traditional types of beacon. They also have a a diffuser for greater visibility and spread of light.
|
|
* Bracket, ceiling, pendant or stanchion mount
* High impact glass dome, dome guard included
* 40W halogen bulb or 25W incandescent bulb
* 75 rotations per minute
* Factory sealed - no external seals required
* Quick connect - threads onto mounting module for easy installation
* Shock absorbing receptacle
* Easy to assemble & relamp
* Gaskets seal out dirt & moisture
* Epoxy powder coat for corrosion resistance
|
|
Blinkers
P123022 - PRL
Protective gauge for LAMPO series blinkers.
D123013 - SLM2
Blinker support for wall applications.
D113696 00003 - LAMP NET
Lamp Net blinker with extractable self-learning FAST-NET receiver for MITTO series rolling code transmitters.
D113686 00001 - LAMPO
AI 24V
Blinker powered at 24Vac/dc with integrated antenna. 4 m antenna cable. Only for receivers operating at a frequency of 433.92Mhz.
D113685 00001 - LAMPO AI 230V
Blinker powered at 230Vac with integrated antenna. 4 m antenna cable. Only for receivers operating at a frequency of 433.92Mhz.
D113719 00003 - RAY X 24V
Blinker powered at24Vac with integrated antenna.
D113719 00002 - RAY X 230V
Blinker powered at 230Vac with integrated antenna.
D113721 00002 - RAY X SA 12V
Blinker powered at12Vac without integrated antenna.
P123023 - RWS
Ray blinker support for wall applications.
D113721 00003 - RAY X SA 24V
Blinker powered at24Vac without integrated antenna.
|
|
* NEMA Type 4X Enclosure
* Panel or conduit mounting
* 18 inch wire leads
The Edwards 104FIN Series AdaptaBeacon flashing halogen lights and 104FLED Series AdaptaBeacon flashing LED lights are designed to provide a bright visual indication utilizing special optics within a shatter resistant polycarbonate lens mounted on a polycarbonate/ABS blend base.
|
|
Sonos Sounder Beacon (DC)
A general purpose electronic sounder for fire, security and industrial applications; the Sonos Sounder Beacon is certified to EN54.
- Simple 'First Fix' installation (no second fix wiring)
- Smooth flow cabling for faster installation
- Quick connect/disconnect
- No locking screw required
- Tone and volume can be preset or adjusted off-base
- Weatherproof to IP65 (deep base units)
- Choice of lens colours
- Low current LED beacon as standard (xenon beacon available on request)
- Sounder and beacon can be controlled separately
|
|
|
|
|
|
Werma has a vast range of LED beacons with different light signals e.g. permanent light, blinking light and flashing light. Furthermore there is a wide choice of sizes, colours, voltages and fixings available e.g. base mounting, tube mounting and bracket mounting.
This year (2009) a groundbreaking innovation in LED technology has opened up a completely new dimension in optical signalling. Enhanced Visibility System,or the electronic improvement of visibility, EVS for short, is the name WERMA has given to this latest development which promises to bring about a revolution in signalling technology. WERMA employs light emitting diodes for the EVS system. A microprocessor generates random light signals. This gives the light a very "agitated" character which proves highly effective in drawing attention.
Countless uses can be found in the industrial sector, public areas or warehouses.
The LED rotating beacon provides an intensive rotating signalling effect. These LED rotating beacons can provide extremely high light intensity up to 70 cd with low power consumption and high vibration resistance.
|
|
NFS - 90 mm
# 90mm LED strobe/double strobe beacon
# very good brightness - highest optical efficiency
# specially designed and optimized lens/optics
# up to date LED-technology
# absolutely shock and vibration proof, maintenance free
# long life time approx. 50.000h
# low nominal current
# inrush current limitation, EMC safe, leakage up to 3mA possible
# modular design - mounting options horizontal, vertical and pole
|
|
IBL-IBM-IBS
# IBL-IBM-IBS LED-steady-/flashing beacon
# versatile usable panel mount beacon series
# 3 sizes 65 - 45 - 30 mm diameter
# selection of stead-/flashing function via terminal
# maintenance free - long lifetime
# PLC fit (leakage/inrush current)
# particular lens pattern for optimum light dispersion
# adapter for 30,5 mm bore holes
|
|
Beacons
A range of high-efficiency xenon visual warning lights 12 to 72 V and 12 to 80 V, 2 W and 5 W. Curtis safety beacons are designed for applications ranging from pallet trucks; construction and airport equipment; agricultural equipment; and forklift trucks - internal combustion or electric powered.
|
|
|
|
|
|
Award-winning: The Rotating Mirror Beacon 885 from WERMA
Following last year’s „red dot design award“, 2006 has seen WERMA re-ceiving another highly acclaimed international design prize: the new Ro-tating Mirror Beacon 885 has been awarded the „iF product design award 2006“.
iF design award – synonymous with current design trends
Since its establishment in 1953 the „iF design award“ has been a consis-tent, renowned hallmark for “excellent” design. The iF label is a clear in-dicator to product buyers that the goods in question are sophisticated and of a high quality, having passed the equivalent of a “Design Exami-nation”.
The winning product: the Rotating Mirror Beacon 885
The award winning Rotating Mirror Beacon 885 is an ideal addition to the existing WERMA product range. It stands out with its clear, no frills design and a new size. When in operation the new rotating mirror beacon gen-erates an extremely high signal effect due to the internal rotating mirror . For the observer the impression is almost that of a flash of light.
During the development of the Rotating Mirror Beacon great emphasis was placed on a stately design that was nevertheless both industry-compatible and functional. WERMA consciously designed the done to enable a clear view of the fascinating technology in its interior - thus cre-ating a successful interplay of appealing design and innovative technol-ogy.
The beacon also impresses with its long lifetime, guaranteed by the low wear wheel and disc drive.
|
|
Industrial Xenon Beacon (10J)
Flashguard industrial xenon beacons are available with a choice of voltages and colours.
Weatherproof to IP65, they are ideal for almost any industrial application.
- Choice of red, amber, blue, green and clear lens
- Weatherproof to IP65
- Choice of voltages
- Range of accessories available
Overview
Flashguard industrial xenon beacons are available with a choice of voltages and colours. Weatherproof to IP65, they are ideal for almost any industrial application.
Xenon beacons are available in either 10J or 24J units and are designed for surface mounting.
The 10J unit is a high intensity beacon with Fresnel lens which produces a penetrating light in the most adverse conditions. Suitable for larger areas, it can be selected for single or double flash.
A range of accessories is available including a protective cage guard and a wall bracket.
|
|
|
|
