Characteristics of CNC pipe bender:
-Multi-servo axis numerical controlled.
-Input data of Y. B. C or according to Descartes X. Y. Z. coordinate can build bending parameter. According to the input data or built parameter the profile of tube will show on the computer.
-Automatic bending rebound numerical compensation according to accurate measured data. Modify the bending rebound compensation data or compensate manually If the bend is different with what you expect.
-Storage capability: 100 bends for each workpiece. 1000 workpieces'data could be memorized.
-Adopt WINDOWS XP Embed operation system.
-Program transmit: (1) Flash Disc (2) Internet (3) Floppy Disc.
-The heavy-duty series CNC pipe bender(Max.Φ325x25) is the most suitable equipment to bend tube for shipyard.
|
|
Features of Profile bending machine:
-Process by mechanical transmission with compact structure and with high reliability.
-It's not easily to skid for three rollers driving and it also can roll thin material.
-It can feed from both sides.
-Two petals and a emergency stop make it to be easy and safy to operate.
-This machine drives stably, which adopts three-roller combined mould, and can bend for different curvature, arc and spire.
-It can process different profiles like angle iron, flat iron, round pipe and other unregular section profile.
-It can bend profiles in large radius but no need large size molds, which covered the shortage of one-end or two-end tube bender.
|
|
V2000 Cambering Machine
The V2000 is a horizontal cambering machine developed for cambering steel profiles. The reaction beam of the cambering machine is provided with two adjustable reaction points. Two motor-driven transport rolls carry the profiles in the machine.
The cambering machine is available in three different sizes, an overview of each machine with their specifications are displayed in the table below.
|
|
|
|
|
|
SB-Oil Tube Master
The Brake Line Tube Benders
The SOCO SB-Oil Tube master is a dedicated CNC Brake Line tube bender ( Pipe Bending Machines ), designed for small tubing, especially Bundy Tubes and hydraulic lines. With multiple electric axes and a unique design to allow bending the most complex shapes and parts, it offers the most advanced solution and pipe bending performance in its range.
Automation
• 3 Electric Axis controlling pipe bending, tube rotation and carriage movement
• Automatic tube bending head reversal (left-to-right) when reaching central clamping area, providing a fully automatic cycle for the entire bending process
• Optional Automatic Loading and Unloading Interface
Performance
• Centralized clamping and rotation system for true simultaneous moving of all axis
• Lowest cycle times because minimal number of moving parts
• Suitable for brake line tubing up to 4000 mm ( Optional 5000 mm )
• Unparalleled Speed:
- seconds for … bends (low number of bends)
- seconds for … bends (high number of bends)
Maximum Tube Bending Working Area = Minimal Interference:
· No interference with machine bed
· No conventional tube bending arm
· No pressure die and wiper die seat interferences
· Central clamping and rotation away from bending zone
· Overmode (Arm Return Mode) capabilities
Keywords
Pipe Benders,Tube Benders,Tube Bending,tubing bender,bending pipe,Pipe Bending,Bending pipe Machine,Tube Bending Machine,Pipe Bending Machine,tube cutting,metal saw,Circular Saw,Sawing Machine,tube cutter,pipe cutting,pipe cutter,circular sawing machines,Saw blades,chamfering machine,deburring machine
|
|
Characteristics of PLC pipe bender:
-Controlled through switches and PLC, with manual, semi-automatic and full-automatic functions work mode.
-It can be set in 2 different angles meanwhile, to bend by turns automatically.
-With counter function, it can count the quantity of bended workpiece exactly.
-It adopt oil pressure valve accumulative body loop can control actions individually to prolong the lifespan of oil pressure parts.
-Tri-step loop possesses cooling and deposit functions which can avoid the deteriorate oil.
-Optional function of core entering and lubricating automatically.
-Optional function of core reversing slowly.
-Optional function of slow bending.
|
|
|
|
|
|
SOCO 6 Electric Servo Controlled Axis Pipe Bender
Draw bending + Roll bending + 1D bending in 1 Tube Benders
The MRV series CNC tube benders equipped with multi-tooling can up to 6 tooling levels. Designed for pipe bending complex parts with 0 straight clamping lengths, as well both small and large pipe bending radiuses, it satisfies even the most demanding applications for the automotive, furniture, healthcare, among other industries.
The MRV series pipe tube bender offers small radius bending + Roll bending + 1D Bending in the same pipe bending machine.
SB-38X6A-MRV
CNC pipe tube benders with capacity up to O.D.38.1mm. Equipped with 6 electric servos, with up to 6 stacks of tooling with Draw bending + Roll bending + 1D tube bending Pipe benders.
Keywords
Pipe Benders,Tube Benders,Tube Bending,tubing bender,bending pipe,Pipe Bending,Bending pipe Machine,Tube Bending Machine,Pipe Bending Machine,tube cutting,metal saw,Circular Saw,Sawing Machine,tube cutter,pipe cutting,pipe cutter,circular sawing machines,Saw blades,chamfering machine,deburring machine
|
|
|
|
|
|
2 ROLLS BENDING MACHINE
This series consists of one model only, the CE2 with two driving rolls with a knurled surface. The machine structure is manufactured in stabilised steel, and the shafts are constructed from thermally treated NiCr steel fitted with ball-bearings to protect mechanical parts from wear, thus ensuring their long lifespan. .
The CE2 is fitted with a helical geared speed reducer, lubricated in oil-bath and is operated via the double pedal board to change the direction of rotation of the rolls.
This bending machine allows the bending not only of section bars, bars and tubes of different dimensions and materials, but also the curling of metal straps and the twisting of square iron up to 8 mm in thickness.
TYPE OF SIMASV BENDING MACHINES
2 DRIVING ROLLS
CE2 - This series consists of one model only, the CE2 with two driving rolls with a knurled surface.
CE2/R - This bending machine is a version of CE2 model which is also produced with tilting rolls bench for processing both horizontally and vertically.
The machine can be equipped with a set of nylon rolls.
3 DRIVING ROLLS
CHV.3360 - Consisting of a solid structure in stabilised steel, the CHV.3360 visualised bending machine is fitted.
CHV.3380 - Consisting of a solid structure in stabilised steel, the CHV.3380 visualised bending machine is fitted.
CHV.4100 - La curvatrice a tre rulli trascinatori CHV.4100 è costituita da una solida struttura in acciaio.
|
|
Press Brake (CNC Folder)
The machine tool adopts welded steel plate construction. Eliminate internal stress by heat treatment, assuring high strength, good rigidity, small deformation, easy operation and high endurance.
The machine with hydraulic driving system can run stably and repair easily. The upper die is sectional type that can combine to the different length willfully, suitable for the plate and case part’s manufacture. The working angle can be adjusted rapidly.
The machine is widely used by manufacturers for forming electrical and electronic switch boxes, which is also used in cooking utensil, furniture, and all kinds of work-pieces, decorative industry and all shops of other industries.
PLEASE WRITE ALL ENQUIRIES ONLY IN ENGLISH!
|
|
|
|
|
|
Characteristics of TNC pipe bender:
-Controlled through PLC and touch control screen and possesses manual, semi-automatic and full-automatic mode.
-All programs can be operated through dialogue mode touching control screen.
-All information is displayed by English and Chinese with simple operation.
-Can set in many different angles to bending by turns.
-Possess automatic error detection function and limit protecting function.
-Guiding module has auxiliary pushing function and at the same time it possesses reiteration and entering repeat functions that can make the guiding module length shorten.
-Counter function can accurately count workpieces quantity.
-Adoption of oil pressure valve accumulative body loop can control actions individually to prolong the lifespan of oil pressure parts.
-Tri-step loop possesses cooling and deposit functions which can avoid the deteriorate oil.
-Optional function of core entering and lubricating automatically.
-Optional function of core reversing slowly.
-Optional function of slow bending.
|
|
|
|
|
|
NC series
NC Control Pipe Bender with Hydraulic Rotary Bending
Cost Effective and easy to bending pipe
The NC Series Tube Benders
The NC series tube benders equipped with NC control unit with Touch Screen Interface. It combines easy-to-use operation with high pipe bending accuracy and cost effectiveness. It is the practical semi-automatic tube bending solution for small to medium productions.
SB-80NC
NC controlled tube bender, with Touch Screen and capacity up to Ø88.9mm. Hydraulic Draw bending pipe bending machine
NC tube and profile bending machine features:
· NC control unit with Touch Screen
· Easy operation interface and enable easy data input
· Large program capacity storage
· High pipe bending accuracy up to +/- 0.15°
· Self diagnosis & error messages on-screen display
· Hydraulic clamping with optional pressure die assist
· Suitable for various materials such as steel, stainless, aluminum and copper
Keywords
Pipe Benders,Tube Benders,Tube Bending,tubing bender,bending pipe,Pipe Bending,Bending pipe Machine,Tube Bending Machine,Pipe Bending Machine,tube cutting,metal saw,Circular Saw,Sawing Machine,tube cutter,pipe cutting,pipe cutter,circular sawing machines,Saw blades,chamfering machine,deburring machine
(Pipe Benders - Tube Benders - Tube Bending - Pipe Bending - Bending Machine - Tube Bending Machine - Pipe Bending Machine - Circular Saw - Sawing Machine - Cutting Machine - Deburring - Tube End Finishing, Bender Tube, bender Pipe, Cutting, Chamfering Machines, Deburring Machines, CNC Tube and Bar Machining Center, HSS saw Blade )
|
|
COIL BENDING MACHINE :
The coil bending machine is suitable for bending single row and double row coils. Different bend radii can be achieved in this machine. The bend former has to be changed as per the radius required.
Features :
- PLC controlled & hydraulically operated machine
- Manual loading & unloading of coils.
- End stoppers are provided to control the length of the bend
- Aesthetically designed, sturdy and rugged construction.
|
|
|
|
|
|
TB series
Extreme Speed Double Head Tube Bender
Cost effective and high speed tube bending
The TB Series Tube Benders
Chosen for its unparalleled productivity, the TB series pipe bending machine of compression tube benders is able to make 2 bends X Multiple tubes simultaneously.
Here are some of the advantages of this Globally Patented design:
- Standard with 90° head rotation for 3D tube bending
- Stationary clamps to maintain the tube in position before pipe bending
- Arc movement of bending heads results in the highest production rates available for any tube bending machine
- Lowest setup times with quick change tooling design and re adout for length and angle settings
- Production speed: 3.8 seconds - 25.4 mm X 2t X 90°, 2 tubes at one time
TB-38
2 X 90° Rotation bending heads, with bending angles up to 110°.
This pipe bending machine's capacity up to Ø 38.1mm
Keywords
Pipe Benders,Tube Benders,Tube Bending,tubing bender,bending pipe,Pipe Bending,Bending pipe Machine,Tube Bending Machine,Pipe Bending Machine,tube cutting,metal saw,Circular Saw,Sawing Machine,tube cutter,pipe cutting,pipe cutter,circular sawing machines,Saw blades,chamfering machine,deburring machine
(Pipe Benders - Tube Benders - Tube Bending - Pipe Bending - Bending Machine - Tube Bending Machine - Pipe Bending Machine - Circular Saw - Sawing Machine - Cutting Machine - Deburring - Tube End Finishing, Bender Tube, bender Pipe, Cutting, Chamfering Machines, Deburring Machines, CNC Tube and Bar Machining Center, HSS saw Blade )
|
|
|
|
|
|
5B – The Powerful Pipe Bending Machines
CNC Proportional Servo Tube Bending
5 controlled axes with max. Ø127mm capacity pipe bender
With models that extend up to Ø127 mm capacity, the SOCO CNC 5B series tube bender ( Pipe Benders ) brings the optimal tube bending power and accuracy solutions for the automotive, trucking, buses, boiler, ship building and other heavy industries.
SB - 130 x 5B - 1S
CNC tube bender with capacity up to Ø127mm. Equipped with 5 individually programmable axes and 1 stack of tooling
5 servo electric / proportional servo controlled axes pipe bending machine
+ Feeding ( Y )
+ Planning ( B )
+ Tube Bending ( C )
+ Horizontal Movement ( X1 and X2 )
+ Pressure Die Assist ( V1 )
Keywords
Pipe Benders,Tube Benders,Tube Bending,tubing bender,bending pipe,Pipe Bending,Bending pipe Machine,Tube Bending Machine,Pipe Bending Machine,tube cutting,metal saw,Circular Saw,Sawing Machine,tube cutter,pipe cutting,pipe cutter,circular sawing machines,Saw blades,chamfering machine,deburring machine
(Pipe Benders - Tube Benders - Tube Bending - Pipe Bending - Bending Machine - Tube Bending Machines - Pipe Bending Machines - Circular Saw - Sawing Machines - Cutting Machines - Deburring - Tube End Finishing, Bender Tube, bender Pipe, Cutting, Chamfering Machines, Deburring Machines, CNC Tube and Bar Machining Center, HSS saw Blades )
|
|
|
|
|
|
SOCO V Series Pipe Benders ( Tube Bending machines )
Draw + Roll + 1D Tube Bending in 1 tube bender
The SOCO V series CNC tube benders combine Draw bending, Roll bending and 1D pipe bending technology. This combination allows 2 different fixed radiuses and multiple large roll bending radiuses in a single part, as well as a programmable carriage boost for CLR = 1D Bending.
This pipe bender coupled with Individual Pressure Die Systems assist in each draw bending stack, this tube bending machine brings superior pipe bending performance and flexibility.
Pipe Bending Machine Features
• Tube bending with SOCO’s unique DGT technology
• Rack pinion feeding
• SOCO Proprietary pipe bending operation software
• Multi-stacks for Draw and Roll (Large Radius) bending
• Programmable Boosting Force for 1D pipe Bending (*)
• Ability to bend parts with “0” straight lengths
• Programmable arc lengths for large radiuses
• Roll Bending Springback compensation settings
• Special bending compensation and data storage fields
• Low noise level with highest transmission performance
(*) in accordance to material’s elongation ratio
Draw + Roll +1D Bending
The technology can create a part which has multiple draw bending radiuses (R1 & R2 ), while creating a larger radiuses through the roll bending process. Coupled with a settable carriage booster, it allows pipe bending radiuses as small as 1 X OD.
Tags:
Pipe Benders,Tube Benders,Tube Bending,tubing bender,bending pipe,Pipe Bending,Bending pipe Machine,Tube Bending Machine,Pipe Bending Machine,tube cutting,metal saw,Circular Saw,Sawing Machine,tube cutter,pipe cutting,pipe cutter,circular sawing machines
|
|
The MC 400 is manufactured from mechanised and welded steel plate.
- Three polished rollers ensure that the profile is kept undamaged.
- Rectified and moderated steel axles.
- Bending regulation independent of the lower rollers
- Measuring belts with scale marked in millimetres to control the positioning of the rollers.
- Horizontal or vertical working position, [depending on the bench].
|
|
Model-51
Universal pneumatic
bending machine
Orient
Mandrel and without mandrel
bending of tubes and profiles. High quality bends in 3 axes
by winding method
Ability
3 axes control (A;L;R)
Tube profile changing control in bending place
|
|
|
|
|
|
CNC Tube Bender with in-built automatic loading and unloading facility
CNC Tube Bender
The Dynamo cnc bender is a highly innovative, fast cycling, 5-Axis CNC tube bending machine, for tubes up to O.D.25 mm, incorporating a fully automatic loading and unloading system, allowing the bending machine to run for long periods without supervision.
Particularityof the Dynam0 cnc bender:
* left or right hand bending sense configuration
* up to four stacks tooling enables the bending of complex components, with different radi
* automatic loading of the new tube takes place whilst the bent part is being unloaded, minimising 'dead' time during the cycle to maximise productivity
* in-built loading/unloading
* very cost effective
VGP 3D - Highly innovative 3D Graphic Programming Software dramatically reducing dependence on operator intervention for:
* real time bend simulation automatically selecting the shortest and most efficient bending cycle to minimise cycle time and reduce cost
* component simulation and feasibility check highlighting any possible collisions
* immediate creation and execution of the machine program with twin data input
|
|
Master
Modular bending machines with different automation levels for mandrel and without mandrel bending by coiling method
Orient:
Mandrel and without mandrel bending of tube and profiles.
High quality bends in 3 axes by coiling method
Abilities
- 3 axes control (A;L;R)
- Tube profile changing control in bending place
Design
- Bending machines Master was developed on replaceable modules base, which allows to complete machines for customer requirements with different characteristics and automation levels
- Machines design allows to change or add modules. Machine can change characteristics and raise automation level
|
|
We have introduced a full range of sheet and profile roll-bending machines. This decision is based on our 'one-source supplier policy' and the many years of experience in building sheet metal machinery.
Three and Four Sheet Roll-Bending Machines
Our selection of sheet roll bending machines includes models with either three or four rolls for sheet lengths from 2,100 mm up to 4,100 mm and thicknesses up to and including 110 mm!
The use of planetary gearboxes and hydraulic motors results in almost maintenance-free equipment with an optimum quality/price ratio.
Range :
-3 rolls type 3HBR
-4 rolls type 4HBR
Universal Profile Roll-bending Machines
We offer affordable, high quality standard Profile Bending Machines that use the same technology as our sheet roll machines. Standard modular tooling can be configured to roll most standard sections.
|
|
TECHNICAL SPECIFICATIONS
- two driven rollers, knurled surface
- manual adjusting of the center roller
- working position horizontal an vertical (optional)
- complete with standard roller set and foot pedal
|
|
Model RE-60
Bending machine RE-60
Orient
- Mobile inch pupe bending works at maintenance
and assembling of plumbing
Abilities
- Control board with Russian interface
- Bending angle and zero position
programmed by microprocessor
- Have pullout handles and wheels for
hand moving, and have rims for
moving by lifting mechanisms
- Bending angle 0-210 with account
of spring back angle
|
|
Fully electric CNC tube bending machine for tubes with OD 80 mm, 9 axis with 3D visual graphic programming (VGP3D),
FEATURES:
* multiradii (up to 8 tools)
* bend head with left or right hand bending sense configuration
* all the critical machine setting parameters set and managed by the CNC control
* Fixed, variable radius and boost bend up to 5000kg
* High reliability and high productivity
* Use of existing tools - low running costs
* Real time bend simulation automatically selecting the shortest and most efficient bending cycle to minimize cycle time and reduce cost,
* Any possible collision points are highlighted and the most practical avoidance routes effected.
* Axis position is read by absolute encoder eliminating all conventional sensors, increasing reliability, performance and reducing maintenance cost
|
|
Simasv's bending machines are extremely heavy-duty and easily adaptable to any working requirement. All models are supplied with speed reducers, adjustable torque limiters and can be positioned both in a vertical or horizontal axis.
They are available in the models with three smooth driving rools and two knurled driving rolls, all equipped with a wide range of standard rolls to bend different types of profiles, bars, tubes, etc...
|
|
4 rolls special machine for guard-rails (2 or 3 waves) suitable for bending either leg-in or leg-out.
|
|
Model-52
Manual stationary bending machine
Orient
Mandrel and without mandrel
bending of tubes and profiles by winding method.
Abilities
- Tube profile changing control in bending place
- 2 axes control (A;L;)
- Bending of M- type parts
- Absense of clash between machine
and tube during complex bending
- Individual tool specification
|
|
|
Pyramidal profiles bending machines, three driver rolls
|
|
|
|
|
|
Series RCMI "double pinch" angle rolls are expressly designed for rolling profiles with high resistance to the bending. This is the reason why the structures are heavily dimensioned and are built with heavy thickness plates of certified quality steel.
They are Electro-welded and heat treated to release the internal stresses. The solidity of the structure is in fact an essential parameter to guarantee reliability and precision trough the years.
The RCMI series angle rolls superior quality is also guaranteed by a complete series of accessories supplied as standard equipment.
For more versatility in rolling aluminium profiles or for super-heavy rolling requirements up to section modulus of 17.000 cubic centimetre (1.000 cubic inches), Faccin offers the TAURUS series of variable geometry profile benders in which the distance between the bending roll is set according to the optimal bending geometry to minimise the distortion of the profile cross-section and the waste of material to be cut at the two edges.
Rotating Table Benders and Flange Rollers complete the wide range of machine designed for optimum rolling quality and maximum productivity.
|
|
|
Positioned with vertical axes.
|
|
Model-55
Three-roller bending machine
Orient
Making of rings, arcs, spirals with specified coils step lifting of tubes and profiles by 3-roller bending method.
Abilities
- 3 rollers drive
- Control of theoretical bending
radius
- Spiral step lifting control
- Work in vertical and horizontal
position
|
|
BENDING: 6 > 42x4 mm
MATERIALS: AISI 316 TI - ST 37.4
DIMENSIONS L x D x H: 680 x 880 x 910 mm
WEIGHT: 100 KG
STANDARD VOLTAGE: 400V 50Hz 3PH
MOTOR POWER: 1.1 KW
CONTROL BOARD: included
ELECTRICAL LIMIT SWITCH: included
OIL: included
|
|
|
|
