SIPA integrated systems, the ECS range, starts from the raw material, the resin, and takes the process through to the finished container without any interruption, with total automated control of all phases of production. SIPA ECS integrated system is the fastest single-stage platform available, with output up to 600 bpm. The range consist of 13 models and all ECS models are available in “Flex” version. The “Flex” version allows the machine to produce also large-capacity containers (up to 30 liters) or with large neck finish (up to 135 mm and over) by reducing the machine’s cavitations.
|
|
There is also a SUPER FLEXIBLE version of the EA2S
with a stretch unit prepared for blowing 5, 10 and 30 litre
sizes with 5-3-2 cavities respectively, just by replacing
the mold and recalling the relevant software configuration
on the video screen.
|
|
DKM-B85 PC Blow Moulding Machine
Special for 5-gal PC Bottle
* Professional
* Stable
* Practical
* Convenient
* Profitable
Technical Specification
* Air Unit: Minimun Air Pressure Requirement: 6-10 bars. Air Consumption:0.4m3/min.
* Control System: B&R control system: 100points wall thickness controller, 6'' color display.
* Water Unit: Minimum Water Pressure Requirement: 2-3 bars. Cooling water Consumption: 6m3/hr
* Machine Dimensions: 4985mm(L)*1465mm(W)*2765mm(H)
* Machine Weight: 6tons (without hydraulic oil and mould)
|
|
SFL Linear Blowmolders
The range consists of 3 basic platforms: SFL 2, SFL 4 and SFL 6: Platform SFL 6, with a production of up to 1500 b/h/c, is available in 3 configurations: SFL 6/6 (6 blow cavities) for the production of containers up to 3 litres; SFL 6/4L (4 blow cavities) for containers up to 8 litres and SFL 6/3L (3 blow cavities) for containers up to 10 litres. Platform SFL 4, with a maximum production of 1800 b/h/c, is available in 3 configurations: SFL 4/4 for containers up to 3 litres; SFL 4/3L for containers up to 5 litres; SFL 4/2 for containers up to 12 litres. SFL 2 is a platform conceived for big size containers, from 25 to 30 liters.
|
|
SFR Rotary Blowmolders
Seven models are today available. The number after the acronym indicates the number of blowing cavities. The model SFR 9/27 is equipped with 9 stations able to carry either 9 standard shell molds or 9 triple-cavity molds for a total of 27 blowing cavities. The model SFR 16/32 is equipped with 16 stations carrying twin cavities for a total of 32 cavities.
|
|
There is also a SUPER FLEXIBLE version of the EA2S
with a stretch unit prepared for blowing 5, 10 and 30 litre
sizes with 5-3-2 cavities respectively, just by replacing
the mold and recalling the relevant software configuration
on the video screen.
SIAPI offers a 360° solution including:
• container design development
• preform design development
• identification of preform manufacturer nearest to
customer’s production facilities
• complete solution development for both cold
and hot filling
• manufacture of blow-molding machine and set-up
to optimize production capacity
• design and construction of blower molds
• routine and extraordinary maintenance and provision
of spare parts
• provision of injection molds and production of
sample preforms by qualified partners
|
|
SIAPI has strengthened its competitive edge also due to containers and bottles dedicated to the beverage trade, achieving productivity of up to 24,000 bph.
In collaboration with the customer and our international partners, we develop solutions for:
WATER / CSD / FRUIT JUICE / TEA-BASED DRINKS / ISOTONIC AND VITAMIN DRINKS / DAIRY PRODUCTS WITH SHORT SHELF-LIFE / OIL / BEER / WINE / FOOD / PET FOOD / MEDICINES / CHEMICAL PRODUCTS / DETERGENTS / COSMETICS / OTHERS
SIAPI's linear technology meets the most complex needs but involves reduced investments, lower than those required for rotary machines, while providing maximum reliability and improved process flexibility.
|
|
system specifications EA1S
mould cavities n.1
max. body diameter mm 340
max. body height mm 550
max neck diameter mm 55
bottle capacity US gal 3÷5 (10÷20l)
max nominal output (*)b/h 250÷500
motors kW 13
heating capacity kW 96
operating air (6 bar)Nm/h 40÷80
blow air (40 bar) Nm/h 400
water inlet temperature C°10
water inlet pressure bar 3
water flow rate l/min 80
cooling capacity kcal/h 18000
length mm 3000
width mm 2100
height mm 3555
weight kg 6000
total installed power kW 109
|
|
Converting GLASS, HDPE and METAL jars and containers to PET and PP makes it possible to explore new markets with highly competitive innovative packaging.
Such containers can be used in many fields, such as:
FOOD / PHARMACEUTICALS / CHEMICALS PAINT/VARNISH / TOYS / PET FOOD / OTHERS
SIAPI has been working on "Wide Mouth" technology since 2004 and has launched on the market the EAWM series of linear blow-molding machines with 1-2-3-4 cavities for containers with mouth diameter up to 180 mm and a capacity of 12 litres.
SIAPI can assist customers in finding a full package that includes preform supply and container production through a preliminary prototyping stage for application validation.
SIAPI technology can also be used for producing hot fill containers in PET or PP.
|
|
SIAPI has strengthened its competitive edge also due to containers and bottles dedicated to the beverage trade, achieving productivity of up to 24,000 bph.
In collaboration with the customer and our international partners, we develop solutions for:
WATER / CSD / FRUIT JUICE / TEA-BASED DRINKS / ISOTONIC AND VITAMIN DRINKS / DAIRY PRODUCTS WITH SHORT SHELF-LIFE / OIL / BEER / WINE / FOOD / PET FOOD / MEDICINES / CHEMICAL PRODUCTS / DETERGENTS / COSMETICS / OTHERS
SIAPI's linear technology meets the most complex needs but involves reduced investments, lower than those required for rotary machines, while providing maximum reliability and improved process flexibility
|
|
| ... products without technical information |
| |
|
|
|
|
DKM Blow Moulding Machine
Extrusion System
The development of the extrusion system has been done by German engineers and has the following main features:
* Frequency controlled drive
* Grooved,force-cooled feeding zone
* Program Computer Controller-controlled heating/cooling zone
* Screw design for high throughput that ensures even plasticizing
* Screws and screw heads are suitable for all common thermoplastics, like PE,PP,PETG,PA…
Die Heads
Like the extruders, the die heads are developed to the highest standards by German engineers.
* Small center distances of the multiple die heads allow higher number of cavities
* Distribution systems with spider and heart curves ensure an even wall thickness distribution and convenient for changing colour
* Single to triple layer die heads give the possibility to produce a wide range products to the special demands of customers
* All die heads are equipped with Wireless Distribution System and adjustable die to optimize the wall thickness and minimize the material use
* View stripe equipment for all die heads is available
Clamping System
Like all main structures of the machine the clamping system is undertaken a stress analyses by finte element method.Guided on STAR-rails and equipped with proportional hydraulic valves,central lubrication system,fast movements are possible to ensure high output rates.The sturdy design and the placement of the cylinder in the center of the clamping platens supports a good cutting and a long ligetime of the moulds.Central lubrication.
|
|
System 4000 S-660
Hydraulic machine with a single shuttle, perfect for fl exible production. The design allows for a fast and simple mould change and effective production capability thanks to an extremely rapid mechanical cycle.
Available in a complete range of versions, designed for low maintenance cost, it represents the first step into the world of the TECHNE SYSTEM.
clamping force: 180 kN
|
|
ADV1-510 / ADV2-510 / ADV4-510
Completely electric machine with linear shuttles, it introduces the modular concept in the extrusion/blow-moulding world through innovative design concepts and developing never before reached performance. The low consumption costs, the total fl exibility and the high reliability offer a highly competitive investment potential. As production volumes increase the system can be developed over time by adding to the existing unit ( ADV1-ADV2-ADV4).
clamping force: 120 kN
|
|
System S900-900
Hydraulic machine with a single shuttle, this model is at the top level for the production of industrial containers dangerous goods. Designed with avant-garde techniques and built with highly resistant materials. It is equipped with latest generation control systems, enabling the production of containers of outstanding quality with reference to the material distribution and mechanical durability.
clamping force: 390 kN
|
|
System 10000 T-900
Hydraulic machine with a double parallel shuttle (TECHNE TWIN International Patent), it combines the speciality of long stroke with the speed and fl exibility of a traditional blow-moulding machine. Widely used all over the world, it is available in all versions and with a large range of options; this model is at the top of the category for very high annual production volume.
clamping force: 260 kN
|
|
