Hydraulic breaker Silenced:
- The internal control valve system provides a shorter, direct and larger oil flow which reduces oil heating and increases by 15% the output and seals life.
- Only two moving parts (piston + control valve) for increased reliability and low maintenance.
- Maximum impact transfer by nitrogen and hydraulic pressure. Perfect piston-tool weight ratio assures less recoil.
- Idle stroke protection : a high pressure cushion ensures piston absorption at full stroke and shock protection. When working : piston recoil is absorbed by the nitrogen chamber compression which releases this energy in strike force.
- All breakers have full protection brackets with noise, shock and vibration absorbers.
- A long fronthead fitted with 2 bushings for a good tool guiding, longer lifetime of toolbushing and tool bending prevention.
- Two retainer pins for longer pin durability, less burr on tool and easy tool replacement.
- Lower bracket part strongly reinforced with abrasive resistant steels.
|
|
Breaker Bucket
The Breaker Bucket Model BB511 has been designed with the Municipal and Utilities market in mind. A backhoe or mini excavator equipped with a Breaker Bucket can do all the work required for a waterline repair or the excavation for utilities, eliminating the need for separate hammer, compactor and even a quick attach system. The Breaker Bucket Model BB511 is available in three bucket widths; 12 inches, 18 inches and 24 inches to meet the demands of any worksite application.
|
|
|
|
|
|
MBS Series Rockbreakers
BTI's MBS Series of Portable Rockbreakers offer an on-plant, road to operations, permanent solution to portable and mobile crushing applications where safety & productivity are essential.
NT Series Rockbreakers
BTI offers a full line of rockbreaker systems suited for the soft-medium rock crushing applications. These systems feature a wide range of working lengths allowing the rockbreaker to rake and break materials while maintaining a constant flow of production through the crusher.
RC Series Rockbreakers
Specifically designed for recycling and light aggregate applications, these systems mount on primary or jaw crushing plants. They provide a safe and efficient way of handling oversize material as it is fed to the crusher.
ESX Series Rockbreakers
For the larger stationary crushing plants, BTI has designed and developed the ESX Series Rockbreaker System. This system used in applications where extremely hard rock is present or a large coverage area is required. It can be used for material handling applications.
TM Series Rockbreakers
Both high strength and performance are top priorities at stationary crushing plants. This system features maneuverability, durability and reliability.
TT/TTX Series Rockbreakers
For the larger stationary crushing plants, BTI has designed and developed the TT/TTX Series Rockbreaker System. This system used in applications where extremely hard rock is present or a large coverage area is required. It can be used for material handling applications.
|
|
TB-XC Series Boxed Breakers
BTI's TB-XC Series of Hydraulic Breakers offer new benefits, while retaining the time proven features of only 2 moving parts and no accumulators.
TB Series Sideplated Breakers
BTI Hydraulic Breakers mount on excavators, wheel loaders, skid steers and tractor backhoes and work across a wide range of applications including trenching, construction, demolition, quarry, mining and recycling.
BT Series Boxed Breakers
The design of the BT Series of Hydraulic Breakers produces stable high-speed percussion, and exceptional value and durability for all construction, demolition, and rockbreaking requirements.
VZ Series Boxed Breakers
The design of the VZ Series of Hydraulic Breakers offer outstanding power to weight ratio, and exceptional efficiency with the energy regeneration system
|
|
Demolition hammer
Fields of application
- Civil engineering
- Underground mining work
- Trench digging
- Gallery construction
Features:
- Sizes from SB 300 to SB 450
- Impact energy from 610 to 800 Joule
- Chisel diameter 80 to 95 mm
Benefits:
- High impact energy and stability
|
|
|
|
|
|
The MAVERICK™ 400HSP Hydraulic Hammer
Energy Impact Class: 250 ft./lbs.
Operating Weight: 230 lbs
Tool Diameter: 1.77”
Required Oil Supply: 5.25-10 gallons/min
Pressure Adjusted: 1305-1740 p.s.i
Blows/Minute: 650-1200
Carrier Weight: 3,000-7,000 lbs
MAVERICK™ Equipment is a leading supplier of high quality hydraulic hammers to the construction, mining, demolition and utilities industries. All MAVERICK™ hammers are designed to provide maximum reliability and long operating life while adding to the bottom line. With 14 models, MAVERICK™ offers hammers compatible with a variety of carriers and applications.
These simple designed breakers are fully enclosed in a Hardox® case which protects the hammer, even in the most challenging environments. With standard features such as slip fit lower wear bushings, which cut down on maintenance to Carbon Martensite pistons, to componentized power cells, owners of MAVERICK™ hammers utilize a product that will last for many years.
Attractive pricing combined with high production and low maintenance equal a high return on investment. Backed by a comprehensive, three year warranty, MAVERICK™ hammer owners can be confident they will get their job done quickly and efficiently.
|
|
|
|
|
|
The MAVERICK™ 1000HSP Hydraulic Hammer
Energy Impact Class: 750 ft./lbs.
Operating Weight: 728 lbs
Tool Diameter: 2.68”
Pressure Adjusted: 1377-1885 p.s.i
Blows/Minute: 450-1,000
Carrier Weight: 10,000-17,000 lbs
MAVERICK™ Equipment is a leading supplier of high quality hydraulic hammers to the construction, mining, demolition and utilities industries. All MAVERICK™ hammers are designed to provide maximum reliability and long operating life while adding to the bottom line. With 14 models, MAVERICK™ offers hammers compatible with a variety of carriers and applications.
These simple designed breakers are fully enclosed in a Hardox® case which protects the hammer, even in the most challenging environments. With standard features such as slip fit lower wear bushings, which cut down on maintenance to Carbon Martensite pistons, to componentized power cells, owners of MAVERICK™ hammers utilize a product that will last for many years.
Attractive pricing combined with high production and low maintenance equal a high return on investment. Backed by a comprehensive, three year warranty, MAVERICK™ hammer owners can be confident they will get their job done quickly and efficiently.
|
|
|
|
|
|
The MAVERICK™ 4750HSP Hydraulic Hammer
Energy Impact Class: 3,500 ft./lbs.
Operating Weight: 2,821 lbs
Tool Diameter: 4.72”
Required Oil Supply: 23-32 gallons/min
Pressure Adjusted: 2,030-2,465 p.s.i
Blows/Minute: 350-750
Carrier Weight: 35,000-48,000 lbs
MAVERICK™ Equipment is a leading supplier of high quality hydraulic hammers to the construction, mining, demolition and utilities industries. All MAVERICK™ hammers are designed to provide maximum reliability and long operating life while adding to the bottom line. With 14 models, MAVERICK™ offers hammers compatible with a variety of carriers and applications.
These simple designed breakers are fully enclosed in a Hardox® case which protects the hammer, even in the most challenging environments. With standard features such as slip fit lower wear bushings, which cut down on maintenance to Carbon Martensite pistons, to componentized power cells, owners of MAVERICK™ hammers utilize a product that will last for many years.
Attractive pricing combined with high production and low maintenance equal a high return on investment. Backed by a comprehensive, three year warranty, MAVERICK™ hammer owners can be confident they will get their job done quickly and efficiently.
|
|
|
|
|
|
The MAVERICK™ 6250HSP Hydraulic Hammer
Energy Impact Class: 5,500 ft./lbs.
Operating Weight: 3,924 lbs
Tool Diameter: 5.51”
Required Oil Supply: 38-48 gallons/min
Pressure Adjusted: 2,320-2,610 p.s.i
Blows/Minute: 350-500
Carrier Weight: 42,000-65,000 lbs
MAVERICK™ Equipment is a leading supplier of high quality hydraulic hammers to the construction, mining, demolition and utilities industries. All MAVERICK™ hammers are designed to provide maximum reliability and long operating life while adding to the bottom line. With 14 models, MAVERICK™ offers hammers compatible with a variety of carriers and applications.
These simple designed breakers are fully enclosed in a Hardox® case which protects the hammer, even in the most challenging environments. With standard features such as slip fit lower wear bushings, which cut down on maintenance to Carbon Martensite pistons, to componentized power cells, owners of MAVERICK™ hammers utilize a product that will last for many years.
Attractive pricing combined with high production and low maintenance equal a high return on investment. Backed by a comprehensive, three year warranty, MAVERICK™ hammer owners can be confident they will get their job done quickly and efficiently.
|
|
|
|
|
|
The MAVERICK™ 10000HSP Hydraulic Hammer
Energy Impact Class: 10,000 ft./lbs.
Operating Weight: 7,100 lbs
Tool Diameter: 6.5”
Required Oil Supply: 52-69 gallons/min
Pressure Adjusted: 2,275-2,702 p.s.i
Blows/Minute: 260-400
Carrier Weight: 79,000-110,000 lbs
MAVERICK™ Equipment is a leading supplier of high quality hydraulic hammers to the construction, mining, demolition and utilities industries. All MAVERICK™ hammers are designed to provide maximum reliability and long operating life while adding to the bottom line. With 14 models, MAVERICK™ offers hammers compatible with a variety of carriers and applications.
These simple designed breakers are fully enclosed in a Hardox® case which protects the hammer, even in the most challenging environments. With standard features such as slip fit lower wear bushings, which cut down on maintenance to Carbon Martensite pistons, to componentized power cells, owners of MAVERICK™ hammers utilize a product that will last for many years.
Attractive pricing combined with high production and low maintenance equal a high return on investment. Backed by a comprehensive, three year warranty, MAVERICK™ hammer owners can be confident they will get their job done quickly and efficiently.
|
|
|
|
|
|
The MAVERICK™ 9250HSP Hydraulic Hammer
Energy Impact Class: 8,500 ft./lbs.
Operating Weight: 5,842 lbs
Tool Diameter: 6.3”
Required Oil Supply: 50-66 gallons/min
Pressure Adjusted: 2,230-2,702 p.s.i
Blows/Minute: 260-400
Carrier Weight: 70,000-105,000 lbs
MAVERICK™ Equipment is a leading supplier of high quality hydraulic hammers to the construction, mining, demolition and utilities industries. All MAVERICK™ hammers are designed to provide maximum reliability and long operating life while adding to the bottom line. With 14 models, MAVERICK™ offers hammers compatible with a variety of carriers and applications.
These simple designed breakers are fully enclosed in a Hardox® case which protects the hammer, even in the most challenging environments. With standard features such as slip fit lower wear bushings, which cut down on maintenance to Carbon Martensite pistons, to componentized power cells, owners of MAVERICK™ hammers utilize a product that will last for many years.
Attractive pricing combined with high production and low maintenance equal a high return on investment. Backed by a comprehensive, three year warranty, MAVERICK™ hammer owners can be confident they will get their job done quickly and efficiently.
|
|
|
|
|
|
The MAVERICK™ 12000HSP Hydraulic Hammer
Energy Impact Class: 12,000 ft./lbs.
Operating Weight: 8,267 lbs
Tool Diameter: 7.08”
Required Oil Supply: 55-76 gallons/min
Pressure Adjusted: 2,275-2,702 p.s.i
Blows/Minute: 250-400
Carrier Weight: 100,000-145,000 lbs
MAVERICK™ Equipment is a leading supplier of high quality hydraulic hammers to the construction, mining, demolition and utilities industries. All MAVERICK™ hammers are designed to provide maximum reliability and long operating life while adding to the bottom line. With 14 models, MAVERICK™ offers hammers compatible with a variety of carriers and applications.
These simple designed breakers are fully enclosed in a Hardox® case which protects the hammer, even in the most challenging environments. With standard features such as slip fit lower wear bushings, which cut down on maintenance to Carbon Martensite pistons, to componentized power cells, owners of MAVERICK™ hammers utilize a product that will last for many years.
Attractive pricing combined with high production and low maintenance equal a high return on investment. Backed by a comprehensive, three year warranty, MAVERICK™ hammer owners can be confident they will get their job done quickly and efficiently.
|
|
|
|
|
|
The MAVERICK™ 5250HSP Hydraulic Hammer
Energy Impact Class: 4,500 ft./lbs.
Operating Weight: 3,765 lbs
Tool Diameter: 5.31”
Required Oil Supply: 33-40 gallons/min
Pressure Adjusted: 2,320-2,610 p.s.i
Blows/Minute: 300-600
Carrier Weight: 38,000-54,000 lbs
MAVERICK™ Equipment is a leading supplier of high quality hydraulic hammers to the construction, mining, demolition and utilities industries. All MAVERICK™ hammers are designed to provide maximum reliability and long operating life while adding to the bottom line. With 14 models, MAVERICK™ offers hammers compatible with a variety of carriers and applications.
These simple designed breakers are fully enclosed in a Hardox® case which protects the hammer, even in the most challenging environments. With standard features such as slip fit lower wear bushings, which cut down on maintenance to Carbon Martensite pistons, to componentized power cells, owners of MAVERICK™ hammers utilize a product that will last for many years.
Attractive pricing combined with high production and low maintenance equal a high return on investment. Backed by a comprehensive, three year warranty, MAVERICK™ hammer owners can be confident they will get their job done quickly and efficiently.
|
|
|
|
|
|
The MAVERICK™ 2250HSP Hydraulic Hammer
Energy Impact Class: 1,500 ft./lbs.
Operating Weight: 1,275 lbs
Tool Diameter: 3.35”
Required Oil Supply: 12-21 gallons/min
Pressure Adjusted: 1,885-2,175 p.s.i
Blows/Minute: 450-700
Carrier Weight: 16,000-24,000 lbs
MAVERICK™ Equipment is a leading supplier of high quality hydraulic hammers to the construction, mining, demolition and utilities industries. All MAVERICK™ hammers are designed to provide maximum reliability and long operating life while adding to the bottom line. With 14 models, MAVERICK™ offers hammers compatible with a variety of carriers and applications.
These simple designed breakers are fully enclosed in a Hardox® case which protects the hammer, even in the most challenging environments. With standard features such as slip fit lower wear bushings, which cut down on maintenance to Carbon Martensite pistons, to componentized power cells, owners of MAVERICK™ hammers utilize a product that will last for many years.
Attractive pricing combined with high production and low maintenance equal a high return on investment. Backed by a comprehensive, three year warranty, MAVERICK™ hammer owners can be confident they will get their job done quickly and efficiently.
|
|
|
|
|
|
The MAVERICK™ 3250HSP Hydraulic Hammer
Energy Impact Class: 2,500 ft./lbs.
Operating Weight: 2,010 lbs
Tool Diameter: 3.94”
Required Oil Supply: 21-29 gallons/min
Pressure Adjusted: 2,175-2,465 p.s.i
Blows/Minute: 400-700
Carrier Weight: 22,000-38,000 lbs
MAVERICK™ Equipment is a leading supplier of high quality hydraulic hammers to the construction, mining, demolition and utilities industries. All MAVERICK™ hammers are designed to provide maximum reliability and long operating life while adding to the bottom line. With 14 models, MAVERICK™ offers hammers compatible with a variety of carriers and applications.
These simple designed breakers are fully enclosed in a Hardox® case which protects the hammer, even in the most challenging environments. With standard features such as slip fit lower wear bushings, which cut down on maintenance to Carbon Martensite pistons, to componentized power cells, owners of MAVERICK™ hammers utilize a product that will last for many years.
Attractive pricing combined with high production and low maintenance equal a high return on investment. Backed by a comprehensive, three year warranty, MAVERICK™ hammer owners can be confident they will get their job done quickly and efficiently.
|
|
|
|
|
|
The MAVERICK™ 8250HSP Hydraulic Hammer
Energy Impact Class: 6,500 ft./lbs.
Operating Weight: 5150 lbs
Tool Diameter: 5.91”
Required Oil Supply: 42-50 gallons/min
Pressure Adjusted: 2,230-2,610 p.s.i
Blows/Minute: 450-750
Carrier Weight: 55,000-89,000 lbs
MAVERICK™ Equipment is a leading supplier of high quality hydraulic hammers to the construction, mining, demolition and utilities industries. All MAVERICK™ hammers are designed to provide maximum reliability and long operating life while adding to the bottom line. With 14 models, MAVERICK™ offers hammers compatible with a variety of carriers and applications.
These simple designed breakers are fully enclosed in a Hardox® case which protects the hammer, even in the most challenging environments. With standard features such as slip fit lower wear bushings, which cut down on maintenance to Carbon Martensite pistons, to componentized power cells, owners of MAVERICK™ hammers utilize a product that will last for many years.
Attractive pricing combined with high production and low maintenance equal a high return on investment. Backed by a comprehensive, three year warranty, MAVERICK™ hammer owners can be confident they will get their job done quickly and efficiently.
|
|
Hydraulic Hammers
Hydraulic HammersA better design that combines efficiency, reliability and serviceability.
1. Excellent power-to-weight ratio
2. Unique gas-charged piston maximizes hammer efficiency
3. Simple, two-moving-parts design for reliability
4. Separate ports for the NPK AutoLube system and an air line for underwater use
5. Bottom tie rod nuts for easier serviceability (GH Models)
6. Quick-change tool system with single round retainer pin
7. Variety of tool configurations available
8. Replaceable cylinder sleeves for easy, economical rebuild
9. Tool bushings engineered for quick, easy replacement
|
|
"IR Montabert's breakers are the result of more than 30 years experience in hydraulic rock breaker design and manufacture.
Based on unique technology and quality, the heavy range offers the best tools adapted for demolition, mining, quarrying and public works thanks to their unequalled performance / weight ratio."
Autopower, Optipower, the BRV strike variation system , discover all the advantages of these innovations: extra power, maximum performance, exceptional reliability.
|
|
|
There is a Sandvik hydraulic hammer for virtually any breaking application that requires a boom-mounted percussive tool. From the advanced in-series hammers for mini-excavators, whose tools are so strong they are guaranteed for life against breakage, to the extra heavy-duty G-series for excavators from 27-100 tonnes in weight, there is a reliable, low-maintenance, easy-to-fit, high-performance Sandvik hammer certain to raise productivity, optimize results and give a lower cost per ton of material broken.
|
|
|
|
|
|
New D&A Hydraulic Breaker Enhanced Strength and Complete Customer Satisfaction
- Noise Protector : less noise
- Cushion Damper : Absorbs repercussion from hammering and increases carrier endurance
- Roomier Gas Chamber : Ensures higher impact power
- Stroke Adjuster : Maximize productivity from variable speed control (D&A 70V-550V)
- Main valve : Internal control valve system is more efficient by 10% to 15% than other breaker's valve, stays cooler and makes the quicker and harder-hitting
- Auto-Lubrication System : Available to install auto-Lubrication or centralizing lubrication kit (over D&A 100V - 550V)
- Accumulator installed (from D&A 30V~) : Less stress to hydraulic components as absorbing pressure fluctuation / Increases efficiency by replenishing short oil flow
- Rock dragger with anti-abrasion steel : used anti-abrasion steel (Hardox steel)
- Wide Chisel pin : safe from abnormal wearing
- Piston : Higher impact power with long stroke
- Well heat-treated tool : Longer life by good material / Safe from blank fire
- Upgraded Through bolt
|
|
|
|
|
|
New D&A Hydraulic Breaker Enhanced Strength and Complete Customer Satisfaction
- Noise Protector : less noise
- Cushion Damper : Absorbs repercussion from hammering and increases carrier endurance
- Roomier Gas Chamber : Ensures higher impact power
- Stroke Adjuster : Maximize productivity from variable speed control (D&A 70V-550V)
- Main valve : Internal control valve system is more efficient by 10% to 15% than other breaker's valve, stays cooler and makes the quicker and harder-hitting
- Auto-Lubrication System : Available to install auto-Lubrication or centralizing lubrication kit (over D&A 100V - 550V)
- Accumulator installed (from D&A 30V~) : Less stress to hydraulic components as absorbing pressure fluctuation / Increases efficiency by replenishing short oil flow
- Rock dragger with anti-abrasion steel : used anti-abrasion steel (Hardox steel)
- Wide Chisel pin : safe from abnormal wearing
- Piston : Higher impact power with long stroke
- Well heat-treated tool : Longer life by good material / Safe from blank fire
- Upgraded Through bolt
|
|
|
|
|
|
New D&A Hydraulic Breaker Enhanced Strength and Complete Customer Satisfaction
- Noise Protector : less noise
- Cushion Damper : Absorbs repercussion from hammering and increases carrier endurance
- Roomier Gas Chamber : Ensures higher impact power
- Stroke Adjuster : Maximize productivity from variable speed control (D&A 70V-550V)
- Main valve : Internal control valve system is more efficient by 10% to 15% than other breaker's valve, stays cooler and makes the quicker and harder-hitting
- Auto-Lubrication System : Available to install auto-Lubrication or centralizing lubrication kit (over D&A 100V - 550V)
- Accumulator installed (from D&A 30V~) : Less stress to hydraulic components as absorbing pressure fluctuation / Increases efficiency by replenishing short oil flow
- Rock dragger with anti-abrasion steel : used anti-abrasion steel (Hardox steel)
- Wide Chisel pin : safe from abnormal wearing
- Piston : Higher impact power with long stroke
- Well heat-treated tool : Longer life by good material / Safe from blank fire
- Upgraded Through bolt
|
|
|
|
|
|
New D&A Hydraulic Breaker Enhanced Strength and Complete Customer Satisfaction
- Noise Protector : less noise
- Cushion Damper : Absorbs repercussion from hammering and increases carrier endurance
- Roomier Gas Chamber : Ensures higher impact power
- Stroke Adjuster : Maximize productivity from variable speed control (D&A 70V-550V)
- Main valve : Internal control valve system is more efficient by 10% to 15% than other breaker's valve, stays cooler and makes the quicker and harder-hitting
- Auto-Lubrication System : Available to install auto-Lubrication or centralizing lubrication kit (over D&A 100V - 550V)
- Accumulator installed (from D&A 30V~) : Less stress to hydraulic components as absorbing pressure fluctuation / Increases efficiency by replenishing short oil flow
- Rock dragger with anti-abrasion steel : used anti-abrasion steel (Hardox steel)
- Wide Chisel pin : safe from abnormal wearing
- Piston : Higher impact power with long stroke
- Well heat-treated tool : Longer life by good material / Safe from blank fire
- Upgraded Through bolt
|
|
Hammers XP - Heavy Series
2350 kg - 4380 kg
Range of hammers from 0.8 to 70 tons. Thanks to the high back pressure up to 25 Bar, the hammers of XP series can be installed on the modern excavators, with no need to change the hydraulic system.
Supplied of underwater and tunnel kits.
|
|
Hammers XP - Light series
70 kg - 565 kg
Range of hammers from 0.8 to 70 tons. Thanks to the high back pressure up to 25 Bar, the hammers of XP series can be installed on the modern excavators, with no need to change the hydraulic system.
Supplied of underwater and tunnel kits.
|
|
Hammers XP - Medium series
750 kg - 1700 kg
Range of hammers from 0.8 to 70 tons. Thanks to the high back pressure up to 25 Bar, the hammers of XP series can be installed on the modern excavators, with no need to change the hydraulic system.
Supplied of underwater and tunnel kits.
|
|
Hammers SH - Light Standard Series
90 kg - 390 kg
Wide range of hydraulic hammers for excavators from 1 to 70 tons. The SH series is characterized on classic models distributed for more than twenty years and therefore super-tested. The SH series is ideal for who tries a product of quality with convenienent price.
|
|
Hammers SH - Medium Standard Series
590 kg - 1390 kg
Wide range of hydraulic hammers for excavators from 1 to 70 tons. The SH series is characterized on classic models distributed for more than twenty years and therefore super-tested. The SH series is ideal for who tries a product of quality with convenienent price.
|
|
|
|
|
|
Hydraulic broken hammer Introduction
SWH Hydraulic Breaker can transform the hydraulic energy to mechanical impacting energy. Featured with high efficiency and low operating costs and high reliability, it mainly takes excavators, loaders or other hydraulic machinery for the carrying equipment. It is widely used in urban construction, mining, smelting, transportation, utilities and other construction. The research, design and test of special hydraulic mechanism of hydraulic impacting machines have long-term theoretical research and engineering practices for Sunward Intelligent. The hydraulic breaker under company independent development and research of the company features with innovative structure, high efficiency and low operating costs. Not only working with excavators loaders of various standards and other ancillary use, the company also develops new complete sets of equipment in accordance with users’ need for a series of mine wellhead and nonferrous metal smelting, blast furnace iron making, and other special breakings.
|
|
Our hydraulic breakers are designed to perform and built to last, combining high impact energy with maximum dependability.
Features:
noise and vibration damping
maximum/high availability
maximum/high productivity
Applications:
road construction
building renovation
primary and secondary breaking in quarries
demolition
tunneling
trenching
foundation work
landscape gardening and landscaping
|
|
|
|
