7200 Capacitance Meter
The Model 7200 offers fast and accurate characterization of active and passive components at 1 MHz. The <50 µs risetime of the analog outputs makes this unit ideal for DLTS measurements.
• Ultra stable and repeatable measurements
• Programmable, internal 100 VDC bias
• 0.01 picofarad resolution
• High-speed, high-resolution analog outputs
• Selectable test levels
• Calibration stored in nonvolatile memory
• GPIB and HPGL
|
|
High-speed LCR meter with up to 120MHz sampling
High Speed Testing of Chip Inductors and Magnetic Heads in Research and Development
Broad Frequency Measurement Range ( 100 kHz to 120 MHz )
High speed LCR testing (6ms/sample)
14 Parameter Types ( |Z|, |Y|, Θ, Rp, Rs(ESR), G, X, B, Lp, Ls, Cp, Cs, D (tan δ) and Q )
Detachable Head Amp
Load Compensation Function
BIN ( Classification ) Measurement
|
|
- LCD Display 128 x 64
- File Management ( Flash Memory Card)
- Test Point Range : 64-2048
- Test Voltage : 50-1500VDC (RT-9651 H / CH )
- Insulation Test : 500K-1000MOhm(RT- 9651H/ CH)
- 4-Wire Rsistance Test : Yes
- Components Test : Resistor,Diode,Capacitor(Option)
- Resistor Measurement : 0.1Ohm-20MOhm
- Capacitor Measurement : 100pF-1000uF
- High Quality Relay
|
|
|
|
