The SCR Marine charge regulator has been especially designed for the Superwind 350 wind generator and guarantees optimum charging of the batteries. The secondary function of the SCR Marine is to electronically keep the wind generator under load. When the batteries have reached their maximum charging voltage, the SCR Marine´s PWM circuit automatically diverts the wind turbine´s surplus power to the dump resistors. Thus with batteries even fully charged, the wind turbine continues operating and provides useable power as soon as electric consumers are switched on. This state of charge is indicated by a LED.
The SCR Marine is suitable for lead acid batteries, gel batteries and AGM batteries (AGM = Absorbed Glass Mat) and has temperature compensated charging characteristics. For special applications, the maximum charging voltage can be adjusted to customer requirements.
The charge regulator SCR Marine is completely sealed and effectively protectet against the marine environment.
It has two separate outputs, which can be used to charge two battery sets separately (eg. starter battery and service battery on a yacht).
|
|
Features:
- A true MPP tracking charge controller that is unique in the industry
- An additional 30% of charge current in comparison to the traditional non-MPPT charge controllers
- Capable of charging 12/24/36/48V battery
- Intelligent battery management to extend the lifespan of batteries
- Built-in power protection when this controller is connected to an over-dimensioned PV module
- Full protection against excess current, temperature, and voltage
- Easy configuration via touch buttons located on front of this device
- Large LED to constantly display the state of charge controller
- Communication interfaces provided: RS232C/RS485/USB
|
|
The charge controller for the 6V lead accumulator has a low own consumption. It is operated through a solar panel or through a momentary supply voltage.
Features
* Lowest own consumption
* Temperature compensated charging characteristic
* Overload and undervoltage protection
* Output short-circuit proof
* Accumulator is polarity reversal protected
* Capacity shown through LED
* Electricity is sealed
* For solar panel or intermitted mains operation
Specifications
Accumulator 6V Lead accu
Own consumption 30 uA, resp. 0.02Ah / month
Max. capacity solar panel 6 Watt
Average charging rate ca. 1.4 A
|
|
Description
With an Alpha Pro charge regulator rest assured that the battery charge process will be handled safely and quickly. Power from the alternator is efficiently transferred to the batteries via the Mastervolt three-step charge method. It is the ideal connection between alternator and battery.
The charge voltage is automatically adjusted if there is any risk of gas formation. Electronics permanently regulate voltage, ensuring that the battery is always kept in good condition. Using a Battery Mate or Battery Isolator in conjunction with an Alpha alternator makes it possible to easily charge two or three separate battery-sets simultaneously. LEDs on the regulator itself indicate the charge phase and an external setpoint can be used to adjust the charge voltage. This means simple monitoring and operating.
|
|
