2-Axis CNC Portable Cutting Machine
Looking for Dealers, Distributors
Cut like a big cutting machine with the provided FastCAM software
Affordable for all small and medium enterprises
Cutting Range: 1200 mm(47”)X2000 mm( 78”). Lenght extendable till 6000mm.
Support both plasma cutter and oxy-fuel cutting torch
With its USB port, the data transmission from a PC is as easy as downloading photos from a digital camera. SteelTailor has all the performance of a gantry machine.
|
|
|
|
|
|
HIGH VOLUME, HEAVY DUTY PLASMA AND OXY CUTTING MACHINE
The Farley Laserlab Trident is single or multi torch cutting machine designed to deliver precision, high definition plasma cutting, oxy-fuel cutting and drilling. The Trident is ideally suited to high volume cutting environments such as shipyards, steel services & distribution centres and shops that require continuous operation – 3 shifts per day, year after year.
The Farley Laserlab Trident achieves its accuracy and high productivity by utilising single piece fabricated beam construction, which eliminates bolted joints. Combined with twin side-drives through high precision planetary gear boxes, the result is a extremely strong long lasting machine capable of plasma profiling speeds of up to 20m/min and rapid speeds of 30m/min, yet retaining the rigidity to accept up to 6 torches for multi-torch plate cutting of 250mm thick material. The Trident also has a BT 40 drilling head with an 8 pocket tool changer with drilling capacity up to 32mm diameter holes.
Profiling speed: to 20m/min
Cutting widths: 2.5m, 3.6m & up to 6m
Rapid traverse: to 30m/min
Cutting length: 3m to 70m
Accuracy: ± 0.3mm
Repeatability: ± 0.15mm
Material thickness: 1mm – 250mm
Spindle taper: BT40
Drive system: Twin side drive rack & pinion with optional Helical rack
Components: Hypertherm plasma up to 400 amp, 5-axis bevel head, oxy-fuel cutting, marking systems, BT40 CNC drilling & tapping head and touch screen controller. All Siemens servos and drives.
|
|
|
|
|
|
SteelTailor Valiant is a new series of SteelTailor portable CNC cutting machine family. The SteelTailor Valiant series improve again the performances of the previous series, and the main improvements are: no more vibration by introducing a damping device, more stability by introducing a wider rails track and more rigid structure. It is an heavy duty cycle machine as all SteelTailor products, reliable and height quality level meeting all the applicable standards.
Key Advantages:
1. Advanced Stability and Precision
The frame is wider with high-quality racks, which makes the cross beam move more stably and keep high precision. The cutting head will not bend.
2. No Vibration
No vibration by introducing damping device. The Valiant can move in high speed with good stability.
3. Optimization of structure design
Modular design of the SteelTailor Valiant allows easy maintenance. The separation of Mechanics and Electrics supplies the user with easy and enjoyable maintenance,
4. Higher speed and better stability
Wider rails track and more rigid structure makes the machine move faster, the highest speed can reach 6000mm/min with plasma with no vibration.
Technical Data:
Rated Power 160W
Electric Power 220AC/110AC, 60/50Hz
Total Machine Weight 135Kg
Cutting Thickness(Flame) 5-150mm
Effective Cutting Range 1.5m X 2.5m, 1.8m X 3.5m,-------2.2m X 15m
Modes of Cutting Flame and/or Plasma
Combustive Gas Oxygen, Acetylene, Propane
Combustive Gas Pressure Max: 1.5MPa
Cutting Speed 0-1000 mm/min(Flame), 0-6000 mm/min(Plasma)
Torch Height Control Automatic
|
|
|
|
|
|
|
ERMAKSAN's CPP ( COMBINED PLASMA PUNCH PRESS ) series proven quality and experience in production of sheet metal workbenches is being presented to the utility of our clients open to technology and continuous innovation. Strong mono block rigid C type body built up by welded steel and stress removed high acceleration axes designed to allow sheet loading from 3 sides economically lets the operation to be watched easily. The combination of HiFocus sensitive plasma cutting and hydraulic punching on a strong body. The moving sheet on X Y axes on a stainless with roller balls type table by clamps can be cut as sensitive as required contour by servo motorized automatic height adjusted torch at plasma unit after being processed by perforating and/or forming operations at punch unit. It realizes cutting and perforating processes at high speed and accuracy, and has the capability aimed at mass production. An alternative cutting process in comparison to other high cost cuttings. Furthermore the production period will be shortened on these kind combined workbenches because the worksheet will not be taken apart and transferred to different workbenches.
|
|
|
|
|
|
SteelTailor B-4 CNC Plasma Cutter cuts flat parts out of metal with amazing accuracy and speed.
The bench constituted with a water table and a cross track has a effective cutting area of 1600 mm x 2500 mm. The external dimensions of the bench are 2000 mm x 3500 mm.
The cutting precision is 0.4 mm and the repeatability 0.1 mm. The positioning precision is 0.2 mm
The advantages of the SteelTailor B-4A is the use for the longitudinal and transverse movements of BALL LEAD SCREWS.
This leads to a faster speed, a higher precision and a longer life time.
Please, note that the cutting effective area can be adapted to the User’s needs
The cross track is supporting the high control and the plasma torch is light and rigid to accept any sort of plasma torch.
The water level of the cutting table is adjustable.
The weight is 1500 Kg (+/- 20kg) without torch and automatic plasma torch high control system.
The rated power is 2500 W. (380 V, 3 phases, 50 Hz- 220 V 3 phases 60 Hz)
The positioning and cutting speeds are adjustable from 50 mm/min till 10 000 mm/min.
The choice of high quality servomotors associated with reliable reducers provides accurate, high-speed motion. The positioning and cutting operations are really precise and smooth.
SteelTailor B-4 is equipped with an automatic plasma torch high control to ensure the correct position of the plasma torch.
The well proven CNC system used by SteelTailor B-4 makes this Bench CNC Plasma Cutter one of the most reliable machines of the market.
|
|
|
|
|
|
HIGH PERFORMANCE PROFILE CUTTING, FROM JOB SHOPS TO PRODUCTION CUTTING
High performance, precision plasma & oxy-fuel cutting, marking and drilling system. This small footprint, robust, reliable machine is currently operating successfully in many companies, from job shops to contract cutting and OEMs.
The Farley Laserlab Magician achieves its accuracy and high productivity by utilising single piece fabricated beam construction, which eliminates all bolted joints. Combined with twin side-drives through high precision planetary gear boxes, the result is a machine light enough to achieve plasma profiling speeds of 20m/min and rapid speeds of 30m/min yet retaining the rigidity to accept up to 6 torches and a BT30 drilling head with 8 pocket tool changer.
TECHNICAL DATA
Profiling speed: up to 20m/min
Cutting widths: 2.5m & 3.2m
Rapid traverse: up to 30m/min.
Cutting length: 3m to 50m
Accuracy: ± 0.3mm
Repeatability: ± 0.15mm
Material thickness: 0.5mm - 150mm
Drive system: Twin side drive rack & pinion
Components: Hypertherm HyDefinition plasma up to 400 amp, 5-axis bevel head, oxy-fuel system, marking systems, center spot drill, Auto Gas, NEW BT30 CNC drilling & tapping head and touch screen controller. All Siemens servos and drives.
|
|
|
|
|
|
SteelTailorTM B-2 is a Bench CNC Plasma cutter able to cut flat parts out of metal sheets with amazing accuracy and high speed.
The structure of the bench made in re-enforced aluminum, makes this Bench CNC plasma cutter rigid and light weight.
The bench constituted with a water table and a cross track has a effective cutting area of 1500 mm x 3000 mm (can bit extended till 6000 mm). The external dimensions of the bench are 2200 mm x 4100 mm, for the 3000 mm long bench.
The water level of the cutting table is adjusted via an electromagnetic valve.
The cross track is supporting the high control and the plasma torch is light and rigid to accept any sort of plasma torch.
The weight of the mechanical parts is 700 (+/- 10) kg (for the 3000 mm long bench)
The positioning and cutting speeds are adjustable from 50 mm/min till 12000 mm/min.
The choice of high quality servomotors associated with reliable reducers provides accurate, high-speed motion. The positioning and cutting operations are really precise and smooth.
SteelTailorTM B-2 is equipped with an automatic plasma torch high control to ensure the correct position of the plasma torch.
The well proven CNC system used by SteelTailor B-2 makes this Bench CNC Plasma Cutter one of the most reliable machines of the market.
The provided cutting software FastCAM professional version makes the conception, drawing, cutting program very easy. The nesting function optimizes the use of the metal sheet reducing the lost metal sheet areas.
|
|
|
|
|
|
SteelTailor Smart series is a new version of SteelTailor family portable CNC cutting machine. Itfs a portable bench CNC cutting machine with same precision and stability instead of traditional bench CNC cutting machine. It can be easily installed and disassembled. Stable and Economic can better meet your needs.
Key AdvantagesF
User Friendly-Rotatable head
The controller head can be rotated to make the user can handle machine in any direction, which makes the operation more comfortable.
Anti-vibration design
The vibration of the beam can be easily eliminated by simple mechanical design using the spring ball.
The framework optimized from gantry machine
The framework optimized from gantry machine and Biaxial synchronization of longitudinal direction movement ensures the stability and high precision.
Technical Data:
Model Smart 2.0
Input Power 200W
Electric Power 220V/110V 50-60Hz
Alternative Effective Cutting Area 1300mm X 2500mm or 1200mm X 1500mm
Machine Size 1600mm X 2800mm or 1500mm X 1800mm
Cutting Thickness Depend on Plasma Cutter
Display 5.7h LCD
Max Cutting Speed 8000mm/min
Weight 160kg
Torch Height Control Automatic
|
|
GO-FER III PLASMA KIT
The GO-FER III Plasma Kit is specifically designed to work in conjunction with a plasma machine. It's travel speed of 8-100 inches per minute (203-2640mm/min) and it's direct rack and pinion drive makes it ideal as an all position portable cutting machine for a plasma torch. The torch holder will accept any standard 1-3/8" (35mm) diameter machine torch that has a 32 pitch gear rack. A built in trigger contactor for initiating the cut makes the GO-FER a convenient self contained package.
|
|
|
High performance plasma cutting units with HiFocus or FineFocus technology for cutting without after-treatment provide high productivity at low cost. Gouching and marking.
|
|
|
CNC plasma cutters by MultiCam are legendary for their ease-of-use and versatility. Successful companies around the world rely on MultiCam plasmas to automate production in countless different industries. MultiCam Plasma systems are exclusively powered by Hypertherm plasma units. To learn more about MultiCam's CNC Plasma & Oxy Fuel systems click the navigation to the left or an image below.
|
|
The design of the HACO KOMPAKT is based on a long experience in the field of CNC Plasma Cutting Machines. The large range of table sizes and Plasma Cutting Sources (conventional as well as high-definition), means that we can offer you the perfect machine for your specific application.
With its macro-based graphical programming system and easily accessible working area, the KOMPAKT is a user-friendly CNC Plasma Cutting Machine.
The Haco KOMPAKT is manufactured to the highest standards and fully according CE safety rules.
The optimum price/quality ratio of the Haco KOMPAKT translates itself into a profitable investment.
The HACO Proxima is a CNC controlled machine for oxy-fuel cutting or a combination of oxy-fuel and plasma cutting. We can offer a machine with length up to 20 meter and width up to 6 meter, with a maximum number of 6 oxy-fuel cutting torches (with or without 1 plasma system).
|
|
|
|
|
|
High performance Durma plasma cutting machines are designed to cut wide range of mild steel,stainless steel and aluminium.The equipments used are the best worldwide brands which ensures the best system development.The high positioning speeds,accelerations and automatic torch high control allow best quality cutting and efficency.
Durma plasma cutting series are available from 1500x3000mm to 3000x12000mm cutting dimensions.Special customer requests for cutting dimensions are also possible.The precision rack and pinion are guiding Y1 Y2 base X gantry bridge with movable cutting plasma torch performs cutting.The bridge is also equipped with precision rack and pinion guiding.
Machine structure is welded stress relieved heavy duty frame.Syncronised double side backlash free dricesystem with high accuracy planet gears allow high cutting quality.
Plasma power source is Hypertherm as well as Siemens 840 DI controls the machine.
Standard equipments
Siemens 840 D-ISL CNC control Unit
Metalix Software with auto nesting
Cutting plate alignment function with Laser
Plasma ignition consol
Command Torch High Control (THC)
Two side motion contro system (low backlash reducers + rack / pinion)
AC Digital Servomotors
Fixed CNC control panel
Marking system
CNC control outputs/inputs for filter unit
Spare parts ,consumables starting kit
High mechanical accuracy to +- 0,1 mm
Axis positioning speed 35 m/min.
Torch height control travel with ballscrew on dual linear guides
Independent cutting tables
Windows based CNC unit
Speed control device
|
|
STANDARD TABLE SIZES (X-Y in mm)
1500x3000
2000x4000
2000x6000
2500x4000
2500x6000
3000x6000
3000x12000
TECHNICAL DATA
- High precision plasma cutting technology.
- High mechanical accuracy to (+,- ) 0.1 mm.
- Axis positioning speed 30 mt/min.
- X and Y axis travel on precision linear rail guides.
- Torch-height travel with ballscrews on dual linear guides.
- Fast and accurate positioning with AC brushless servo motors.
- Cutting table independently constructed of bridge and machine frame yo maintain positional accuracy under any table-load.
- Patented crash protection on torch.
- Automatic torch height control.
- Sectional cutting table with automatic fume extraction system.
- Windows(R) based CNC unit.
- Automatic nesting software.
- Remote control option on large tables.
- Optional dust and fume collector devices conforming to safety regulations.
- Additional plasma or oxygen torch option.
|
|
The MIKROSAM'S newest series of plasma cutting machines is the perfect choice for those looking for value in a machine tool quality CNC Plasma Cutting System.
MIKROSAM'S plasma cutting machines are designed with solid quality components and engineering. These machines can be fitted with many options to suit your requirements.
New designs are beginning to incorporate complex-looking plasma cut parts that actually replace multiple, more expensive parts previously made through labour intensive manual processes. The result is faster, more accurate production at a lower cost.
Pictures and drawings can be quickly scanned into a PC, imported into the MIKROSAM software, and cut on the machine. Complicated artistic designs can be easily incorporated into a variety of metal projects.
|
|
| ... products without technical information |
| |
|
Programmable Gantry System provides coordinated motion in two axis. Can be easily programmed to repeat any contour or pattern for either cutting or welding applications.
|
|
|
The MM1 is a computer-controlled machine that automates the cutting of profiles, holes, nozzles and shapes on pipe with diameters from 4" to 16" (100-400 cm). It rotates the pipe on it’s roller bed with a three jaw chuck while simultaneously moving a cutting torch back and forth along the pipe’s axis.
|
|
CCT - CNC GLASS CUTTING TABLES (STRAIGHT AND SHAPE)
Cutting size 3.700x2.600 mm or 6.000x3.210 mm. Cutting thickness range 2mm - 19mm. Accuracy± 0,2mm. Cutting speed from 0 to 120 m/min. Total power 10 Kw. Lenght 4.200mm. - Width 3.200mm. - Height 890-950mm. - Weight 2.400 kg. - Noise emission within 80 dB. CE brand.
CNC glass cutting machine for only straight is aviable.
|
|
High speed cutting table equipped with "brushless" motors on X and Y axes to allow a higher acceleration (working time reduced), a higher precision and to remove maintenance (the absence of brushes "brushless" system, maintenance-free).
With frame in robust electro welded steel of elevated torsion resistance, 4 cutting wheels (on request) for straight and shaped cutting on glass sheets to a maximum thickness of 25 mm.
TECHNICAL FEATURES
- Option for Low-E removal head
- Automatic oil dosing system according to cutting speed
- Total digitally governed axes
- Working speed up to 140 mt/min
- Instant electronic squaring of the bridge
- Stainless steel and reinforced metal plate frame
- New mechanical tilting system giving maximum efficiency an long lasting reliability
- Electric system with busfiled
- Double zero position for laminate cutting
-The Moving system runs along the X, Y axes by high-precision rack and pinion (GUDEL, from CH)
|
|
| ... products without technical information |
| |
|
|
|
|
|
ERMAKSAN's CPP ( COMBINED PLASMA PUNCH PRESS ) series proven quality and experience in production of sheet metal workbenches is being presented to the utility of our clients open to technology and continuous innovation. Strong mono block rigid C type body built up by welded steel and stress removed high acceleration axes designed to allow sheet loading from 3 sides economically lets the operation to be watched easily. The combination of HiFocus sensitive plasma cutting and hydraulic punching on a strong body. The moving sheet on X Y axes on a stainless with roller balls type table by clamps can be cut as sensitive as required contour by servo motorized automatic height adjusted torch at plasma unit after being processed by perforating and/or forming operations at punch unit. It realizes cutting and perforating processes at high speed and accuracy, and has the capability aimed at mass production. An alternative cutting process in comparison to other high cost cuttings. Furthermore the production period will be shortened on these kind combined workbenches because the worksheet will not be taken apart and transferred to different workbenches.
|
|
|
|
