The JN5139-xxx-Myy family is a range of surface mount modules that enables users to implement IEEE802.15.4 or ZigBee compliant systems with minimum time to market and at the lowest cost. They remove the need for expensive and lengthy development of custom RF board designs and test suites. The modules use Jennic's JN5139 wireless microcontroller to provide a comprehensive solution with high radio performance and all RF components included. All that is required to develop and manufacture wireless control or sensing products is to connect a power supply and peripherals such as switches, actuators and sensors, considerably simplifying product development.
Five hardware module variants are available: JN5139-xxx-M00 with an integrated antenna, JN5139-xxx-M01/M03 with an antenna connector and JN5139-xxx-M02/M04 with a power amplifier and LNA for extended range. Each variant can be provided pre-programmed with a ZigBee network stack (JN5139-Z01-Myy).
|
|
|
Canon Precision's fan motors, with energy saving designs incorporated, are some of the quietest in the industry. The improved bearing design achieves longer operating life than predecessors, and allows operation at higher temperature ranges. High airflow variants are also available.
|
|
|
|
|
|
Fan Driver/Electric Oil Cooler Control
Fan Driver Overview
Kar-Tech's Fan Driver/Electric Oil Cooler Control is a low-cost, highly intelligent control module for controlling electric DC fans or oil coolers for use in mobile hydraulic applications. The Fan Driver can drive a single fan in both directions with sustained supply current of 10 amps (up to 30 amp optional). An onboard temperature input accepts a sensor or switch for fan on temperature (programmable with a sensor input), and by using programmable ramp up and ramp down times, shock on the motor and mounting flanges is reduced or eliminated.
At A Glance:
- Powerful: Sustained 10 or 30 amp supply current in either fan forward or reverse in a 4"x3" package.
- Intelligent: Forward and reverse directions with ramp up and down
- Built To Last: Epoxy-potted "hockey puck" enclosure eliminates the issues in a mobile environment
- User Programmable: Onboard potentiometer-based programming, or use Kar-Tech's Palm Pilot interface
Basic Technical Info:
The Fan Driver operates between a range of +9 to 35VDC, and is protected for voltage spikes and reverse battery. It can provide up to 2 outputs capable of supplying 10 amps per, with a 30 amp option. It is supplied in a 4.2"x3.07"x1.4" enclsoure which is fully encapsulated; 5 16ga. loomed GXL wires provide connections.
Typical Applications:
- Electric DC fans
- DC Motor control
|
|
|
Our Thermo-Electric Cooler (TEC) controllers have the features of high efficiency, high precision, high reliability and compact size. They are widely used for the temperature control in telecommunications such as DWDW, EDFA, passive fiber components etc., and also the temperature control of laser modules, diode pump lasers and sensors in instrumentation.
|
|
TEC1-12706
Size: 40*40*3.8mm
Internal resistance: 1.98Ω+/- 10%
Imax.: 6.0 A
Vmax.: 15.4 V
Qmax.: 53.3W
Tmax.: 68 degree
Solder melting point: 138degree,150degree,200degree.
Maximum. Compress.: 1Mpa
|
|
- Laser diode current source with integrated 32W temperature controller
- Three models available with up to 4A laser drive current
- GPIB/IEEE-488 remote interface
- High stability, low noise laser current source operating in constant power or constant current modes.
- Analog modulation capability to 1MHz
- 4-wire laser forward voltage measurement and adjustable voltage limit
- Temperature controller compatible with thermistor, IC, and RTD temperature sensors
- Temperature stability of ±0.004°C
- TE voltage measurement
|
|
|
The OP250 is a configurable stabilized light source with a variety of Lasers and LEDs. Available in a single port or dual port configuration, selectable wavelengths, and various power levels and industry standard optical interfaces this instrument offers all the features and functions necessary for the development, testing and inspecting of optical components and cables.
|
|
FEATURES:
- Ultra Low Noise: <10mA*
- High Current without Heat Sink: 1A
- High Absolute Accuracy: <0.1%
- High Stability: 100ppm/°C
- Dual Modulation Ports: High/Low Speed
- Low Drop Out Voltage: 1V
- Complete Shielding
- Compact Size
- SMT Package Available
- *Total RMS between 0.1Hz to 0.5MHz.
APPLICATIONS
- Driving diode lasers with low noise, including DPSSLs,
EDFAs, fiber lasers, diode laser modules, etc.
|
|
| ... products without technical information |
| |
| ... products without technical information |
| |
Linear Motor Modules
Ready-to-Use - single bearing rail, limit switches, drag-chain, encoder
Environmental - laser-welded bellows, nickel plating
Consult Copley sales representative to specify
a module for your applicaton.
|
|
Modular, Scalable I/O System in IP20
This I/O system offers complete scalability, easy wiring and powerful diagnostics. Choose from the following interfaces: PROFIBUS-DP, INTERBUS, DeviceNet or SERCOS. For the sensor/actuator connection, digital and analog I/O and corresponding infeed modules are available.
|
|
|
|
|
|
I/O Modules
The Serial Bus System is a completely integrated solution with an extremely fast I/O backplane that uses change-of-state (COS) connections to maximize performance
Power Type: Electro-Pneumatic
Modularity features allow easy module replacement with unique latching mechanisms and auto device replacement which allows OEMs to add I/O modules without making changes to the control software. A full set of I/O modules accept signals from sensors, photo eyes, limits and other field input devices as well as providing signals to remote solenoid valves and other output devices. There is a choice of digital, analog, and high-watt I/O modules, which include built-in short circuit and open circuit detection circuitry with electronic feedback. A single ROSS serial bus communication module supports up to a maximum of 63 I/O modules and up to 264 inputs and 264 outputs.
- Accepts signals from sensors, photo eyes, limits and other field input devices.
- Provides signals to remotely operating solenoid valves and other field operating output devices.
- Choice of digital, analog, high watt I/O Modules.
- Choice of connectors: 8mm, 12mm or M23.
|
|
|
|
|
|
S900 provides all input and output modules needed for intrinsically safe field signal connection. The field signals are amplified in every S900 functional module, electrically isolated, and then output via an internal serial bus. A communication interface converts the digitized signals to adapt them to the standardized PROFIBUS DPV1 fieldbus protocol. Supervisory process control systems, DCS or SCADA systems use an intrinsically safe fieldbus to communicate with the communication interface.
A single fieldbus network suffices for configuring the individual fieldbus nodes, for cyclic data exchange, for all acyclic services, and for communication with HART®-compatible field instruments. All functional modules can be replaced easily and quickly in the installation or maintenance phase. The functional modules and the - optionally redundant - communication interfaces of systems placed in Zone 1 can be removed and plugged in while operation is running, without affecting the communication of the remaining modules. Only the primary power for the plug-in type power supply modules requires increased safety EEx-e.
Integrated encapsulated switch-off mechanisms allow for hotswapping, i.e. the power supply units can be replaced without interrupting the primary power. Due to its little space requirements and robust design and its environmentally ruggedized case, the I/O system S900 is the best, cost-saving solution for use on site, in hazardous Zone 1 or Zone 2 areas.
|
|
S800 I/O is a comprehensive, distributed and modular process I/O system that communicates with parent controllers over industry-standard field buses. Thanks to its broad connectivity it fits a wide range of process controllers from ABB and others.
By permitting installation in the field, close to sensors and actuators, S800 I/O reduces the installation cost by reducing the cost of cabling. And thanks to features such as "hot swap" of modules, "on-line" reconfiguration and redundancy options, it contributes to keeping production -- and thereby profits up.
S800 I/O features include:
- Comprehensive coverage
- Flexible configuration and installation
- Ease of set up
- Reliability and accuracy
|
|
S100 I/O consists of one or more I/O racks with several I/O boards, connection units and cables covering a wide variety of applications and specific needs. The I/O boards are divided into groups, depending on their function. Within each group, there are several I/O boards with differing functionality and complexity.
The Advant Controller 410 includes an integral S100 I/O rack, while the Advant Controller 450 interfaces up to five S100 I/O sub-racks through a single or redundant interface module and cables. Optical modems enable remote location of S100 I/O sub-racks.
|
|
Rexroth Inline is the flexible, scalable and modular I/O system for time-saving control cabinet installation – be it locally on the IndraControl L itself or as a distributed I/O station.
Rexroth Inline is available in two different versions for all standard fieldbus systems:
• Inline Modular – with fine scalability for individual configuring
• Inline Block – a bus coupler with integrated I/Os as the ideal solution for nodes with a limited number of I/Os
Advantages
* simple – use and application
* integrated – as fieldbus or local I/O
* open-architecture – support for all common bus systems
* flexible – best modularity
* reliable – wide bandwidth and low temperature sensitivity
* time-saving – installation without tools and precise diagnostics
* space-saving – high-density modules
|
|
| ... products without technical information |
| |
| ... products without technical information |
| |
Flexible tubing lines are utilized for a more direct and simplified hookup between the throttle pedal and carburetor. Pedal angle is adjustable up to 85 degrees from the floor plate and the operational pedal travel is a full 30 degrees.
|
|
Pressure reducing / relieving valves can be used to reduce the pressure in a leg of the circuit lower than system pressure. The valve also acts as a relief valve, relieving any shocks or surges that occur between the regulated port and the actuator. When the valve is in the relieving mode, the inlet port is blocked. Parker offers pressure reducing/relieving valves in both pilot operated and directing acting styles. The direct acting version is generally used in static applications where response is critical, or leakage is a concern.
|
|
D.C. Electro-pumps, series ET...
The essential components of series ET elektro pumps are an external gear pump and an elctro motor.
The 12 and 24 VDC motors feature high efficiencies and precision-balanced rotors for low-vibration running. They are combined with our AP05 - AP100 external gear-pumps to produce the ET series of electro-pumps, a family of products that are notable for their low noise levels in operation.
Simplicity of construction and reduction in size are the fundamental objectives in the design of the ET electro-pumps.
Advantages
Noise levels have been drastically reduced
Wide range of displacements and electric motor
|
|
| ... products without technical information |
| |
|
Electromechanical NC joining systems systems offer significantly more advantages than hydraulic presses. NC drive control allows accurate positioning or force-controlled joining and force-displacement evaluation in both the compression and the tension direction. The new generation of NC joining modules is outstanding for its extremely compact design with integral piezoelectric sensor.
|
|
The electro mechanical assembly units of the PREFERENCE SERIES are available in a large selection of force ranges and nominal strokes. Due to their modular construction, the units can be integrated in automated assembly lines as well as in manual work-places. A special synchronous belt connects the motor directly with ball/roller gear drive and guarantees a positioning accuracy of 0.01 mm. The angled motor favours a low installation height. This is of high importance if the unit has to be installed under a conveyor belt or a transfer system.
The mechanics comprise of the following components:
- Round steel housing with mounting flange
- Ball / Roller gear drive
- Force transducer
- Axial bearing
- Press ram
- AC-servomotor
|
|
| ... products without technical information |
| |
|
Electromechanical NC joining systems systems offer significantly more advantages than hydraulic presses. NC drive control allows accurate positioning or force-controlled joining and force-displacement evaluation in both the compression and the tension direction. The new generation of NC joining modules is outstanding for its extremely compact design with integral piezoelectric sensor.
|
|
The electro mechanical assembly units of the PREFERENCE SERIES are available in a large selection of force ranges and nominal strokes. Due to their modular construction, the units can be integrated in automated assembly lines as well as in manual work-places. A special synchronous belt connects the motor directly with ball/roller gear drive and guarantees a positioning accuracy of 0.01 mm. The angled motor favours a low installation height. This is of high importance if the unit has to be installed under a conveyor belt or a transfer system.
The mechanics comprise of the following components:
- Round steel housing with mounting flange
- Ball / Roller gear drive
- Force transducer
- Axial bearing
- Press ram
- AC-servomotor
|
|
|
|
