A core material produced from certified kiln-dried balsa wood in the 'end-grain' configuration. The properties of balsa make it ideal as a core for sandwich construction. It has extremely high strength and stiffness to weight ratios, and achieves an excellent bond with all types of resins and adhesives. It is compatible with a variety of manufacturing processes and is resistant to temperature changes, or exposure to fire, or chemicals such as styrene. It is an ideal core material for an extensive range of applications. All while being a renewable resource.
- extremely high strength and stiffness to weight ratios
- excellent fire performance
- ecological product
- wide operating temperature range (-212°C to +163°C, -414°F to +325°F)
- excellent fatigue resistance
- good sound and thermal insulation
- high impact strength
- good moisture resistance
|
|
A thermoplastic foam that combines outstanding fire resistance with low smoke and toxicity, along with excellent dielectric properties. It has a high strength to weight ratio, low moisture absorption, is thermoformable, and ductile. It is an exceptional core material for use in applications that demand structural fire resistance, are required to be transparent to radar, or operate in extreme hot or cold environments.
- fulfils most stringent fire requirements
- operating temperature from -194°C to +160°C (-317°F to 320 °F)
- remains ductile at cryogenic temperatures
- excellent dielectric properties (radar transparent)
- very low moisture absorption
- good fatigue resistance
- high impact resistance (non-brittle failure mode)
- thermoformable
- good sound and thermal insulation
|
|
A unique closed cell, cross-linked polymer foam that combines high stiffness and strength to weight ratios with superior toughness. It is non-friable, contains no CFCs, has negligible water absorption, and provides an excellent resistance to chemicals. A fine cell structure offers an excellent bonding surface that is compatible with most resins and manufacturing processes. It is ideally suited as a core material for a wide variety of light-weight sandwich structures subjected to both static and dynamic loads in service.
- high strength and stiffness to weight ratios
- good impact strength (highest elongation in class)
- low resin absorption
- high fatigue resistance
- good fire performance (self-extinguishing)
- sound and thermal insulation
- non biodegradable
- good styrene resistance
|
|
|
|
|
|
Corecell™ is the leading structural foam core material, which has become widely accepted for the construction of large, high performance structures. It is the latest in foam core technology and although originally developed for the marine industry, it is now used in other applications such as wind turbines and sub sea vessels.
Corecell™ uses SAN polymer base, resulting in unique high tougness and impact resistance characteristics. The foam acts as a 'shock absorber' between the two skins - absorbing the impact without failing, distributing the stresses evenly within the core and, in the case of a boat, ensures it remains watertight even after high point impacts.
Corecell™ foams provide low weight, excellent stiffness, and structural integrity under dynamic loads. They have high shear elongation and retain their mechanical properties even in the higher ambient temperature range.
Corecell™ foams are compatible with polyester, vinylester, and epoxy resins. Corecell™ is type approved by the American Bureau of Shipping (ABS), Lloyds Register of Shipping, Det Norske Veritas (DNV) and Germanischer Lloyd (GL).
The Corecell™ product range provides increased levels of performance, strength, structural integrity and comfort, unmatched by any other core material. Suitable for a wide range of demanding structural applications and different composite manufacturing processes.
|
|
|
|
|
|
Corecell M-Foam – The Marine Foam
• Replacement for PVC cores
• High shear strength combined with low density
• High temperature processing (prepreg compatible)
• High elongation for toughness
• Suitable for all composite processes including prepreg
Corecell M-Foam is the newest addition to the Corecell range and shares the benefits of SAN chemistry common to all Corecell products.
Corecell M-Foam has been developed to deliver one product for all Marine applications. It provides a unique combination of high shear strength with low density, high elongation, high temperature resistance and low resin uptake. M-Foam is the performance leader whether your application is slamming area or superstructure, hull or deck, using hand lamination, infusion or prepreg.
Corecell M-Foam delivers reliable processing through the benefits recognized in all Corecell products of fine cell size and unique knife-cuts giving low resin uptake in infusion processes. For prepreg, M-Foam offers high temperature resistance to allow shorter cure cycles and the confidence to process without fear of inhibition of prepreg catalysis. Where static properties are important, M-Foam delivers market-leading shear strength at a lower density. Where dynamic performance is crucial, the high elongation delivers higher useful properties and the toughness to give impact resistance and superior fatigue performance,
Corecell M-Foam is available in resin infusion format and is compatible with polyester, vinylester and epoxy resin systems.
|
|
ArmaFORM is the solution capable of coping with all requirements in the composite market, the innovative foam core made of PET foam is lightweight, strong and resistant to both heat and chemicals. It can be covered with most laminates and foils.
- Low weight (Available densities: 100 kg/m3 and 150 kg/m3)
- Extreme mechanical resistance through high compression strength, high stability and high shear modulus
- High structural stability
- High temperature resistance: has an excellent processing temperature.
- Short-term maximum temperature up to 200°C.
- Thermoformable
- High resistance to chemicals
- Very good thermal insulation due to its excellent thermal conductivity properties
- Very low water absorption due to its inherant cell structure
- Good bonding behaviour with all laminates and foils
- Easy to use with all common procedures used in composite applications
- Low toxic smoke emission and no corrosive gas development in the event of a fire
- Gridscore version also possible
|
|
| ... products without technical information |
| |
|
Metal ores are mainly produced and exist in formation and fracture band of rocks, mostly hard, brittle and broken rocks which are very abrasive. With good diameter keeping ability and abrasion resistant bond, our diamond impregnated drill bits drill fast and last long. The newly developed wire line bits are excellent for drilling holes deeper than 800 metres. Most drill bits are produced with hot press sintering, the bond hardness is HRC26-45
|
|
