Max. Lifting Capacity: 80 t x 3.0 m
Max. Crane Boom Length: 54.9 m
Max. Fixed Jib Combination: 42.7 + 18.3 m, 45.7 + 12.2 m
The CKE800 crawler crane from KOBELCO takes advantage of new technologies to raise performance to new heights. Winches with extremely powerful line-pull handle the toughest jobs, while the innovative "wettype" multi-disc braking system provides safe and sure control with minimal maintenance. A large winch capacity promotes ultra-smooth operation and enhanced component service life. An optional full-sized third winch enables the use of an impressive selection of attachments. Add these new features to the renowned power and reliability of KOBELCO cranes, and you have the ideal combination of lifting performance, economical operation and durability.
|
|
Max. Lifting Capacity: 70 t x 3.1m
Max. Crane Boom Length: 54.9 m
Max. Fixed Jib Combination:
42.7 + 18.3 m
45.7 12.2 m
The CKE700 crawler crane from KOBELCO takes advantage of new technologies to raise performance to new heights. Winches with extremely powerful line-pull handle the toughest jobs, while the innovative "wettype" multi-disc braking system provides safe and sure control with minimal maintenance. A large winch capacity promotes ultra-smooth operation and enhanced component service life. An optional full-sized third winch enables the use of an impressive selection of attachments. Add these new features to the renowned power and reliability of KOBELCO cranes, and you have the ideal combination of lifting performance, economical operation and durability.
|
|
HEAVY DUTY BASE MACHINE FOR FOUNDATION WORK
Max. Lifting Capacity: 80 tons x 3.6 m
Max. Boom Length: 54.9 m
Heavy-duty reliability from wet-type disc brakes. Powerful and large capacity drums to handle any job with power to spare. Drawing on long experience in crane manufacture, KOBELCO researched the bottom line in boosting operating efficiency in civil engineering and foundations work, and has unveiled a new generation of base machines.The BME800HD features power and precision in operations, simple controls and comprehensive safety features. Economic to run, easy to transport, kind to operator and environment alike. In every respect the BME800HD delivers a performance that sets new standards for heavy-duty foundation work.
|
|
Max. Lifting Capacity: 110 t x 3.6 m*
Max. Crane Boom Length: 70.1 m
Max. Fixed Jib Combination: 61.0 m + 21.3 m
The CKE1100 crawler crane from KOBELCO takes advantage of new technologies to raise performance to new heights. Winches with extremely powerful line-pull handle the toughest jobs, while the innovative "wettype" multi-disc braking system provides safe and sure control with minimal maintenance. A large winch capacity promotes ultra-smooth operation and enhanced component service life. An optional full-sized third winch enables the use of an impressive selection of attachments. Add these new features to the renowned power and reliability of KOBELCO cranes, and you have the ideal combination of lifting performance, economical operation and durability.
|
|
CRANE BOOM
Max. Lifting Capacity: 60 tons @ 3.0 m
Max. Boom Length: 51.8 m
FIXED JIB
Max. Lifting Capacity: 6.6 tons @ 16.0 m
Max. Fixed Jib Combinations: 42.7 m x 12.2 m
39.6 m x 18.3 m
The CKE600 crawler crane from KOBELCO takes advantage of new technologies to raise performance to new heights. Winches with extremely powerful line-pull handle the toughest jobs, while the innovative "wettype" multi-disc braking system provides safe and sure control with minimal maintenance. A large winch capacity promotes ultra-smooth operation and enhanced component service life. An optional full-sized third winch enables the use of an impressive selection of attachments. Add these new features to the renowned power and reliability of KOBELCO cranes, and you have the ideal combination of lifting performance, economical operation and durability.
|
|
Over more than 50 years, SENNEBOGEN has built up an excellent reputation in the materials handling industry worldwide. Our current range of state of the art, high performance materials handling machinery is the result of intensive development work. Flexibility and maximum customer benefit are the prime considerations when it comes to developing new products. Our consistent implementation of customer requirements means that the “green line” series can offer the perfect machine for any application.
SENNEBOGEN - Material Handling Machines are avaiable from 22t - 270 t service weight
|
|
Wharf truck crane designed and built on the basis of our large heavy duty rope excavator series. A stable construction and big, robust drive components guarantee good reliability and performance and long service life. We offer a comprehensive package of ancillary equipment to meet as many customer-specific requirements as possible including, e.g. elevating harbour cabs - eye level up to 11m.
SENNEBOGEN - harbour mobile cranes are avaiable from 38 t - 210 t service weight
|
|
CRANE BOOM
Max. Lifting Capacity: 135 tons @ 4.5 m
LUFFING BOOM
Max. Lifting Capacity: 80 tons @ 8.0 m
LONG BOOM
Max. Lifting Capacity: 44.3 tons @ 10.6 m
FIXED JIB
Max. Lifting Capacity: 26.8 tons @ 16.0 m
LUFFING JIB
Max. Lifting Capacity: 36 tons @ 12.0 m
Whether positioning bridge girders or constructing tall buildings, smooth and speedy operation is the most important performance. KOBELCO CKE1350 crawler crane is designed with latest job trends in construction environment. With its excellent operability, sensitive controls, and most important, its safety features, the CKE1350 achieves the best balance in its
overall performance. In regular crane or luffing jib operations for building construction, as well as general foundation work, there's more than enough capacity. The difference is in its basic performance.
|
|
Max. Lifting Capacity: 180t x 3.75m
Max. Crane Boom Length: 85.3m
Max. Long Boon Length: 85.3m
Max. Fixed Jib Combination: 73.2m + 30.5m
Max. Luffing Jib Combination: 54.9m + 51.8m
|
|
SL 6000
Max. Lifting Capacity: 550 ton
STANDARD
Max. Boom Length: 108 m
Max. Luffing Jib Combination: 60 + 72 m
HEAVY LIFT
Max. Boom Length: 108 m
Max. Luffing Jib Combination: 66 72 m
SUPER HEAVY LIFT
Max. Boom Length: 126 m
Max. Luffing Jib Combination: 84 84 m
The KOBELCO SL6000 crawler crane, with a lifting capacity of up to 550 tons, targets large-scale energy-related projects and large infrastructure installations. In addition to its superb lifting capacity, the SL6000's innovative unit assembly system' is designed to comply with transport regulations worldwide and to minimize labor required for assembly/disassembly. The SL6000's wide range of attractive features includes advanced safety devices, a wide, comfortable cab giving excellent visibility and other enhancements. KOBELCO is proud to premiere this much-awaited new model, which will further enhance our global reputation for tough, reliable, and outstanding performance.
|
|
Raw power and durability alone are no longer enough in today's fs construction environment, as operators and owners increasingly demand greater comfort and operability. KOBELCO has evolved accordingly with advanced hydraulic technology and onboard electronics that help you get the job done more quickly and reliably than ever before. But the real focus of our machine design is safety, both for the operator and for all the workers on the site. With their ideal combination of power, speed, comfort, operability, and advanced safety features, KOBELCO cranes are being used with confidence throughout the world. And now, we are proud to present them to the European market as the CKE Series.
CKE2500
Max. Lifting Capacity : 250t @ 4.6m
Max. Crane Boom Length: 91.4m
Max. Fixed Jib Combination: 76.2m + 30.5m
Max. Luffing Jib Combination: 61m 61m
|
|
Max. Lifting Capacity: 400 ton x 5.5 m
Max. Luffing Boom Length: 96 m
Max. Luffing Jib Combination: 78 m + 66 m
|
|
Lattice mast crawler cranes are enjoying a real renaissance, and with good reason. Outstanding lifting capacities, almost unlimited mobility on building sites, simple and quick to transport, self-assembly systems and low investment and running costs guarantee maximum benefit for operators. SENNEBOGEN's robust crawler cranes feature state-of-the-art technology, maximum flexibility and excellent economy.
SENNEBOGEN - Crawler Cranes are avaiable from 80 t - 180 t service weight
|
|
For nearly 50 years SENNEBOGEN has been developing heavy-duty universal rope excavators. Years of experience and the continuous intensive refinement of the product family have produced a complete range of high performance rope excavators featuring state-of-the-art technology. Adaptable to a wide range of jobs, extremely stable and with universal utility; rope excavators will remain indispensable in the 21th century.
SENNEBOGEN - HD crawler cranes are avaiable from 30 t - 180 t service weight
|
|
SENNEBOGEN telescopic cranes are extremely reliable and useful for assembly jobs on any building site, as well as in industry and wherever precise, safe load positioning is required. Low operating costs, compact construction and excellent mobility make our telescopic cranes on crawlers or wheels the ideal machinery for universal applications.
SENNEBOGEN - telescopic cranes are avaiable from 16t - 80 t service weight
|
|
SENNEBOGEN telescopic cranes are extremely reliable and useful for assembly jobs on any building site, as well as in industry and wherever precise, safe load positioning is required. Low operating costs, compact construction and excellent mobility make our telescopic cranes on crawlers or wheels the ideal machinery for universal applications.
SENNEBOGEN - telescopic cranes are avaiable from 16t - 80 t service weight
|
|
Over more than 50 years, SENNEBOGEN has built up an excellent reputation in the materials handling industry worldwide. Our current range of state of the art, high performance materials handling machinery is the result of intensive development work. Flexibility and maximum customer benefit are the prime considerations when it comes to developing new products. Our consistent implementation of customer requirements means that the “green line” series can offer the perfect machine for any application.
SENNEBOGEN - Material Handling Machines are avaiable from 22t - 270 t service weight.
|
|
|
|
|
|
Over more than 50 years, SENNEBOGEN has built up an excellent reputation in the materials handling industry worldwide. Our current range of state of the art, high performance materials handling machinery is the result of intensive development work. Flexibility and maximum customer benefit are the prime considerations when it comes to developing new products. Our consistent implementation of customer requirements means that the “green line” series can offer the perfect machine for any application.
Reliability and maximum availability are of crucial importance in most applications. SENNEBOGEN constantly focuses on developing robust, high performance technology that will have a long service life and require low maintenance even under the toughest conditions. Ergonomically optimised work stations and intelligent diagnostic systems ensure maximum efficiency in everyday work. The name “green line” represents SENNEBOGEN’s responsible approach: By increasing efficiency and reducing noise emissions, we are improving the environmental impact of our materials handling machinery.
SENNEBOGEN’s worldwide service network guarantees a high level of machine support and excellent spare parts availability.
|
|
|
Cranes are supplied by Hitachi Sumitomo Heavy Industries Construction Crane Co., Ltd. (a Hitachi group company). If you want information about these types of equipment, please visit their website.
|
|
HIGH PERFORMANCE
Comansa luffing-jib cranes are in demand, for high rise buildings on congested sites. To obtain the necessary high performance in material handling for high rise buildings, the new LCL-500 uses frequency controlled drives rated at 110 kW on both luffing and hoist movement.
With the Comansa frequency control, not only the maximum speed with any permissible load is possible, but also ultra-low speeds in the positioning mode. In this mode the frequency controlled system can drive thru the zero point, without applying the brake. Furthermore, for more efficiency of the system and a comfortable “feel” of the load, the control lever will adapt automatically its full control range to the given loads.
For high-rise buildings, the drum of our new 110 kW hoist winch has a standard cable capacity of 940m (3,083ft.). Optionally under consultation, a bigger drum is available with a cable capacity of 1,400m (4,593ft.). This capacity drum has been engineered for special high projects.
|
|
LUFFING-JIB CRANES
COMANSA completes its product range with the LCL Series, Luffing-JibCranes.
At the moment COMANSA offers three types, the LCL 200, LCL 250 and LCL 500 with a max. capacity of 12 tons (LCL 200 and 250) and 24 tons (LCL 500) and jib lengths of 50, 60 and 65 meters.
Characteristics:
- Parking position with very reduced radio
- Latest generation electronic control system
- Folding cross base compatible to all COMANSA tower sections
- Modular mast sections
- Frequency controlled motors for luffing and hoisting, with positioning quote!
- Progressive Slewing, with up to 3 motors, sequentially powered up as jib luffed down
- New generation of digital indicators in the cabin
|
|
LC 2100
170 –750 T/m Capacity cranes up to 48t Max. Load and 110kw Frequency-control hoisting. The perfect fast-track tool, with all the advantages of all the LINDEN COMANSA “Flat-tops”. Major contractor and rental companies' ideal, all-round, machine.
|
|
LC 500
25 years after the first Linden 8000 Modular Series cranes, Comansa continues the development of flat top cranes and is proud to present today its latest crane range, the LC 500 series.
The main objective of this new range is an update of the highly successful NT series by introducing the flat-top design and latest crane technology.
This new range of flat-top cranes consists of four models with jib lengths from 35 meters up to 50 meters with a maximum jib-end load of one tonne.
Advantages
- Easy transport and stocking.
- Economical, simple erection .
- Sequential erection/dismantling of jib-modules.
- Smaller height distance between two overlapping machines.
- Modular compatibility with NT-Series of towers, anchor stools and hoist mechanisms.
- Safer erection /maintenance.
|
|
|
|
|
|
LC 1100
The LC 1100 Series is available from summer 2008, and has a lot of innovations in comparison to the previous series of Linden Comansa cranes.
While keeping the Flat-Top modular system, the new LC 1100 series is even easier to erect, mainly because the hoisting and slewing systems and the electric cabinets will be pre-installed within the cat head at the factory and delivered in this way to the customer. The lesser weight of the slewing structure in comparison to the previous series, also helps to make an easier erection of the crane.
The 6 models also incorporate innovations on the motorization. The whole series have 2 slewing motors that reduce the stress of the crown; two hoist motors, with more hoist rope capacity on the drums and, consequently, higher under-hook heights; and the single or single / double trolley system with an innovative automatic change controlled by the operator from the cab, substantially improves the adaptability of the crane to different loads and thus increases working efficiency.
|
|
|
Builtrite offers 5 different back of cab/back of trailer mounted cranes for a wide variety of applications including scrap pick-up, trash pick-up, handling pipe, cable, jersey barriers and other construction materials. These cranes are designed for every day, heavy duty use. We also offer a wide variety of grapples for handling a wide variety of materials. We customize our product to suit our customers' needs.
|
|
|
North Shore Manufacturing designs and builds 8 different models of heavy duty electric over hydraulic pedestal cranes used for waste transfer stations and scrap handling applications. Since these are electrically operated, these cranes are excellent for working in indoor environments since they do not give off emmissions and they are relatively quiet as compared to diesel operated units.
|
|
|
Designed specifically for applications requiring particular manoeuvrability and compactness. LTC stands for "Liebherr-Telescopic-Compact", indicating the special compactness of the new crane design. A hydrostatic travel drive, the tightest of turning radii, active rear axle steering and shunting mode and the 7-section, 36 m compact boom distinguish the 55 tonner as the ideal lifting gear for crane assembly within restricted industrial buildings.
|
|
|
Compact industrial cranes are used for plant maintenance and material handling jobs. Simple to operate, these units feature carry decks and multi-mode steering allowing operation in tight quarters. These machines offer compact dimensions, good maneuverability, and excellent pick and carry capacities.
|
|
Floating sheerlegs are part of the scope of supply of Huisman-Itrec since 1981. Huisman-Itrec was then awarded with the order of engineering and manufacturing the Taklift 4, a 1600t floating sheerleg for Smit Tak.
Later orders brought the capacity for Huisman Floating Sheerlegs up to 3200t. We have also a design for a skiddable A-frame, at which both the lifting and transport are possible.
A special kind of these types of cranes is the Rambiz.
This is an ocean going twin hull lifting vessel, equipped with 2 x 1350t cranes.
This lifting vessel is originally built in 1996 to build the Vasco di Gama bridge in Lisbon, Portugal. The Rambiz (see picture) is modified after the project.
Some principal data (after the modification):
- Length: 85 m
- Beam: 44 m
- Depth: 5.6m loaded
- Lifting cap.: 3400t at 23m radius
- Lifting cap.: 3300t at 26.3m radius
|
|
C850 NG - Technical Data
- Lifting capacity: 90 t | 3.9 m
- Engine power: 440 kW
- Main winch: 250 kN
- Auxiliary winch: 110 kN
- Max boom length: 42 m
- Operating weight: 80 t
|
|
|
|
