Electrohms Current sensors (ac /dc) designed for use with different interfaces in closed loop applications.
FEATURES
High Accuracy
Fast response
Numerous packaging options
PCB Mountable
Suitable for automated assembly
0.25A to 1000A or higher
Economically priced
APPLICATIONS
Motor control applications
AC variable speed drives and servomotor drives
Uninterrupted power supply
Switch mode power supplies
Power Electric Applications
Industrial Motor Drives
|
|
|
|
|
|
Honeywell's closed loop current sensors consist of a Hall-effect sensor mounted in an air gap of a magnetic core, a coil wound around the core and a current amplifier. The current carrying conductor placed through the aperture of the sensor produces a magnetic field that is proportional to the current. The core concentrates the magnetic field which is measured by the Hall sensor. The Hall sensor is connected to the input of the current amplifier, which drives the coil. The current through the coil produces an opposing field to that provided by the current through the aperture. The magnetic flux in the sensor core is constantly controlled at zero. The amount of current required to balance zero flux is the measure of the primary current flowing through the conductor, multiplied by the number of turns on the coil. This current can be expressed as a voltage by passing it through a resistor. Variety of package styles available.
Best Used For:
Applications requiring high linearity and accuracy, fast response and low temperature drift such as variable speed drives, overcurrent protection, current feedback control systems, robotics and welding power supplies.
|
|
HE055T01
High Accuracy,
Fast response,
Numerous packaging options,
PCB Mountable,
Suitable for automated assembly,
50Arms
|
|
HE025T01 CLOSED LOOP TYPE
HE500T01 CLOSED LOOP TYPE
Electrohms Current sensors (ac /dc) designed for use with different interfaces in closed loop applications.
FEATURES
High Accuracy
Fast response
Numerous packaging options
PCB Mountable
Suitable for automated assembly
0.25A to 1000A or higher
Economically priced
APPLICATIONS
Motor control applications
AC variable speed drives and servomotor drives
Uninterrupted power supply
Switch mode power supplies
Power Electric Applications
Industrial Motor Drives
|
|
Honeywell open loop current sensors consist of a Hall-effect sensor mounted in an air gap of a magnetic core. The current carrying conductor placed through the aperture of the sensor produces a magnetic field that is proportional to the current. Open loop current sensors measure dc and ac currents, and provide electrical isolation between the circuit being measured and the output of the sensor. Variety of package styles available.
Best Used For:
Applications requiring galvanic isolation such as battery circuit management.
|
|
# For use at 20 kHz - 50 kHz and higher
# 1 Volt per Ampere sensitivity (variable through suitable termination)
# Available in molded (CS1XXX Series) or encapsulated (D18XX Series) versions
# 0.5 mm minimum wall thickness meets IEC 380, VDE 0730 and other requirements
# RoHS-compliant. Tin-silver over copper terminations.
|
|
A broad range of AC and DC current sensing devices with a variety of AC and DC contacts. Available with fixed and adjustable setpoints for underload and overload detection.
‘AS1’ Current Switches from NK Technologies combine a current transformer, signal conditioner and limit alarm into a single package. The AS1 series has an extended current input range, universal solid-state outputs and a wide frequency response. Available in a split core case or two styles of solid core cases.
Application :
Electronic Proof Of Flow
— No need for pipe or duct penetrations.
— More reliable than electromechanical pressure or flow switches.
Conveyors
— Detects jams and overloads
— Interlocks multiple conveyor sections
Lighting Circuits
Easier to install and more accurate than photocells.
Electric Heaters
Faster response than temperature sensors.
|
|
* The only two-in-one current/voltage detector designed for electrical testing
* Non-Contact AC Voltage detection
from 12V to 600VAC
* Non-Contact AC Current detection
from 200mA to 1000A
* Sensitivity adjustments to increase or
reduce sensor trigger threshold
* Current sensor detects current flow through shielded wires, conduit, and metal circuit breaker/junction boxes
|
|
* Non-contact AC Current range
is from 200mA to 1000A
* Locates current flow even where
voltage detectors cannot work
* Detects through shielded wires, conduit, and metal circuit breaker or junction boxes
* Sensitivity adjustment for locating wires/conduit through walls
* Audible and visible indication
|
|
|
An extensive range of high specification transducers providing measurement, isolation and conversion of electrical parameters into industry standard DC output signals, RS232 and Modbus. The ranges offer protection against high voltage and overload, and are resistant to vibration in harsh electrical environments.
|
|
VFD and SCR output waveforms are rough approximations of a sine wave. There are numerous spikes and dips in each cycle. ATR transducers use a mathematical algorithm called "True RMS," which integrates the actual waveform over time. The output is the amperage component of the true power (heating value) of the AC current waveform. True RMS is the only way to accurately measure distorted AC waveforms. Select ATR transducers for nonlinear loads or in "noisy" power environments.
The current waveform of a typical linear load is a pure sine wave. AT transducers measure the peaks of these sine waves, then calculate the average amperage. This works well on constant speed linear loads in a "clean" power environment. Select AT transducers for strictly linear loads on "clean" power.
|
|
| ... products without technical information |
| |
Non-contact displacement sensors using eddy current technology measure distances, displacements, or positions of any electrically-conductive target. These objects may have both ferromagnetic and non-ferromagnetic properties. Due to the high insensitivity to oil, dirt, dust, moisture, interference fields, etc. the eddy current principle is ideally suited to applications in harsh industrial environments.
Eddy current sensors designed for industrial use in factory automation, for machine monitoring, for inspection and for measuring and testing.
|
|
DIN Rail mounted electronics,
Aluminum encased electronics,
Edge-connector PCB electronics for OEM use.
Ranges: 0.5mm to 15mm
|
|
|
Eddy current transducers detecting contactless all metals with high accuracy and are not influenced by non-metallic media between target and probe tip. Oscillating applications can be realised with high measurement frequencies up to 10 kHz.
|
|
CURRENT SENSORS - FLY LEAD TYPE
Electrohms's products comply with system standards likes IEC 62053-21 [supercedes IEC 1036], IS 13779.
Applications
Metering & energy Management
Protection and Control
Custom current sensing solutions Electrohms specialises in developing special CT's for individual custom requirements
|
|
|
Toroid Corporation offers two low cost standard design current transformers. Both are used in applications where you want to detect or measure AC-currents with no need for tight tolerances. Typical applications include power limiting controllers for air conditioning equipment, electrical heating systems, electrical furnaces, and motor drives.
|
|
