| The Jet Edge Versacutter is a motion controlled, portable abrasivejet cutting and beveling system. The system is used in a variety of cutting applications including pipelines, steel reinforced concrete, professional reactor vessels and fabricated metal structures. The Versacutter cuts without flames and does not generate heat. This makes it possible for operators to cut in areas where flames are restricted, and eliminates heat-affected zones. |
|
Jet Edge's High Rail Gantry System will produce complex parts out of virtually any material. The overhead design allows full access to the work envelope and raises the critical components out of the process environment.
The stress-relieved steel fabricated frame provides unparalleled rigidity coupled with welded lightweight dynamic beams for stable but fast operation.
Moving elements are supported on THK linear ways with precision duplex pair factory ground and matched bearing manufacturer sets. |
|
Abrasive waterjet systems excel at three-dimensional cutting, and Flow manufactures a complete line of turnkey systems for cutting complex shapes. The AF-Series cuts with precision accuracy, at speeds up to 400 inches per minute.
Specifications
Size/Work Envelope:
- Base: 6 ft, 12 ft, 16 ft, 20 ft
- Industrial bridge: 8 ft; custom sizes also available
Accuracy: ± 0.005 inches
Repeatability: ± 0.003 inches
Traverse Speed:
- X- & Y-axis: 0 to 900 ipm
- Z-axis: 0 to 450 ipm
Contour Speed: 0 to 400 ipm
Control System: Siemens 840D CNC controllers
Z-axis Adjustability: 24 inches
|
|
The Waterjet Cutting System
The waterjet - a tool with which you can master nearly every cutting task!
Our proven and easy-to-use Waterjet Cutting System JETMax is for daily purposes. These machines are easy to operate and are delivered with all options and accessories you need for cutting with water or with abrasives - at a great price! An optimization in price and performance enable a fast repayment also for small and medium sized companies.
The key benefits are that this waterjet cut does NOT cause any thermal stress and does NOT set free any toxic dust and/or vapour. The only tool we are using is pure water or - in abrasive mode - water and garnet sand. That´s it!
Delivery Premium includes:
- Rustproof, welded system structure of aluminum and high grade steel
- Catcher with grid layer
- Hidden and encapsulated guidance devices
- Abrasive dosage system with storage bin
- Safety system
- Complete high pressure tubing between cutting table and hp-pump
- Servo-Control NUM AXIUM POWER
- Drive system NUM MDLU
- PC with waterjet software EasyCut (purpose on several Professional pcs possible)
- Brushless digital servomotors
- Manual operating device
- Z-axle with automatic height- and collisionsensor
- Hp-cock with abrasive cutting set
- Abrasive dosage system NC-controlled with sensor to prevent system failure
- Abrasive transfer system
- Tool kit incl. all special tools for hp-pump and cutting valve
- Spare parts kit for hp-pump and cutting valve
- Start kit production facilities incl. abrasive
- Training of waterjet users
- High pressure pump 37 kW Premium
Working Areas Premium:
- from 1.000 x 1.000 mm up to 12.000 x 3.000 mm |
|
| Large scale precision machining: For larger parts or multiple parts from large stock up to 5' x 10' (1.5 m x 3 m). The 60120 JetMachining Center cuts complex flat parts out of most materials including metal, plastic, glass, ceramics, stone and composites directly from a CAD drawing or .DXF file. Extremely hard, reflective and nonconductive materials can also be cut, making it a valuable addition to existing shop capabilities. No tool changes or complex fixturing dramatically reduces setup times and the smooth finish often eliminates the need for secondary machining. |
|
Model Fabricator
Large format abrasive waterjet cutting for stone or metal fabrication shops
at a price you can afford.
Positioning Accuracy: +/-.005" (+/- 0.13 mm)
Table Size: 174" x 91" (4419 mm x 2311 mm)
Footprint: 243" x 134" (6172 mm x 3403 mm)
Weight: 10,000 lbs table only (4536 kg)
Height: 144" (3657 mm)
Expandable X Travel : 168" + 72" + 72 " (4267mm ou 6000 mm ou 7830 mm
Y travel : 80 " (2032 mm)
|
|
Model 55100
Precision machining workhorse: From prototypes to production runs, create parts in a variety of materials in sizes up to 4' x 8' (up to 2.5 m x 1.4 m).
Dynamic Positioning Accuracy: +/-.003" (+/-0.08 mm)
Table Size: 126" x 65" (3200 mm x 1650 mm)
Footprint: 155" x 94" (3937 mm x 2388 mm)
Weight: 8,000 lbs table only (3629 kg table only)
Height: 76" (1930 mm)
X-Y Travel: 100" x 55" (2540 mm x 1400 mm) |
|
Cutting system
The STM Waterjet System is ideally suited for short-run part production, just-in-time manufacturing, bulk production, prototyping and product development. It does not require tool changes or complex fixturing and allows you to reduce setup times by up to 50%. In addition, the smooth finish does not require expensive and time-consuming secondary machining. You will see that STM Waterjet Systems considerably increase your profitability!
Features & Options
Standard Features
• Entire system in stainless steel and aluminum
• Covered slideways, flat side walls
• Brushless, digital AC servo motors
• Robust and durable system due to box and pinion drive
• Pneumatic-actuated QuickUP Z-axis
• EasyCut, the waterjet cutting program
Options and Accessories
• Automatic height sensor
• Collision protection
• Pump-pressure control by the cutting program
• Abrasive dosing by the cutting program
• Automatic abrasive desludging system
• Abrasive industrial hopper ensures 20% increase in cutting performance
• Up to 4 waterjet cutting heads
• 40 m/min rapid transverse speed
• 0-35 m/min contouring range
|
|
High Productivity with an Integrated, Compact Design
The Integrated Flying Industrial bridge (IFB) incorporates a design that combines the motion control, pump and high-pressure components of a waterjet parting tool into one compact machine. It consumes minimal floor space, provides excellent operator access, and is configured for easy material loading and unloading. This abrasive waterjet machine is capable of cutting any metal, stone, tile, and glass material with unmatched accuracy and intricacy.
The World's Most Popular Waterjet Cutting System
The Integrated Flying Bridge is a design that has been field proven through over a thousand installations worldwide. The robust open gantry is designed and constructed using advanced finite element engineering to ensure it will consistently deliver an extremely high level of accuracy and performance well into the future.
For maximum productivity, it's possible to equip the machine with optional features such as dual cutting heads, Dynamic Waterjet®, height and collision detectors, and an automatic abrasive removal system to keep the catcher professional tank clean and eliminate downtime associated with having to remove used abrasive. Finally, because the machine is equipped with FlowMaster, Flow's intelligent Windows-based PC control and programming system, it is extremely easy to learn and simple to use. No waterjet or programming experience is necessary to begin producing perfect parts.
|
|
The Waterjet Cutting System
The waterjet - a tool with which you can master nearly every cutting task!
Our proven and easy-to-use Waterjet Cutting System JETMax is for daily purposes. These machines are easy to operate and are delivered with all options and accessories you need for cutting with water or with industrial abrasives - at a great price! An optimization in price and performance enable a fast repayment also for small and medium sized companies.
The key benefits are that this waterjet cut does NOT cause any thermal stress and does NOT set free any toxic dust and/or vapour. The only tool we are using is pure water or - in abrasive mode - water and garnet sand. That´s it!
Delivery Ecocut includes:
- Rustproof, welded system structure of aluminum and high grade steel
- Catcher with grid layer
- Hidden and encapsulated guidance devices
- PC-control
- Brushless servomotors
- Waterjet software
- Hp-valve with abrasive cutting head
- Abrasive dosage system with storage case
- Safety system
- Complete high pressure tubing between cutting table and hp-pump
- High pressure pump 37 kW Eco
Working Areas Ecocut:
- JETMax HS 1010 1000 x 1000 mm
- JETMax HS 2515 2500 x 1500 mm
- JETMax HS 3015 3000 x 1500 mm
- JETMax HS 3020 3000 x 2000 mm
- JETMax HS 4020 4000 x 2000 mm |
|
The Waterjet Cutting System
Our compact cutting systems unite the high accuracy of ball screws with minimal dimensions. The cutting systems are available with protective hoods or with light curtains.
Advantages
- Compact dimensions
- High accuracy because of ball screws with direct measuring system
- Ergonomical control rack
- Individual demands possible
- Protective hoods or light curtains
Technical data:
- Working area: 800 x 500 x 150 mm
- Dimensions: 1.550 x 1.250 x 2.000 mm
- Feed rate: 10 m/min
- Accuracy: ± 0,05 mm
- Max. Working area: 1.000 x 1.000 x 150 mm
Scope of supply:
- Welded machine rack
- x-, y-, z-axis with totally enclosed ball screws
- Catcher made of high grade steel with integrated flushing device
- Brushless AC-Servomotors
- Servo-drive system with superordinate PC-contro including control terminal with monitor, professional keyboard and mouse
- CAD/CAM-Software CutCAM to generate and process your cutting data
- High pressure pump, flow rates according to your needs
- Complete high-pressure tubing between cutting table and pump
- Cutting cock with abrasive mixing chamber and accessories
- Abrasive dosage system with storage vessel and sensor
- Pressure sensor manufacturer and indication at the machine
- Protection hood or light barrier as safety system
Optionally available:
- Non-standard workpiece support
- High-speed drilling manufacturers of spindle as parallel working head
- NC controlled high-pressure pump and abrasive dosage
- Water processing
- Separation of abrasive material and cutting water
- Multi-stage waste water processing systems
- Supervision of process-specific parameters for wear control and increased process security |
|
| The Model 5555 JetMachining Center cuts complex flat parts out of most materials including metal, plastic, glass, ceramic and composites directly from a CAD drawing or .DXF file. JetMachining is ideal for short-run part production, just-in-time manufacturing, tooling and prototype part development. No tool changes or complex fixturing reduces setup times by at least 50%. |
|
Model 2626
Smaller work envelope: Compact size, precision abrasivejet machining of smaller parts.
Dynamic Positioning Accuracy: +/-.003" (+/-0.08 mm)
Table Size: 46" x 31" (1168 mm x 787 mm)
Footprint: 116" x 72" (2946 mm x 1829 mm)
Weight: 3,000 lbs table only (1364 kg table only)
Height: 92" (2337 mm)
X-Y Travel: 29" x 26" (737 mm x 660 mm)
|
|
The Waterjet Cutting System
The waterjet - a tool with which you can master nearly every cutting task!
Our proven and easy-to-use Waterjet Cutting System JETMax is for daily purposes. These machines are easy to operate and are delivered with all options and accessories you need for cutting with water or with abrasives - at a great price! An optimization in price and performance enable a fast repayment also for small and medium sized companies.
The key benefits are that this waterjet cut does NOT cause any thermal stress and does NOT set free any toxic dust and/or vapour. The only tool we are using is pure water or - in abrasive mode - water and garnet sand. That´s it!
Delivery Ecocut includes:
- Rustproof, welded system structure of aluminum and high grade steel
- Catcher with grid layer
- Hidden and encapsulated guidance centers
- PC-control
- Brushless servomotors
- Waterjet software
- Hp-valve with abrasive cutting head
- Abrasive dosage system with archive bin
- Safety system
- Complete high pressure tubing between cutting table and hp-pump
- High pressure pump 37 kW Eco
Working Areas Ecocut:
- JETMax HS 1010 1000 x 1000 mm
- JETMax HS 2515 2500 x 1500 mm
- JETMax HS 3015 3000 x 1500 mm
- JETMax HS 3020 3000 x 2000 mm
- JETMax HS 4020 4000 x 2000 mm
Optionally available:
Several cutting heads on one cross-beam and/or several z-axes |
|
BENEFITS:
Remove Material and Shape Constraints of Electronic Component Design
Proven Omni-directional and Curvilinear Cutting System
Simple, Stable, and Reliable
High Reliability (CPK > 1.66)
High Productivity with 24 Hour Uptime
Superior Cut Edge Quality
Cut & Professional drill on Same Machine
Heat and Smoke Free
No Component Melting
No Lead frame smearing
No Substrate Delamination
No Edge Chipping
Minimal Programming & Setup Time
Low Maintenance Requirements
STANDARD FEATURES:
High Accuracy
Waste Removal System
Paser ECL Abrasive Waterjet Cutting Head
Vacuum Assist
Integrated Vision Positioning center
Abrasive Bulk Transfer System
Process Monitoring & Data Logging
Small Footprint
Worldwide Technical Support
OPTIONS:
Auto Loading/Unloading & Wash/Dry Module
Part Fixtures
Service Contract
SPECIFICATIONS:
Gantry Design
Modularized Design
Linear Servomotor Drive System
Cutting Envelope XYZ 820mm x 480mm x 90mm
Max Traverse Speed 833mm/s
Max Cutting Speed 233mm/s
Accuracy = ± 0.025mm
XY Repeatability ± 0.025mm
Auto Holding System
Manual Load/Unload
|
|
Waterjet cutting systems for the future
A brand new generation of STM Waterjet Systems has been developed to meet the specific needs of our clients and their special cutting applications. A modern concept and efficient design characterize a reliable system that fulfils the latest shape cutting requirements.
STM Waterjet Systems offer our clients flexible, high-performance and tailor-made cutting solutions for any material and desired shape.
Powered by a HYTRON High pressure pump from Böhler/ Austria with a maximum pressure of 400 MPa, STM Waterjet Systems find their daily, efficient application in cutting various materials up to a thickness of 100mm, including:
• industrial gaskets, plastic materials, rubber
• foam materials
• stainless steel, aluminum, copper, titanium
• professional carbon fiber reinforced plastic, carbon fiber, composite materials
• granite, marble, glass, ceramics
The key benefits are that this waterjet cut does NOT cause any thermal stress and does NOT set free any toxic dust and/or vapor. The only tool we are using is pure water or – in abrasive mode – water and garnet sand. That’s it!
The specially designed EasyCut waterjet cutting program uses CAD shapes for “wysiwyg” (what you see is what you get) programming and guarantees user-friendly handling and high-quality cutting performance. |
|
Waterjet cutting is particularly advantageous where conventional methods only provide insufficient quality. No further additional costs due to reworking or lower processing speed. Since during the cutting no gases or vapors are generated, the method is also safe, clean and environmentally friendly.
Modern waterjet cutting systems continually boost the process optimization and quality improvement in the processing industry. |
|
The Waterjet Cutting System
The waterjet - a tool with which you can master nearly every cutting task!
Our proven and easy-to-use Waterjet Cutting System JETMax is for daily purposes. These machines are easy to operate and are delivered with all options and accessories you need for cutting with water or with abrasives - at a great price! An optimization in price and performance enable a fast repayment also for small and medium sized companies.
The key benefits are that this waterjet cut does NOT cause any thermal stress and does NOT set free any toxic dust and/or vapour. The only tool we are using is pure water or - in abrasive mode - water and garnet sand. That´s it!
Delivery Premium includes:
- Rustproof, welded system structure of aluminum and high grade steel
- Catcher with grid layer
- Hidden and encapsulated guidance equipment
- Abrasive dosage system with storage bin
- Safety system
- Complete high pressure tubing between cutting table and hp-pump
- Servo-Control NUM AXIUM POWER
- Drive system NUM MDLU
- PC with waterjet software EasyCut (purpose on several Professional pcs possible)
- Brushless digital servomotors
- Manual operating device
- Z-axle with automatic height- and collisionsensor
- Hp-cock with abrasive cutting set
- Abrasive dosage system NC-controlled with sensor to prevent system failure
- Abrasive transfer system
- Tool kit incl. all special tools for hp-pump and cutting valve
- Spare parts kit for hp-pump and cutting valve
- Start kit production facilities incl. abrasive
- Training of waterjet users
- High pressure pump 37 kW Premium
Working Areas Premium:
from 1.000 x 1.000 mm up to 12.000 x 3.000 mm |
|
Model 80160
Large scale precision machining: For larger parts or multiple parts from large stock up to 6' by 12' (up to 2m x 4m)
Positioning Accuracy: +/-.003" (+/-0.08 mm)
Table Size: 174" x 91" (4419 mm x 2311 mm)
Footprint: 243" x 134" (6170 mm x 3405 mm)
Weight: 10,000 lbs table only (4500 kg table only)
Height: 144" (3660 mm)
X-Y Travel: 160" x 80" (4267 mm x 2030 mm) |
|
Model 2652
Quick turn-around for the general machine shop: precision machining of small to medium-sized parts.
Dynamic Positioning Accuracy: +/-.003" (+/-0.08 mm)
Table Size: 69" x 30" (1750 mm x 760 mm)
Footprint: 139" x 67" (3531 mm x 1702 mm)
Weight: 3,320 lbs table only (1505 kg table only)
Height: 77" (1955 mm)
X-Y Travel: 52" x 26" (1320 mm x 660 mm) |
|
Cutting system
The STM Waterjet System is ideally suited for short-run part production, just-in-time manufacturing, bulk production, prototyping and product development. It does not require tool changes or complex fixturing and allows you to reduce setup times by up to 50%. In addition, the smooth finish does not require expensive and time-consuming secondary machining. You will see that STM Waterjet Systems considerably increase your profitability!
Features & Options
Standard Features
• Entire system in stainless steel and aluminum
• Covered slideways, flat side walls
• Brushless, digital AC servo motors
• Robust and durable system due to rack and pinion drive
• Pneumatic-actuated QuickUP Z-axis
• EasyCut, the waterjet cutting program
Options and Accessories
• Automatic height sensor
• Collision protection
• Pump-pressure control by the cutting program
• Abrasive dosing by the cutting program
• Automatic abrasive desludging system
• Abrasive industrial hopper ensures 20% increase in cutting performance
• Up to 4 waterjet cutting heads
• 40 m/min rapid transverse speed
• 0-35 m/min contouring range
|
|
High Productivity with an Integrated, Compact Design
The StoneCrafter incorporates a design that combines the motion control, pump and high-pressure components of a waterjet parting tool into one compact machine. It consumes minimal floor space, provides excellent operator access, and is configured for easy material loading and unloading. This abrasive waterjet machine is capable of cutting any natural or manufactured stone, tile, and glass material with unmatched productivity and accuracy.
Benefits
Quickly and easily cut stone and engineered solid surface materials
Improve shop output and maximize material yield
Unique design saves valuable floor space and provides easy access to work zone from 4 sides at an ergonomically correct height
Proven station tool design and technology for durability and reliability
No CNC or abrasive waterjet experience necessary: "Trained in a day, proficient in a week"
Cut parts using virtually any CAD file, or scan drawings directly into FlowMaster® Professional software
Standard Features
Choice of 60,000 psi or 87,000 psi HyperPressureTM intensifier pumps
CleanCutTM material support system with heavy duty construction and easy loading design
Rugged two-piece construction provides accuracy and durability
FlowMaster Windows®-based PC machine control and programming with custom stone software with popular sink .dxf file library
PASER® ECL Plus abrasive waterjet cutting system
Swiveless plumbing for fast cutting
WaterVeyorTM abrasive removal and recovery system (optional)
Height and collision sensors (optional)
Specifications
Net Cutting Area and Speed
X-axis (industrial bridge) and Y-axis (base): 6.5 ft x 12 ft (1.95 m x 3.7 m)
Z-axis: up to 8 in (200 mm)
Rapid transverse maximum: 500 in/min (12.5 m/min)
Contouring range: 0 - 150 in/min (0 - 3.8 m/min)
Machine Positional Specifications (per linear axis at 68 %u02DAF ± 3 %u02DAF /20 %u02DAC ± 2 %u02DAC)
Linear positional accuracy: ± 0.003 in (0.08 mm)
Repeatability: ± 0.002 in (0.05 mm)
Specified in accordance with ISO 230-2 and applicable NMTBA specifications
Drive System
Digital AC servo motors with closed loop feed
X- and Y-axis utilize a suppliers of ball screw with driven nut
X- and Y-axis utilize recirculating ball, linear bearings and hardened precision ways
Full protection package (covers and internal bellows) for drive system and ease of machine maintenance
|
|
This machine can cut flat and soft material into various shapes by discharging ultra high-pressure water.
With NC control, precise cutting can be achieved even for complicated shapes. |
|
Ultra-precise abrasivejet machining: When you need ultimate precision with an abrasivejet. The Model 2626|xp JetMachining Center is a programmable abrasive waterjet machining system that produces complex parts out of most materials directly from a CAD drawing or .DXF file. All stainless steel construction (catcher tank, slats and slat holders) prevents rust contamination for medical applications.
X-Y Cutting Area 29" x 25" (737 mm x 635 mm)
Table Size 46"x 31" (1168 mm x 787 mm) |
|
5-axis cutting head with IKC technology
Efficient head handling for making inclined cuts and
controlling the kerf of the cutting groove
(IKC – Intelligent Kerf Compensation) |
|
| Accustream waterjet cutting machines manufacturers can be integrated into a variety of waterjet cutting applications. Whether you are purchasing a new system or looking to upgrade out-dated waterjet cutting equipment, Accustream can be of assistance. For new cutting systems, Accustream partners with integrators which can provide standard cutting tables, 5-axis cutting machines and custom automated cutting solutions. |
|
|
