Horizontal decoiling reels
Hydraulic coiling and decoiling reels
One-sided vertical reels
Double-sided decoiling reels
Customised coiling and decoiling reels
Our coiling and decoiling reels covers a wide range of applications in the sheet metal proccesing. According to the needs and wishes we produce different reels. The maximum strip width is 2000 mm and the maximum strip thickness 7 mm. The loading capacity goes up to 25 t.
Base frames of decoilers are manufactured as rugged welded constructions. The internal and external diameters of the coils are aligned to norm. There are various possibilities of braking and drive modes.
The spreading is operated hydraulically by shuffled cotters. Decoilers with low capacities are partially operated by bell-crank lever systems.
Further accessory equipment, like:
- double decoiler,
- press rolls,
- conical drums,
- coil load cars, etc.
relievable the coil change, coil load and coil feed.
|
|
The automated lines for sheet metal and rod manipulation, respecting the differences according to the load type and size being handled, consist of the following:
-Decoilers: The decoiler represents the first stage in the process and its mission is to coil / uncoil the reel of sheet metal or other material used and supply it to the press, either directly or by means of a feeder, a feeder-levelling machine.
The decoilers are programmed so they coil or unwind by means of the time control loop (connection and disconnection) and with clockwise or counter-clockwise rotation.
|
|
Single coil unwinder for any kind of cable, coil size Ø 295mm outside, 180-80mm inside; 80mm high
Highest performance of TRONÍC to unroll any kind of cable
thanks to its new singular shape even without holder by
simply laying it on any surface.
Extremely light , just 0.7 kg, free and easy to unroll. No
cable could become twisted inside the box at any speed.
Very serviceable and practical way to put the coil in
thanks to a simple pressure in the middle of the box
to remove the top cover and the easy solid rack
adjustable system to fasten the coil.
|
|
| Suitable for versatile application with segment -, high performance - and CNC controlled spring coiling machines. The wire can be coiled off both vertically and horizontally, depending on the type of decoiler. |
|
The printed products from a web press could be delivered as forms or sheets, as folded in various sizes or could also be rewound into a new roll. This last-mentioned production form is often called continuous (non-stop) roll-to-roll production.
MEGTEC supplies automatic rewinders for the printing and converting industries. The product line is comprised of small machines with web widths in the range of 14 inches (350 mm) up to large rewinders made for widths well over 40 inches (1000 mm). Depending on the model, the web speed could be up to 2,450 fpm (750 m/min).
All rewinders are specially designed to produce high quality rolls in a variety of materials producing rolls that are consistently firm right from the core. The perfect rolls produced in a MEGTEC rewinder increase your company's productivity and profitability. |
|
The mechanical handling system on Model SBE 15.SF enables one operator alone to swiftly and saftely transfer coils from the stotage position onto the decoiler without having to use lifting equipment.
A drive is provided so that the strip is decoiled without being strained. |
|
Dynamics and reliability, user friendliness, plant safety
and short set-up times are features of the decoilers made by ARKU. They accommodate coils weighting up to 30 tons. |
|
Application:
The MRH and MRM reels combine Minster's considerable knowledge and experience with thoughtful customer feedback and extensive market analysis. The result is a line of reels featuring carefully thought-out improvements and very competitive pricing that will increase your productivity and profits. The MRM reels are manually operated, offering a high-quality, low-cost alternative to our hydraulically-powered MRH reels for light duty applications.
|
|
The frame is fabricated from steel pipes.
- The ND models are fitted with an adjustable brake.
- Support by orientables roll bearings.
- The mandrel from steel by 3 inclined plane with expansion range from 470 to 550 mm and hydraulic cylinders which are activated by a electric pump.
- Brake with pneumatic clamp.
- Planetary gear-box + trasmission by double or triple chian. |
|
DIMECO offers a comprehensive range of uncoilers for coils from 50Kg to 25 tons, up to 2000mm wide.DIMECO uncoilers can afford 1,2 or even 4 coils. They are equipped with a pneumatic brake or driven.
Gifted with a particularly robust design, our machines are manufactured in mass production and can be fitted with a number of accessories, which improve stamping line productivity and enhance personnel safety (pressure arm, lateral guides...).
Our coil-car range from 1 to 25 tons makes coil handling easier.DIMECO uncoilers own dedicated features to process HLSA steels or delicate material (pre-coated, copper, mirror finished aluminium...)
The « PITSTOP » configuration allows automatic strip feeding and recoiling and offers an automatic line parameters adjustment when selecting a new job in the press terminal.
Our machines can uncoil from top or bottom, clockwise or anticlockwise and even without loop.
When combined with a DIMECO roll feeder, DIMECO uncoiler speed is automatically tuned to the press rate and to the feeder output. |
|
DLC 5000 Match Speed Splicer
Standard equipment & features:
Match speed splicer with split arms to load 2 full rolls
Core acceleration and braking by 4 quadrant AC motors
Control and regulation by PLC
Modem for remote diagnositics
Splice pattern straight-across, V or W
Black pasting tabs with photo cell detection
Simultaneous cut & paste under tension
Local push-button panel and WEBVIEW
Simple roll loading directly from floor
Arm automatic positioning
Auto load pre-position and auto chucks
Automatic roll alignment before splicing (aligns on operator side)
Normal and Symmetric arrangement for centre loading
MEGTEC motorized web-up device or provision for press system with web-up assist
Motorized cocking roller adjustment to assist running deformed rolls
Independent frames, no mechanical connection to the press
Fully assembled, pre-wired, pre-piped and tested for easy installation
Splice efficiency data counter
CE compliant
Versions at additional cost:
Remote control panel for sidelay, web tension and brakes
WEBCOM (WEBVIEW + interface for press communication i.e. Ethernet, Profibus, Serial Link)
Integrated DSA Infeed 180daN (for 67" (1700 mm) width) or 210daN (for 82" (2080 mm) width)
Automatic roll-load system/interface
Arm web feedback (splicer sidelay interfaced to web guide)
UL508A certification
6-roll web-over assembly (MEGTEC standard design)
QUALIROLL Paper Management System
Load bearing splicer (press supporting) |
|
| Also available in motorized version, this reel features industry preferred design with a sturdy one piece all welded "A" frame base, low profile outlet riser and open drum slot for non-crimping, flat smooth hose wrap. |
|
Series 40 offers considerable strength in a lighter weight aluminum frame that is combined with stainless steel fasteners and powder coated flanges to offer the greatest amount of corrosion resistance and durability. It handles larger diameter hose and is nearly limitless with regaurds to fit and function. To view a listing of our standard models or request a qoute, please visit us on the web at www.reelcraft.com.
|
|
HR/UR/TW series: hosereel/umbilical/transponder
Hose reel, Umbilical or Transponder winches are mainly built for the purpose. Winches are built to order and can be executed with a self braking worm gear or planetary gear, depending on the load required. The drive can be either electric, hydraulic or pneumatic.
The Hose reels are mainly used to spool hoses for Fresh Water supply, MDO Fuel supply and Hydraulic Oil or to spool Electrical Power Supply Cables.
The Umbilical winches in general are used to spool a combination of hoses, signal cables, coax or even Fibre Optic cables. Most of them come with slip rings and/or rotating swivels.
Transponder winches used for powered transponders are mainly used with electrical signal cables and have in most cases an electrical slip ring mounted. Winches can be supplied complete with A frame if required.
EMCÉ has supplied systems for all applications including reels with SS swivels of 6" or slip rings for High Voltage.
Applications we have supplied for can be found on the following type of constructions; Offshore Heavy lift vessels, Offshore Semi Subs, Diving Support vessels, Research vessels, Cable and Pipe laying vessels and Offshore Pile Driving barges.
|
|
| Hannay Reels provides thousands of standard hose reel models and unmatched custom design and manufacturing capabilities for virtually limitless applications. The most prominent include air hose reels for pneumatic tools and machinery; water hose reels used for washdown, power washing, potable water, or in-plant fire protection; dual hose reels for oxygen/acetylene welding; and hydraulic hose reels for powering tools and machinery. |
|
| Hannay Reels provides manual, spring and power rewind cable reels for a variety of industrial applications, including rescue and haz-mat operations, grounds maintenance and repair, video inspection, portable lighting, and broadcast and entertainment industry applications. Hannay also manufactures reels to handle arc welding cable, static grounding cable and electrical cable for power tools, lights, machinery and generators. All Hannay reels can be mounted on walls, ceilings and worktables. |
|
The Tecreel range of self-retracting hose reels provides an efficient means of conveying hydraulic power from fixed to moving points on cranes, lorry mounted cranes, forklift trucks and other materials handling equipment. An integral coil spring ensures that the hoses remain constantly under tension
Maximum operating pressure 300 Bar (4350 Ibf/in)
Large ports provide efficient flow characteristics
Siamese 1/4in, 5/16in, 3/8in or 1/2in bore thermoplastic hoses
Cassette loaded coil spring for safety and easy removal
Left or right hand mounted, easily changeable on site
|
|
| 1275 Series dual hose reel features dual plumbing with two swivel inlets and two low profile outlest that compliment the open drum slot providing a non-crimping, flat smooth hose wrap. Features one piece all welded "A" frame construction. |
|
- Motorized cable reels -
Conductix-Wampfler engineers were from the very beginning convinced that permanent magnetic couplings offered a host of advantages. As a result, they developed a complete series of motorized cable reels that make it possible to configure efficient, economical standardized systems to meet all power requirements and cover virtually all applications. In addition, customers can choose from various drive options. |
|
| Hannay Reels provides both hose and cable portable reels in a variety of sizes for many applications, including: broadcasting, industrial maintenance and on-site repair, construction, grounds and lawn maintenance, entertainment, fire and rescue, plus power tools and lights. |
|
| Spring Driven "Power Cord" reels are heavy duty, industrial grade power sources. They replace tangled extension cors and self retract to increase safety, productivity and efficiency. |
|
The L4000 and L5000 Electric Reels are designed to be compact, but are still capable of holding 35-50ft of tangle-free power cable. They are spring retractable with latch and engineered for industrial use. Compact for critical space requirements, these reels are finished with a durable abrasion resistant baked-on powder coat, keeping these reels looking new and maintenance free through years of use. All models supplied with cord are equipped with a 4-5ft. pigtail and three prong plug. Made with wall, ceiling, or bench mounts in mind, the L4000 and L5000 models also come standard with adjustable cord stop.Optional fluorescent lights, outlet receptacles, and incandescent hand lamps are available as options.
|
|
- Spring cable- and hose reels -
Conductix-Wampfler spring cable reels provide the optimum solution for all hoisting and material-handling applications. Rugged, heavy-duty construction guarantees exceptional reliability under extreme operating conditions.
- Spring cable reels -
Spring cable reels are used for the automatic reeling of cables on various types of moving equipment. These include most hoisting and other material handling devices; e.g. portal cranes, grabs, magnets, lift and working platforms, machinery, excavators, mobile cranes, transfer cars, transport systems and skimmers in purifying plants.
- Spring hose reels -
Spring hose reels are used for the automatic reeling of hoses on various types of moving equipment. Mostly these machines are track-based and operate in a straight line. The orientation of these applications can be horizontal or vertical. |
|
Woodhead cable reels are suitable for use in situations requiring portable lighting and power tools or a movable power supply, including mobile electrical equipment and are appropriate for indoor or outdoor use, and available with and
without cable. |
|
| Factory-matched spring-rewind safety reel retracts up to 80% slower than standard spring rewind reels. |
|
| The ReelTek's unique hybrid design offers great strength and reliability at a lighter overall weight than conventional reels. It is designed to hold 1/4", 3/8", and 1/2" I.D. hose up to 50' in length. It is suitable for air/water, oil, and grease applications. Other features include: Composite glass-filled polymer spring case, lath pawl mounts on guide arm to eliminate "latch-out" at full extension, ribbed base and upright, multi-positional guide arm that adjusts to seven different positions, and field tested long-life swivel. For more information about the ReelTek Series or Reelcraft in general, please visit us on the web at www.reelcraft.com. |
|
Aero-Motive® hose reels are designed to provide top performance, long service life and ease of maintenance. Our hose reel line includes: Open Spring Driven, Hand Wind, Enclosed Spring Driven, Stainless Steel, and Specialty Reels.
Aero-Motive® Open Spring Driven Hose Reels are designed to withstand the toughest industrial challenges. Ideal for production lines, material handling equipment, service areas, maintenance applicaitons and service vehicles.
Aero-Motive® Enclosed Spring Driven Hose Reels feature an enclosed design to protect the hose in difficult environments.
Aero-Motive® Stainless Steel Hose Reel models make it easy to meet the hygienic standards of the food processing industry. Also ideal for use in harsh environments.
Aero-Motive® Specialty Hose Reels includes reels for static discharge, welding, and truck mount applications.
Hand Wind Hose Reels
Aero-Motive® Hand Wind Hose Reels are industrial strength reels that provide a convenient way to keep floors clear and hoses from getting kinked and tangled. |
|
The Series 7000 incorporates contemporary engineering and manufacturing techniques to give trouble-free performance. Reels are all steel constructed and compact for applications with critical space requirements. Hose I.D.s range from ¼ to 3/4, with available lengths up to 70ft.
These Industrious reels feature: full flow shaft and swivel for maximum product delivery, individually powder coated components, reel springs manufactured from the highest quality scaleless blue tempered steel, and adjustable guide arms for floor, wall, or ceiling mount.
|
|
HOSE REELS FOR WATER - LOW PRESSURE
HOSE REELS FOR HOT WATER - HIGH PRESSURE
HOSE REELS FOR HOT WATER - EMPTY (NO HOSE)
- Fixed or mobile stations
- daily tasks and occasional chores
- indoors or outdoors
Hose protection
Epoxy coated steel case protects retracted hose
Strong steel spring automatically rewinds hose after catch is released
Easy operation
Mounting bracket: wall or ceiling, fixed or pivoting support Stop catch: automatically stops the hose at the desired length
Efficiency
Air inlet: nickel-plated brass coupling, 360° rotation
High quality hose: food-grade rjubber
Connection: hose connects to tool quickly with automatic coupling
Safety in use
Automatic hose storage after use protects the operator against any risk of accident |
|
DRUM WINDING MACHINE CAPACITY 700KG
ART. BOB-MAT
Mobile compact and practical cable winding machine , CE marked, shaft loading for drums Ø up to 1000mm. Complete with metercounter for cables Ø up to 60mm, electronically controlled variable speed single or three-phase motor , available for delivery with optional extras on demand to get a best performance.
|
|
|
|
