Design the way you think.™ SpaceClaim Professional lets the extended development team import and work freely with the designer's model, without having to understand the method used to construct it. Engineers across multiple disciplines are able to immediately add their expertise to the design, rather than spend time deciphering the model or struggle with the software, increasing productivity and hastening time to market.
|
|
With SpaceClaim, you work directly with the 3D model to fully investigate the impact of each idea and validate the geometry of change requests before sharing them with the design team. This improves the quality of each design iteration and frees the CAD designer to work with only valid requests, resulting in higher quality products and shorter time to market.
SpaceClaim Professional fits into the existing workflow of product development by enabling users to import and work with models created in many CAD systems. Additionally, SpaceClaim's open XML data format ensures that its customers, rather than the software vendor, retain ownership of and access to their product data.
|
|
ARgyle, a built-in software enhancement to the MFP-3D System software, allows many advanced 3D viewing capabilities all while scanning samples in real time, and for offline analysis:
- Advanced OpenGL® rendering technology provides extensive capabilities utilizing the latest advances made by video card manufacturers.
- View images in 3D by simply clicking and dragging on the image to pan, rotate, tilt and zoom into specific areas of the image.
- Multiple images and channels of a single scan such as phase, amplitude, topography, MFM, conductivity may be opened and viewed simultaneously, or overlaid on a primary channel for signal correlation (see the image to the right).
- Independent scaling of each axis allows adjustment of aspect ratios to best represent your data. Now view your data with a 1:1 aspect ratio to visually compare height structures with scan size.
- Enhanced lighting effects provide shadowing on surfaces as the light is rotated. Specular highlighting creates reflection that enhances the features of surface roughness.
- Many color tables, along with a color table editor, provide optimal data rendering for stunning presentations.
- Files may be exported to the clipboard or saved as JPEG, PNG, BMP, TIFF, or other files.
|
|
|
FUTUREX 02 is efficient and versatile measuring software for all 3D coordinate measuring machines, irrespective of the type or brand, manual or CNC-controlled. FUTUREX 02 enables you to use the same software for horizontal-arm measuring machines, Bridge machines, 6-axis articulated measuring arms and laser trackers.
|
|
HiCAD next has been setting new standards in the field of development and design engineering for many years now, due to innovative working techniques, comprehensive industry solutions and integrated PDM software.
HiCAD next is the only CAD system in the world offering true 2-D/3-D associativity. State-of-the-art working techniques and automatisms help you minimise routine tasks, simulation and analysis tools enable you to detect and prevent collisions in your product models. By this means, product quality can be improved and product development costs will be reduced.
As a universal CAD system, HiCAD next is not only optimally suited for mechanical engineering, but can also be used in almost all branches of industry - from steel and metal engineering to sheet metal processing and plant engineering. Even hybrid projects involving several industries can be realised effortlessly.
|
|
SolidWorks Premium
SolidWorks Premium software integrates a broad range of mechanical CAD, design validation, product data management, design communication, and CAD productivity tools in a single, affordable easy to use package.
Go from concept to virtual prototype faster than you ever thought possible with the desired quality using a single easy to use application. SolidWorks Premium is so complete, you can progress from a product concept to a highly accurate virtual prototype without employing any other software.
Mechanical CAD. SolidWorks eliminates the need to learn how the software thinks, and frees you to focus on designing innovative products.
Design Validation. With SolidWorks Simulation, you can test your designs in real-world conditions on screen minimizing cost and time spent in physical samples.
Workgroup Product Data Management. SolidWorks Workgroup PDM helps small engineering workgroups minimize errors and duplicated effort by capturing file revision histories automatically and managing data access and use.
|
|
Alibre Design is the easiest to use and most accessible mechanical 3D CAD software on the market.
Alibre Design 3D CAD software delivers parametric modeling, associative 2D drafting and detailing, and real-time Team Design for a fraction of the cost of other mid-range solid modeling software.
|
|
Alibre Design Expert
Engineers' Answer to Advanced Prototyping and CAM
In today’s market, eliminating costly rework and getting your product to market quickly is integral to success. Alibre Design Expert delivers a full range of add-ons designed to do just that. With dynamic motion simulation, FEA analysis, integrated CAM, and many other tools, the most demanding designers will choose Alibre Design Expert.
|
|
|
Edgecam is an industry leading solution for all your production machining needs. Applications include prismatic and 3D milling, complex multi-axis turning, mill/turn, rotary and multi-plane milling and family of parts machining. Innovative solutions for a more productive and profitable machine shop are supplied. These include excellent toolpath simulation, a unique wizard approach to post processing, a comprehensive tooling database, intuitive and flexible machine tool communications and a web-enabled job management system.
|
|
SINGULA Features:
- Physical Optics hybridized into MoM to solve problems such as large antenna dishes that plain MoM or FEM cannot handle
- Sources include: Incident plane wave, delta voltage, line voltage, waveguide, and magnetic frill
- A wide range of graphs & plots (near field, far field, rectangular, Smith Charts, radiation patterns) can be created based on parameters such as H, B, E, D, J, Z, S, Y
- Display rectangular plots of current, fields and input impedance. Display polar plots of power gain, contours of currents and fields. Display 3D surface plots of radiation patterns and display Smith charts of s-parameters
|
|
What could you do with radically more powerful ID tools?
Create freely. Revise faster. And forget the math.
Industrial design is critical to the success of nearly every product. Designers now find themselves under more pressure than ever to:
Deliver designs that perfectly balance innovation, function, and aesthetics,
Reduce time to market without sacrificing design intent or quality, and
Improve design efficiency.
Focused on the creative design process, think3 gives you the power to bring your most attention-grabbing ideas to life. Explore more directions and unleash more possibilities. Envision, revise, share, and reuse information more easily. And see your products quickly reach showrooms and consumers around the world.
thinkiD DesignXpressions Series™: unlimited power in your hands
For the first time, designers are truly free to focus on creative design — not software. think3 technology does the interpretation and the math, automatically, to create the shape you've envisioned. Evolving from think3's 2001 introduction of Global Shape Modeling (GSM) technology, designers can create anything by mixing and matching surface and solids modeling to best reach their design goals. thinkiD DesignXpressions, powered by GSM³, lets you modify quickly, on the fly, while retaining design intent. From concept through manufacturing, you can enjoy creative freedom and dynamic, real-time control.
|
|
Freeform Shape Modeling
NX Shape Studio is a tailored styling and industrial design package that offers the freedom and accuracy designers need to explore shapes and what-if styling in the conceptual modeling phase. By seamlessly integrating curve- and surface-based modeling, NX Shape Studio puts cutting-edge CAD tools into the hands of industrial designers. At the same time, the easy-to-use toolbox fosters innovation. These flexible tools, from drag-and-drop templates to dynamic construction, enable fast, easy creation and evaluation of design alternatives while providing real-time visual feedback. And there's no worry about changes or iterations, as associativity takes care of downstream data integrity.
With Shape Studio, designers can use practically any approach or modeling technique. For example, the designer might begin modeling by using standard parametric design techniques that employ curve-driven geometry. Then, when creating contours and integrating ergonomics, the designer might use freeform techniques. Or the designer could begin modeling without precise definitions, adding geometric constraints later. Construction geometry and style details can be rapidly generated by the dynamic mapping of 3D curves onto freeform shapes. Or surfaces can be constructed using pre-set combinations of section and guide curves, with the designer monitoring impact as it occurs.
All model data transfers directly downstream. And the fully associative database ensures that any changes are automatically updated in related applications such as engineering design, assembly, drafting, simulation, and manufacturing.
|
|
Maximizing the value of your brand: Solid Edge provides you with a complete end-to-end design solution for aesthetic engineering, encouraging unrestricted creativity while speeding results, ensuring the design that is in your head is the one that ends up in your computer.
|
|
As a machine designer today you are constantly facing one very clear but difficult issue: the ever increasing complexity of your product designs. Driven by market demand for new and innovative products with an increasing array of options, product complexity has multiplied exponentially in the last decade. Add the need to apply new technologies before your competitors do, customer demand for faster delivery – and the need to fit more and more capability into smaller and smaller spaces while delivering increasingly functional shapes with optimized material costs – and product complexity becomes almost impossible to manage.
|
|
TopSolid'Design is a fully integrated and associative CAD software enabling the operator to draft and design products more efficiently. Kinematics, structural calculation, sheet metal processing and mechanical components form an integral part of the software and improve efficiency in the design process
CAD solution for all mechanical manufacturers
- Easy communication with customers
- Shorter lead times (calculation, kinematics, dynamics)
- Modeling of different part types
- Easy management of assemblies containing thousands of parts
- Industry-specific design functions: tool design, sheet metal processing, piping, wood and plastics processing, etc.
- Comprehensive management of technical data
- Transmission of data to the ERP solution
Data retrieval
- Interfaces : IGES, DXF, Catia, STEP, SAT
- Automatic and manual cleaning
Product development
- Kinematics, dynamics
- Structural computation (CETIM's TopSolid'Castor)
Parametric modeling
- Powerful functions for surface modeling
- Solid modeler Parasolid
- Optimization of shapes
- Industry specific mechanical features
Components
- All standards (AFNOR, ANSI, DIN, ISO...)
- Associated machining operations
- Supplier components
Large assemblies
- Top-down and bottom-up assemblies
- Several thousand parts
- Model simplification and part detail levels
Drawings and parts lists (BOMs)
- Associative to 3D models
- Comprehensive labeling functions, tolerances, symbols
- Parts lists, customized title blocks
Integrated project management
- "Where-used" list
- Technical database
Output
- Exploded views, notes
- Animations, integrated VCR
Integrated CAD/CAM solution
- Sheet metal processing (Topsolid'Punch, TopSolid'Cut)
- Wood processing (TopSolid'Wood)
- Machining (TopSolid'Mold, TopSolid'Cam, TopSolid'Wire)
The following options are available, in addition to the standard TopSolid'Design functions, under the umbrella name TopSolid'Pro:
- TopSolid'Fold
- Standardized component library
- Kinematics
- Piping
- Conception of assembly/disassembly sequences
|
|
