LEDI range
LED digital clocks
GORGY TIMING propose the most complete and updated range on his market.
Hour, minute, second, analogue circle second displays. Aluminium extra-flat case Height figures from 14mm to 500mm. Clocks for Indoor and outdoor use.
The LEDI clock range comply to the EMC directive 98/366 including directive 93/68, EN 55024, EN 55022, EU 60950
Versions :
- Stand alone 230VAC
- Minute 24V reversed pulses
- AFNOR NFS 87500/IRIG B
- NTP (RJ45)
- 869MHZ wireless (DHW)
- WI-FI Ethernet 802.11b
LED lamps colour :
- Red
- Green
- Yellow
- Blue
- Amber/Red high luminosity for outdoor
Case :
- Wall mount surface IP20, IP54
- Flush mount IP20, IP63
Power supply :
- 230VAC
- 115VAC
- 48VAC
- 18/36VDC
- 18/72VDC
- 24VAC
Option :
- Radio synchronization on France Inter or DCF77 transmitter
- Timer
- Date displayed alternatively with time
- Temperature
- ASCII input/output
- Beeps audio 1KHZ
|
|
HM-02N Digital Clock
The HM-02N is the solution if you want to display time in enterprise and to synchronize (by broadcast) all terminals LBC-02 and/or with the server (Windows, AS/400, Linux, Unix...). The 4" digit height red colour can be readily visible up to two hundred feet. Can also become a meter (increment) with a dry contact relay such as a switch. Other possibilities such as display machines numbers, machines speed, percentage (%), performances, production status, rejected material number, etc. If desired, you can use only the 2 left and 2 right digits on the display (deactivate the 2 center digits) to allow comparisons like different information on the display.
Facts:
In clock mode, the HM-02N can display exact time (hour) with minutes and seconds or hour and minutes only. The clock can be synchronized with the server via a simple command. In display mode, you can program up to 6 digits via a simple command. Available in Ethernet TCP/IP, RS-422M or RS-232. A sealed model is also offered for harsh environments. The stainless steel casing (24 7/8" X 3" X 9 5/8") of the HM-02N has a yellow membrane. An internal relay may be used to connect a bell or other peripherals that can be activated from a distance via a simple command.
|
|
