The PXA125 is a 125MS/s Arbitrary Waveform Generator that features a combination of arbitrary generator and synthesizer in a 1-slot 3U PXI form factor. Combined with its versatility, high resolution and wide frequency range the PXA125 offers the best timing arbitrary waveform generator within the compact, sturdy, modular architecture of PXI.
The PXA125 Arbitrary Waveform Generator is fully PXI compliant and based on the desktop computer industry standard PCI bus. The plug and play functionality of the PXA125 provides ease of set-up and use. It seamlessly integrates with LeCroy PXD family of digitizers from 150 MHz to 500 MHz and other PXI modules. Fast data transfer rates and improvements in test times are realized compared to traditional GPIB instruments.
Leading Features:
125 MS/s clock
14-bit vertical resolution
2 Meg memory depth
1ppm clock stability
10-digits sample clock frequency
PXI Form Factor single slot
Multiple instrument synchronization
Ultra fast waveform downloads using DMA
Extremely low phase NOISE carrier
Free-running asynchronous internal trigger generator
Frequency agility - FSK, ramped FSK, sweep, FM
Sequence generator controls 128K segments and 4096 links
"ArbConnection" software for easy waveform creation and control
|
|
|
Digitizers offer several advantages over traditional stand-alone oscilloscopes by delivering an open architecture and flexible software. With a National Instruments digitizer, you can not only perform standard oscilloscope measurements but also easily build other instruments such as spectrum analyzers, transient recorders, and ultrasonic receivers. In addition, you can synchronize multiple NI digitizers and other mixed-signal instruments with picosecond-level accuracy for high-channel-count and mixed-signal applications.
|
|
VXI Technology is one of the leading suppliers worldwide of modular test solutions, offering a broad selection of instruments capable of meeting widely varying customer needs and applications. We develop high-performance instrumentation with a focus on density, modularity and price/performance.
All of our products come with industry standard drivers. These include driver source code and executable soft front panels for interactive control with the instruments.
VXI Technology provides the following types of instruments:
1. Single function, single-slot VXIbus modules
2. Multi-function instruments based on our VMIP™ platform
3. VMEbus instrumentation
|
|
