Forge Europa is renowned as a leader in the field of high reliability numeric LED displays. We offer a wide range of standard 7 segment displays in both single and multiple digit formats with character heights ranging from 7.6 mm (0.3") to 200 mm (7.9").
|
|
ED-07.CA-R - EUROLED SMD 7- Segment Display, Common Anode, Red, 624nm
EUROLED SMD 7-Segment Display, red, Common Anode,
Brilliant light output
Only 4 mm total height
Withstands high solder treatment
For all miniature applications
On 24 mm blister tape
|
|
|
Alphanumeric displays are available in a range of sizes from 12.7 to 57 mm character height in single and 13.6 mm dual digit options plus a siingle digit monolithic version.Ideal for low cost text displays, 14 & 16 segment configurations can be supplied and the dual digit 13.6 mm alpha display is also offered with inbuilt driver IC.Typical applications include transportation and point of sale information.
|
|
|
High performance LED bargraphs in a variety of standard stackable packages are designed for use either singly or as a multiple units in applications such as instrumentation, audio equipment, level indicators and computer peripherals. Using an LED bargraph eliminates the alignment and colour matching problems associated with arrays of single LED indicators.
|
|
ATT300 :
can work with any current or voltage input of any transmitter : pressure, humidity, temperature, air flow, air velocity...
Display : -9999 to 99999
Display of the reading : 5 matrix digits
Display of units : 4 digits
Power supply : 24 Vac/Vdc
Analog inputs : 3 x 4-20mA, or 3 x 0-10V, or RS232 + one current or voltage input.
Housing : Stainless steel, IP65
Output : RS232
Modbus system (RS485 network)
Join our distribution network all over the word....Contact us !
|
|
AX 020:
Panel Meter for Standard Signals
Simple low cost indicator with front dimensions 48x24 mm
and LED size 8 mm
Power supply 10 ... 30 VDC
Analogue inputs 0-10V, 0-20 mA and 4-20 mA
Display range -19 999 to 99 999, adjustable zero and full scale value,
14 bits of resolution
Latch input to freeze the display, minimum/ maximum record memory
Easy to set up by only two front keys and menu support
Delivery includes adapter frame for 50x25 mm cut out and
label set with dimensions
|
|
|
|
|
|
The Centor Star is the most advanced force gauge currently available, it has become the benchmark tool for force measurement. Besides having all the functionalities of the Centor Easy, it also provides additional handy possibilities: with its graphic capabilities, it can calculate and display in real time, not only the maximum, but also the values of the particular points of the curve, such as the rupture force, force on a trigger, force at a given time, first peak, etc.
The new features:
– Maximum within a time window: makes it possible to define a particular time period for a test and to calculate the maximum force during that period while keeping the test maximum in memory
– Calculation of the time necessary to reach the maximum force in tension or compression
– Average force over the duration of the test
All these results are stored in memory (up to 100 tests) which allows statistics to be calculated on the maximum values and on configurable calculations, then sent to a PC along with the dates and times of the measurements.
Furthermore, it is possible to freeze its configuration to avoid handling errors. It is the most versatile instrument designed for all tests in industrial surroundings.
|
|
|
Forge Europa dot matrix LED displays are widely used in graphics and moving message applications.Standard configurations include 4 x 4, 5 x 7, 5 x 8, 8 x 8 and 16 x 16 with display heights ranging from 18 mm (0.7") to 121.5 mm (4.8"). Interlocking versions are also available for accurate positioning of multiple displays.The Standard Dot Matrix are supplied with white dots/grey faces.
|
|
Excellent readability, ergonomic handling and smart use: SIKO’s electronic displays are the instruments of choice wherever clear signals from measurement encoders are to be displayed in digital form and combined with logical functions.
All displays are equipped with scaleable intelligence. They allow monitoring of up to three measurement processes at the same time. Information is displayed on a single compact device – regardless of the type and combination of the sensors or encoders connected.
|
|
|
|
|
|
CA 306 and PB 306: Simple preset units with front thumbwheel switches, for easy remote setting of single parameters (i.e. setspeed of a drive) via fieldbus. By pressing the ENTER button, the actual BCD setting will be transmitted to the selected register of the target unit as PDO or SDO (CANBUS) or hold in the polling register for readout (PROFIBUS)
Front dimensions 96x48 mm
CA 340 and PB 340: Simple indicators unit for remote display of all register data which are available on the network. The use of this display can provide operator information about any of actual process data or parameter settings, at any place around the machine. The CAN version is able to handle PDO objects as well as SDO objects.
Front dimensions 96x48 mm
Bright 6 decade LED display with 15 mm size
CA 541 and PB 541: This unit combines both, preset switch and indicator. Whilst the BCD switch allows to make register changes via fieldbus, the LED display provides information about the actual setting of the same or any other register.
Front dimensions 96x72 mm
Bright 6 decade LED display with 15 mm size
|
|
What is OLED?
Organic Light-Emitting Diode (OLED) Display Panel, or Organic Electroluminescence (OEL), possesses the new generation technologies that other flat displays are hard to accomplish –brighter and clearer full color images with more agile responding speed.
The advantages of using OLED
Wide Range of Visibility:
Good visibility from long distance & wide viewing angle
Small Size:
Thickness down to 1,8 mm possible & dot pitch size smaller than for any other
Image Quality:
High colour saturation, high contrast & high speed
Low Power Consumption:
Efficient transformation of electricity into light and low heat output
Operation at low temperatures:
Operates effectively under very low temperatures
Replacement OLEDs
We are now expanding our OLED range to include drop-in replacements for products recently discontinued by other manufacturers.
|
|
Bright LED display with 15 mm size
Master- and Slave operation with Baud rates up to 1 MHz
Easy to set up by two front keys and menu dialogue
Programmable scaling of display and free zero definition
Programmable bit blanking, round-loop mode and more
Aux. 24 V output for encoder supply
Standard housing 96x48x150 mm
115/230 VAC or 17-30 VDC power supply in one unit
|
|
|
|
|
|
Planar's innovative see-through display technology is ideal for applications that require fresh new look with wide angle and crisp viewing characteristics.
- Perfect for transportation, premier consumer electronics and architectural applications.
- Easy to customize into curved shapes to help bring innovative product designs to life.
With the ALD technology - used in creating Planar's electroluminescent displays - where the layers used to coat the display are extremely thin, it is possible to create transparent layers on the display surface. As there are no liquids involved, the displays can be bent or curved to any imaginable shapes. Demos have been developed on a mirror-surface and other even or uneven surfaces can be made into a display with Planar¡'s unique technology.
Planar's EL display range combines long life time with endurance and great visual performance. Traditionally electroluminescent displays use a non-reflective back electrode, which enables high contrast and over 160-degree viewing angle even in high ambient light. The displays have been designed for the most demanding conditions: extreme temperatures and high vibration environments. The operating temperature range of EL displays is -50 degrees Celsius up to +85 degrees Celsius. Properly mounted they can withstand high shock loads as well as severe vibration found in demanding applications.
|
|
|
The 16-channel thermocouple monitor designed to read, scan, print and log temperatures or voltages. You can use any one of seven standard thermocouple types to read temperatures from -200 °C to +1700 °C. For remote monitoring applications, the SR630 can time-stamp and store up to 2000 readings in non-volatile memory for later analysis.
|
|
We offer an extensive range of high quality off-the-shelf 7 segment LCD panels, with a wide range of character heights and applications in mind.
These displays can be provided with or without metal pins for easy interconnection to your product. If there are specific icons and sizes that you require other than those shown our low cost custom design service can create ANY type of display you can think of!
|
|
When you focus on the process, you're focused on productivity & efficiency. Our highly visible, Alpha 4000 series NEMA 12 displays, ensure continued productivity & safety throughout your production facility. From your desktop PC, your PLC or HMI system you can relay real time production data and manage quality assurance during the process.
Download brochure Alpha 4000 IP55 (182Ko)
Don't risk production coming to a screeching halt.
Our 4000 Series NEMA 12 provides maximum protection against windblown dust and splashing water aroundany of your industrial processes.
|
|
|
|
|
|
What is TFT?
Short for thin film transistor, a type of LCD flat-panel display screen, in which each pixel is controlled by from one to four transistors. The TFT technology provides the best resolution of all the flat-panel techniques, but it is also the most expensive. TFT screens are sometimes called active-matrix LCDs.
The advantages of using TFT
High Pixel Density: > 100 ppi
Scalable Resolution: from 128 x 128 dots to SXGA
Crisp colours: high colour saturation & high contrast
Excellent readablity:
due to high contrast and wide viewing andle
Portrait/Landscape support: by use of symmetric viewing cone
Multimedia capability: high speed
Applications of OLED technology
Today TFT displays are used in number of devices that require electronic display panel. Among most popular types of application are:
• Communications;
• Industrial;
• Marine;
• Consumer;
• Office equipment;
• White goods;
• Dynamique information displays;
This type of display can be used for almost any possible type of application due to versatility of its features and high level of electro-mechanical properties.
|
|
COMPACT ELECTRONIC DISPLAY UNIT
Quick Read family is made up of three slim, compact versions, each complete with analog and digital displays, and easily programmed via local keypad.
The 3-colour (green, yellow and red) analog display and 8-digit alphanumeric display provide clear definition and easy reading of the measurement results.
|
|
Intrinsically safe analogue indicators - GSI / BSI series
Located in EX area
Field mounting (IP66) or panel mounting
3 1/2 and 4 1/2 digits display or bargraph
4-20 mA loop powered
Front face programming
Agreement : ATEX II 1G
Options : alarms, backlight, internal calibrator, set point station
|
|
S Line - Compact / modular Displays:
Scalable display: 4, 6, 8, 4+7 digits
Universal input: Analog, Digital, By sensor
Retransmission output: Analog or digital
Power supply extended range: 80-265 Vac; 10-40 Vdc / 19-28 Vac; power transducers
Accuracy: 0,1% precision class; A/D conversion 14-16 bit
Alarms (relay): Hysteresys and threshold control
Multiple visualization: Real-time, integrated, totalized measured values
|
|
Symmetricom time displays are designed to provide widely visible time to local or remote areas. Ranging in character size from 0.5 inches to 4 inches high, these displays can be mounted in instrumentation racks, consoles, on ceilings/walls or desktop areas. Our Airborne Time Display is a small and rugged airborne display that can be mounted in a standard aircraft instrument panel.
All of Symmetricom's time code products are available with several optional configurations, and several are capable of displaying countdown time.
|
|
As well as the standard functions - preset, alarms, RS232 output, Max, Min, Difference, etc - Solartron digital readouts and dual digital displays boast a number of new functions.
For example, the new "Scaling Factor" function can be used to compensate for angled or lever operated probes, or diameter when measured in a V block. It also enables measurement of angles or squares.
Other new functions include the "Gauging Mode" - allowing global pass/fail evaluation of up to 30 scan channels -and "Max A Max B".
Ergonomically designed for the operator, the DR700 can be used with multiple probe fixtures using either Linear Encoders, Digital Probes or a combination of both - making it a truly versatile addition to the Solartron "Orbit" range.
|
|
Complete Display Solutions
In a world where consumer demand for information is burgeoning, Densitron ensures that the display solution brings the product capabilities to life.
Densitron actively works with our client partners and consumer research organisations to deliver exciting product display solutions for the designs of tomorrow.
We have extensive experience in design and manufacture of customised display modules as well as standard colour and monochrome display solutions for electronic devices. We are also proactive in the development of the product and packaging to provide a complete turn-key solution.
|
|
|
|
|
|
The AlphaEclipse™ RoadStar™ series is designed for maximum visibility along highways, highly elevated installations, or any application requiring long distance visibility. Its unique, modular, state-of-the-art design produces a dynamic advertising message center that is highly energy efficient, easy to operate, install and service.
* Character sizes from 17.5" to over 9' feet tall
* AlphaNet™ software included with exclusive user tutorial CBT (computer based training) program
* Five-year limited factory depot warranty
* PureColor™, exposed LED pixel design enables optimized readability
* Convenient calendar scheduling of messages
* Display text, graphics and animations (BMP/GIF)
* Front access to all electronic components
* Modular design enables fast delivery
* Over 200 sizes from 1.5' x 5' to 14' x 46'
* Convenient PC control from home/office
* Wired or wireless connectivity
* 256 shades of red or amber
* Protector™ case keeps out external contaminates
* No filters to maintain and clean
|
|
Strong portfolio of electroluminescent display solutions and broad selection of high-bright, rugged and open-frame displays: Planar has the right embedded display for your particular application.
When you need EL display solutions, no one offers more experience, more expertise or more innovation than Planar. From our pioneering research that brought the technology to life 20 years ago to our continued commitment to providing our customers with the right solutions for their demanding applications, we create EL displays you know you can count on.
Learn more about Planar's embedded display solutions at http://www.planarembedded.com where you can access white papers, application notes, case studies and our engineering team's blog all in one place.
|
|
A better way to communicate with your customers
LIGHT, COLOR and MOTION are combined in the new ALPHA Window Display to attract the most attention, and drive more customers into your store.
This ideal indoor window display has message impact from a distance of 15 to 200-feet, day or night. Our patented display design with pixel "hoods", increases image contrast and provides shading from the sun. We use our own super-bright LEDs and a 4-inch character to create a sizzling, moving messages you know your customers won't miss
|
|
What is CSTN?
CSTN (Colour Super-Twist Nematic) is a Liquid Crystal based Display technology that produces full-colour paper-like image. Unlike TFT, CSTN is based on a passive matrix, which is less expensive to manufacture. Recent advances in technology and manufacturing process have made CSTN an economical alternative to active matrix displays.
The advantages of using CSTN:
Economical solution
- produces TFT comparable image quality at a low cost
Easy to customize solution
- resolution and display size can be tailored to suit
customer's specification
Easy upgrade from monochrome
- Limited software and hardware modification are
necessary to run CSTN display with 8051 microcontoller
Low power consumption
- from 0.7 mW; Lower heat output
|
|
DF30 Display Facia is available in four different window sizes, extra small, small, medium and large as listed below.
Any combination of these window sizes can be supplied in any format, mixed as required in a single display to make up the appropriate matrix required.
Extra Small (30x15mm)
Small (30x3Omm)
Medium (60x3Ornm)
Large (60x6Omm)
|
|
|
|
|
|
PFM - PLANT FLOOR MARQUEE SERIES
LARGE DISPLAYS WITH UNPRECEDENTED COMMUNICATION ABILITIES
* Tri-color Display Provides Instant Notice of Important Information
* Displays Information From Any G3 HMI, And SX/GT Models of the Data Station and Modular Controller
* Graphical Design Allows Bargraphs, Custom Symbols and Graphics
* Four Sizes for a Wide Range of Applications
* AC Powered (110 or 220 VAC, 50 / 60 Hz)
The PFM series facilitates the collection, calculation and communication of critical production and process information such as production targets, cadence, alarms, machine uptime and downtime measurement, and OEE (overall equipment effectiveness). Available in four models, the PFM series offers highly visible, multi-color conveyance of data to the entire plant floor and to the enterprise level. The smallest is suitable to provide data at the machine level, while the largest can be used to communicate information across an entire factory floor at distances of up to 600 feet (182 meters).
Far more than a simple large display, the PFM series features the unprecedented capability to communicate with over 170 different protocols, and to send and receive data from seven or more device types simultaneously.
These unique capabilities, which are provided through a required host device ( Red Lion G3, DSP, or MC), allow collection of data from various sources - with integrated calculation to optimize displayed information in the way it is most useful to your facility. Along with the advanced network communication and data collection, the PFM host enables remote monitoring and FTP transfer of data.
|
|
Large Displays for process control
· Inputs: ±10V, ±0-20mA.
· Three digits size available : 57, 100 and 250 mm.
· From 2 to 5 digits, 1 or 2 displaying sides.
· Serial line option (RS232 or RS485) and dual relay output option.
|
|
|
|
