Function
Concentrating inputs, allowing local preliminary handling (in the form of logic functions) of signals sent from all types of detector.
Areas of use
All sectors of automated equipment etc.
Advantages
Preliminary data handling, reduction in number of inputs to be managed by the programmable automated equipment, reduction in cabling costs, possibility of carrying out particular logic functions by connecting several distributors together, LED condition display, numerous logic functions available.
|
|
Exact12 molded homerun cable
MVP12 Single components
MVP12 UNIVERSAL
M12 potted
MSDS8 Safety distribution box M12
|
|
|
The CL03: Food specific VTS. 5/2, 5/3 and 2x3/2 Flow: 700 Nl/min With possible filtration 5µm. Piloting by BUS. Hygienic design, resists the chemicals (washing with detergents for example) Ideal for the food applications.
|
|
HF03-LG high flow 700Nl/min. All functions of distributor: 2x3/2, 5/2 and 5/3 Piloting: multipôle or drunk
-> Modular
-> High flow
-> Weak weight
-> Compact and robust
|
|
|
The CD01 available in version 3/2, 5/2, 5/3 in DN4. Flow: 650 to 1.010 Nl/min. ISO standard 15407-1. Compact with a very high flow. Many options of electric connections.
|
|
|
Series 581: poured 3/2, 5/2, 5/3 Flow 250 with 6000Nl/min. ISO sizes 1, 2, 3 and 4. >50 million cycles. Broad range of flow. Electric drive or pneumatic. Model with connector industry DIN forms A and M12.
|
|
- Standard Version or ATEX
- Pressure 0 to 10 bars
- Valves with cde manual:
Specific BP 22 and 12 mm, +leviers
- Mechanical End of the road with cde or air blast
- Detector of pressure ((manostat, pressure controller, vacuostat)
- Data processing:
Logical cells (OR, AND, NOT, YES,...)
Timing relays
Meters
Generators of impulse
Indicators
Sequencer
- Mini-distributer 3/2, 4/2
- Mini-electromagnetic sluice gates 3/2 NF, NO, 1 W
- Order Bi-manual
|
|
Even the smallest components can contribute significantly to the efficiency and economy of whole systems. Valves from HOERBIGER-ORIGA are a perfect example of this:
S9 - robust and heavy duty modular valves: The S9 range of standard and special valves are designed for durability, versatility and efficiency for the most diverse pneumatic requirements.
Reliable, maintenance-free and long-lasting: The S10 valve series represents compact precision which is also economical.
|
|
555 Series
The Humphrey Series 555, 565 and 575 Electro-pneumatic Valve and Sensor Systems are complete valve/wiring/plumbing solutions designed exclusively for pneumatically actuated accumulation-type conveyors. Use with common photo-electric sensors to electrically operate pneumatic actuators controlling drive belts and carrier rollers. The 555, 565 and 575 replace sensor rollers and mechanically operated pneumatic systems with electronic controls and intelligence.
|
|
VTS ISO flow of 300 with 4.800Nl/min.
Version pluggin. ISO sizes 1-2-3.
Modular version HF04-03-02 and compacts CA04, LP04.
Connector industries multipôles M1 or SubD25, DRUNK Profibus, Interbus, Devicenet, Canopen, DLL, VDS or AS-I.
|
|
The CD01 available in version 3/2, 5/2, 5/3 in DN4.
Flow: 650 to 1.010 Nl/min.
ISO standard 15407-1. Compact with a very high flow. Many options of electric connections.
|
|
The CL03: Food specific VTS. 5/2, 5/3 and 2x3/2
Flow: 700 Nl/min
With possible filtration 5µm. Piloting by BUS.
Hygienic design, resists the chemicals (washing with detergents for example)
Ideal for the food applications.
|
|
Series 581: versions 3/2, 5/2, 5/3
Flow 250 with 6000Nl/min. ISO sizes 1,2,3 and 4.
>50 million cycles. Broad range of flow. Electric drive or pneumatic. Model with connector industry DIN forms has and M12.
|
|
PS1 ELECTRO-PNEUMATIC INTERFACE MODULES
High speed poppet type valves
3/2 and 4/2 electro-pneumatic modules
Push-in connections 4mm or 6mm
High performance 15mm solenoids
Building block type modules with DIN rail mounting
Built in electrical terminal blocks
|
|
Versatility is the key when it comes to Clippard's Minimatic Modular Valves. Available in an unlimited variety of directional, flow, pressure and special control valves - each in a valve body designed to mount and link together with a simple piping system. The piping system eases assembly and plumbing, resulting in reduced labor costs, errors in installation, and the potential for plumbing leakage.
In addition, multiple valve elements can be contained in a single body; providing incredible flexibility and variety to accomplish a myriad of control challenges. The Minimatic Modular Valves are the supreme "Plug & Play" devices for pneumatic applications.
|
|
ISO-Standard ISO 5599/I (Series W60, W63, W64)
ISO 5599/II (Series W65)
ANSI-Standard (Series W70 and W74)
SAE-Standard (Series 80 and 84)
All piping is to the base, not the valve, for easy valve removal and servicing.
Other features:
Three constructions available:
poppet
stainless steel spool & sleeve
resilient seal spool
Valves are fully interchangeable with any other valves using a standard mounting interface
Compact design (manifold mounting system)
5/2- and 5/3-way valves in all sizes available
Port size up to G 1½
Flow rating up to kv = 22
Electrical connections provided by:
drop-cord plug (ISO 5599/I)
body-to-base / plug-in base (ANSI or ISO 5599/II)
3- or 5-pin connectors (SAE-Norm)
Variety of interposed control devices available.
|
|
A new range of distributers of metal power for a use under Xtrèmes conditions.
Technical description:
Available in four diameters of opening G1/8, G1/4, G3/8 and G1/2
Drawer of only one moulded aluminum part
Applications low temperature until -40°C
Operating pressure until to 16 bar.
Advantages:
Component count reduced
Optimal lifespan
Robustness
Versatility
High efficiencies and small overall dimensions
High flow
Short times of inversion
Minimal pressure of piloting.
Applications:
Forestry developments and mining, machines of building site,
Pulp mill and paper mills
In conformity with the standards vibrations pulverization saltworks in force in the transport sector.
|
|
|
ASi fieldbussystem suitably for small, distributes clusters of PLC combination PLC, entrance/output interface and distribution block integrated by actuators and sensors field bus ii-system modular system for up to 64 Stationenn
|
|
|
Pneumatic distributor TC08: 800 Nl/min 5/2, 5/3 in G1/8. 800 Nl/min. Direct connection or associable DIN C or M8. Is appropriate for all the applications. Pneumatic distributor TC15: 1500Nl/min 5/2, 5/3 in G1/4. 1500 Nl/min. Direct connection or associable DIN C and M8. Is appropriate for all the applications. Great flow.
|
|
Modular Manifold
10-32 & 1/8 NPT 2, 3 & 4 Way Valve Series 3853
Composite Solenoid Valve, 2 & 3-Way
Normally Closed or Normally Open
Hex Body
1/8 & 1/4 NPT 2 & 3 Way Valve Series 38MP
Composite Solenoid Valve, 2 & 3-Way
Normally Closed or Normally Open
18 Series
1/8 NPT 2, 3, & 4 Way Valve Series 3953
Stackable Composite Solenoid Valve
14, M14 & 34 Series
1/4 & 3/8 NPT 2, 3 & 4 Way Valve Series 3500
1/4, 3/8 & 1/2 NPT 2 Way Normally Closed/Open
12, 12A, 12B & 38 Series
3/8 & 1/2 NPT 2, 3 & 4 Way Valve Series 3510
1/4, 3/8 & 1/2 NPT Composite 2 Way Normally Closed/Open
|
|
The spool valves and mini spool valves are available in ISO 1,2,3,4 and ISO 01,02 standardized and non-standardized versions. With pneumatic or electropneumatic control (integrated or via CNOMO pilots), they provide an extended service life of 30 million cycles.
The non-standardized versions give priority to:
- High size/throughput ratio
- Assembly in line or on multiple subbases
|
|
5/2, 5/3 in G1/8. 800 Nl/min.
Direct connection or associable DIN C or M8.
Is appropriate for all the applications.
|
|
5/2, 5/3 in G1/4. 1500 Nl/min.
Direct connection or associable DIN C and M8.
Is appropriate for all the applications. Great flow.
|
|
|
Metal Work offers a full range of valves and solenoid valves to meet all the possible requirements regarding compressed air supply, cut-off and regulation. The range of conventional valves with in-line couplings is available in four different types of actuation: mechanical, manual, pneumatic and electro-pneumatic. Standard valves come with either pneumatic or electro-pneumatic actuation. A comprehensive range of accessories including bases, manifolds and adaptors makes this valve range extremely versatile. All solenoid valves can be equipped with low power absorption solenoids. A new type of Mini Valve serie Mach is available with multiple electrical connector as well as the provision for interconnection with fieldbus systems.
|
|
2005 Series
Modular reality, plug together flexibility in design! 4-way solenoid air pilot actuated valves. Available in manifold & base mount. Supported electronic interface/bus protocols include DeviceNet, Allen-Bradley, Remote I/O and Profibus DP.
2012 Series
Modular reality, plug together flexibility in design! 4-way solenoid air pilot actuated valves. Available in manifold & base mount. Supported electronic interface/bus protocols include DeviceNet, Allen-Bradley, Remote I/O and Profibus DP.
2035 Series
Modular reality, plug together flexibility in design! 4-way solenoid air pilot actuated valves. Available in manifold mount. Supported electronic interface/bus protocols include DeviceNet, Allen-Bradley, Remote I/O, and Profibus.
|
|
A05/A12 ADEX VALVES
Miniature high flow body ported and manifold valves
5/2 and 5/3 configurations
Ultra fast response times
10mm and 15mm Body widths
Threaded or push-in connections
Single sub base or IEM manifolds
Low power solenoids
Collective wiring system
|
|
SX
The SX series unique design combines both solenoid assemblies (when using double solenoid 2/3 position) on the same side of the valve, opposite the ports, allowing for greater space savings and simplified wiring access. The SX series valves are available with numerous manifold options which allow for easier installation and improved operation.
|
|
The spool valves and mini spool valves are available in ISO 1,2,3,4 and ISO 01,02 standardized and non-standardized versions. With pneumatic or electropneumatic control (integrated or via CNOMO pilots), they provide an extended service life of 30 million cycles.
The non-standardized versions give priority to:
- High size/throughput ratio
- Assembly in line or on multiple subbases
|
|
