Eccentric presses

P. 17
idraulico - Hydraulic screw block Retro pressa con scivolo per scarico sfridi Machine back side with chute for scraps discharge Particolare lato macchina Machine side detail Pulpito di comando a due pulsanti Two pushbuttons control station Slitta con sei guide a V

P. 1
40V 2G PF 55V 6G PF 65V 6G PF 80V 6G MAXIMUM PRESSURE KN. 200 250 300 400 550 630 800 STROKES FOR MINUTE C/min 200 200 180 160 150 140 130 *STROKES FOR MINUTE (2 SPEEDS) C/min 150-230 143-220 135-220

P. 67
P
70 kW n1
1450 min?1 Driven machine: eccentric press n2
285 min?1 Service conditions: evaluation via service factor c2 daily operating period 10 hours diameter of disk flywheel dg
1400 mm Example of calculation for V-flat drive Service factor c2 from table 10, page 31 c2
1

P. 11
This conveyor belt transfers lids from an eccentric press after which the lids are stacked up with a stack roller. The chute placed horizontally after the stack roller has not been installed on this photo
