The motors are solidly designed and are maintenancefree for life.The multi-grooved stator contains a threefold winding which, together with the phase-shifting capacitor, creates a symmetrical rotating field at the rated working point of the motor.The rotor is of the squirrel-cage type. Two- or four-pole motors with a variety of design Iengths and diameters provide rated torques from 0.75 to 12.6 Ncm. Can be combined with reduction gear units, brakes, and tachogenerator systems.
|
|
Product Overview:
Baldor is the largest motor and mechanical power transmission company in North America and the second largest worldwide. Baldor•Reliance® motor products now range from 15 watts to 11,000 kW. Our range includes:
• 'Super-E' motors that exceed the new IEC 60034-30, IE3 rating for efficiency
• NEMA motors that cover every need for OEM exporters
• NEMA Premium Efficiency rated motors, meeting the new EISA legislation covering motors supplied into the USA
• We also offer broad lines of brake-motors, explosion-proof, C-face, pump-motors and gear-motors to provide solutions for any purpose or environment.
• Custom motors to meet client specific requirements. Custom motors are manufactured to the shortest lead times in the industry.
|
|
|
|
|
|
MS and MY series Transtecno motors are closed and fan cooled.
MS series includes induction threephase 4 poles motors
230/400 Vac at 50 Hz and 275/480 Vac at 60 Hz, 4 poles; it
covers power sizes from 0.09 kW up to 1.5 kW. These motors
run quietly and are dinamically well balanced; they match
quality, strength and cheapness.
MY series includes induction singlephase motors 230 Vac at
50 Hz and covers power sizes from 0.09 kW up to 0.75 kW:
they are particular suitable to be mounted on machine for low
power applications.As well as MS series motors, they match
quality and cheapness.
Both series are made in aluminum frame and are available
with B5 or B14 flange mountings.
Standard features for both the series are:
• Class F thermal insulation
• IP55 enclosure protection
• PTO thermostat for overheating protection
• Phases separators between windings: this feature
makes these motors particularly suitable for use with
variable frequency drives.
MY series motors have a large terminal box, which includes
the run capacitor, in order to protect it from external environment.
|
|
Delphi ATDC series self-braking motors use spring-pressure brakes, firmly spliced onto a cast iron shield at the back of the motor.
These motors include:
+ The hand release lever that permits to release the brake, making it possible to move the shaft.
+ The separate brake power supply that is achieved, whenever needed, by connecting directly to the brake terminal board located inside the motor terminal box.
+ The PTO thermal protectors in the winding
Delphi ATDC series maintain also the peculiarities described in the Delphi series catalogue
|
|
|
Today's venetian blind motors are the result of decades of experience and co-operation with manufacturers of blind systems. The constant development process, which results out of this co-operation, led to products of a high level in technique and quality.
|
|
Applications: For normal medium and high thrust in-line pump applications.
Waste water treatment plants, petro chemical industries, pulp and paper mills and agricultural irrigation applications.
Features: Severe duty construction with corrosion-resistant epoxy finish, cast-iron construction, designed for vertical mounting. Rotatable conduit box, stainless steel nameplates, shaft seals. Energy efficient windings. Two lifting lugs for balanced lifting. VHECP motors have NEMA Premium® efficiency and are Inverter-Ready. 1.15 Service Factor.
|
|
|
Today's venetian blind motors are the result of decades of experience and co-operation with manufacturers of blind systems. The constant development process, which results out of this co-operation, led to products of a high level in technique and quality.
|
|
|
Today's venetian blind motors are the result of decades of experience and co-operation with manufacturers of blind systems. The constant development process, which results out of this co-operation, led to products of a high level in technique and quality.
|
|
Since the 1940s, when Baldor introduced its first explosion-proof motor, the company has designed and manufactured motors that meet or exceed industry standards, ensuring safety, energy efficiency and overall reliability. Today, Baldor offers nearly 300 different explosionproof stock motors, from 1/4 hp to 300 hp, in frame sizes up to NEMA 449T. Motor models include:
• Single phase and three phase
• Super-E® NEMA Premium™ efficiency
• 50 Hz
• Standard 1.0 or 1.15 Service Factor
• Severe Duty Service
• NEMA C-face
• Jet-Pump
• Close-coupled pump
• Brake motors
• Inverter Drive®
• SCR Drive permanent magnet DC
• SCR Drive shunt wound DC
Baldor’s explosion-proof motors meet all the stringent UL and CSA requirements for use in hazardous locations. Custom motors are also available. Combine this selection with Baldor’s unmatched service, support and stock availability, and you’ll see why Baldor is the value leader in explosion-proof motors.
|
|
|
ECOFIT external rotor motors are available with IP 20 or IP 44. IP 20 motors are self-ventilating and can give superior power to IP 44 motors with equivalent heat rise. The power on the shaft, voltage and frequency, shaft, connections and protection... can be defined according to your requirements and application. If specified, ECOFIT external rotor motors can be manufactured in multispeed.
|
|
|
|
|
|
Whether it’s a standard efficient motor operating at a
rock crusher in a quarry, or an 841XL motor operating
continually in a refinery, Baldor offers customers a variety
of choices.
Standard efficiency Severe Duty motors are designed
for general processing industry applications requiring
protection from severe environmental operating
conditions. In applications where the motor works
continually and energy efficiency is a consideration,
Baldor•Reliance Super-E® Severe Duty motors are
available in TEFC ratings from 1 through 2250 Hp. Castiron
construction, epoxy primer inside and out, and
gaskets on all joints are some of the features of Baldor’s
Severe Duty motors.
For the ultimate in protection from severe environments
– where you need added insurance against downtime
– Baldor offers 841XL motors. Delivering reliable,
rugged performance with the industry’s highest energy
efficiencies, these motors exceed IEEE 841 – 2001
standards for severe duty TEFC induction motors.
Baldor also offers a variety of special-purpose severe duty
motors, including Dirty Duty®, Quarry Duty, Crusher Duty,
Explosion-Proof and Vertical Shaft Pump motors.
|
|
Single-phase capacitor motors Series KD.1 and three-phase motors Series DR.1
The motors are solidly designed and are maintenancefree for life.The multi-grooved stator contains a threefold winding which, together with the phase-shifting capacitor, creates a symmetrical rotating field at the rated working point of the motor.The rotor is of the squirrel-cage type. Two- or four-pole motors with a variety of design Iengths and diameters provide rated torques from 0.75 to 12.6 Ncm. Can be combined with reduction gear units, brakes, and tachogenerator systems.
|
|
|
|
|
|
APPLICATIONS
SAER submersible motors series CL 95 are suitable to be immersed in wells having diam. 4” and larger to be coupled to hydraulic submersible centrifrugal and peripheral pumps with 4” Nema coupling.CHARACTERISTICS
4” oil filled submersible motor, completely rewindable
Non –toxic oil (USA FDA, US Pharmacopoeia/National Formulary,
USDA (Department of Agriculture), European Pharmacopoeia
approved)
Flange and shaft protrusion in compliance with NEMA standards
4"
Degree of protection: IP 68
Insulation class: B
Shaft entirely made of stainless steel AISI 431
Outer shell made of stainless steel AISI304. Cast iron flange
A compensation membrane on the bottom of the motor ensures
the balance between the internal and external pressures, along
with the variation of the oil volume due to the temperature.
Triple seal system on rotor shaft: bi-directional mechanical seal
+ radial seal +sand-guard with laminar seal.
Single phase motors: PSC type (Permanent Split Capacitor).
Capacitor have to be provided by the customer.
Rotation: Single phase motors: counter clockwise facing shaft
end, three phases motors: clockwise or counter clockwise without
distinction.
Cable material suitable for use with drinking water.
All motors 100% tested (test report supplied upon request).
SAER submersible motors are suitable for use with frequency
changer. You can address to our technical servicing for any further
information.
|
|
|
We invite you to see motive catalogue to understand the peculiarities of this product. Few words are not enough to illustrate its advantages.
|
|
K-2 Series AC Induction Motor
Horsepower: 1/1600 to 1/200 HP
Rated Torque: 0.31 to 3.2 oz-in
Phase: Single Phase
30R Series AC Induction Motor
Horsepower: 1/40 to 1/30 HP
Rated Torque: 10 to 20 oz-in
Phase: Single Phase
34R Series AC Induction Motor
Horsepower: 1/15 to 1/5 HP
Rated Torque: 38 to 119 oz-in
Phase: Single and Three Phase
42R Series AC Induction Motor
Horsepower: 1/12 to 1/4 HP
Rated Torque: 48 to 148 oz-in
Phase: Single and Three Phase
48R Series AC Induction Motor
Horsepower: 1/5 to 1/2 HP
Rated Torque: 112 to 296 oz-in
Phase: Single and Three Phase
|
|
|
ElectroCraft's SolidPower Plus AC motors are designed from the ground-up to create efficient, low-noise power. Annealed laminations and stator windings electronically matched to your application ensure efficient operation. While dynamically balanced, skewed rotor bars and precision-machined fits, keep noise and vibration down.
|
|
BISON 100 SERIES
The 100 Series offers a wide speed range and many voltage options in an ultra-compact package. Up to 100 In-lbs. Continuous.
|
|
Our Universal (120 - 240 VAC Input) motors are based on our popular
Round K, Square K, and B-style laminations, with operating speeds
up to 30,000 RPM. These cost effective motors typically include
customer specific lead terminations, mounting details, housing
types, and overheating protection. We have extensive
experience in induction motor conversions.
|
|
Mounting size: 60mm - 90mm
Output power: 6W - 90W
Speed range: 90 - 1400r/min for 50Hz, 90 - 1600r/min for 60Hz
Max. permissible torque: up to 30Nm
Gearheads: 20 different gear ratios of 1:3 - 1:180
Power supply: 110/115V AC or 220/230V AC
Marking: CE, UL and cUL
|
|
Mounting size: 60mm - 90mm
Output power: 6W - 90W
Speed range: 90 - 1400r/min for 50Hz, 90 - 1600r/min for 60Hz
Max. permissible torque: up to 20Nm
Gearheads: 20 different gear ratios of 1:3 - 1:180
Power supply: 200 - 230V AC or 100 - 115V AC
Marking: CE, UL and cUL
|
|
The motors type EL are thought to be installed on wood, aluminium, granite, marble and stone processing machines where high performances in a compact design are required.
Ideal for tenoners.
TECHNICAL FEATURES:
STATOR: windings featuring double encapsulation
ISOLATION CLASS: F or superior.
BEARINGS: Front: 2 deep groove ball bearings for EL11; angular contact ball bearings for axial and radial loads for EL 13 and EL 16.
Rear: deep groove ball bearing
MAXIMUM SPEED: 6.000 rpm.
ROTOR: squirrel-cage rotor
HOUSING: high resistance extruded aluminium
BEARING HOUSINGS: front and rear bearing housings made of cast iron
COOLING: self cooling with fan
TOOL FIXING: Shaft provided with key and threaded output
IP CLASS 54.
UPON REQUEST: Varnishing, different power and polarities
Speed of 9.000 rpm. (with front pre-loaded precision bearings)
|
|
The IEC-normalized BN motors comply with all the applicable international standards, including the EMC and LV Directives. They are available in the 0.06 - 30 kW range in the foot and the flange mounting version, the latter in both the IM B5 and the IM B14 configuration. Single and dual pole version available with generally, three brake options offered, one DC and two AC supply, lending further flexibility to the system. Finally, all motors are inverter duty.
|
|
|
Iskra AC motors are four-pole induction motors with Al squirrel cage rotor and three phase winding on the stator. With their robust construction and superior output performance they represent the best traction and pump motor solution on forklifts and other electric vehicles. The best drive performances and system efficiency can be achieved in combination with Iskra AC controllers.
|
|
|
|
|
|
ASYNCHRONOUS MOTORS
- Single-phase motors :
Single-phase LS : Aluminium alloy housing
- Three-phase motors:
LSES : High efficiency motor - Fixed speed
LSHT/FLSHT : High temperature Smoke extraction
FLS : Cast iron housing - Fixed speed
LS : Aluminium alloy housing - Fixed speed
LS Zone 22 : Aluminium alloy housing - Dust ATEX Zone 22
FLSES : Energy savings motor - Fixed speed
FLSC : Corrobloc finish motor - Fixed speed
FLSB/FLSLB : Slip ring wound rotor motor - Fixed speed
PLS : Open Drip Proof motor IP 23 - Fixed speed
LSMV : Variable speed motor
LSiA : Food and beverage applications motor
LS MO : Machine tool applications motor
LS FA : High ambient temperatures Ovens
LS/FLS 85°C to 150°C : High ambient temperatures Driers
LSPX : Aluminium alloy housing - Dust ATEX Zone 21
FLSPX : Cast iron housing - Dust ATEX Zone 21
FLS Zone 22 : Cast iron housing - Dust ATEX Zone 22
LSE zone 1 : Aluminium alloy housing - Increased safety - Gas ATEX
FLSD(E) zone 1 : Cast iron housing - Flameproof safety - Gas ATEX
FLSE zone 1 : Cast iron housing - Increased safety - Gas ATEX
LSN zone 2 : Aluminium alloy housing - Non-sparking safety - Gas ATEX
FLSN zone 2 : Cast iron housing - Non-sparking safety - Gas ATEX
VARMECA : Variable speed motor with integrated drive
With our Guaranteed Availability, determine your own delivery date!
|
|
Mounting size: 80mm, 90mm and 104mm
Output power: 25W - 90W
Max. permissible torque: up to 30Nm
Gearheads: 20 different gear ratios of 1:3 - 1:180
Power supply: 230V AC
Protection class: IP67
Marking: CE, UL and cUL
Fixed speed motors.
|
|
Mounting size: 42mm - 104mm
Output power: 1W - 200W
Max. permissible torque: up to 40Nm
Gearheads: 20 different gear ratios of 1:3 - 1:180
Power supply: 100/110/115V AC or 220/230V AC
Protection class: IP54 for 200W-type
Marking: CE, UL and cUL
|
|
|
The asynchronous motors of the series 13.710 are compact and space-saving. Available in a power range from 12 to 90 W, these motors are naturally ventilated. Since they do not have a fan they have low noise emissions and can be applied in production areas with fluff or dust. The motors are available with solid shaft and keyway, with flange mounting and can be fitted with a brake.
|
|
Outside of our range of motor elements (built-in motors) SycoTec is developing and manufacturing customized Drive Systems specific to your requirements. The choice of motor-technology as well as the design of the system is always a very tight, hand-in-hand effort with our customers. As a system supplier, we certainly support and research with you the right drive (inverter), if it is not presently available. SycoTec, as a inverter manufacturer, can offer you a quite good range and suitable units.
Our challenge is, to offer you the highest quality system as the single source provider, which means for you "one point of contact".
Application field:
- Motor for a leakage-searching unit up to 90,000 rpm (motor is running under vacuum)
- Motor for air cargo transportation systems (requirements: high torque and low weight)
- DC-motor element for a micro spindle up to 100,000 rpm
|
|
|
|
|
|
Armstrong HE Series motors are general purpose polyphase squirrel cage induction motors meeting all required NEMA and IEEE standards. In addition to numerous in-factory sampling motor tests to verify and improve designs, motors were tested at Hydro-Quebec’s independent motor testing laboratory in Canada. Armstrong HE Series TEFC motors from 1 hp to 100 hp currently meet or exceed the efficiency requirements of the US Energy Policy Act of 1992 (EPAct) and Natural Resource Canada Standards (NRCan).
For assurance of low motor vibration and noise levels, dynamic balancing on every rotor and alignment checks are performed on the production line. Only high strength, non-metallic, non-sparking external fans are used on HE Series motors to enhance the ventilation, provide additional safety, and reduce noise levels.
- Cast iron TEFC Three phase general purpose
- Class F insulation, class B temperature rise
- 1.15 Service factor
- 208 V, 230 V, 460 V, 575 V at 60 Hz
- Wye-Delta starting standard on frames 213TC and larger
- Rigid base F1 mounting
- C-face
- CSA and ISO 9001 certified
|
|
High Voltage Motors
This is our principal field of business. We supply high voltage motors of any kind, and will ship anywhere in the world.
We stock and build high voltage motors of the squirrel cage or slip ring type, typically for nominal voltages between 3 kV and 11 kV. Custom constructions deviating from these specs are available for nominal voltages of up to 13.8 kV. Standard frequencies are 50 and 60 Hz.
We build high-voltage motors with the following standard configurations:
Configuration IM B3 for horizontal installation
Configuration IM V1 for vertical installation
|
|
|
|
