WATERFLUX 3070 is an electromagnetic water meter for standard applications in the water and wastewater industry. It has a very long battery life of 15 years, making it especially suitable for applications where no power connection is available. The meter also has the option of a GSM module for remote transmission of measurement data and status information.
|
|
...for flow, level, pressure, analysis and temperature
Sensors, transmitters and fittings for measuring and controlling of fluid or gaseous media.
Bürkert....the Smart choice for Fluid Control System !
|
|
At KROHNE, all electromagnetic flowmeters are wet-calibrated by direct comparison of volumes, the most accurate calibration method of all. The KROHNE calibration rig is the world's largest and most accurate.
|
|
The new inbuilt diagnostics not only fulfil the NAMUR guidelines, they exceed them by far. The new converter can check and detect whether it is still within its specifications or has been correctly installed.
The 3 x 100% diagnostics consist of:
|
|
|
|
|
|
The Ultra Mag is a leading-edge electromagnetic flow meter. Field-proven for the needs of the water & wastewater industries, the unit’s unique NSF-approved UltraLiner™ provides superior electrical insulation as well as protection against corrosion and abrasion.
The Ultra Mag is the standard for performance, ease-of-use and value. It's designed for liquids, slurries and sludge. It uses a non-intrusive measurement element. Debris/solids don't clog the line. It excels in hard-to-reach, harsh environments requiring minimal maintenance, and is ideal in water well production, pump stations, industrial/municipal water & wastewater and more.
Magmeters provide worry-free flow measurement where high accuracy over a wide flow range is critical. Unlike mechanical flow meters, there are no moving parts. Measurement is unaffected by changes in fluid density and viscosity. The Ultra Mag is exceptionally stable and reliable.
Key features:
Outstanding electrical insulating properties
Non-intrusive sensing element, debris/solids don't clog lines or cause excessive wear
NSF-approved UltraLiner for superior abrasion/corrosion resistance
Accuracy of +/- 0.5% of actual flow
Wide rangeability: 0.2 FPS to 49 FPS
Low maintenance: in slurries and sludge
Accurate and reliable in hard-to-reach areas
|
|
|
|
|
|
The Marsh Single-Mag Flow Meter is an insertion-type device that provides a highly cost-effective solution for the accurate measurement of liquid flow in closed conduit, pressurized pipe applications. Unlike conventional magnetic meters, the Single-Mag’s cost is independent of pipe size. Velocity and pipe diameter information are utilized by the Single-Mag to determine flow over wide flow ranges with a high degree of accuracy.
The Marsh Single-Mag reliably measures flow in water and wastewater and any type of industrial flow processes involving conductive fluids such as potable water, slurries, sludge, cooling water, and pulp stock.
Supports pressurized line sizes from
2 to 96 inches (50-2500 mm)
Accuracy: ±2% of reading ± zero
stability at -3 to +10 ft/s (-0.9 to +3 m/s)
Wide flow range: -5 to +20 ft/s
(-1.5 to +6.1 m/s)
4-20 mA output signal
Proven electromagnetic technology
based on Faraday’s Law
Debris shedding, self cleaning sensor
eliminates costly maintenance
Cost is independent of pipe size.
Easy installation/no interruption of
flow process
Special sensors for harsh
environments
|
|
|
Ideal laboratory conditions are rarely found in any water system. Low flows, wide flow ranges, bends, elbows, and even the obstruction of the measuring device affect accuracy. The Marsh Multi-Mag L Series Insertable Electromagnetic Averaging Flow Meter is truly a revolutionary instrument with unprecedented accuracy even in these most difficult flow conditions. It is ideal for measuring potable water, chilled water, raw water, water with sand and grit, and other debris-free water applications.
|
|
|
|
|
|
Ideal lab conditions are rarely found in water systems. Low flows, wide flow ranges, bends, elbows, and obstruction of measuring devices affect accuracy. The Marsh Multi-Mag Insertable Electromagnetic Averaging Flow Meter is a revolutionary instrument with accuracy in difficult flow conditions.
Recently, only expensive spool-piece mag meters, turbine meters, and other insertable flow meters providing single point measurement were utilized. After years of extensive testing and thousands of installations worldwide, the patented Marsh Multi-Mag Flow Meter provides measuring points precisely positioned according to pipe size, making it the most accurate flow meter. Applications include: custody transfer, filter balancing, filter backwash, water treatment processes, distribution management and head flows, measuring potable water, chilled water, raw water, water with sand and grit, and other debris-free water applications.
Key features:
Ideal for difficult conditions: low flows, wide flow ranges, bend and elbow installations, and vertical pipes
Quick install without system shut-down
Automatic sensing/correcting for shifting flow profiles
Streamlined sensor for low pressure drop
High turn-down ratio
Lower energy costs than most flow meters
Low cost -- won’t increase with pipe size
|
|
Since developing its first magnetic flowmeter for industrial use in 1953, Yokogawa has focused on broadening the range of applications for this technology. To ensure a high degree of reliability, the manufacturing of all key components is done in-house and in accordance with our rigorous quality control standards.
|
|
Calorimetr. Flow Monitor KAL-D
Calorimetric Flow Monitor KAL
Calorimetric Flowmeter /- monitors KAL-K
Calorimetric Flow Monitor f. Gases KAL-L
Calorimetric Flowmeter,-switch,-totalizer DVK
Differential Pressure Flowmeter RCD
Mass Flowmeter and /-controller for Gases MAS
Mass Flowmeter and /-regulator for Gases DMS
Mass Flowmeter for Gases MFC
Mass Flowmeter and /-regulator for Gases DMW
Therm. Mass Flowmeter for Gases KES
Mass Flowmeter and Counter PMS
Magnetic Inductive Flowmeter / -monitor PME
Magnetic Inductive Flowmeter/-monitor/-counter DMI
Magnetic Inductive Flowmeter/-monitor MID
Magnetic Inductive Flowmeter/-monitor PMG/PMH
Oscillation Flow Meters DOG
Ultrasonic Flowmeter DUB
Ultrasonic Flowmeter/-counter DUL
Vortex-Flowmeter,-switch DVZ
Vortex Flowmeter PWL
|
|
|
|
|
|
Magnetic-inductive flow sensor, compact and cost-effective
The cost-effectiveness of the extremely compact magnetic-inductive flow sensor VMI from SIKA means that this field-proven process technology method can now also be applied for mechanical engineering measuring procedures. The VMI functions according to the induction principle.
If an electrically conductive medium flows through the measuring tube and, therefore, at right angles to the magnetic field, a voltage will be induced in the medium. This means, the flow velocity-dependent voltage signal provides a flow-proportional frequency signal as the output signal. The measuring range of the quick-response sensor is 2…40 l/min, the process connection occurs via an external thread G½.
The advantages of the sensor are mighty impressive:
• No moving parts, no wear
• Free pipe cross section, no additional pressure loss
• Resistant to soiled liquids
Thanks to the measuring principle, changes to the temperature, density, viscosity, concentration or electrical conductivity of the medium do not affect the output signal. The VMI can be used in areas where flow sensors with moving parts, e. g. vane sensors, cannot be applied due to soiled media. The sensor is intended for measuring flow rates or dosing liquids. The VMI is the ideal flow sensor for interference free operation combined with long service life.
|
|
|
The Dynasonics Series MFX Insertion MagProbe is an excellent tool for measuring conductive liquids (such as water and water-based fluids) in closed pipe systems. The hot-tapped probe can be inserted and removed from the process without interrupting the process stream. The system includes a wide array of electronic output options and provides an accuracy of +/- 1%.
|
|
VersaFlow Magnetic Flow Meters
The VersaFlow Mag 4000 is a process industry standard suitable for the most demanding applications. All meters consist of a sensor and a converter that may be mounted integral to the sensor or remotely either with a field mount kit, wall mount housing or a 19" rack mount housing. The TWM 9000 is the only electromagnetic flow converter with diagnostics for the instrument and application. The TWM 9000 is compatible with all electromagnetic flow sensors and is suitable for all applications
|
|
ISOMAG FLOWIZ is the revolutionary battery powered electromagnetic flow-meter.
- Internal GPRS modem for wireless communication through e-mail sent directly into a selected e-mail account;
- Internal Data Loggers at different sampling rates;
- Battery lasting up to 10 years;
- Possibility of powering by battery and by the main line ai the same instrument;
- Electronic adaptable to all diameters, up to DN 2000 mm for the full bore sensors and 8000 mm for the insertion ones;
- Accuracy of +/- 0.5% on the read value;
- Possibility of manage flow and pressure data;
- Perfect for Leakage Detection processes inside Water Distribution Networks;
- Supplied with software able to extract automatically data files attached in the e-mails and save them into organised folders;
- Available on request with specific software for the graphical elaboration of data from the field;
- Performances significantly better than the requirements in CEN 14154, ISO 4064 and OIML R49.
|
|
Electro magnetic flow meter
DN 10, 15, 20, 25, 32, 40
sanitary connection acc. to DIN 11851
aseptic connection acc. to DIN 11864-1 with 3A approval
Tri Clamp acc. to DIN 32676 with 3A approval
Tri Clamp acc. DIN 11864-3 with 3A approval
filling quantum from 1 ml
CIP/SIP-procedures up to 140°C
product conductivity >1µS
power supply 24 VAC
|
|
- Magnetic flow meter with specific functions for the calculation of the
thermal energy;
- Able to manage internally data of Flow rate, power, inlet temperature,
outlet temperature and Delta T;
- Internal module for the calculation of the thermal energy through an
algorithm according to the DIN1485 normative;
- CE Certificate.
|
|
|
|
|
|
The ISOMAG meters are the ideal solution for the flow measurement of any kind of fluid with a minimum conductivity of 5 mS/cm granting high accuracy and repeatability of the measure.
The ISOMAG serie is composed by full-bore meters, available from DN 3 to DN 2000 mm; in compact or separate execution (up to 500 m); with lining in Polypropylene, PTFE and Ebonite; with a wide range of electrodes materials according to the compatibility needs with the fluid; with different kind of process connections, which allow them to be adaptable for all the different existing applications (from the food & beverage, to the chemical, water distribution, etc.)
The ISOMAG serie is completed by the insertion sensors which, thanks to the hot tap system, are able to be inserted in the pipe without the need of tremporarly interrupting the flux, with clear advantages for the users.
The ISOMAG converters are equipped with LCD graphical display which visualise all measure data; send them out through digital, analogical or serial outputs; they have internal Data Loggers; in the dedicated versions, they can provide PID regulation and thermal energy totalization.
The news: ISOMAG FLOWIZ, the battery powered electromagnetic flow-meter able to communicate wireless through the GPRS protocol.
|
|
Magnetic flow meter with ‘2 wires’ technique, simple end economical with basic and essential features:
- 1 digital output;
- 1 digital input;
- Power supply: 4/20 mA 2 wires;
- Available with all the Isomag sensors up to the DN1000;
- Available with plastic or Alluminium (IP 67) housing.
|
|
Electromagnetic flowmeters
The advantages of the SITRANS F M electromagnetic flowmeters are numerous. These include a wide and flexible product program, the possibility of compact or remote installation using the same transmitter and sensor and the use of a USM II communication platform for easy integration with other systems.
Furthermore, they feature a unique SENSORPROM memory unit which stores sensor calibration data and transmitter settings for the lifetime of the product.
|
|
FLOMOTION SYSTEMS MS501 Electromagnetic Flowmeter
The MS501 provides reliable flow measurement with high accuracy, ease of installation and low operating cost.
MS501 FEATURES
* Accuracy to ±0.2% of rate from 3 to 33 fps.
* Lower cost than flanged units.
* Six sizes from .125" to .75" Pipe Diameters.
* Flow ranges from 0.034 to 49.84 GPM.
* Standard Pressure: 230 PSI.
* Volumetric flow rate measurement independent of fluid viscosity, density and temperature.
* No moving parts for zero maintenance.
* Wide range of process connection types; threaded, flanged, tri-clamp or compression.
* Bi-directional flow measurement.
* No pressure drop through sensor.
* Minimal straight pipe run required.
* Every sensor is factory wet-calibrated.
|
|
Applications:
Volume flow measurement
Flow measurement of conductive liquids
Special features:
Reliability
Different materials for electrodes (e. g. Hastelloy, Platinum, Tantalum, Gold, and many more.)
Tailor made solutions.
Transmitter UMF (to be used in hazardous areas)
Transmitter UMF2
|
|
VersaFlow Magnetic Flow Meters
The VersaFlow Mag 4000 is a process industry standard suitable for the most demanding applications. All meters consist of a sensor and a converter that may be mounted integral to the sensor or remotely either with a field mount kit, wall mount housing or a 19" rack mount housing. The TWM 9000 is the only electromagnetic flow converter with diagnostics for the instrument and application. The TWM 9000 is compatible with all electromagnetic flow sensors and is suitable for all applications
|
|
LCMag™ Electromagnetic Flow Meters
- Sizes: 1/8" through 72"
- Flow Rates: 0.05 through 400,000 GPM
- End Connections: ANSI Flanged, Wafer, Threaded, Tri - Clover (sanitary)
- Pressure Ratings: 150 - 300 ANSI
- Materials of Construction:
- Housing: Carbon Steel - 304 SS
- Electrodes: 316 SS - Hastelloy B, C & Titanium
- Liner: PTFE (Teflon®), Ebonite, EPDM & Polypropylene
- Accuracy: Capable of ±0.2% of rate over 10:1 range for flow velocity between 6 to 33 feet per second
- Repeatability: Capable of 0.1% of full scale
- Certifications: HMS 2410 Series models 3-A certified.
|
|
|
|
|
|
Phoenix America Inc.'s proprietary thermoplastic based bonded magnetic materials allow for intricate shapes and form factors to be developed. This capability has allowed magnetics to be used in variety of custom applications such as Flow Sensing.
The ability of Phoenix America Inc. to manufacture a magnetic target in literally any shape imaginable leads to employing magnetic speed sensing technology in several novel ways. On application is flow sensing. Phoenix America Inc. magnetic targets and magnetic speed sensors can be employed to derive fluid or air flow.
Replace an expensive flow sensors with complex mounting and interpreting algorithms with a Phoenix America Inc. magnetic sensor and propeller. We will custom develop a flow sensor for your application should you solution require it.
Since a Phoenix America Inc. magnetic based sensor is a non contacting device it can literally see through non ferrous objects such as water lines. Interfacing with a custom developed Phoenix America Inc. magnetic propeller, a Phoenix America Inc. sensor can either be threaded into a galvanized pipe to sense through a plastic tube.
|
|
Suitable for harsh environments and more sophisticated outputs either ABS or Aluminium.
Features:
- Easy to set (MENU);
- Analogue output 4-20 mA;
- RS 485 output (insulated);
- Pulse and alarm ON/OFF output;
- Bi-directional flowrate reading;
- Measurement frequency 10/20 Hz;
- Metric system (SI, UK, US);
- Input for connection of TRM 100 programmer;
- Power supply: 90...264 Vac 50-60 Hz or 24 Vac/dc 50-60 Hz;
- Keyboard;
- 2 lines 16 characters display;
- Batching function; batching alarm
- Low consumption operating mode;
- Empty pipe alarm (*);
- Alarm min and max flowrate;
- Alarm full scale change and reverse flow;
- Modbus protocol (*) ;
- Digital input for totalizer remote reset or batching start/stop;
|
|
The ISOMAG serie of insertion sensors offers different possibilities for any need:
- MS3700, sensor version with hot tap system to be mounted in pressurised pipes. Available in different sizes for pipes from DN 80 to DN 2000 mm. Accuracy equal to +/- 2% over the read value. Available in compact and separate version with all the ISOMAG converters, also the battery powered one.
- MS3770, sensor version for non–pressurised pipes. Available in different sizes for pipes from DN 80 to DN 2000 mm. Accuracy equal to +/- 2% over the read value. Available in compact and separate version with all the ISOMAG converters, also the battery powered one.
- MS3800, sensor version with hot tap system to be mounted in pressurised pipes through an axial thrust. Available in different sizes for pipes from DN 80 to DN 8000 mm. Accuracy equal to +/- 2% over the read value. Available in compact and separate version with all the ISOMAG converters, also the battery powered one.
|
|
|
|
|
|
CIAO has become very popular on the market as a valid and revolutionary alternative to the usual mechanical Woltmann counters for any application in the integrated water cycle.
Valid, because it is a magnetic flow-meter realised in plastic fusion (polyurethane rubber); simple in the installation, as it is equipped with ‘metallic wrappers’; available in a wide range of diameters: from DN 20 to DN 80 mm.
Revolutionary, because it guarantees exact and stable measures thanks to the electromagnetic induction principle and unlike the normal mechanical counters which have, by their own definition, mechanical moving parts subjected to wear and tear.
The absence of internal mechanical moving parts eliminates any need of assistance and maintenance and makes it an economical instrument in the initial cost and along all its life years.
CIAO allows data transmission trough analogical and digital signals.
CIAO is installed into the process through revolutionary connections made of metallic wrappers and covered by official patent.
|
|
- Electromagnetic flow-meter for sanitary applications.
- The smallest of the serie, from DN 3 to DN 100 mm.
- 3A certificate.
- According to the FDA Standards
- Available with a wide range of process connections.
- Version resistant to the vacuum in the process (200 mbar, absolut, at 100 °C)
- Body material: AISI 304
|
|
The world’s largest and finest choice of electromagnetic flowmeters from ABB for conductive fluids – water, pastes, acids, lyes, juices and emulsions including fluids with a conductivity as low as 0.5µS/cm (0.5µmhos). With a vast range of capabilities, our extensive range includes electromagnetic flowmeter for virtually any application.
HygienicMaster is designed specifically for the food & beverage, pharmaceutical and biotechnology industries. Manufactured from FDA approved materials and certified in accordance with EHEDG and 3A, HygienicMaster sets a new benchmark.
The stainless steel exterior, the variable process connection, the advanced signal processing and the state-of-the-art data storage provide a complete and cost effective flow solution.
- Highest measurement accuracy
- Intuitive navigation and configuration
- Backlit, high-contrast and configurable display
- Detailed diagnostics for rapid decision making
- Standard HART protocol
|
|
