Safety Relays
Standard-PCB-Relays
Remote switch
PCB-Relays, bistable
Miniature Power Relays
|
|
|
Our industrial relays (TEC and MTI trade marks) are approved by power and transport companies and are mounted in power plants (thermic or nuclear) and power distribution substations worldwide.
|
|
Features/Benefits:
- up to 8GHz
- High Repeatability
- up to 12Gbps Bandwidth for Digital Testing
- Surface-Mountable
Description:
The GRF312 relay is a DPDT surface mount relay with improved RF switching repeatability over the frequency range DC to 8GHz, with signal integrity characterised to 12Gbps. The relays have 5 or 12 Vdc coils as standard with special voltages available on request.
The relay is designed to provide high levels of resistance to shock and vibration.
All GRF312 relays are hermetically sealed to maintain the inert contact switching atmosphere over an extremely long period of time.
They are designed for use in load-board, attenuator, RF circuits and signal integrity applications. Its features include high resistance to electrostatic discharge (ESD) and high isolation between control and signal paths.
|
|
MRC SERIES Features
This series introduces 3 models one with 2 relays with 2 changeover contacts, one with 3 relays with one changeover contact and finally a model with 2 relays with 2 changeover contacts. The input voltage are 24VDC or 115VAC. It is possible to realize special executions and/or models upon request.
|
|
Intrinsically Safe galvanic isolated bistable relay for voltage free switch or proximity sensor.
2 models :
2 inputs - 1 output
4 inputs - 2 outputs
|
|
|
A demonstrated knowledge base for 40 years : whatever your activity, we offer relays perfectly adapted to your application.
|
|
|
Yaskawa's Bestact high capacity 3 & 5 amp reed (RB- series) multi-pole relays offer industry standard 8 pin (octal), DIN and panel mounting capability. They have UL/cUL recognition for gaseous Class I, Division 2 hazardous locations or corrosive environments and have been shown to significantly reduce downtime and/or maintenance costs. They offer greater shock/vibration resistance than electromechanical relays and better voltage isolation versus solid state relays. These multi-pole relays have pilot duty inductive switch ratings of 360VA (AC), 69VA (DC) and horsepower ratings of 0.5 & 1/8 HP respectively. For low-level loads, they exhibit a wiping action that keeps contact resistance very low and stable. 2, 3 and 5 pole configurations of normally open and normally closed contacts are available.
|
|
General description :
Panasonic automotive relays offer a sealed construction, ideal for harsh environments where resistance to moisture and contamination is essential. In addition to standard automotive applications, they are used extensively in construction and agricultural vehicles, as well as recreational vehicles and commercial landscaping equipment. Panasonic offers a full range of automotive relays:
- Plug-in types for powertrain control such as Mini-ISO, Micro-ISO, Micro-280 and JIS; both with through hole and SMT packaging
- PC board relays for a wide variety of automotive applications;
- High capacity types for hybrid and fuel cell vehicles and 42V systems
- New CN-H and CN-M for smart junction box, best space savings in its class, large capacity 30A load switching, high heat resistant & SMD types.
|
|
Panasonic automotive relays offer a sealed construction, ideal for harsh environments where resistance to moisture and contamination is essential. In addition to standard automotive applications, they are used extensively in construction and agricultural vehicles, as well as recreational vehicles and commercial landscaping equipment. Panasonic offers a full range of automotive relays:
- Plug-in types for powertrain control such as Mini-ISO, Micro-ISO, Micro-280 and JIS; both with through hole and SMT packaging
- PC board relays for a wide variety of automotive applications;
- High capacity types for hybrid and fuel cell vehicles and 42V systems
|
|
- contains R2, R3, R4, R2M, RY2, R10/R16, R15, R20,
RUC, RU400
- Range of rated load: from 5A up to 30A
- Range of coil voltage: from 5 up to 220 V DC and from 6 up to 380VAC
- Assembly: plug-in sockets for DIN rail or for panel, PCB
|
|
When it comes to selecting the appropriate type of relay, it%u2019s competence and flexibility that count. HENGSTLER relays offer a unique combination of competence, experience and flexibility.
The names of HENGSTLER and KACO have been a hallmark of leading-edge know-how in relay technology for decades. Their common product portfolio has been offered since 1966 and includes a variety of relays for switching currents from 1 to 100 A , suitable for a wide range of applications.
H-464:
Number of contacts: 8,10
Forced guided contact
set: Yes
Dimensions (LxWxH): 77.4 (87.4) x 20.5 x 48.6
Operation Voltage: DC 2.5 to 500 V
Max. switching
voltage: AC 230 / 240
DC 300 V
Max. switching
current: 10 A
Max. switching
capacity: 2000 VA; 120 W
RoHS-compliant: Yes
|
|
The RY/RM series of relays satisfy applications for lower level switching needs such as pilot lights or logic level devices. The RY has standard gold plated contacts to prevent contact oxidation from affecting circuit continuity, while optional Palladium alloy bifurcated contacts reduce contact bounce and allow circuit switching in the micro-amp range.
Terminated with a standard footprint of blade plug-in terminals or with PCB pins, the RY/RM series fit into many competitors' sockets as well. Available in 4PDT or two different arrangements of DPDT: the RM2 uses the same socket as the RY4, but the RY2 is a true two pole relay that occupies half the width of the four pole. Available options include manual check buttons, LED indicators, or top flanged dust covers for direct surface mounting.
|
|
The RY/RM series of relays satisfy applications for lower level switching needs such as pilot lights or logic level devices. The RY has standard gold plated contacts to prevent contact oxidation from affecting circuit continuity, while optional Palladium alloy bifurcated contacts reduce contact bounce and allow circuit switching in the micro-amp range.
Terminated with a standard footprint of blade plug-in terminals or with PCB pins, the RY/RM series fit into many competitors' sockets as well. Available in 4PDT or two different arrangements of DPDT: the RM2 uses the same socket as the RY4, but the RY2 is a true two pole relay that occupies half the width of the four pole. Available options include manual check buttons, LED indicators, or top flanged dust covers for direct surface mounting.
|
|
|
|
|
|
Industrial Plug-in Relays
Comprehensive range of industrial relays capable of switching loads from just 100 micro amps up to 15 A, incorporating many features and contact configurations covering most industrial applications. Plug-in relays are used in combination with industrial sockets for DIN-rail mounting. Wiring by conventional screw terminals or by screwless clamp technology.
Industrial High Power Relays
The power relay range is able to switch high currents of up to 160 A in various contact configurations, as recently, the 4 pole 40 A G7Z series has been added to the portfolio. Power relays can be mounted using screws, clips or on a DIN rail, whereas wiring the cables is possible using screw, pcb or quick-connect terminals, depending on the product family.
Sealed/Latching Plug-in Relays
Special plug-in relays for those applications that cannot be solved by standard products as they require a hermetically sealed cover or latching contacts. The latter available as magnetic double winding coil or alternatively as ratchet version performing make / brake operation at each pulse input.
|
|
For Control Panel
A wide range of products are available for the purpose of sequence control to direct load switching, which will suit for various applications depending on the control method or environment inside of a panel.
For Built-in
Multi-pole Relays provide high capacity and high dielectric strength. The G7L and G7J can be used selectively according to the characteristics of a compressor, a heater, or a motor.
Special-purpose
Special Relay can be used for alternating operation of motor drives.
|
|
|
Allen-Bradley offers the broadest range of relays and timers worldwide. They are designed, manufactured and tested to meet the most demanding worldwide standards and ratings. One-stop shopping saves you time and money, lowering your total cost of ownership. Our General Purpose Relays and Timers offer reliable design, quick replacements, panel space-saving and solutions. Our Industrial Relays and Timers are designed for heavier-duty applications, large loads, long life and safety circuits. Use our main menu to see the latest line-up of Relays and Timers that offer increased functionality, flexibility and performance.
|
|
Magnetic Latching Relays RH2L Series
The smaller magnetic latching relays with blade or PC board terminations are still rated up to 10A. They operate by pulse inputs, which saves power and eliminiates the need for a continuous control voltage. DIN rail, panel, and PCB mount sockets are available for a wide range of mounting applications.
Key Features
Contacts rated to 10A/250V AC, 10A/20V DC
Available with blade and PC mount terminals
Compact miniature size saves board space
Coils rated for continuous duty
Built-in operation indicator to show set/reset condition
10A
|
|
Electromechanical Relays
- Comprehensive range of general purpose and special purpose industrial relays capable of switching loads from micro-amps to 30 A, incorporating many features and contact configurations.
|
|
|
The PLC-RELAY is the only pluggable quarter inch terminal block, which accepts either a solid-state relay or an electromechanical relay. Using only one part number, you are able to order both the base terminal block and the pluggable relay as a single unit. The PLC-RELAY is also available with switching capacities up to 10 A at 250 V ac.
|
|
|
|
|
|
In the area of suppression modules for contactors, valves and motors, we offer the corresponding components to increase EMC throughout the whole installation. We can meet all normal requirements in the field of power supplies with our power supply units, incorporating primary switching technology and control-power transformers.
Interface technology is represented in the Lutze programme by a wide range of different components that can be used to create just about any interface needed in your application.
Lütze Relay Modules: For volt free, isolated switching applications; Space-saving Microcompact 6.2 mm design or with wide-range inputs; Modules with special certification available (UL, GL, EN50155); Over 60 different types; Wide-range input; Pluggable.
Lütze Semiconductor Relay Modules: For non-contact switching; For long service life even with frequent fast switching operations; Space-saving Microcompact 6.2 mm design with built-in monitoring and pluggable; Over 30 different types; Overload protected; Monitoring function.
|
|
7PA22 and 7PA23 are fast-acting lockout relay with eight changeover contacts and four changeover contacts, respectively.
Due to their quality, reliability and design, these relays are optimal for applications requiring high reliability and availability such as power stations, substations, railway and industrial plants. Typical examples include petrochemical industry, chemical industry, cement industry, rolling mills etc.
The relays comply with the IEC, EN, IEEE standards (type and routine test) and bear the CE mark.
The robust switch contacts are characterized by high make/break capacity, overload capability and continuous current intensity capacity; thus perfect insulation is obtained. Direct control of high-voltage and medium-voltage switchgear is possible. Their high degree of protection and the transparent cover ensure reliable operation in tropical and/or salty sea air ambient conditions.
|
|
|
The adaptable RU series are available in either 2 pole (DPDT) or 4 pole (4DPDT) models. Both RU2 and RU4 models have multiple standard features, including a non-polarized green indicator LED, a mechanical indicator flag, an easily accessible and replaceable marking plate, and a manual latching lever, coded orange/red for AC coil and green/blue for DC coil.
|
|
|
The adaptable RU series are available in either 2 pole (DPDT) or 4 pole (4DPDT) models. Both RU2 and RU4 models have multiple standard features, including a non-polarized green indicator LED, a mechanical indicator flag, an easily accessible and replaceable marking plate, and a manual latching lever, coded orange/red for AC coil and green/blue for DC coil.
|
|
|
Designed with attention to every detail, IDEC Relays go the extra mile in performance and dependability. RU relays are constructed with no internal wiring in a 100% automated, robotic-assembly process, which for you means no weak solder points. Our RH relays are built-to-last and 3rd party tested at 500,000 operating cycles, even though UL approval only requires an electrical lifespan of 6,000 cycles. And the newest addition to our relay family is no exception. RJ relays have an optional green, non-polarized LED that uses a unique light guide to give you a brighter and more noticeable status indicator, viewable from multiple directions
|
|
7PA27 is monostable fast-acting relay with four changeover contacts.
The design, durability and quality of these relays guarantee their application in high responsibility controls such as power stations, substations, railway, industries of continuous processes (petrochemical, rolling mills, cement and chemical industries), etc.
The relay has been tested in accordance with IEC,EN and IEEE standards. The relay is CE marked. The great power of the output contacts allows direct action on HV and MV switchgear, because of its making/breaking capacities, high permanent current and overvoltage capacity.
|
|
Everel relay sockets meet various application requirements with five main series:
sockets for relays with 8-11 pins (octal-undecal)
sockets for miniature relays
sockets for PCB relays
sockets with PCB pins for PCB relays
sockets for Slim relays
Our offer is completed by an highly diversified series of accessories and modules.
|
|
|
The IMO Automotive Relays, including the products manufactured by NEC-Tokin, offer switching capability up to 45A in PCB mount, and 70A in Plug-In Termination.
|
|
Terminal relay Spring clamp/screw terminals
Relays Screw terminals
base sockets
Relay sockets
MIRO 6.2 plug socket Spring clamp terminals
Plug-in relay
Accessories
|
|
Features:
- Variety of Operating Voltages.
- Switching Current upto 10 A at 230 VAC (or 30 VDC)
- Low Coil Drive Current (4.7 mA to 100 mA)
- Easy to replace pluggable relays.
- Possibility of Bussing (Jumpering) relays in common negative or common positive configurations.
- LED Indication to denote relay actuation.
- Relay Coil Protection by means of a Freewheeling Diode.
- Mounting Options available: DIN Rail mounting & Panel Mounting.
- Type of Connection: Screw Connection
- Contact Type: 1CO (SPDT) / 2CO / 4CO / 1NO / 2NO
|
|
SocketPac® helps eliminate heat distribution problems during wave soldering operations, protecting power supplies, and making replacement, upgrades, and repairs easier. SocketPac® utilizes our patented Peel-A-Way® carrier and delivery system to quickly load socket pins into the PC board prior to soldering, and allows for complete soldering visibility on both sides of PC board. Completely customized to your application.
Featured with :
- no special assembly is required
- multiple terminal types available on single sheets for simple one-step loading
- available in a thru-hole design for board-to-board applications, with tape seal and solder preform options
- complete line of Relay Sockets with a variety of terminal options available
heavy power socket terminal available
|
|
|
|
