SIMCO Chargemaster systems are excellently suited for temporarily bonding materials; adhesion between the material surfaces is brought about by generating an electrostatic charge. As a result, production processes can often be simplified and accelerated. A system consists of a DC highvoltage generator and one or several charging electrodes. The generator generates the high voltage for the high voltage points in the electrodes. The high voltage points produce ions to charge the materials, which then adhere to each other or to other surfaces electrostatically. Highfrequency switching technology is used in the generators. This technology ensures a consistent output voltage at a preset value, until overloading. The generators are electronically current limited and protected from spark-over. Features of the modern design include the control panel, which has membrane switches and rotates through 180°.
|
|
|
|
|
|
992v3 - 30kV Static Generator
The Meech Model 992v3 30kV Static Generator creates a controlled level of static charge to impart temporary bonding between materials, at least one of which is insulative. The 992v3 provides a high voltage output adjustable over the range 0-30kV or a constant current that can be adjusted between 0 and 500µA. The selected output voltage or current is shown on a digital display. The adjustability of the output voltage and current enables the unit to be used in a multitude of applications and with a variety of materials. The 992v3 is used in conjunction with the Model 993R sparkfree generator bar (refer to separate datasheet) and is available in either negative or positive output polarity versions.
Technical Characteristics
Output voltage 0-30kV
Output polarity Dedicated positive or negative
Maximum Output current 0 to 500µA
Power input requirements Mains supply of 85 to 265V, 47 - 63Hz
Maximum temperature 60 ºC
Dimensions 95mm x 180mm x 235mm (HxWxD)
Weight 3.25Kg
Construction Painted steel enclosure
|
|
|
HVDC 2000 Charging Generator is suitablefor high voltage applications in industry and for DC powered bars. The unit output voltage and protection current value are set digitally by using the front panel. The output voltage can be set between 3kV-20kV and current can be set between 0-740uA. The power supply includes remote on/off and remote voltage andjustment settings and is available as positive or negative.
|
|
