| The Waukesha Engine System Manager (ESM) is a total engine management system designed to optimize engine performance and maximize uptime. The ESM integrates spark timing control, speed governing, detonation detection, start-stop control, diagnostic tools, fault logging and engine safeties. |
|
| ... products without technical information |
| |
This compact engine is purposely designed from the ground up for stationary, spark ignited, gaseous fuel applications. The VGF is not limited to weight-sensitive mobile equipment requirements. Its high weight-to-power ratio provides a solid foundation for years of consistent and dependable operation. For the size and price of other high speed engines, the VGF provides full power around the clock, with substantially reduced maintenance and operating costs. You get more engine, more reliability, more performance, more uptime, and more value - at less cost.
Because of their size to power ratio and high speed continuous-duty capability, VGF engines are remarkably cost-effective to their "clean" design requires less piping. |
|
Waukesha Engine%u2019s VHP%u2122 Series Four line-up offers lower-cost horsepower with the simplicity, dependability and low emissions potential of a simple, rich burn design. Our engineers took a "clean sheet" approach in developing this series%u2019 cylinder head. We combined the best features of existing Waukesha Engine products with the latest engineering technologies. Finite element analysis and solid modeling were used to create a head that%u2019s 33% stronger at increased BMEP levels.
Realizing that the permitting process for air quality standards can vary greatly, Waukesha Engine%u2019s VHP engines are available in a variety
of configurations %u2013 rich burn or lean burn ... standard or pre-chamber %u2013 and with your choice of two control types. Here are the most
popular models:
GSI: The VHP GSI rich burn engine can be combined with a catalytic converter to meet the strictest emissions regulations. In addition,
the GSI Series provides low-cost maintenance, good fuel tolerance and excellent load response.
GL: Waukesha Engine%u2019s VHP GL engines provide both low emissions and high efficiency. The GL Series features a pre-chamber combustion
system to assure low emissions across a wide load and speed range, without a loss of combustion stability at lean air/fuel ratios.
LT: The VHP LT offers the flexibility and reliability of rich burn engines while still meeting regulatory standards for emissions. |
|
In an era where more power and lower life-cycle costs are expected,
the Waukesha ATGL delivers. More power. More fuel efficiency. More emissions control. More uptime. More productivity.
Built on the proven strength of a diesel frame and key diesel components such as crankcase, crankshaft, and connecting rods, the ATGL also incorporates some of the most sophisticated combustion and control
technologies available. The result is an engine series that not only
extended Waukesha%u2019s legendary reputation for hard-working, reliable gas engines but sets the industry standard for high-horsepower, high-torque productivity.
The sixteen-cylinder ATGL
As customer requirements for power, reliability and performance
increased, Waukesha went to work to make the ATGL meet the greatest
demands. The new 16V-AT27GL achieves world-class emissions and fuel
economy, while increasing torque and horsepower by 37% relative to
the 12V-ATGL. It also offers better turndown, better altitude capability,
longer service intervals, lower environmental impact and reduced
maintenance requirements. |
|
VSG%u2122 Series Gas Engine 166 - 260 BHP: F11GSID
BASE ENGINE
CAMSHAFT %u2013 Forged alloy steel, quiet helical gear drive.
CONNECTING RODS %u2013 Forged alloy steel. Angle split.
CRANKCASE %u2013 Integral alloy cast iron crankcase and cylinder frame with nodular iron main bearing caps.
CRANKSHAFT %u2013 Forged alloy steel with precision ground and induction hardened main and crankpin
journals, statically and dynamically balanced. Viscous vibration damper.
CYLINDERS %u2013 Replaceable wet cylinder liners of centrifugally cast alloy iron.
FLYWHEEL %u2013 With 148 tooth ring gear (for Delco electric and Ingersoll Rand air/gas starters). Flywheel
machined for Twin Disc 14%u2033 industrial clutch.
FLYWHEEL HOUSING %u2013 SAE #1 with provision for three magnetic pickups and vertical mounting pads.
PISTONS %u2013 Aluminum alloy, with cast iron top ring insert. Oil cooled. Top ring is chrome plated keystone
type. 10:1 compression ratio.
|
|
APG3000: Gas Enginator® Generating System Featuring ESM® Technology 2800 - 3200 kW
BASIC SPECIFICATIONS
AFR – Air Fuel Ratio control included with ESM®. Load based control with continuous feedback. Requires kW input.
CONTROL SYSTEM – Waukesha Engine System Manager (ESM) integrates fuel injection, spark timing control, speed governing, detonation protection, start-stop control, diagnostic tools, fault logging and engine
safeties. Engine Control Unit (ECU) is central brain of the control system and main customer interface. Interface with ESM is through 25 foot (7.6m) harness to local panel, through MODBUS RTU slave connection RS-485 multidrop hardware, and through the Electronic Service Program (ESP). Customer’s connections are only required to the local panel, fuel valve, and for 24V DC power supply. Compatible with Woodward load sharing module. ESM meets Canadian Standard Association Class I, Division 2, Group D, hazardous location requirements. Logic provided for engine preheat, engine prelube, gas train and exhaust venting.
CRANKCASE - Nodular cast iron, fully ribbed, integral with cylinder frame. Hydraulically fastened main bearing caps. Optimal compact and rigid design including large inspection doors.
CYLINDERS - Removable wet type cylinder liners, centrifugally cast iron with anti polishing ring.
CYLINDER HEADS - Eighteen interchangeable robust design cylinder heads with hydraulically tensioned studs. Grey cast iron. Four valves per head - two intake and two exhaust valve with replaceable intake and exhaust valve seats, stellite-coated seat faces and chromium-plated stems. Watercooled flame deck and prechamber. Prechamber is heat resistant alloy steel.
|
|
APG2000: Gas Enginator® Generating System Featuring ESM® Technology 1860 - 2100 kW
AFR – Air Fuel Ratio control included with ESM®. Load based control with continuous feedback. Requires kW input.
CONTROL SYSTEM – Waukesha Engine System Manager (ESM®) integrates fuel injection, spark timing control, speed governing, detonation protection, start-stop control, diagnostic tools, fault logging and engine
safeties. Engine Control Unit (ECU) is central brain of the control system and main customer interface. Interface with ESM is through 25 foot (7.6m) harness to local panel, through MODBUS RTU slave connection RS-485 multidrop hardware, and through the Electronic Service Program (ESP). Customer’s connections are only required to the local panel, fuel valve, and for 24V DC power supply. Compatible with Woodward load sharing module. ESM meets Canadian Standard Association Class I, Division 2, Group D, hazardous location requirements. Logic provided for engine preheat, engine prelube, gas train and exhaust venting.
CRANKCASE – Nodular cast iron, fully ribbed, integral with cylinder frame. Hydraulically fastened main bearing caps. Optimal compact and rigid design including large inspection doors.
CYLINDERS – Removable wet type cylinder liners, centrifugally cast iron with anti polishing ring.
CYLINDER HEADS – Twelve interchangeable robust design cylinder heads with
hydraulically tensioned studs. Grey cast iron. Four valves per head - two intake and two
exhaust valve with replaceable intake and exhaust valve seats, stellite-coated seat faces and chromiumplated stems. Water-cooled flame deck and prechamber. Prechamber is heat resistant alloy steel.
|
|
APG1000: APG Gas Enginator® Generating System Featuring ESM® Technology 1000 - 1100 kW
The first of the new APG Series, the APG1000 Enginator genset, is a 1MW unit that extends Waukesha's high-speed product offering into the 800 to 1100 kW range. Used alone or grouped with other units, this one megawatt genset is one of the key building blocks in developing gasdriven
power generation solutions that meet customer needs.
The APG1000 has been developed in cooperation with the U.S. Department of Energy (DOE) as part of the DOE's Advanced Reciprocating Engine Systems (ARES) program. The ARES program was created to accelerate the development of large natural gas engines that operate
with increased efficiency while meeting tight emissions requirements, maintaining current levels of reliability and durability, and reducing ownership costs.
The APG1000 is a 16-cylinder, turbocharged, intercooled, lean combustion power generation unit that features ultra-low NOx capability and patented ignition system and combustion chamber concepts. It is rated at 1000 kW at 50 Hz and 1100 kW at 60 Hz - 500 and 1800 rpm, respectively. It is one of the most efficient 1 MW units available at 1800 rpm, 42 % BTE (brake thermal efficiency) and is among the lowest in lean burn emissions (1 g/bhp-hr NOx). At 42 % BTE, the APG1000 is six percentage points better than the previous generation of the engine from which the APG1000 is derived.
CONTROL SYSTEM - Waukesha Engine System Manager (ESM) integrates spark timing control, speed governing, detonation protection, start-stop control, diagnostic tools, fault logging and engine safeties. Engine Control Unit (ECU) is central brain of the control system and main customer interface. Interface with ESM is through 25 foot (7.6m) harness to local panel, through MODBUS RTU slave connection RS-485 multidrop hardware, and through the Electronic Service Program (ESP). Customer’s connections are only required to the local panel, fuel valve, and for 24V DC power supply. Compatible with Woodward load sharing module. ESM meets Canadian Standard Association Class 1, Division 2, Group D, hazardous location requirements.
|
|
| ... products without technical information |
| |
The ATG Series Is the largest-size engine line Waukesha Engine manufactures. ATGL engines are available in 8, 12 and 16 cylinder configurations.
By using a Waukesha Enginator engine/generator set to produce energy, you'll significantly reduce or eliminate your reliance on the electric utility. ATGL Englnator units are available from 1330 kW to 2960 kW continuous 60Hz power at 900 rpm.
The sixteen-cylinder ATGL
As customer requirements for power, reliability and performance
increased, Waukesha went to work to make the ATGL meet the greatest
demands. The new 16V-AT27GL achieves world-class emissions and fuel
economy, while increasing torque and horsepower by 37% relative to
the 12V-ATGL. It also offers better turndown, better altitude capability,
longer service intervals, lower environmental impact and reduced
maintenance requirements.
|
|
|
|
