FNL – for an optimum connection of fieldbus and Ethernet networks up to 100 Mbit/s.
FNL allows the connection to all PROFIBUS DP networks based on RS485 (up to 12 Mbit/s) and supports DP Master class 1/2 on the basis of DP and DPV1 services as well as DP Slave.
The access to FNL is carried out through a TCP/IP socket interface. The interface is operating system independent, completely unfolded and because of its quickness convincing.
The Ethernet based operation mode as MODBUS TCP/IP Slave provides easy integration of FNL as PROFIBUS DP Master into a large number of visualisation and control systems. The PROFIBUS DP based diagnostics and IO data are dynamically compiled into the MODBUS TCP/IP structure and do not have to be configured additionally.
OPC Server
The OPC Server directly connects FNL to all OPC-client-capable Windows applications. OPC is supported by all common SCADA, control, visualization, and process control systems.
Programming Interface
The FNL TCP/IP socket interface provides the exchange of the DP Slaves' process and diagnostics data as well as all DP/DPV1 Master class 1/2 and DP Slave services. So FNL can be easily integrated in any operation systems.
FDT 1.2 Communication DTM
FDT allows the standardized configuration of fieldbus devices via different bus systems like HART-Bus, Foundation Fieldbus, PROFIBUS DP/PA or Ethernet.
LabVIEW Driver
The driver can be integrated in a simple manner into every LabVIEW version due to its standard TCP/IP socket interface. Ethernet and PROFIBUS DP configuration are generated via full graphical tools, included in the delivery. The package also includes LabVIEW sample VIs incl. source code.
|
|
|
|
|
|
SNL2-E Ethernet/RS232/RS485 Gateway
SNL2-E – the optimal solution for connection of serial interfaces and Ethernet networks of up to 100 Mbit/s.
SNL2-E allows the connection of two serial end devices. The serial interfaces can be configured via software as RS232- or RS422/RS485 interfaces. Also, a mixed operation mode is possible.
In addition, for operating the RS485 bus, terminating resistors can be switched on via software. Operation in TTY mode can be realized by means of an external adapter.
Both interfaces support full duplex DMA mode operation. In synchronous operation mode, rates of up to 1 Mbit/s can be reached.
The protocol firmware is loadable. The serial interfaces can be run completely independent from each other. On every serial interface a different protocol driver can be loaded and run.
DF-compatible driver interface
For Windows, as well as UNIX operating systems the DF-board compatible interface allows the replacement of an existing DF-board by an SNL2-E module without any changes in the application software.
|
|
Industrial Ethernet
In this area all Ethernet Gateways, Protocol converters and All-In-One bus nodes are filtered out and displayed. We are already offering solutions for 4 of the more then 20 Industrial Ethernet-versions. Others will be added.
Additionally you will find the Routers in this area, such as the Powerlink-Router. With these devices you connect Industrial Ethernet networks with the "standard" Ethernet.
|
|
|
|
|
|
Anybus Communicator® is a family of certified and proven gateways, connecting automation devices via their serial interface to all major fieldbusses. The Communicator enables industrial devices without a network interface to connect to all major standard fieldbusses including Profibus, DeviceNet, CANopen, ControlNet, CC-Link, Modbus-RTU, Modbus-Plus, Interbus and FIPIO.
The Communicator performs an intelligent conversion between the serial protocol of the automation device and the chosen fieldbus network.
The Anybus Communicator supports RS-232, RS-422 and RS-485 serial electrical signals without any change in hardware. This allows for connectivity to a broad range of serial devices. Typical serial applications include variable frequency drives, sensors, actuators, human machine interfaces, barcode readers, RFID readers and industrial scales among others. It is much more than just a standard tunneling gateway and provides full flexibility and extended connectivity options.
The Anybus Communicator is configured using a very simple Windows%u2122 based software package that requires that the user simply fill in the blanks to match the protocol of the serial device it is connected to. Applications that require conversions from serial Modbus to fieldbus protocols are even easier as a built-in software wizard guides the user through each step of the configuration process.
|
|
|
|
|
|
Anybus Communicator® is a family of certified and proven gateways, connecting automation devices via their serial interface to all major real-time industrial Ethernet networks. The Communicator enables industrial devices without a network interface to connect to all major real-time Ethernet standards including EtherNet/IP, Profinet, Modbus-TCP and EtherCAT.
The Communicator performs an intelligent conversion between the serial protocol of the automation device and real-time industrial Ethernet network.
The Anybus Communicator supports RS-232, RS-422 and RS-485 serial electrical signals without any change in hardware. This allows for connectivity to a broad range of serial devices. Typical serial applications include variable frequency drives, sensors, actuators, human machine interfaces, barcode readers, RFID readers and industrial scales among others. It is much more than just a standard tunneling gateway and provides full flexibility and extended connectivity options.
The Anybus Communicator is configured using a very simple Windows™ based software package that requires that the user simply fill in the blanks to match the protocol of the serial device it is connected to. Applications that require conversions from serial Modbus to real-time Ethernet protocols are even easier as a built-in software wizard guides the user through each step of the configuration process.
|
|
|
|
|
|
Solve most any Modbus conversion challenge with the MESR Modbus Gateway
MESR Modbus Gateways bridge devices on Modbus serial networks (RS-232, RS-422 or RS-485) with those on Modbus TCP networks, allowing seamless integration of any Modbus device. Each serial port is accessible over a LAN or WAN by up to 16 simultaneous Modbus TCP masters. All Vlinx™ MESR gateways feature auto detecting 10/100Base T copper and fiber optic connections.
Simple Installation and Setup
Removable terminal blocks simplify power and data connections
Slimline IP30 DIN mount enclosure minimizes footprint
Simple configuration through the built-in web server, or Windows configuration software
Built-in traffic monitor for instant verification of successful installation and simple network diagnostics
Optional pass-through Ethernet port eliminates need for additional Ethernet switch port
Optional Fiber Optic Ethernet connections for long-distance and total noise immunity
Features
Slim, Industrial Enclosure
Modbus Master/Slave Flexibility
Web Server Configuration Software
Complete Fiber Options Low Latency
High Throughput
Heartbeat Connection
Benefits
Save DIN rail space while maintaining industrial ratings
Modbus master or slave can be on any serial port or on the Ethernet port. Customizable to your application.
Program through web browser or local port. Same user interface; no training required
Connect to all fiber networks in your plant without converting to copper connections
View status in real time
Detects communication failures and automatically reconnects to keep the system online
|
|
|
|
|
|
MGate™ EIP3000 series products can be used to connect DF1 devices and EtherNet/IP devices to provide Allen Bradley PLCs with remote maintenance capability. By supporting PCCC objects on CIP, the MGate™ EIP3000 can communicate seamlessly with Rockwell Ethernet devices. The EIP3000 protocol gateways come with either 1 or 2 serial ports to allow users to select a suitable gateway depending on the size of the network. The EIP3000 series supports up to 8 Ethernet/IP clients and 8 Ethernet/IP servers simultaneously; each client can send up to 16 requests at one time. Moreover, each MGate EIP3000 gateway supports four virtual serial ports for remote control over an Ethernet connection. OPC servers and SCADA systems can use these virtual COM ports to communicate with EtherNet/IP devices or DF1 devices through the gateway.
Features:
ÿPCCC objects for Rockwell Automation networks supported
ÿProCOM provides a virtual serial port for multiple DF1 and ››EtherNet/IP device communication
ÿ16 simultaneous EtherNet/IP clients/servers with up to 16 ››simultaneous requests per client
ÿSerial redirector function provided
ÿEmbedded EtherNet/IP and DF1 protocol analyzer
ÿRedundant dual DC power inputs
ÿBuilt-in Ethernet cascading for easy wiring
|
|
|
|
|
|
ACKSYS renews its serial to wireless solution offer by introducing the WLg-DONGLE, a compact wireless RS232 serial to WiFi Ethernet server with support for 2.4 GHz and 5 GHz radio bands.
WLg-DONGLE relies on the same technology used in the "WLg-xxx" series and thus profit from proven technology, device is very compact and is specially designed to satisfy the needs of the system integrator market.
Product rely on the IEEE 802.11 a/b/g/h standards (2.4 GHz & 5 GHz), it features an full high speed serial port (250 Kbps).
The radio link is made safe by using most modern methods of protection: WEP 64/128 bits, WPA-PSK, WPA2-PSK and authentification IEEE 802.1x (RADIUS).
The nominal range (open space) of the module is 300 m for a transmit power of +20 dBm and -92 dBm in reception (a/g modes) and -95 dBm (IEEE 802.11b mode).
This module supports the following modes : TCP Client / Server, TELNET RFC2217, COM port redirection, TELNET server, raw, point to point (virtual cable) and the serial MODBUS to MODBUS/TCP gateway.
Easy configuration and administration with your web browser, TELNET, SNMP and from the ACKSYS administration software NDM.
|
|
Connects your PROFIBUS to Ethernet
-Scalable from one PB channel to up to three PB channels per device
-Master or slave
-Ethernet 100BASE-TX / 10BASE-T, 100Mbits/s and 10 Mbits/s
-Application interface identical to Profibus interface cards
-PC drivers for Windows
-No fan
-OPC server available
-Suitable for use with DTM / FDT
|
|
The Westermo Fieldbus devices are industrial PROFIBUS DP modules. There are different types of slave modules and one Master module. PROFIBUS adapters that is able to transfer PROFIBUS DP I/O data via serial communication. I.e leased lines, dial up modems, Ethernet adapters, GSM modems or radio modems without any use of special drivers or special PLC bords. The FD-20, PROFIBUS DP Master module act the same way as the adapters on the serial side and act as a stand alone master on the PROFIBUS side. A combination with our Ethernet adapter gives the opportunity to connect PROFIBUS to Ethernet PROFIBUS DP converter to make a transparent connection for a different serial interfaces to a PROFIBUS DP network.
|
|
|
INAT echolink is a Serial Ethernet converter. With echolink, devices without network adapter are able to communicate via network. Echolink supports a wide range of serial protocols. Therefore echolink is much more than a simple data converter. It supports complex applications such as PLC programming or process data visualisation.
|
|
|
|
|
|
|
Ethernet Direct Panda Series PROFIBUS DP products are in production technology as well as in the connection of distributed intelligence such as the networking of multiple controllers to one another. The data rates are up to 12Mbit/s on twisted pair cables and fiber optics are also possible. Panda Series PROFIBUS converter and gateways are designed for a wide range of applications, particularly in the fields of factory and process automation. It is suitable for both fast, time-critical applications and complex communication tasks with safety and stability when use in industrial applications. The Panda converters are designed specifically for the slave device of PROFIBUS DP protocol. It offers RS-232, RS-422 and RS-485 three kinds of communication way. With the Hybrid COM 1 design, users can readily choose one type of comport to use. By using this module, suers can put their RS-232/422/485 devices into PROFIBUS network very easily. The Panda Series gateways are also designed for the salve device of PROFIBUS DP protocol. It allows the PROFIBUS master to access the Modbus devices. These Modbus devices may be a PLC, a sensor, modules and other equipments. In addtion, Ethernet Direct also provides the utility software for users to configure the Panda gateways. By using this module, users can put their Modbus devices into PROFIBUS network very easily.
|
|
|
|
|
|
The Anybus- X-gateway® family consists of over 180 certified and proven industrial gateways connecting almost any two industrial networks. The X-gateway is a simple, easy to use gateway connection real-time Ethernet networks to almost any fieldbus.
Real-time Ethernet protocols supported:
• EtherNet/IP scanner or adapter
• PROFINet IO Device
• Modbus TCP slave
• EtherCAT slave
• HTTP Server
• FTP Server
• Telnet Server
• SMTP Client
Fieldbusses supported:
• Profibus master or slave
• DeviceNet scanner or adapter
• AS-interface master
• CANopen slave
• ControlNet adapter
• CC-Link slave
• Modbus RTU slave
• Modbus Plus slave
• Interbus slave
• FIPIO slave
Slave to Slave Gateway:
Many applications need to take two disparate independent networks with each having its own master control and allow them to exchange data. This happens where two PLCs need to exchange information. The X-gateway helps to accomplish this by acting as an I/O slave device on the fieldbus and Ethernet networks. Each master/client writes to the output table of the X-gateway on its network and then the X-gateway maps this data to the input table of the opposite fieldbus or Ethernet network where it can be easily read by the other master/client.
Master to Slave Gateway:
Many applications needs to interface field I/O devices to a controller that has a different fieldbus or Ethernet protocol from the I/O. In these cases, the X-gateway serves as a fieldbus or Ethernet master on one side while acting as a fieldbus or Ethernet slave on the other. The I/O data is polled from the field devices then mapped into the I/O table of the controller.
|
|
|
|
|
|
UP for an industrial strength painkiller?
Enabling communication from factory floor devices to PLC controllers just got a whole lot easier. The DeviceMaster UP industrial Ethernet gateway offers a flashable solution that configures in minutes via the web, allowing you to support the major industrial Ethernet PLC networks – EtherNet/IP, PROFINET, or Modbus/TCP – on a single platform.
Whichever protocol you need, the DeviceMaster UP provides an RS-232/422/485 software-selectable connection to an industrial Ethernet network.
By accommodating multiple protocols, the DeviceMaster UP provides an adaptable and flexible platform device integrators and distributors need to thrive in rapidly changing markets. It's the pain-free Industrial Ethernet solution that simplifies supply chain management and reduces expenses for you and your customers.
It's power over protocol.
DeviceMaster UP Highlights
DualConnectPlus™ Technology – simultaneously connect both serial and Ethernet devices to PLCs and/or applications. String, RFID, and barcode data filtering eliminates redundant data while extracting the RFID and barcode parameters.
Provide PLC connectivity to standard serial devices with flashable protocol support for EtherNet/IP, PROFINET, Modbus/TCP, and TCP/IP
Compact and hardened form-factor — wide -37° to 74°C industrial temperature range
Variable power input eliminates need for power converters
PortVision® enables user to view status, update firmware and resolve issues remotely.
RoHS Directive 2002/95/EC compliant
|
|
|
|
|
|
UP for an industrial strength painkiller?
Enabling communication from factory floor devices to PLC controllers just got a whole lot easier. The DeviceMaster UP offers a flashable solution that configures in minutes via the web, allowing you to support the major industrial Ethernet PLC networks – EtherNet/IP, PROFINET, or Modbus/TCP – on a single platform.
Whichever protocol you need, the DeviceMaster UP provides an RS-232/422/485 software-selectable connection to an industrial Ethernet network.
By accommodating multiple protocols, the DeviceMaster UP provides an adaptable and flexible platform device integrators and distributors need to thrive in rapidly changing markets. It's the pain-free Industrial Ethernet solution that simplifies supply chain management and reduces expenses for you and your customers.
It's power over protocol.
Highlights
DualConnectPlus™ Technology – simultaneously connect both serial and Ethernet devices to PLCs and/or applications. String, RFID, and barcode data filtering eliminates redundant data while extracting the RFID and barcode parameters.
Provide PLC connectivity to standard serial devices with flashable protocol support for EtherNet/IP, PROFINET, Modbus/TCP, and TCP/IP
Compact and hardened form-factor — wide -37° to 74°C industrial temperature range
Variable power input eliminates need for power converters
PortVision® enables user to view status, update firmware and resolve issues remotely.
RoHS Directive 2002/95/EC compliant
|
|
| ... products without technical information |
| |
Wirelessly connect PLC's on a new machine to an existing factory automation LAN
Interface different automation LAN's in different sections of a plant
Connect different protocol devices into a common wireless network
Use ELPRO Wireless I/O units as remote I/O for PLC's
Features
Wireless extension of factory automation buses such as Profibus and Ethernet, providing a high security firewall
Interconnect different data buses - Wireless protocol conversion
Interface between PLC's, DCS, HMI or SCADA and ELPRO wireless I/O units
High security data encryption
Automatic acknowledgment and error-correction,
Peer to peer addressing, and Multiple path routing
|
|
|
SENCITY®LINK operates at a frequency of 60 Ghz with a net data rate of 100 Mbps full duplex over a distance of up to 800 m (2600 ft). Measuring only 16x16 cm (6.3"x 6.3"), its compact size is due to deep integration of its active and passive components. The SENCITY® Link system is unique in its small unobtrusive size and ease of installation which is facilitated by the simplicity of an optical pointing and alignment bracket. Extensive trials and customer installations have proven that this HUBER+SUHNER solution mitigates expensive civil works and minimizes visual impact.
|
|
PC-W provides wireless connectivity for serial devices of RS-232/422/485 and Ethernet devices. It is suitable for bridging communications in places difficult to wire or impractical to wire and also useful for mobile user interfaces, especially in an industrial environments. It can be used with all Brainchild's products HMI, IO modules, recorders & controllers or other industrial products.
FEATURES:
* 2 numbers serial ports
* Selectable RS-232/RS-485/RS-422 serial mode by software
* Transparent between Ethernet to Wireless networking
* Support UDP, TCP server and client protocols for Virtual COM mode and pair connection
* Configurable via built-in web server and Windows-based utilities
* Metal housing and IP50 standard with DIN-Rail mounting
* 15KV ESD protection for serial ports
* IEEE 802.11g 54Mbps wireless network connectivity
* Standard 2.4GHz High-gain antenna
** Please visit us at coming exhibition Hannover Messe 2009 at "Hall 9, Stand H24" during April 20-24, 2009.
|
|
HyperLan-Pack
Ready-to-use Point-to-Point Wireless Ethernet Bridge
HyperLan-Pack is a solution to establish a high speed Ethernet wireless link between buildings, factories, CCTV cameras, offshore platforms and temporary installations ... to connect Ethernet networks or Ethernet devices between each other.
HyperLan-Pack is available in two versions : long range (up to 5 Km) and medium distance (up to 1.5 Km) at 40 Mbps.
Range increase significantly (up to 50 Km) if data rate is reduced to 10 Mbps.
The kit is built around two WiFi units and two parabolic antennas, installation is very easy as described below :
Antenna height calculation depending on distance and land topography
Antenna mounting on masts
Antenna tilt calculation using ACKSYS software and a GPS
Antenna vertical alignment according to calculated tilts using a clinometer
Antenna horizontal alignment using a compass
Ethernet cable connexion on each unit
Radio quality and sustained data rate checking
|
|
Ethernet Air-Pack
Ready-to-use Point-to-Point wireless Ethernet Bridge
Ethernet Air-Pack is a ready-to-use solution designed to :
- replace any Ethernet cable between equipments (PC, IP video, printers ...),
- replace the network cable between the RJ45-wall outlet and the computer
- or even to establish a wireless bridge between two independent Ethernet networks (between two buildings, two PLC's networks ...).
The kit is built around two pre-configured WiFi units already associated, installation doesn't require any configuration.
|
|
|
|
|
|
Moxa's AWK-5222 AP/bridge/client has two independent RF modules to resist disconnections caused by radio interference. This robust feature makes the AWK-5222 series the most stable wireless solution for critical industrial wireless applications. The two independent RF modules create a exclusive wireless redundancy mode to increase the reliability of your entire wireless network. The AWK-5222 not only gives you a highly reliable solution for your industrial wireless networks, but also offers you a greater variety of wireless connection configurations to fit different wireless applications. For example, its wireless bridge mode is designed to optimize the problem of WDS (Wireless Distribution System) mode’s poor performance. On the other hand, the AWK-5222’s AP Client mode can be used to provide Internet access in areas where cabling would be too expensive or impractical to install. The AWK-5222 is a rugged, IEEE 802.11 a/b/g-compliant, 3-in-1 industrial wireless AP/bridge/client also compliant with IEEE 802.3af Power-over-Ethernet (PoE). With high speed Turbo Roaming™, which is great for rolling stock applications, and fast BSS (Basic Service Set) transition between access points, data transmission latency is prevented and wireless network roaming is seamless and super fast. On top of it all, the AWK-5222 is equipped with dual Ethernet ports that support RSTP or Turbo Ring™ for added reliability for your entire network.
Features:
‧Redundant dual-RF design for rapid failover
‧Industrial wireless AP/bridge/Client with IEEE 802.11a/b/g
‧100 ms Turbo Roaming™ for rapid handover during client roaming
‧RSTP for dual Ethernet redundancy
|
|
|
|
