! Efficient inspection of medium & heavy quality fabric.
! Efficient inspection through top & bottom illumination.
! Tensionless movement of fabric on inspection table.
! Full forward & reverse run of fabric.
! Speed variable from 0 – 50 mtrs/ min.
! Compact & crease free rolling on winding tubes.
! Max. Roll dia. Up to 400 mm.
! Length measurement by reputed counter meter.
! Straight & uniform roll winding through efficient selvedge guider.
! Operator friendly, improves productivity, reduces labour.
|
|
|
|
|
|
We have perfected the design & manufacturing of wide range of Fabric Inspection Machines available in various working widths which are easy to operate, technically advanced and programmable machines in the field of fabric quality control. Being developed by highly qualified engineers having vast experience of this field, our machines are equipped with all necessary features like tensionless handling, accurate length measuring, appropriate illumination, Straight roll selvedge, variable roll hardness, auto cutting etc.
! Efficient inspection of medium & heavy quality fabric.
! Efficient inspection through top & bottom illumination.
! Tensionless movement of fabric on inspection table.
! Full forward & reverse run of fabric.
! Speed variable from 0 – 50 mtrs/ min.
! Compact & crease free rolling on winding tubes.
! Max. Roll dia. Up to 1000 mm.
! Machine with any input & output of Roll/ Pile/ Big Batch can be manufactured.
! Length measurement by reputed counter meter.
! Straight & uniform roll winding through efficient selvedge guider.
! Operator friendly, improves productivity, reduces labour.
|
|
MASTER MEND:-
! Unique design for comfortable & efficient mending operation.
! Top & bottom illumination for efficient mending.
! Hands free foot operated with fixed speed drive.
! Machine with any input & output of Roll/ Pile can be manufactured.
! High production efficiency with minimal operator fatigue.
! Available in various working widths.
|
|
Allows mending, examination or inspection. All types of material successfully processed. Choice of input-roll, pile, 'A' frame, bale. Sloping or flat table with or without illumination.
Precision measurement by 'Birch' AutoMeasure. Guided roll up or plait. Optional cross cut. Doff out, with or without taping. Fault recording. Made to your specification.
|
|
|
|
|
|
Features:
- Inspection table is laminated with adequate number of tubes provided underneath and overhead the glass with variable lighting arrangement.
- Push button controls are given on the drive box on the right hand side.
- Cloth can run in FORWARD as well as in REVERSE direction instantaneously.
- Fabric runs face in/face out
- Special jogging or inching device is provided to stop the machine at the right location of the defect.
- Soft start and instantaneous stoppage of fabric.
- Automatic stop arrangement to stop the machine at the end of the fabric piece.
- Robust and attractive design.
- Bow bar has been provided in the batching device to open out the creases in the fabric.
- Perfectly aligned straight edges in tunes of +/- 1 to 2mm in our model with automatic edge guiding system. The device comes with an electronically operated motorized screw type arrangement, thus doing away with requirements such as compressed air etc.
- Perfect tension during the flow of the fabric is provided using guide roll assembly, thus no hassles of nip rolls.
- Meter Counter is installed in front on platform top for easy reading.
- Specially designed Thyristor based DC drive with MCB's for auto tripping of the machine.
- World renown AC drives with companies such as DELTA, ALLEN BRADLY, SEIMENS, TELEMECHANIQUE, etc. can be provided on our machines
|
|
|
|
|
|
INSPECTION MACHINE
FOR FABRICS WITH PLATFORM
Mod. ISP 220
The inspection, winding and plaiting machine with platform Mod. ISP 180 PLAIT / ROLLS,
Allows a check of the fabric quality.
Tanks at the linear geometry of the drawing, to the sensitive system of synchronization and the motorization of all the rolls of delay fabric, the machine is excellently for the verification of elastic fabrics to sweater and shuttle.
Besides, thanks to the management from PLC interfaced to inverter, the operator can modify in real time tension fabric and hardness roll.
With the addition of a platform to allow the operator a qualitative control more near at the fabric. The winding or PLAITING process happens behind the operator.
The machine can be inserted in an automatic layout of more inspection machine with an automatic packing
Technical characteristics:
• Inlet fabric from J-BOX with synchronization / Small rolls / Plait / Big rolls
• Inclined inspection table with rear light
• Up light
• Platform
• Auto-centring winding unit
• Winding of the roll
• Adjustable compactness of the rolls
• Adjustable fabric tension
• ø500 mm diameter knitted fabric rolls
• 3÷60 m/min. speed control without step.
Optional:
• Digital weight measuring system
• Automatic linear cut
• Wood or special light
• Comatex software for store all the faults
• Barcode labelling for more type of error
• Mark-fault one or more fault
• Doubling system in 2 or 4
• Packing system
|
|
|
|
|
|
Features
- Inspection table is laminated with adequate number of tubes provided underneath and overhead the glass with variable lighting arrangement.
- Push button controls are given on the drive box on the right hand side.
- Cloth can run in FORWARD as well as in REVERSE direction instantaneously.
- Fabric runs face in/face out
- Special jogging or inching device is provided to stop the machine at the right location of the defect.
- Extremely sensitive soft start and instantaneous stoppage of fabric.
- Automatic stop arrangement to stop the machine at the end of the fabric piece.
- Robust and attractive design.
- Bow bar has been provided in the batching device to open out the creases in the fabric.
- Perfectly aligned straight edges in tunes of +/- 1 to 2mm in our model with automatic edge guiding system. The device comes with an electronically operated motorized screw type arrangement, thus doing away with requirements such as compressed air etc.
- Meter Counter is installed in front on platform top for easy reading.
- Specially designed Thyristor based DC drive with MCB's for auto tripping of the machine.
- World renown AC drives with companies such as DELTA, ALLEN BRADLY, SEIMENS, TELEMECHANIQUE, etc. can be provided on our machines.
|
|
|
|
|
|
- MS Side frames pointed with hardwearing stipple finish stowing enamel . This makes the finish permanent..
- A cradle with tow M.S. side brackets and 6 rollers running on ball bearing to place the fabric roll. This arrangement allows tensionless unwinding of the fabric.
- Inspection table is laminated black/white, which enhances the defect identification procedure by making defects more easily visible to the operator.
- The angle of the table is changeable in order to allow the operator to select the right viewing angle. Also, mending of the fabric is easily possible due to this arrangement.
- Two overhead and two underneath tube lights are provided to optimize the lighting.
- Positive driven batch winding mounted on M.S. fabricated frames having two rubber strip coated rollers and batching roll guides. The fabric is wound on the batch roll by surface contact.
- A scroll rolls right after the inspection table opens the fabric roll.
- A bow bar is also provided to open the fabric right before the winding, which gives perfectly wound tight rolls.
- This winding arrangements winds rolls by 25% tighter than the traditional winding mechanisms.
- Measuring Counter is provided in front on the inspection table for easy viewing
- FORWARD/REVERSE/STOP push button controls mounted on inspection table on both sides.
- A special jogging (Inching) device is also provided.
- Soft start and instantaneous stoppage of fabric.
- MCB's to automatically stop the machine at the time overloading.
|
|
|
|
|
|
INSPECTION MACHINE
FOR FABRICS DIRECTLY FROM THE RAMEUSE
Mod. ISN 220 NO STOP
The inspection, winding machine,
ISN NO STOP, allows a check of the fabric quality;this machine can be interfaced with the exit of Rameuse, or other machine kind calendar, without stop it. Tanks at the linear geometry of the drawing, to the sensitive system of synchronization and the motorization of all the rolls of delay fabric, the machine is excellently for the verification of elastic fabrics to sweater and shuttle.
Besides, thanks to the management from PLC interfaced to inverter, the operator can modify in real time tension fabric and hardness roll.
Technical characteristics:
• Inlet fabric from J-BOX with synchronization
• Inclined inspection table with rear light
• Up light
• Auto-centring winding unit
• Winding of the roll
• Adjustable compactness of the rolls
• Adjustable fabric tension
• ø500 mm diameter knitted fabric rolls
• 3÷60 m/min. speed control without step.
Optional:
• Digital weight measuring system
• Automatic linear cut
• Wood or special light
• Comatex software for store all the faults
• Barcode labelling for more type of error
• Mark-fault one or more fault
• Doubling system in 2 or 4
• Packing system
|
|
|
|
|
|
TENSIONLESS INSPECTION MACHINE
FOR ELASTOMER FABRICS WITH RELAX BELT
Mod. ISR 220
The inspection, winding tensionless machine
ISR 07’ TENSIONLESS,
provided of axial or tangential unwinding for big rolls, it’, an excellent machine for the elastomer fabrics.
The fabric gently comes situated, in the form of small folding, on a conveyor belt, that allows it to relax and particularly as it regards the elastic materials to resume its own elasticity. An additional conveyor belt incline ® (Exclusive Patent COMATEX) accompanies the fabric, without altering its acquired stability, to the summit of the table of inspection illuminated, where possible to view and mark the defects eventually found.
Before the end phase of winding, a special software Comatex combined to the electronic sensor of tension, it allows to maintain results of relaxation and to get rolls without residual tension.
Technical characteristics:
•Inlet fabric from J-BOX with synchronization / Small rolls / Plait / Big rolls
•Relax conveyor belt
•Patent conveyor belt
•Inclined inspection table with rear light
•Up light
•Auto-centring winding unit
•Reading fabric tension with adjustment of the bad tensions
•Winding of the roll
•Adjustable compactness of the rolls
•ø500 mm diameter knitted fabric rolls
•3÷60 m/min. speed control without step.
Optional:
•Digital weight measuring system
•Automatic linear cut
•Wood or special light
•Comatex software for store all the faults
•Barcode labelling for more type of error
•Mark-fault one or more fault
•Doubling system in 2 or 4
•Packing system
|
|
|
|
|
|
TENSIONLESS INSPECTION MACHINE
FOR ELASTOMER FABRICS WITH RELAX BELT WITH PLATFORM
Mod. ISRP 220
The inspection, winding tensionless machine
ISR 07’ TENSIONLESS,
provided of axial or tangential unwinding for big rolls, it’, an excellent machine for the elastomer fabrics.
The fabric gently comes situated, in the form of small folding, on a conveyor belt, that allows it to relax and particularly as it regards the elastic materials to resume its own elasticity. An additional conveyor belt incline ® (Exclusive Patent COMATEX) accompanies the fabric, without altering its acquired stability, to the summit of the table of inspection illuminated, where possible to view and mark the defects eventually found.
Before the end phase of winding, a special software Comatex combined to the electronic sensor of tension, it allows to maintain results of relaxation and to get rolls without residual tension.
Technical characteristics:
•Inlet fabric from J-BOX with synchronization / Small rolls / Plait / Big rolls
•Relax conveyor belt
•Patent conveyor belt
•Inclined inspection table with rear light
•Up light
•Platform
•Auto-centring winding unit
•Reading fabric tension with adjustment of the bad tensions
•Winding of the roll
•Adjustable compactness of the rolls
•ø500 mm diameter knitted fabric rolls
•3÷60 m/min. speed control without step.
Optional:
•Digital weight measuring system
•Automatic linear cut
•Wood or special light
•Comatex software for store all the faults
•Barcode labelling for more type of error
•Mark-fault one or more fault
•Doubling system in 2 or 4
•Packing system
|
|
Rewinding, inspection and cutting machine for rolls of all kinds of fabrics (decorating textiles, fabrics for clothing industry, knitted fabrics).
Used by wholesalers for rewinding decorating textiles, upholstery, clothing and other technical fabrics.
* Maximum roll diameter 40 cm (other dimensions on request)
* Flexible and modular concept.
* One person operation
* Tilted 45° Inspection table with back lighting
* Accurate length measurement system
* Winding up station with adjustable speed control
* Power supply 230V, 50/60Hz, 1 kW
|
|
Low-cost rewinding and cutting machine for rolls of fabrics.
Used by wholesalers.
# Fabric width up to 1800mm
# Maximum roll diameter 300mm
# One person operation
# Optiona accurate length measurement system with digital readout
# Varispeed rewinding system
# Machine dimensions 2100x 1000x 950
# Power supply 230V, 50/60Hz, 0.3kW
|
|
Used by wholesalers for rewinding decorating textiles, upholstery, clothing and other technical fabrics.
* Maximum roll diameter 40 cm (other dimensions on request)
* Flexible and modular concept.
* One person operation
* Inspection table with back lighting
* Accurate length measurement system
* Winding up station with adjustable speed control
* Power supply 230V, 50/60Hz, 1 kW
*Several options are available as loop control device and special equipment for tensionless inspection.
|
|
Checking - rolling - measuring machines with automatic or half automatic packing.
Main operations:
-Checking, rolling, measuring any type of cloth.
-Cloth inlet from small/big rolls and from folds.
-Cloth outlet on small/big rolls and on soft folds.
-Infinitely variable speed from 0 to 160 m/min. according to the type and the cloth to be rolled.
-Selvedge alignment of proportional photo-electric type.
-Innovative synchronisation systems of the driven cylinders allow rolling operation with constant tension of any type of cloth, needed compactness besides precise measuring.
-These machines are manufactured till max. working width of 4500 mm.
-You can add, on request, informatic control systems, fault detection, labelling, sewing unit, cutting machines, automatic elimination of second choice cloth without manual intervention of the operator, packing, etc.
|
|
Checking - rolling - measuring machines with automatic or half automatic packing.
Main operations:
-Checking, rolling, measuring any type of cloth.
-Cloth inlet from small/big rolls and from folds.
-Cloth outlet on small/big rolls and on soft folds.
-Infinitely variable speed from 0 to 160 m/min. according to the type and the cloth to be rolled.
-Selvedge alignment of proportional photo-electric type.
-Innovative synchronisation systems of the driven cylinders allow rolling operation with constant tension of any type of cloth, needed compactness besides precise measuring.
-These machines are manufactured till max. working width of 4500 mm.
-You can add, on request, informatic control systems, fault detection, labelling, sewing unit, cutting machines, automatic elimination of second choice cloth without manual intervention of the operator, packing, etc.
|
|
|
|
|
|
INSPECTION MACHINE
FRONT-REAR FOR TUBOLAR FABRICS
Mod. ISD 220
The inspection, winding machine, ISN NO STOP,
allows a check the quality of the front and the rear side of the fabric.
Thanks to the linear geometry and to a new system of drew-in of the fabric, the machine is able to check both the fabrics tubular that the fabrics in open, the new system of wrapping allows besides to wind the roll in hourly sense or ant-clockwise.
The machine is excellently for the verification of elastic fabrics to sweater and shuttle.
Besides, thanks to the management from PLC managed to inverter, and to the sensitive system of synchronization and the motorization of all the cylinders of transport fabric, the operator can modify in time real tension plotted and compactness roll.
Technical characteristics:
• Inlet fabric from Roll of plait
• Special draw-in of the fabric
• Double inclined inspection table with rear light
• Up light
• Auto-centring winding unit
• Winding of the roll in clockwise sense or ant-clockwise sense
• Adjustable compactness of the rolls
• Adjustable fabric tension
• ø500 mm diameter knitted fabric rolls
• 3÷60 m/min. speed control without step.
Optional:
• Digital weight measuring system
• Automatic linear cut
• Wood or special light
• Comatex software for store all the faults
• Barcode labelling for more type of error
• Mark-fault one or more fault
• Doubling system in 2 or 4
• Packing system
|
|
|
|
|
|
- MS Side frames pointed with hardwearing stipple finish stowing enamel . This makes the finish permanent..
- -A cradle with tow M.S. side brackets and 6 rollers running on ball bearing to place the fabric roll. This arrangement allows tensionless unwinding of the fabric.
- Inspection table is laminated black/white, which enhances the defect identification procedure by making defects more easily visible to the operator.
- The angle of the table is changeable in order to allow the operator to select the right viewing angle. Also, mending of the fabric is easily possible due to this arrangement.
- Two overhead and two underneath tube lights are provided to optimize the lighting.
- Positive driven batch winding mounted on M.S. fabricated frames having two rubber strip coated rollers and batching roll guides. The fabric is wound on the batch roll by surface contact.
- A scroll rolls right after the inspection table opens the fabric roll.
- A bow bar is also provided to open the fabric right before the winding, which gives perfectly wound tight rolls.
- This winding arrangements winds rolls by 25% tighter than the traditional winding mechanisms.
- Measuring Counter is provided in front on the inspection table for easy viewing
- FORWARD/REVERSE/STOP push button controls mounted on inspection table on both sides.
- A special jogging (Inching) device is also provided.
- Soft start and instantaneous stoppage of fabric.
- MCB's to automatically stop the machine at the time overloading.
|
|
|
|
see the results for the following category :
