-Feeders: The feeder works by taking up the sheet metal supplied by the decoiler or straightener and regulating the exact quantity that should be furnished to the press at all times. By using CNC technology (numeric computer control) the process can be parametrized so that it is possible to program maximum speed, acceleration / deceleration and with the position in either millimetres or inches. To see figure
-Feeder/levelling machine: This machine is an evolution of the above and today most feeders incorporate the levelling function. As its name indicates, its purpose is to level out the sheet metal that, due to the slightly convex morphology, it adopts on the coil. Therefore, it is necessary to flatten the sheet metal so that it is absolutely level on reaching the press. Otherwise, the quality of finish produced by the feeder-levelling machine would not be obtained.
|
|
|
The SpeedFeeder is specially designed for quick and easy handling of sheet metal parts in presses and other metal processing machines. Up to 4 units can be mounted on the same Y-beam. With the units connected to one control system the axes can be synchronized to provide parallel operation.
|
|
Blank loaders
to feed single presses and press lines. The cut blanks are delivered to the blank loader as a stack. After blank isolation the top blank of the stack is lifted by suckers or magnets to be transported to the transfer equipment or to a conveyor belt.
If required we can guarantee a production without interruption during stack exchange.
The transfer operation of the blanks from stack to the transfer system or conveyor belt can be realized with feeder or robot. In both cases, a continuous production are possible.
|
|
-Feeders: The feeder works by taking up the sheet metal supplied by the decoiler or straightener and regulating the exact quantity that should be furnished to the press at all times. By using CNC technology (numeric computer control) the process can be parametrized so that it is possible to program maximum speed, acceleration / deceleration and with the position in either millimetres or inches. To see figure
-Feeder/levelling machine: This machine is an evolution of the above and today most feeders incorporate the levelling function. As its name indicates, its purpose is to level out the sheet metal that, due to the slightly convex morphology, it adopts on the coil. Therefore, it is necessary to flatten the sheet metal so that it is absolutely level on reaching the press. Otherwise, the quality of finish produced by the feeder-levelling machine would not be obtained.
|
|
In the semi automatic setup, it is possible to set any measure on the keyboard and pressing the START button the Speedy moves to the set distance. In the automatic setup, is it possible to set up to 99 programs with 1 to 99 different pitches repeatable from 1 to 99 times. It can be used both in incremental or inverse. In other words in can work pushing the piece, or pulling it from the machine. It can include:
a. Mechanic vice.
b. Pneumatic vice.
c. Rotary vice.
d. Fixed or tip-up length stop.
e. Supporting and sliding roller conveyor.
It can be selected the function to retry few centimetres on the use of the bending or cutting positioning in order to avoid the bars to jam.
It can be used as:
a. Saw machine positioner.
b. Saw machine feeding system.
c. Shearing machines positioner.
d. Feeding system for an automatic run of punches of bars.
e. Feeding system for automatic and semi automatic drills.
f. Feeding system for tube benders.
g. Positioner for wood boards cutters.
h. Automatic feeding system for punching units.
It has an electronic zero setting and it is available in Italian, English, Spanish, German and French version.
|
|
Metalfab's ruggedly built MetaTech Feeder features a compact, space-saving design, low maintenance direct drive, and new Delrin® bushing for highly accurate and dependable metering of powders, pellets, flakes, and agglomerates.
Features/Benefits
NEW - Only 2 moving parts (Drive and Screw)
- ensures reliable, long lasting performance with minimal process downtime
NEW - O-Ring Sealed Inline Drive
- ensures dust-free operation and makes screw shaft alignment easy after changeout or cleaning.
Teflon® Rear Seal Standard
- for years of maintenance-free service. Also available with cinch seal
Unique Agitator/Conditioner Screw
- completely fills the feed screw for high accuracy of ± 1 to 1 1/2%
Interchangeable Screw/Tube Combinations
- available in 1/2" to 6% sizes and permit feed rates from 0.05 to 550 cu. ft./hr.
Wide Range of Models
- includes space-saving mini, sanitary, and combination feeder/conveyor units
All Metalfab Volumetric Screw Feeders feature Metalfab's rugged design and unique agitator/conditioner screw. In operation, the agitator/conditioner screw begins to move materials forward in the feeder's trough. Since the agitator/ conditioner screws are larger in diameter than the metering (feeding) screw and of wire configuration, they carry a greater capacity than the metering screw, allowing material to flow through and around it. This 360° influence of material forces entrained air up and out of the metering area and force feeds material into the flights of the metering screw to ensure they are completely full with uniformly dense material.
|
|
Feeding Technology Components
Afag is your worldwide presented partner for high quality feeding technology with innovative products, customized solutions and excellent service.
Linear conveyors
* innovative KLF
* conventional LF
* conveyor belt FB
Feeder bowl drives
* innovative feeder drives
* conventional feeder drives
Feeder bowls
* plastic
* aluminium
* stainless steel
Refilling units
* Conveyor belt hopper
* Vibratory hopper
Control devices
* Type SE
* Type IRG
Standard feeding station
|
|
|
Eriez offers a complete line of vibratory equipment to convey, screen and feed materials in quantities ranging from a few spoonfuls to tons per hour. If the many standard systems available are not quite right for your operation, Eriez' Technical Center can develop custom-designed vibratory and screening equipment to precisely meet your needs.
|
|
Ranging from the extra heavy-duty stationary models to the most flexible feeders for mobile applications, Metso Minerals feeders offer minimum downtime and maximum tonnage for thousands of installations around the world. Our feeders feature a rugged yet flexible design, extra heavy-duty construction, exclusive vibrator technology and ease-of field-changes in grizzly opening and deck-slope.
Metso Minerals feeder series is designed particularly for continuous use with any hard and abrasive materials. They combine a robust frame design with
high feeding capacity and a limited overall height. These features make it ideal for operation in restricted space, and in both stationary and mobile plants.
|
|
The patented clamp feeder VEGA Bialternato® has unique characteristics that put it at the top in terms of precision and versatility.
Using CNC grippers means that all materials, even the most delicate, with thickness ranging from 0.2 to 2mm, can be processed mar-free.
|
|
|
Dose feeder is a steel block having two inputs to be connected with dual line coming from the lubricating pump. Outlet connections of dose feeders are connected to lub points by branch pipe line. Dose feeders are normally installed in the vicinity of lubrication points to be greased. Discharge quantity can be adjusted with the help of screw. Functioning of each dose feeder can be noticed by the movement of indicating pin.
|
|
Application : Cement, Mineral or Ore Material
Suitable for feed control
Can be adjust feed rate
Pre-assembled with heavy duty Rotor
Sub-drive through Worm Reduction Gear Box
Capacity : 3 - 10 ton per hour
|
|
Application:
The Minster Straightener, equipped with the Production Management Control (PMC) System, is the core of the stock preparation system. In its basic form, this multi-function machine provides precise straightening of the stock, and accurate control of the storage loop. When equipped with the optional hold-down arm and peeler table, the Minster Straightener facilitates safe and efficient threading of the coil. When installed along with a complete Minster coil line, it controls and supplies hydraulic power to the thread table, reel and coil car. It also communicates via its PMC with the press and feed PMC, providing complete coil line control and diagnostics.
|
|
Accu-Flo Screw Feeder
Series 495
The Series 495 Accu-Flo screw feeder is used for feeding weigh scales or other process equipment where a precise or consistent flow of dry bulk solids needs to be conveyed. Fabricated of all mild steel or stainless steel tubular construction, it is also available with air purged bearings, a fixed rate or variable speed drive and a TEFC motor. A standard inflatable seated butterfly outlet valve is also available upon request..
|
|
The patented clamp feeder VEGA Bialternato® has unique characteristics that put it at the top in terms of precision and versatility.
Using CNC grippers means that all materials, even the most delicate, with thickness ranging from 0.2 to 2mm, can be processed mar-free.
|
|
Eriez offers a complete line of vibratory feeders for materials in quantities ranging from a few spoonfuls to tons per hour. If the many standard systems available are not quite right for your operation, Eriez' Technical Center can develop custom-designed vibratory and screening equipment to precisely meet your needs.
Small
Light and medium-duty feeders accurately feed and control material flows at rates ranging from pounds to many tons per hour. Totally enclosed magnetic drives. Low power consumption. AC operation.
High Speed
Exceptionally high-speed feeding of light, bulky materials.
High Deflection
handle powders and leafy products that normally could not be fed successfully in an electromagnetic feeder.
Heavy-duty
large capacity and difficult material handling operations up to 850tph (765mtph)
Mechanical Feeders and Conveyors
Low-horsepower, high-capacity mechanical feeders handle bulk materials in volumes up to 2250tph (2040mtph).
Conveyors - Single Mass and Mechanical Tuned Two-Mass
Volumatic Feeder Machines
Made up of a hopper, vibrator, feeder and controls. Assures accurate flow of dry bulk materials for weigh scales, packaging and bagging equipment, small batch operations and additive feedings.
|
|
|
Adjustable flows from 0 to 10 tonnes/hour according to the choice of the electromagnetic feeder.
|
|
NETX Vibratory Feeder
Series 661
The Series 661 Netx air operated Vibratory Feeder by Dynamic Air Inc. has an infinitely variable speed natural frequency drive system, which utilizes compressed air as the power source. A powerful oscillating piston coupled with special leaf springs, feeds dry granular materials at almost any rate desired. The Netx Vibratory Feeder is especially ideal for feeding weigh scales and other process equipment, where a constant and/or reliable feed rate is required. A standard PLC programmable controller can be used to electronically control the feed rate, at up to a 100 to 1, turn down ratio. It is available in a wide variety of sizes and materials of construction.
|
|
DESCRIPTION:
Conceived by specialists in the automation of work on press, the automatic chargers Norda bring an answer to all the requirements:
- High Production pace.
- Tooling and Staff safety.
- Accuracy of mouvement
- Greasing and separation of the blanks.
- Reliability of the production.
- Simplicity of the adjustments.
NORDA builds its chargers in series under patent and sell them in the whole world. The hundreds of solved cases and a close cooperation with the customers make of it the leader of the automation of the presses in Europe.
FEATURES:
The charger is a specialized robot which supplies the presses intelligently. The horizontal adjustments of translation for the loading of the presses vary according to the models from 300 to 1100 Misters the charger takes in the store a sheet metal or an already worked part and carries out of it the transfer to a station of centering where the part is positioned precisely. At the same time, the part previously centered is taken and transported until on the outiil. The charger control then the press and starts again a new cycle.
The movement of the mobile arm of the charger traverses a trajectory in "U" reversed. The movement is carried out by a device actuated by ensuring motor reducer raised speeds, of the accelerations and decelerations controlled with a constant precision.
The charger also carries out controls in the course of cycle: catch of the part, ejection out of the tool, sunchronism with the press...
The flexibility is ensured by a system of vertical regulation of the charger allowing the fast adaptation to a change of tool.
|
|
► Power supply by vibrating bowls
► Loading crane
► Digitize system insertion for pieces
► Loading and unloading conveyor
► Manual devices to put down pieces between wheels (secured)
► Device for admission of bars
|
|
CDSF7-PR is a special edition of the CDSF6. To prevent the excessive spring effect of the coil, usual for the compact lines, we add a pinch-roll to pull the coil from the braking decoiler. This system is appreciated in Germany.
- The CDSF7-PR is a compact line consisting of:
- single motorised decoiler: work at variable speed with a loop control to guarantee a soft movement
- straightener/feeder: with 2 rolls pinch-roll Ø 180 mm
- Straightener station with rolls at big distance, adapted for medium width strip - 9 rolls Ø 90 mm, to guarantee the necessary planarity.
- The line requires 8 meters of space.
- The CDSF7-PR is the best solution in case you don't need high speed (max 90 spm) but you have few space. The line have a competive price.
|
|
Electronic roller feed units
Dreher roller feed units stand out for high precision and constant feed exactness at a high dynamic force. Roller feed units can be delivered for a strip width until 2000 mm and a strip thickness from 0,1 to 10 mm for co-ordinated roller diameters.
Pneumatic strip feed units
The cost-effective well-tried alternative to roller feed units disposing of an integrated sequentiell phase control and guaranteeing easy installation, precision and product assurance. These units can also be used for foils, sensible strip material, stripe and wire profile material.
Number of strokes: 1200 1/min
Precision: +/- 0,025 mm
Minimum set-up times by easy adjustment
Easy strip insertion
Mechanic intermediate release device
Feeder with linear motor
High precision feeder for very large strokes and for more flexibility in the production.
Particularly suitable for:
- the feed of three dimensional parts
- Large strokes
- For sensitive and coating strips
- Flexible feed length
|
|
FULLY AUTOMATED
ZERO SECOND CHANGE OVER TIME
This bar feeder has been designed bearing in mind the requisites of silent running, reliability, solidity and rapid change over time.
The KAYENNE is able to pass from a maximum to a minimum bar diameter within very shot time with no need for keys simply by selecting the bar diameter on the PLC.
Thanks to this simple operation the bar feeder automatically sets the guide channel, the bar storage adjustment and the pusher thrust within the space of just 1 minute and 20 seconds.
The rear extraction collet features a quick-connect mechanism requiring a rapid 30 second change over time.
|
|
This bar feeder has been designed bearing in mind the requisites of silent running, reliability, solidity and rapid change over time.
The X-FILES is able to pass from a maximum to a minimum bar diameter within very short time with no need for keys, simply by selecting the bar diameter on the PLC.
Thanks to this simple operation the bar feeder automatically sets the guide channel, the bar storage adjustment and the pusher thrust within the space of just 1 minute and 20 seconds.
The rear extraction collet features a quick-connect mechanism requiring a rapid 30 second change over time.
|
|
RECORD
This bar feeder has been designed on all Swiss type machines. The front chuck, as well as the bar storage, are automatically controlled by simply digiting the relevant diameter on the PLC.
The upper guides, which do not need to be replaced, can be regulated manually, while the lower guides feature a quick change system allowing for reduced change over times.
Remnants are extracted by means of a self-centring ejector.
The maximum extractable remnant length is 500mm.
The bar feeder is equipped with a mechanical system for Swiss machine synchronisation.
|
|
FULLY AUTOMATED
The Magic bar feeder has been designed for machining bars with diameters of between 8 and 110mm, with a maximum length of 1600 and a minimum length of 200 mm.
The MAGIC self-adjusts to the bar diameter selected on the PLC.
The maximum workable lenght of the bar is equal to the lathe spindle lenght.
|
|
Servo Bar 300 Automatic Bar Feeder
The all-new Haas bar feeder features a heavy-duty yet compact design, with up to 3 1/8" (79 mm) bar capacity and a footprint of only 4.5' x 8'.
Designed to boost productivity and streamline turning operations, this servo-driven bar feeder is built by Haas exclusively for Haas CNC lathes.
Servo Bar 300 Features:
• Wide capacity range up to 3 1/8" (79 mm)
• Precision servo ballscrew drive system
• Simple setup
• Easy interface to Haas CNC control
• Accuracy of ±0.005" feed length without deadstop
• Accepts random length bars
• Automatic bar length measurement
• Liner storage tray
Specifications:
• Capacity: 3/8" to 3 1/8" dia., up to 60" length
• Haas CNC control
• Standard 3/8" and 3/4" pushers
• Tray capacity: 1" dia. bars x 30 pcs.
• Weight: 900 lb
|
|
Roll feed systems from ARKU guarantee high feed and repetition accuracy. ARKU produces them in two series for all strip cross-sections.
ARKU has developed the feed series ServoMaster® PowerMaster® as successful solutions based on its many years' experience with successful sheet shaping installations.
|
|
DIMECO roll feeder range results from a combination of 5 mechanical models and 3 numerical control packages. They fulfil your needs for strips from 0,1mm to 10 mm thickness and up to 2000mm wide.
Cutting edge roll performances are reached thanks to an optimized inertia to reach up to 1000 rpm and 150m/mn. Rolls are hardened, chromed and sand blasted for a better grip.
The use of a comprehensive electronic package (sensors, motors, controls) provided by the same supplier selected among worldwide leading O.E.M. provides outstanding positioning accuracy and reliability (+/- 0,05mm).
You can select the HMI that most fits your needs: simple but efficient with ECODRIVE, sophisticated with SIMOSTAR370, which offers access to the entire operating and maintenance data on a 12” colour touch screen.
With PFS and ADA functions, feeding line machines speeds and accelerations are synchronized according to press rate, feeding angle and pitch. Material strains are therefore avoided, loop length may be reduced and machine lifetime is increased.
Built-in electronic cams and active safety device controls | | |
