Unlike a conventional laser which is constructed from components such as mirrors, rods and lenses a fiber laser is an all bulk material device. The laser rod is effectively substituted by a length of doped active fiber several metres long. The rest of the components are also all fiber devices each of which are spliced together to form a laser resonator. An immediate advantage of this is that there is no need for alignment, adjustment or subsequent cleaning of optical surfaces once the laser has been built, which means little or no maintenance requirement.
Fiber Laser Delivery OptionOur JK™ Fiber Lasers can be supplied with patented Luminator™ fiber-delivery options, laser processing tools and scanheads. These ensure safe and reliable 3D manipulation of the laser beam and high-performance materials interaction at the workpiece. The JK™ Fiber Laser range includes both rack-mountable and OEM units, offering both air and water-cooled options.
|
|
|
In creating the NuFIRE laser, Nufern listened to real users' needs, then set out to build a new generation of fiber laser. The NuFIRE system is a complete, self-contained fiber laser designed to achieve high performance specifications for reliability and cost-efficiency. It offers unparalleled ease of use to enable experts and non-engineers alike, and the flexibility to handle virtually any application in the 200 W regime.
|
|
In creating the NuFIRETM laser, Nufern listened to real users' needs, then set out to build a new generation of fiber laser. The NuFIRE system is a complete, self-contained fiber laser designed to achieve high performance specifications for reliability, precision, and cost-efficiency. It offers unparalleled ease of use to enable experts and non-engineers alike, and the flexibility to handle virtually any application in the 200 W regime.
The quality of a fiber laser depends very much on the fiber inside. Nufern is the leading supplier of laser fibers worldwide; the design and manufacture of superior specialty fibers is our heritage. Our NuPOWERTM fibers offer the highest in efficiency, beam quality, and lifetime performance. When it comes to true production efficiency, NuFIRE changes everything.
|
|
|
|
|
|
The 7210 and 7310 pulsed fibre laser markers (10 Watt and 20 Watt respectively) are compact and versatile and can be used reliably, quickly and economically on metals, plastics and other hard-to-mark materials. This makes the Videojet 7210 and 7310 ideal for marking tools and instruments, as well as for use in the electronics, automotive and automotive supplier industries. They mark complex, variable data (codes, logos, symbols, serial numbers, individual data, etc.) on to both stationary and moving products and with a multi-lingual user interface, they also offer ease of integration into host equipment.
Compact, simple integration
The compact design and smallest marking head on the market combined with tried-and-tested flexible software and hardware platforms makes integration into end customer lines and OEM equipment extremely simple.
Wide range of applications
A large range of options (high-performance software, superior galvanometer scanners, compact marking heads, beam deflection options [0°/90°], etc.), enables the VJ 7210 and VJ 7310 to mark virtually anything to the highest quality.
Minimum waiting time, maximum runtime
Shorter setup times, an air-cooled, highly efficient, virtually maintenance-free laser and the option of PC-independent operation increase production times and lower costs.
|
|
The ML50-CW-R-OEM is a compact CW Fibre Laser delivering up to 50W of output power, through a near diffraction limited beam (M²<1.1). The excellent beam quality and power stability make the Manlight Fibre Laser a multi-purpose tool. Our patented “Injection Technology” allows the use of highly reliable broad area laser diode pumps, for a cost effective and maintenance-free operation. The all-fibre design guarantees the robustness of the laser, without any optical parts to align or to stabilize. The simple integration of the system requires no after-installation service. The ML50-CW-R-OEM is the ideal solution for a broad range of industrial and scientific applications.
It also exists in 5, 10 or 20W version or in a 19", 3U Tunrkey version.
|
|
CLEVER Nd-YAG / CO2
The winning solution for the vertical marking and engraving operations with a Nd-YAG laser on metallic and clatted or plated surfaces or with a CO" laser for NON metallic parts. The immediate “plug and play” installation with any machine or pre-existing production line and ...
|
|
An extremely compact for both performance and reliability.
Smaller than a Legal sheet of paper.
COMPACT & STURDY
Compact, sturdy, lightweight cast aluminum head
Integrates even in the most restricted spaces, in any position
Electronic controls and alarms for material protection
Adapted for intensive and heavy-duty operating.
PERFORMANT & RELIABLE
Power level used for contrasted marking at exceptional speeds: up to 2,5m/sec
Long-lasting diode (100,000hrs, on average), for minimal maintenance
A minimum of optical elements for a constant marking quality.
TECHNICAL SPECIFICATIONS
Type: ...................................... Ytterbium Laser fibre
Wave length:............................1 064nm
Frequency range:....................20 - 100kHz
Fiber length .............................2,8m
Marking area range:.................from 65 to 240mm
Air cooling
WEIGHT & SIZE
TF420 marking head.................L375xl139xh202mm, 7Kg
UC420 control unit: ..................L483xl376xh184mm, 18Kg
|
|
|
The ML50-CW-R-TKS Fibre Laser is a compact CW Ytterbium Fibre Laser delivering up to 50W of output power, through a near diffraction limited beam (M²<1.1). The excellent beam quality and power stability makes the Manlight Fibre Laser a multi-purpose tool. This product is also available as OEM Version.
|
|
|
|
|
|
Among the TEEM PHOTONICS offer, our High power fiber laser PicoSpark family allows to achieve up to >7W of average power, with Peak power > 280KW, with picosecond pulses down to 300ps and repetition rates between 20KHz to 40KHz.
Its architecture allows the pulse width to stay constant, while allowing the user to vary the pulse energy (or Peak Power) and the repetition rate independently of each other; this is done in a compact, turnkey package, with an output collimated in free space.
They are proposed with outputs at infrared (1064nm) and green (532nm)
They are specialized for utilization in applications as Marking, Micro Machining, drilling, scribing, Trenching for Photovoltaic, medical, Dermatology, Ophthalmology, dentistry, stereolithography types of processing.
Features & Benefits:
- Ultrashort picosecond Nd:Yag pulses (As low as 550ps durations)
- High Energy (Up to 250uJ/pulse)
- Ultra high peak power (Up to 280KW at 25KHz)
- Variety of frequency options (Up to 40KHz in free running, triggerable up to 3KHz)
- Excellent beam quality (Gaussian, TEM00, M2 <1.3)
- Efficient, air cooled
- ultra-violet Long life (lifetimes expected to exceed 5k hours)
-Licensed Technology
Passively Q-switched pico-second microchip laser:US Patent 5394413
- Fiber amplifier : 4 US patents with IMRA
Optional features:
- Photodiode output for synchronization
- Manual controls for CDRH compliance
|
|
|
|
|
|
The ML20-PL-R-OEM Module is a compact 1mJ Pulsed Ytterbium Fibre Laser delivering up to 20W of average output power, through a near diffraction limited beam (M²<1.5). It allows to obtain more than 20 kW of peak power due to a pulse duration lower than 50 ns. One of the key features is the possibility to operate the Fibre Laser in Pulsed or CW mode. Pulse repetition rate and output power can be controlled either by 8-bits TTL signal or RS232 or Analog. The excellent beam quality and power stability make the Manlight Fibre Laser a multi-purpose tool. Our patented “Injection Technology” allows the use of highly reliable broad area laser diode pumps, for a cost-effective and maintenance-free operation. The all-fibre design guarantees the robustness of the laser, without any optical parts to align or to stabilise. The simple integration of the system requires no after-installation service. The ML20-PL-R-OEM is the ideal solution for a broad range of industrial applications.
It also exists in a 0,5mJ version (ML10-PL-R-OEM) and in a 19" 3U Tunrkey version.
|
|
|
|
|
|
General description: Talisker
Fiber based industrial laser for micromachining
Features :
- Scalable fiber laser platform
- High peak power picosecond pulses for precision machining
- Industrial packaging and reliability
- Minimizing thermal damage and heat affected zone
Talisker™ is a new family of high peak power and high average power picosecond lasers designed specifically for materials processing. Based on a scalable fiber laser platform Talisker is designed for an industrial environment and meets availability requirements of demanding industries. Delivering picosecond pulses these lasers minimize thermal damage and heat affected zone to enable smaller feature sizes for high precision micromachining. Minimizing thermal damage and heat affected zone enables a new range of high precision applications such as silicon machining, wafer dicing, solar cell manufacturing or glass scribing. Available at wavelengths of 1064 nm, 532 nm and 355 nm Talisker processes a wide variety of materials, including: silicon, polyimide, metals,"hard materials," and glass.
|
|
|
LEUKOS offers you the first supercontinuum source emitting a continuous spectrum in the UV-A range (typically from 320 nm to more than 1750 nm)
|
|
|
LEUKOS designes the first supercontinuum laser source with external trigger (from 10 Hz to 4 kHz). This LEUKOS-ST source covers all the silica transparency domain spectrum (from 370 to more than 1750nm). The spectrum is flat and steady. The spectrum shape and the spatial profile can be adapted, according to the targeted application (IR-optimized, multimode fiber, ...)
|
|
|
Leukos light sources are fibered wideband sources based on supercontinuum generation. The light emission covers all the silica transparency domain spectrum (370-2400nm) and is spatially singlemode in the visible. The spectrum is flat and steady. The repetition rate is typically 8kHz or 20kHz. The spectrum shape and the spatial profile can be adapted, according to the targeted application (IR-optimized, multimode fiber, repetition rate...)
|
|
|
Leukos light sources are fibered wideband sources based on supercontinuum generation. The light emission covers all the silica transparency domain spectrum (400-2400nm) and is spatially singlemode in the visible. The spectrum is flat and steady. The repetition rate is typically 8kHz or 20kHz. The spectrum shape and the spatial profile can be adapted, according to the targeted application (IR-optimized, multimode fiber, repetition rate...)
|
|
The ELR Series Erbium fiber laser is a unique instrument that combines a diffraction-limited, high-power CW light source in an "eye-safe"* (1530 to 1600nm) spectral range with all solid-state laser reliability. Its turnkey operation, compact size, and air-cooled simplicity make it an ideal light source for material processing and a variety of IR systems.
Purchasers can select from a wide range of options including: random, linear or circular polarization, kHz, MHz or nm linewidth, direct (up to 2KHz) or AOM (up to 200MHz) modulation, optical isolation at the output, package, redundancy, termination and many others.
|
|
|
|
|
|
Koheras BasiK™ and Koheras BoostiK™ Modules are narrow linewidth fiber laser systems based on a truly single mode, single frequency DFB (Distributed-Feedback) Fiber Laser with extremely high frequency stability and low phase and intensity noise.
This range of lasers offered as compact modules typically for industrial OEM integration. It is also designed as a building block for higher power benchtop systems or multi-wavelength systems. It is supplied with Koheras GraphiK™ software for the control and read-out of numerous laser parameters on a pc such as wavelength, output power, and RIN suppression.
Any interferometric use that requires high frequency stability or a long coherence length will benefit from this type of laser technology. The typical applications include seismic sensing such as oil and gas exploration and exploitation, security (perimeter and pipeline detection), and structural health monitoring. Furthermore, the low intensity noise of the lasers combined with the high spectral stability make them ideal as sources for wind LIDAR systems used for the wind turbine and aerospace industry.
|
|
|
YLIA M20 - 20W double clad fiber laser for high speed marking and engraving on a wide range of materials. 1mJ at 20kHz in 100ns pulse duration, it reaches 10kW useful peak power to ablate most of the common used metals in the industry.
|
|
FemtoMaster is a passively mode-locked soliton fibre laser with a semiconductor saturable absorber as one of the cavity mirrors. The active medium is a core-pumped Yb-doped fibre. The laser oscillators generate transform-limited 5-15 ps pulses.
The lasers have been designed for maintenance free OEM applications. Compact size, built in electronic drivers and monitoring photodiode makes this unit ideal for demanding laboratory and industrial applications.
APPLICATIONS
Seed source for high energy systems
Fundamental study
High resolution OTDR
Metrology
|
|
StarFiber
ROFIN provides robust and compact fiber lasers with a power range of 100 - 200 W, especially for finest welding seams. Our fiber lasers feature
among others:
closed loop power control
power control dependent on travel speed
safety features (industrial standard)
convenient operator control
innovative ROFIN control unit (RCU)
|
|
The FemtoPower1060 is a range of high-power picosecond passively mode-locked fibre lasers operating in the 1060 nm spectral range. Based on Fianium's FemtoMaster1060 and custom made high-power fibre amplifier, the FP1060 range can provide average powers up to 20W and repetition rates from 20 to 100MHz.
APPLICATIONS
Micromachining
Fundamental study
Metrology
Bio-medical
Optical source for THz imaging
|
|
Main Features:
- 1060 to 1070nm Wavelength Range
- Extinction Ratio >20dB
- TEMoo (M2<1.1)
- Air or Water Cooled Versions
- 100,000 hours Est. Pump Diode Lifetime
- Maintenance Free Operation
- Single Mode Fiber Delivery
Applications:
. Materials Processing
. SHG
. Medical
. Scientific
|
|
Applications:
- LADAR/ Rangefinding
- Surveillance
- Mapping
- Sensing
- Seed for power Amp
Features
- Fully self contained
- Ultra Low Jitter
- High beam quality
- Optical trigger out (to)
- EMI filtering MIL-STD-461E
- Transient protection MIL-STD-704F
|
|
The YLP Series are maintenance-free MOPFA and Q-switched pulsed Ytterbium fiber lasers designed for OEM applications.
These lasers deliver a high power 1.07 µm laser beam directly to the work site via a flexible metal-sheathed fiber cable. Collimated, and then typically focused to a spot size of a few microns or less, the near diffraction-limited beam can mark, drill or machine a variety of materials.
YLP Series provides a wide choice of pulse durations, repetition rates and peak powers.
Main Features:
- Up to 2mJ energy per pulse
- Up to 200W average output power
- 40 to 500ns pulse duration
- 20 to 400kHz tunable rep. rate
- 10% wall-plug efficiency
- Maintenance free operation
- Compact, rugged air-cooled package
Applications:
- Marking
- Trimming
- Micromachining
- Precision Drilling
- Welding
- Cutting
|
|
|
|
|
|
The YLP Series high energy series of pulsed fiber laser is designed to be easily integrated into OEM applications, such as marking, drilling or machining systems. It delivers high peak power (up to 25kW) and high average power (up to 200W) in 400 nanosecond pulse durations. The increased power levels allow you to work more efficiently and use thicker materials.
These lasers embody all of the advantages of IPG's fiber laser technology including compactness, high efficiency and reliability at a reasonable price. The 100% solid state design is robust, maintenance-free and requires no consumables.
Like IPG's other industrial pulsed lasers, this laser is based upon IPG's ultra-reliable pumping technology and comes with a heavy duty optical isolator that improves output pulse stability and eliminates back reflection.
Main Features:
- Up to 10mJ energy per pulse
- Up to 200 W average output power
- 400 ns pulse duration
- Output optical isolator
- Output power tunability 5-100%
- High beam quality M2~10
- Maintenance-free operation
Applications:
. Marking
. Trimming
. Micromachining
. Precision Drilling
. Welding
. Cutting
|
|
The KOHERAS SuperK™ Compact is a supercontinuum white light source with a broadband output spectrum. It is a complete stand-alone unit with integrated controller and computer interface for easy and stable operation. The output is provided through a connectorized optical fiber.
Features & Benefits
Broadband output: 500nm - 2400nm
> 100mW total average output power
Single mode, diffraction limited, fiber delivered beam
External trigger
Computer controlled trigger
Turn-key bench-top source
Standard FC connector or collimator fiber termination
|
|
SC400 is a high power fiber laser generating supercontinuum radiation in the 400 - 2500 nm spectral band with average power up to 6W. The laser consists of a master source based on the FemtoMaster1060, a custom made nonlinear high power fibre amplifier. The lasers are air-cooled, maintenance free and do not require any adjustments.
APPLICATIONS
Fundamental study
Optical coherence tomography
Bio-medical
Metrology
|
|
|
|
|
|
Koheras AdjustiK™ and Koheras BoostiK™ Systems are narrow linewidth fiber laser turn-key benchtop systems based on a truly single mode, single frequency DFB (Distributed-Feedback) Fiber Laser with extremely high frequency stability and low phase and intensity noise.
The Koheras AdjustiK™ System is a single stage amplified system with up to 200 mW of output power, whereas the Koheras BoostiK™ System is based on dual stage amplification with up to 2 W of output power.
This range of benchtop laser systems is typically offered as rapidly deployable sources for research laboratories that wish to use it as a tool for scientific work and not spend time on setting up a laser system. The benchtop models are based on the Koheras BasiK™ Module seed technology and are upgradable in terms of output power. The systems are supplied with Koheras GraphiK™ software for the control and read-out of numerous laser parameters on a pc such as wavelength, output power, and RIN suppression.
A part from interferometric sensing and LIDAR, these laser systems are very useful sources for various scientific applications (more information available in the application section)
|
|
|
The EBS-4022 Erbium Broadband Source is an extremely stable, flattened broadband source delivering 22 dBm in a 40-nm wide spectrum spanning the whole Erbium C band. It utilizes amplified spontaneous emission (ASE) from diode-pumped Erbium-doped fiber and a spectral shaping scheme which flattens the output to better than 1 dB from 1527 to 1567 nm.
|
|
Based on all-fiber designs, and pumped by multiple high-reliability multi-mode laser diodes, MPBC fiber lasers are dependable and easy-to-use sources for a variety of industrial, military and scientific applications.
The all-fusion-spliced optical trains eliminate the traditional concerns of keeping optics clean and cavity alignment sensitivity to temperature and mechanical vibrations.The lasers are essentially maintenance-free and highly reliable. Both self-contained, ready-to-use benchtop units and OEM modules designed for further system integration are available.
|
|
|
|
