1. Element diameter is 63.5 mm with cover.
2. Pressure drop calculations based on 20 micron elements.
3. Element length is for mesh pack and does not include end fitting.
4. Polymer viscosity is 250 Pas (2500 Poise).
5. Design conditions are 241.5 Bar (3500 psi) and 343.5C (650F).
6. Vessel material is 304SS and system is designed per ASME Code.
7. System configuration is MPST's patented close-coupled design.
8. System includes manual vent valves and hydraulically automated diverter valves with control panel.
9. System prices are Ex Works Maag Factory.
|
|
CPD pleated polypropylene depth cartridges are designed for clarifying applications requiring high flow capacity. The depth media utilized in the CPD product line is high loft Melt-blown polypropylene which gives exceptional flow characteristics and high dirt holding capacity because of its high internal porosity. Fine polypropylene fibers are bonded together to ensure no fiber release in a fiber matrix that maintains high porosity. Rated at 99.9% efficiencies make it a cost effective filter designed to extend final filter life.
|
|
|
|
|
|
The reliability and efficiency of any filtration system is chiefly dependent on the quality of the cartridges used in it. Our full line of quality HILCO cartridges includes various sizes, filtration efficiencies and dirt-holding capacities for virtually every application. HILCO can restore many oils and coolants to a like-new condition.
All cartridges are developed to provide long service life and high quality. Many different media are specially selected, formulated and fine tuned on a regular basis to provide the most effective combination of fluid compatibility, particle-separation efficiency, low pressure drop and structural properties.
Controlled radius pleats are designed to maximize filtration area and dirt-holding capacity while resisting pinching, distortion and rupture. Gasket materials and adhesives are selected based on their compatibility with fluids and operating temperatures of each application. Cartridges feature rugged, fiberglass filled nylon and plated steel centertubes which resist collapse at high pressure differentials.
Fuel gas, process gas, seal gas, H2O injection, and transformer oil applications can also be accommodated by HILCO. We also make HILCO-quality replacements for other brands of cartridges used in lube oil and fuel oil applications.
|
|
Claris® Series Filter Cartridges
High Consistency Polypropylene Melt Blown Cartridge
Graded Pore Structure Enhances Dirt Holding Capacity
E-core, an Extruded Fibrous Core, Provides Excellent Strength
Unique Proprietary Process
Easy and Safe Cartridge Incineration and Disposal
All Polypropylene Construction
Free of Surfactants, Binders, and Adhesives
NSF Certified
Plastic and Metal Spring Assembly End Configurations Available
Performance Specifications
Filter Grades:
1, 3, 5, 10, 20, 30, 50, 75 µm
Maximum Differential Pressure:
50 psid (3.45 bar) @ ambient
25 psid (1.72 bar) @ 140°F (60°C)
Recommended Change Out Differential Pressure1:
35 psid (2.4 bar)
Purity:
Claris Series filter cartridges are free of surfactants,
anti-static agents, binders, and adhesives.
|
|
|
General grade membrane cartridges are designed for general purpose use wherever a cost effective membrane filter is required and is offered in polyethersulfone, nylon, Teflon, and polypropylene. Designed to hold the maximum amount of filter media that can be completely and effectively utilized in a cartridge, General grade membrane filters lower the cost of filtration . Membrane cartridges are flushed with 17+ megohm-cm water to remove potential extraneous manufacturing debris. These cartridge modules are also individually tested. Priced below special purpose cartridges, General grade membrane cartridges are still manufactured with the same careful attention to both quality and performance.
|
|
|
|
|
|
3-inch and 4-inch diameter modules available in 10-foot and 12-foot lengths.
The use of KMS SUPER-COR® membranes for juice processing eliminates the need for pretreatment and associated handling equipment-no more centrifuges, screens, rotary drums, diatomaceous earth, or fining agents. It also does away with the maintenance associated with pretreatment processes, saving you time and money. The latest SUPER-COR® modules have a robust backing structure that supports the extended processing requirements of today's juice processing plants.
SUPER-COR®, designed around the needs of juice processors worldwide:
• Higher product yield
• No preprocessing required-eliminates diatomaceous earth and fining agents
along with their associated maintenance and disposal costs.
• Transparent module housing for ease of inspection
• Long membrane life
SUPER-COR® Systems, combined with last stage of SUPER-G® modules, clarify juices at extremely high yield rates. Up to 98% yield can be achieved without adding diafiltration water.
|
|
TARGA® industrial water cartridges provide compact pretreatment for ultrapure water systems.
8-inch TARGA® cartridge
TARGA® industrial water ultrafiltration cartridges are produced for general water treatment applications. They are particularly effective for pretreatment to reverse osmosis membranes.
• pH Tolerant
• Chlorine Resistant up to 200 PPM at 10.5 pH
• Temperature range of 32 degrees - 104 degrees F
8-inch diameter cartridges are available in two lengths: 48-inches and 72-inches.
TARGA® cartridges have a broad range of applications, including:
• Carbonated Soft Drinks and Bottled Water
• Boiler Make-up Water
• Microelectronics
• Pharmaceuticals
|
|
Take advantage of the KMS proven track record
For more than thirty years, the highly innovative FLUID SYSTEMS® brand of Koch Membrane Systems has been serving the residential and commercial water filtration and purification markets with state-of-the-art membrane elements.
|
|
SC series cartridges have been designed to tackle the toughest of filtering applications. The cartridges are available in 304 or 316 Stainless steel with a complete option of end cap configurations. You can choose the pleated style for extra surface area and extended life or the cylindrical for easy cleaning. SC cartridges are the perfect choice for high temperature, high pressure, and resolve chemical compatibility with polymer elements. SC filters are cleanable and reusable and offered in retention ratings as low as 2 micron through 840 micron.
|
|
Self cleaning filters are available in either manual or automatic versions with standard design options for either low pressure (14 BARG) or high pressure (35 BARG) system.
In operation the liquid enters the body and flows through the element from outside to inside.
Debris is collected on the outside of the wedge wire element, which is cleaned without flow interruption by rotating the cylindrical element against twin scraper blades.
The debris accumulated during element rotation is deposited into the bottom of the filter body from where it is periodically discharged, manually or automatically.
|
|
|
|
|
|
|
EUROFILTRAZIONE is a leading company in the production of filter elements for industrial applications, and produces a complete range of filter cartridges for EDM machines, of both edge and plunge type. The use of filtering materials specifically conceived for this purpose, ensures the best possible results. EUROFILTRAZIONE filter cartridges are in fact top of the range both in relation to national and foreign production output. The winning features of these cartridges being a high filtering capacity with low charge loss, and considerable storage capacity in even the most severe operating conditions, thereby ensuring the long working life of the product. Thanks to these features, and highly competitive price levels, it possible to greatly reduce filtering and electro-erosion costs without in any way jeopardizing performance levels. EUROFILTRAZIONE is therefore a truly top-level manufacturer, capable of meeting customer requirements both with a range of standard products as well as with special products, suitable to face specific challenges.
|
|
MultiMaster Vario Active-Carbon Cartridge System CKG
The CKG mounting frame is manufactured from galvanized steel. As an alternative, 1.4301 steel is possible.
Special features:
- Mounting frame for 16 active-carbon cartridges
Application:
- Filtration of odours and pollutant gases
Technical data:
- Air-flow rating: 1,000 – 144,000 m³/h
- Filtration rating: Up to 99%, depending on the length of the contact period and on the type of pollutant gas
- Maximum operating temperature: 40°C
- Maximum relative humidity: 70%
- Weight (mass): 305 - 1324 kg
|
|
Specialty Membranes
CUNO manufactures a wide range of native and charge modified, symmetrical and asymmetric nylon membranes; as well as micro fiber polypropylene media. These solid supports can be customized to suit your specific needs. When it comes to innovation, CUNO has the answer to your solid support membrane needs.
Please contact CUNO SMP for information on designing a solid support structure to fit your exact requirements.
Applications Include:
* Lab Filtration Devices
* Disk Filters
* Medical and Dialysis Filters
* Roll Stock
* Cartridge Filters
* Diagnostics
|
|
|
|
|
|
Polymer candles
Polymer candles are the choice of the processor when it is important to have the lowest capital cost combined with ease of replacement, lower downtimes and overheads. Candles are available in pleated stainless steel fibre (e.g. for PET film, fibre and resin) or cylindrical woven meshes (e.g. for BOPP film) utilising stainless or speciality steels. Our designs encompass the fully welded, REMPAKTM and re-coverable versions, with the last two options representing a lower cost product where the valuable hardware can be reused when the media has reached the end of its life.
Our candles are available in industry standard designs, or can be custom designed to fit any particular housing. With high strength, they are available in filtration ratings from 3-100 microns, and would normally be supplied with an outer guard both to protect the media. Our range of high strength, highly permeable steel stainless fibre media gives candles with low initial pressure drops and long on- stream life.
Our candles are readily cleanable with current technology and we would be happy to advise on appropriate cleaning methods available.
|
|
Designed always to meet the needs of the cleanliness class, pressure requirements and characteristics of the medium, stable and constant pressure MAHLE filter elements with their high contamination retention ability ensure economical and trouble-free operation. Our extensive range of standard and DIN version products also contains alternative variants for virtually every make of filter and filter element for aggressive fluids, cooling lubricants and aqueous media.
We will also develop special versions to meet individual customer requirements.
|
|
|
|
|
|
Cartridge filtration units generally operate most effectively and economically on applications having contamination levels of less than 50 – 80 ppm. For heavier contamination applications, cartridges are normally used as final polishing filters. In the following the basic systems of cartridge filters are listed
Wound Cartridge Filters:
- the most common type of depth filters
- materials: natural or synthetic yards, which are wounded around a central tube or former
- numerous applications in the industry
Bonded Cartridge Filters:
- one-piece cordless construction, consisting of resin bonded fibers of solid particles
- their filtration range is between 5 to 125 micron, good chemical compatibility/flow rate
- frequent application: viscous fluids, process duties
Pleated Cartridge Filters:
- today's most common cartridge filter system
- materials: cellulose basis, resin impregnation; polyester, micro fiber glass, polypropylene
- advantages: increased surface area (up to 60 %) compared to traditional cartridge filters
Metal Fiber Cartridge filters:
- material: stainless steel fibers, connected to a mat
- used in the polymer industry
|
|
LyPore Defender is Lydall's newest liquid media series. Extensive R&D coupled with industry leading expertise in wet-laid microglass media results in a series of products that truly push the boundaries of dirt holding, particle removal, and flow.
Our unique blend of fibers and binders are optimized for each grade to provide ultimate performance in a pleated configuration. While initially designed for hydraulic filters, LyPore Defender can be used in virtually any industrial liquid application that requires high performance and long life.
These grades are optimal when co-pleated with multiple support layers and can be used as the sole efficiency and dirt holding layer or in conjunction with a separate pre-filter. The LyPore® Defender series is available in standard acrylic latex binder or optional epoxy binder for more demanding fluid and temperature requirements.
|
|
Liquid Filtration Media
A suite of liquid filtration media optimized for a wide range of filtration applications, including hydraulics, metalworking, process filtration, power generation, chemical, electronics, bio-pharmaceutical, medical diagnostics, food and beverage, drinking water and pre-filtering. With its high efficiency, superior dirt holding capacity, low pressure drop and pleatability, Lydall's liquid filtration media advances filter performance in the most demanding of applications.
|
|
|
Extended Filtration Surface. Sixty deepfold pleats multiply the available filtration surface area. This construction offers greater contaminant holding capacity compared to the cylinder-type tube. Other advantages of the Sethco Pleated Filter Cartridge are high strength, polypropylene construction, resistance to deterioration, inertness to tough liquids such as corrosive electroplating and sensitive photo and processing solutions. Reusable and long lasting under the toughest liquid conditions make it ideally suited to all industrial and laboratory filtration applications.
|
|
|
|
|
|
Mikropor Continuous Wound liquid filters (MW) feature a special diamond pattern which maintains uniform micron retention throughout the length and depth of the element and provides superior particle trapping capabilities.
Mikropor continuous wound liquid elements also eliminate the problems of segmented elements, such as contaminate by-pass, inconsistent micron retention, flow restriction and reduced filtration area where joints are over-wound.
Mikropor Wound liquid cartridges offer a gradual pressure increase during cartridge life while surface-type media experience abrupt flow cutoff when loaded. Each layer on Mikropor wound cartridges contributes to true depth filtration by trapping its share of particles. Furthermore, the irregular outer surface reduces surface binding, delivering both longer cartridge life and full cartridge utilization.
Applications for Mikropor Continuous Wound Filters
- Fluids Chemical Industry
- Electronic Industry
- Polymer Solutions
- Pharmaceutical
- Electrical Power Generating
- Petrochemical & Refineries
- Printing Inks
- Reverse Osmosis Units
- Pre-Treatment Oxidizing Agents
- Electroplating Solutions
- Process Water
- Concentrated Alkalis
- Cooking Oils
- Oil & Gas Mineral Acids
- Photo Solutions
- Food & Beverage Industry
|
|
We design filter cartridges which have hinged bolts damp lids. These cartridges are used for a variety of applications like filtration of hydraulic oils, lube oils, fuels, cutting fluids, coolants, washing fluids etc., Their housings are sized depending on the application & rated flow requirement. These can be designed for higher pressures. The housings of verity of material of construction are supplied depending on the requirement.
Working:
The dirty fluid is pushed in the filter housing under pressure. Filter elements of correct filtration rating are placed in the housing depending on the flow & other requirements. The ends of the filter elements are sealed so that the fluid is made to pass through the filter medium only, to leave the dirt on the filter medium. Generally the inlet & outlet are in one line. However the position of the inlet could be altered as per the requirement.
|
|
|
|
|
|
Betafine® XL Filter Cartridges
Providing Reduced Total Filtration Costs and Predictable Filtration Performance The Betafine XL filter represents a major advance in pleated filter technology. Building on Cuno's history of filter design innovation, this absolute-rated, 100% polypropylene, pleated cartridge features a patent pending Advanced Pleat Technology (APT) that increases the usable filtration surface area while maintaining standard industrial cartridge dimensions. The result is a filter cartridge that dramatically enhances service life to provide:
* Reduced Total Filtration Costs: Fewer cartridges used, reduced cartridge change-out frequency, reduced downtime and product waste, and reduced labor and disposal costs.
* Predictable filtration performance: Reduced quality checks, reduced product rejects and rework, and increased productivity and plant capacity.
Advanced Pleat Technology™
The service life of a pleated cartridge is often dictated by the accessible surface area. Conventional pleated filters may offer a large gross surface area, but when the media is packed too tightly into the cartridge, only part of the surface area is usable resulting in both flow restrictions and limited contaminant holding capacity. The "blind" or unusable area commonly occurs near the inside diameter where the pleats are packed most tightly.
|
|
Biofil PES
Incorporating a hydrophilic membrane, the Biofil cartridge has a unique mirrored asymmetric structure which gives the media added strength and very low clean pressure drops. This helps to ensure that cartridge integrity is maintained when repeatedly steam sterilised. The characteristics of the membrane also results in excellent resistance to hydrolysis, along with low protein binding and colour stripping. Furthermore Biofil PES cartridges have excellent chemical compatibility across the full range of pH values.
Biofil PES cartridges have been validated and are ideal for applications ranging from the production of beverages to the filtration of blood and serum. They compare favourably in many applications with alternative cartridges manufactured using Nylon, Cellulose and PVDF.
|
|
Filter cartridges
2fi manufacture a range of industry standard stainless steel filter cartridges suitable for use in a wide range of industries, including pharmaceutical, chemical process and petrochemical, at extreme conditions of temperature and pressure.
Wholly constructed of grade 316L stainless steel, in fibre, powder or mesh media, the cartridges are available plain or pleated with a choice of end fittings.
|
|
High impurity removal rate, excellent dirt-holding capability and longer life extension of the filters are obtained by special filter paper and paper folding.
High impurity removal rate, excellent dirt-holding capability and longer life extension of the filters are
obtained by special filter paper and paper folding.
MTL filters have the following features:
- Filtering ratings: between 3-5 µm.
- Longer life extension.
- Excellent filtration of deionization.
- Great filtration area and filtration efficiency with special origami techniques and methods.
- Stable and durable quality of every filter is assured by strict manufacturing technics and quality
check.
- All sizes and specifications are available to meet customers' different requirements for all types of
machine tools.
|
|
You need cartridge filters with long life, high efficiency and low total operating cost and that's what you get from GE Water and Process Technologies. With an extensive range of filters to meet all of your microfiltration needs:
- RO pre-treatment
- Pure water filtration
- Food and Beverage
- Electronics
- Oil and gas
- Chemical processing
- Pharmaceuticals
- Medical
- General industry
GE provides, and continues to develop, high-performance products backed by years of experience. Our cartridge filters are made with no wetting agents, solvents, anti-static agents, or binders. FDA-compliant filters are available for food and beverage contact.
|
|
The filter elements are manufactured by isostatic pressing or co-axial pressing. The pore size can be adjusted by suitable selection of the powder size fraction and the process parameters. It includes the type of tube, disc and stack of lamination and so on.
Main advantages
1. Good shape stability
2. High strengthen and good integrity
3. Controllable pore sizes and porosity
4. Good permeability
5. Good corrosion and thermal resistance
6. Easy to be made into complicated shapes
7.Highly mechanical strength, can diffusing air homogeneously.
|
|
The Bossmanfilter Boss-SSPL series filter elements specialy made in SS media and designed with guarantee for optimum number of pleats and improved area of filteration.
Thease filter elements having maximum removal ratings makes it possible to be used for different applications..Also it can be used for high and low viscous fluids as well as all types of gases.
It can be withstand for maximum operating fluid temperature of upto 240°C.
Advantages of thease filter elements are because of the pleated construction small sizes will handle more filteration flow volume
|
|
|
GS Series Polyethersulfone Membrane Cartridges are designed for general industrial service where the need for cost effective filtration is a must. These cartridges utilize a pleated membrane design, incorporating the maximum amount of media that can be used in a cartridge. These units, manufactured for general industrial use, are manufactured to the same high standards as our special application cartridges. Pore sizes start at 0.03 µm with a polyethersulfone membrane.
|
|
|
|
