These cartridge-filter housings are rugged and low in cost. They hold five cartridges, in 10-inch, 20-inch, 30-inch, or 40-inch lengths, using industry standard designs (222, SOE, or DOE). The unique, “quick-opening” clamp design uses a standard gasket.
Standard Features
- Low pressure drop
- Permanently piped housings are opened without disturbing the piping or requiring tools
- Quick-opening, clamp-type cover
- Carbon or stainless steel housings
- Adjustable-height tripod legs
- Holds 5 cartridge elements
- Accommodates cartridge elements in four lengths: 10”, 20”, 30”, 40”
- 125-psi rated housing
- 3/4-inch clean-dirty/gage ports
- 2-inch female NPT ports
- V posts or threaded-center posts
- Standard hardware V-post and spring seals are 316 stainless steel.
- O-ring seals: Buna N, EPR, Viton®
|
|
|
AAF AmerKleen filter cartridges are protected at all times by an all metal, filter housing. The AmerKleen housing is equipped with an anti-surge assembly consisting of a wire form attached to the back of each sealing frame. By holding the cartridge firmly in place, the housing protects it against turbo-surge. The AmerKleen cartridge is designed to be changed at the normal 90-day maintenance cycle, with an adequate safety margin should the locomotive encounter delays in servicing. When the time comes, installation is a fast and easy process. By the simple removal of two bolts and a sealing frame, the AmerKleen cartridge is front-loaded. Replacing the sealing frame automatically forms an air-tight seal. Normal air flow through the filter insures that all seals remain tight without the need for time-consuming alignment.
|
|
High efficiency terminal filters for highest requirements for air purity and hygiene.
High efficiency terminal filters are used as final filters in areas with the highest requirements for air purity and hygiene such as in the medical, biological and pharmaceutical industries as well as in other sensitive areas.
Both HEPA and ULPA filters can be used.
These filters can be combined with different ceiling diffusers from the TROX standard product range.
- Particulate air filter ceiling diffuser
- Main filter for high air purits and sterility
- Ceiling diffusers are a comfortable way to generate mixed air flow quietly,
even for large quantities of air.
|
|
CIH multi cartridge V-band clamp closure housings are a proven design suited for commercial and industrial applications. Offered in 4,5,7,12,and 21 round configurations and in 304 SS or 316L SS. All CIH housings are designed with Universal cartridge cups, allowing you to use DOE style cartridges or 222 SOE cartridges with fin or flat end. This gives you one housing that can meet your nominal and absolute filter needs and provides quick cartridge change outs. Housing is standard with EP gasket and also offered in other materials and port sizes, allowing the CIH to meet a wide spectrum of applications. Every housing is supplied with a mounting kit and operations manual.
|
|
The Hilco TurboFlo Duplex Filter line is easy to operate and maintain with a low turning torque and no jacking of the sealing pads. Welded-in transfer valves and high flow synthetic elements save space, and flow is under the filter cartridge which does not impinge on the filter elements. With no flanges between the transfer valve and filter housing, there are fewer potential leak points.
Features includes:
• ASME Code construction
• O-ring sealed covers
• Coreless elements
• Standard carbon steel and 316 stainless steel
The TurboFlo Duplex Filter is also available in 1-1/2” to 8” inlet and outlet connections for flows up to 2000 gpm and pressures up to 5000 psi.
For complete product information, request bulletins TBF-2 and TEB-2.
Other Filter Housing products include:
• Integral Duplex Filters
• Standard Housings for High Flow Synthetic Elements
• Standard Non-Code Housings
• Bag Filter Housings
• Seal Gas Duplex Filter Housings
|
|
FM4X1-1: 4-round 10 in. Cartridges, 1 in. NPT; 25 gpm max; (Legs Optional)
Description:
100% stainless steel design, V-band clamp lid closure, pressure rating 150psi. Available in 304 or 316ss.
|
|
|
|
|
|
CCL Series Housings
Pall CCL Series Housings accept Pall 1000 style filter elements in a 10, 20 or 30 inch length, or Pall 21/2%u2033 diameter UNI CAP style pleated filter elements. This series of housings is typically used for flow rates of 15, 20 and 25 GPM for the 10, 20 and 30 inch cartridges respectively. The housings are constructed of a 316 stainless steel investment casting head and a 316L stainless steel bowl. One or two polypropylene couplers, to join 10%u2033 1000 style filters together, are included for 20 and 30 inch housings, respectively. Inlet/outlet connections are 1%u2033 NPT or 1%u2033 flange. The head and bowl of the housing are fastened with a quick opening stainless steel Tee handle V-band clamp. Head to bowl sealing is by standard 242 O-ring.
Specifications
Design Ratings:
Pressure: 200 PSIG (1379 KPA)
Temperature: Limitations due to O-ring material.
Buna N: -20°F to 250°F (-29°C to 121°C)
Viton A*: -20°F to 400°F (-29°C to 204°C)
Ethylene Propylene: -20°F to 300°F
(-29°C to 148°C)
A bowl drain connection, as well as 2 pressure taps in the head are standard on all models.
The housings may be mounted in any position except for oil mist removal from compressed gases, where it must be mounted vertically with the bowl down.
|
|
|
CSH sanitary cartridge housings, available in 1,3,6,8,12 and 21 round models with swing bolt and clamp closures are a proven design suited for high purity beverage, chemical and pharmaceutical applications. They are manufactured in 316/316L Stainless Steel with a 25 RA internal finish. All CSH housings are standard with 2-226 style cartridge adaptors with removable tube sheet, giving you a positive locking tab seal. This allows flexibility in one housing to use different cartridge lengths and maximize filter performance and cost. CSH housings have no internal threaded parts that come in contact with the process fluid and are standard with food grade silicone gaskets. 1” sanitary gauge port tops with 1/2” sanitary vent and drain ferrules are standard features.
|
|
CHR single cartridge ring closure housings are a proven design suited for commercial and industrial applications. Available in 304 SS, 316 SS or Brass head with 304 SS sump. The CHR housings are rated for 300 psi and are designed for DOE style cartridges with machined knife edge seal surfaces for a no-bypass seal. All sump seals are spring loaded allowing you a variety of cartridge lengths and providing quick cartridge change outs. With the complete range of O-ring materials and port sizes the CHR will meet a wide spectrum of applications. Every housing is supplied with a mounting kit and sump rod.
|
|
PiP housings and PiP elements are used for process filtration. It is about a brand-new developed series of filters. It includes pleated cartridge filter elements and bag replacement elements for process filtration as for instance filtration of cleaning liquid, lacquers, colors. Originally, pleated cartridge filter elements were developed for the filtration of cleaning liquids, nevertheless they are applicable in a wide range of areas.
|
|
|
Designed for removing trace contaminants down to 1 micron. Ideally suited for filtering and corrosive solutions including electroless copper and nickel to 200°F (93°C).
|
|
|
A FLOWLINE stainless steel bag filter housing from Eaton is the best choice for industrial, commercial and OEM applications that do not require a Code Stamp. Its cost-effective design incorporates all of the features heavy duty applications demand, including an investment cast swing bolt cover that can be adapted to different opening directions in the field and a quality stainless steel mesh restrainer basket for reduced pressure drop.FLOWLINE's stainless steel construction ensures years of trouble-free, consistent performance at a price comparable to that of many carbon steel housings.
|
|
The SONDERMANN filter housings are specially designed for the removal of organic and inorganic impurities from aggressive and neutral liquids by means of deep- bed and surface filtration.
Advantages
- Vast range of varieties
- Solid plastic version
- Easy operating thanks to the quick fastening
- Combination possible with the complete range of products
Applications
- Electroplating
- Caustic and purifying plants
- Waste and fresh water treatment
- Photographic industries
- Textile and foodstuff industries etc.
|
|
|
|
|
|
Industrial Housings
1B1/2
* Available in either cast-iron and steel, or 304 stainless steel construction.
* Centerpost design for easy cartridge changeout.
* Choice of one- or two-high cartridge models.
* Three-piece construction for easy cleaning.
P SERIES
* PE and PT Models are cast iron and steel housings designed for industrial oils or non-aqueous applications.
* Available separately or mounted as mobile units, ideal for transformer oil filtration.
* PTS Model is a 304 stainless steel housing designed for aqueous or corrosive applications. Single V-band clamp closure.
1H1 MODEL
* Ideal for high-pressure applications (1000 psi @ 250°F).
* Dual purpose/use for liquids or compressed air and gas.
* Durable steel construction.
* Housing design prevents cartridge erosion.
* Uses single cartridge of a variety of cartridge types.
CT SERIES
* Choice of either forged brass and 304 stainless steel or all 316 stainless steel construction for versatile applications.
* Drilled and tapped mounting pads, ready for mounting bracket installation.
* Choice of one-high or two-high models.
* Available in 300 psi design.
|
|
Features
Available in Type 304 Stainless Steel, Type 316 stainless steel or carbon steel with standard Buna N o-rings, Viton® o-rings are an available as an option.
A counter balanced spring assisted cover lifting mechanism balances the cover perfectly giving it a "weightless" feel. Opening and closing the cover is "finger tip" easy.
QIC-LOCK rapid opening and closing mechanism ensures simple, operator friendly operation with minimal downtime for bag change-outs. Reduces downtime to increase productivity and decrease operating costs.
Unique 3-point hold down for bayonet fitting ensure high quality of the seal between each filter bag and the housing body. A supplied special tool ensures, simple effective operation.
Side inlet and bottom outlet provides easy and complete drainage. A standard tangential outlet reduces housing height.
Available in three sizes for 4, 6 or 8 standard size 02 double length filter bags.
|
|
Sanitary grade housings
Designed for the demands of critical applications particularly in the pharmaceutical, microelectronics and food and beverage industries, our sanitary grade housings have easy to use closures with a crevice free construction. The internal surfaces are resistant to bacterial accumulation and are easily steam sterilised or chemically sanitised. Microbial security can only be guaranteed with this grade of housing.
|
|
| ... products without technical information |
| |
|
|
|
|
Whatever type of filter you use, Allegheny Bradford can supply a housing that meets your needs. Our line of Universal housings combines the best features of the finest stainless steel filter housings on the market with a full range of custom options to tailor your housing to your specifications.
We offer an array of Universal housings to fit virtually any filtration system, designed especially for use in ultrapure, sanitary and hitechnology industries including electronics, pharmaceuticals, food, dairy, beverage and chemicals. These flexible Universal housings accept a wide variety of cartridge, disc, membrane, ceramic and metal media, to meet even the most complex multiple processing requirements. They are available in a full range of sizes to fit everything from small gas filtration units to massive 270-element housings for water purification.
Best of all, they provide the advanced design, precision fabrication and superior quality of the industry's leading manufacturer - at very competitive pricing.
Our fabrication specialists use only the finest materials available including type 304, 316 and 316L stainless steel. To insure accuracy, machining is performed on state-of-the-art CNC equipment. Our welders are ASME certified, and use the most advanced welding equipment available. In addition, mechanical polishing or electropolishing can be performed right at our facilities to achieve the quality finish your application requires. From the initial inspection of raw materials, to the final ASME Code compliance check, our filter housings undergo rigorous testing and documentation procedures throughout the manufacturing process to meet the most stringent industry standards. All Allegheny Bradford filter housings can offer:
ASME Code Compliance with U and UM stamps and National Board Registration
Material test reports
Profilometer-certified surface finish
Hydrotest
Radiograph analysis of welds
Helium leak test
Borescope inspection
Other certificates of compliance
As the largest independent manufacturer of stainless steel filter housings for sanitary, ultra-pure and high technology applications, Allegheny Bradford is uniquely positioned to meet your filter housing needs. By purchasing your filter housings directly from us, you receive the highest quality units on the market, customized to your specifications at a very competitive price. And our dedicated team of engineers, designers and customer service specialists make sure you get what you need in a timely manner. Quality. Value. Availability. When it comes to filter housings, Allegheny Bradford puts it all together for you.
Whatever stainless steel components you need for your ultra-pure process, from filter housings and skids to custom tanks and heat exchangers, count on Allegheny Bradford Corporation to deliver - on time and on budget. For more information on our full range of products and services, call us today at 800-542-0650.
Our Universal filter housing line combines the affordability and availabilty of standardized units with the custom features your application requires. By manufacturing a wide variety of components in advance, we are able to design and deliver a filter housing that incorporates features specifically for your processing environment, quickly and cost-effectively. Choose from an extensive range of options, including:
T-Style or in-line construction
ASME code stamp
Various cartridge sockets
Gauge ports
Vent and drain valves or ports
Various inlet and outlet connections
ID surface finish to less than 10 microinches Ra
Electropolish
OD surface finish to 400 grit
Steam/hot water or cooling jacket
Private label etching
Click here to download a PDF version of the Sanitary Stack Disk Housing (SD-WS) drawing.
Click here to download a PDF version of the 12.75" OD 1-Post Stack Disk Housing (stackdisk) drawing.
Click here to download a PDF version of the Sanitary 1 Round In-Line Housing (USI01-WS) drawing.
Click here to download a PDF version of the Sanitary 1 Round T-Type Housing (UST01-WS) drawing.
Click here to download a PDF version of the Sanitary 3 Round T-Line Housing (UST03-WS) drawing.
Click here to download a PDF version of the Sanitary 6 Round T-Line Housing (UST06-WS) drawing.
Click here to download a PDF version of the Sanitary 12 Round T-Line Housing (UST12-WS) drawing.
|
|
|
|
|
|
For more than 25 years Allegheny Bradford Corporation has been an innovator in the design and manufacture of stainless steel equipment for sanitary processing. As specialists in ultra-pure applications, we offer a full range of standardized and custom products from shell and tube heat exchangers, to tanks and filter housings, to customized modular process skids. Our experience in understanding and meeting the needs of sanitary processing has led to equipment breakthroughs that include the revolutionary Opti-CleanTM Filter Housing with its unique drainable, CIP design. For stainless steel components that enhance your ultra-pure processing environment, look to Allegheny Bradford Corporation.
Drainable. Cleanable. Unbeatable. That’s the innovative Opti-Clean™ Filter Housing from Allegheny Bradford Corporation. Its advanced technology and unique patentpending design practically eliminate hold-up volume and speed clean-up to make your entire processing environment more efficient – and more profitable.
The Opti-Clean™ Filter Housing is designed for maximum drainability. Unlike traditional housings with a collection chamber under a flat cartridge plate, Opti-Clean’s one-piece design eliminates the collection chamber and features an integrated sloped cartridge plate to aid in drainability. All the cartridge sockets drain to individually machined and sloped slots that lead directly to the central outlet port.
|
|
Camfil Farr offers a wide range of housings in different versions i.e. galvanised or staniless steel. All Camfil Farr housings are always best in class products.
Example of advatages:
* Easy to install
* Modular construction
* No tools needed to change filters
* Gasket to seal between door and filter
* Clamping device for the filter
* Stable and secure design
|
|
|
Suitable for both liquids and gases, these housings are ideal for high flow corrosive applications with 1” to 2” line sizes. A variety of flange connections is also available and the housing can be supplied in exotic materials such as Monel and Hastelloy.
|
|
Filter Houses
The Preferred Choice
Braden filter houses are the preferred choice of OEM’s for new installations and the favorite choice of GT owners retrofitting their systems. With proprietary designs and numerous global manufacturing locations to satisfy local content requirements, Braden can provide an outstanding solution.
• Filter Houses
• Inlet Cooling / Heating Coils
• Evaporative Coolers
• Over 700 Filter Houses Built
|
|
Trade name: ECO III
Filtration of the air of admission - News approaches
Advantages:
- Not need for supports to measure
- Important Profit of time and money
- Output raised for small overall dimensions
it system of air filtration can be close to the turbo-compressors
- Profit of output
- By its reduced dimensions, releases from space in the driving compartment.
Applications:
- Road vehicles including the buses
- Specialized Applications, practically including all the types of vehicles and installations.
|
|
AP&T manufactures and delivers complete production units for pressing filter housings in different designs.
The equipment is standardized and adapted to meet the customer's demands on finish and cost per detail.
|
|
 see the results for the following category : Axial fans |
|
|
