Interfaces USB V1.1
Fingerprint Sensor CMOS reader
Fingerprint Sensor Resolution 500 dpi with distortion<1%
Capture Area 13mm x 16mm (256 x 320 pixels)
Dimension 61mm(L) x 34mm(W) x 32mm(H)
Image Capture Time 8 Frames /sec.
Verification Time < 1 sec.
FAR 0.001%
FRR 0.1%
Power Consumption Max Current < 120mA
Operating Environment Temperature 0°C ~ 60°C
Supported OS Win 98SE/Me/2000/XP
Professional software Demo Program for Windows Series
1. Windows logon (replacing password)
2. File encryption/decryption (ensure the files won't be used by other people)
3. Time Limitation (parents can control the time of their children spend on professional computers)
4. Group Setting (multiple users share the same encrypted files)
5. Screen Saver
|
|
(1)PCI Expressi34j type design and plug and play function. Support PCI Express 34 or 54 Card slot.
(2)Up to 10 sets fingerprint enrollment.
(3)Multi-Factor Authentication.(Biometrics - fingerprint;Password - for computer sign in)
(4)Use chip based sensor for live-scan capturing of 3D-fingerprint
Minutiae.
(5)Advanced Password Management.
(6)Windows 2000, Windows XP, Windows Vista 32bit supported.
(7)AIAC-Advanced image auto-calibration technology. No matter dry or wet of your finger skin, it can get clear fingerprint image easily
(8)AES256 bit file/folder encryption technology.
(9)Multilingual support: English/Japanese/Traditional Chinese/Simplified Chinese/Korean/French/German
(10)5-in-1 Software:Auto-Login,Screen Saver Lock,Password bank,File/Folder Encryption,Magic Disk |
|
The device control the starter and oil pumper based on your fingerprint
SPEC:
Power dispenser DC 9V ~ 12V
Power Consumption CMOS Module Max.140mA@12V
Chip Sensor Module Max.121mA@12V
4 Output Relays 4 Output Relays, Max. Driving Current: 1A each
Environment Temperature CMOS Module(0Ž ~ 60Ž)
Chip Sensor Module(-40Ž ~ 85Ž)
Dimension Of INDUSTRIAL DSP Board 121 x 105 x 11mm
Cable Length Max. up to 2m for the sensor devices
Fingerprint Sensor CMOS Module / Chip Sensor Module
Cable Length Max. Up To 2M For The Sensor Devices
Users Record Stored 20 Fingers, Can Be Extended
Dimension Of DSP Board 121 x 105 x 11mm
Users Record Stored 20 fingers
FAR 0.001%
FAR 0.1%
Matching Speed < 2sec for 1-to-N Identification
Communication Interface RS232
Processor 400 Mhz DSP
|
|
Interfaces USB V1.1
Fingerprint Sensor CMOS reader
Fingerprint Sensor Resolution 500 dpi with distortion<1%
Capture Area 13mm x 16mm (256 x 320 pixels)
Dimension 80mm(L) x 45mm(W) x 35mm(H)
Image Capture Time 8 Frames /sec.
Verification Time < 1 sec.
FAR 0.001%
FRR 0.1%
Power Consumption Max Current < 150mA
Operating Environment Temperature 0°C ~ 60°C
Supported OS Win 98SE/Me/2000/XP (WinCE 3.0/4.1)
Software Demo Program for Windows Series |
|
Digital ID Hardware Engine - UPEK's Digital ID Hardware Engine is a secure processing environment for all biometric operations. Using secure processing protects privacy and insures that biometric results are trustworthy, secure, and accurate. All critical processing is protected from hackers, software viruses and other malware.
The TouchChip Fingerprint Sensor (TCS1) is a touch sensor offering an intuitive, easy-to-use interface, ideal for multi-user applications such as point-of sale terminals or enrollment stations. The TCS1 offers the best image quality of any silicon sensor in the market in a compact, easy to integrate package. |
|
EikonTM and TouchChip® USB Fingerprint readers
UPEK's® USB fingerprint readers provide quick and reliable biometric authentication to desktop or network resources. They include cost effective Eikon swipe readers for personal use, or larger TouchChip readers for multi-user applications.
UPEK's USB fingerprint readers use the same patented technology built into most of today's fingerprint sensor-enabled notebook PC's, as well as many mobile phones, professional keyboards, POS terminals, door locks, handheld ID terminals and more.
Applications
Single Sign On -replace multiple passwords for enterprise,
financial and healthcare network users
VPN (Virtual Private Networks) - secure network access
from remote locations
OTP (One-Time Passwords) - increase the security of static
(unchanging) passwords
Windows® Logon - more secure access to professional computing resources
Protect Encrypted Data - control who views or changes digital data
Privacy Protection - medical records, financial records, web transactions. For compliance to HIPAA, FFIEC, Sarbanes-Oxley and other government regulations. |
|
Interfaces USB V1.1
Fingerprint Sensor CMOS reader
Resolution 500 dpi with distortion<1%
Image Capture Area 13mm x 16mm (256 x 320 pixels)
Dimension 121mm(L) x 63mm(W) x 38.5mm(H)
Verification Time 8 Frames /sec.
FAR 0.001%
FRR 0.1%
Power Consumption Max Current < 150mA
Operating Environment Temperature 0°C ~ 60°C
Switch Life 1,000,000 Cycle Life
Supported OS Win 98SE/Me/2000/XP (WinCE 3.0/4.1)
AP functions
1. Windows logon (replacing password)
2. File encryption/decryption (ensure the files won't be used by other people)
3. Time Limitation (parents can control the time of their children spend on professional computers)
4. Group Setting (multiple users share the same encrypted files)
5. Screen Saver
|
|
| ... products without technical information |
| |
Features:
- 13.56 MHz Contactless Smart Card. Ability to add a magnetic stripe, professional barcode, anti-counterfeiting feature, custom artwork, or photo ID.
- 13.56 MHz HID proximity reader (read only) Slim design is perfect for metal mullions or any other space-limited installation. |
|
The new Omni-Access reader line is in-tune with the demands placed on modern architecture. Their contemporary design, in two shades of stainless steel, adds a subtle but elegant accent to their surroundings.
The readers, designed for secure and reliable access regulation, offer a broad variety of functionalities and technologies. They are ideal for mounting on door frames.
Choose either the Mifare or EM proximity technology with optional pin pad for access security.
|
|
| ... products without technical information |
| |
| The sleek and compact design of Rosslare's new Convertible dual-application biometric reader/controller adds to its versatility and multi-faceted capabilities. When connected to a Rosslare intelligent Secure Smps, it converts into a 500-user fully featured secure access controller. This unit utilizes an award-winning algorithm, which provides highly accurate fingerprint recognition, along with the options for PIN code or proximity card reading, for the ultimate ID verification security. |
|
bioCLASS Biometric Keypad Smart card reader
The bioCLASS products provide three levels of fingerprint verification. During the enrollment process, the RWKLB575 is connected to your PC via a USB port. The software will guide the user to place their finger on the sensor. The fingerprint template is collected at the unit and immediately transferred to the card. During this enrollment process, the fingerprint template is stored ONLY on the card; it is never transmitted to an external host. During verification at the door, the LCD graphical display will assist the user with instructions about finger placement on the biometric sensor.
Benefits of the bioCLASS line include:
Users can choose the level of security to meets their needs: card and PIN; card and fingerprint; card, PIN, and fingerprint.
The finger pad at the bottom center of the biometric unit offers ease-of-use for either right or left-handed enrollment.
The location of the finger pad is compliant with ADA standards.
The bioCLASS RWKLB575 read/write contactless smart professional card reader with keypad, LCD display, and fingerprint biometric verification.
LCD display provides feedback on user finger placement and defines custom menu keys.
Fingerprint templates are stored on the iCLASS card and not in the reader, resulting in increased security, faster throughput, easier system management, lower costs for the biometric reader and reduced concerns over individual privacy.
HID's offerings encompass the industry's broadest range of open standard contactless smart card products, available from over 40,000 resellers worldwide.
Specifications
The bioCLASS products provide three levels of fingerprint verification. During the enrollment process, the RWKLB575 is connected to your PC via a USB port. The software will guide the user to place their finger on the sensor. The fingerprint template is collected at the unit and immediately transferred to the card. During this enrollment process, the fingerprint template is stored ONLY on the card; it is never transmitted to an external host. During verification at the door, the LCD graphical display will assist the user with instructions about finger placement on the biometric sensor.
Benefits of the bioCLASS line include:
Users can choose the level of security to meets their needs: card and PIN; card and fingerprint; card, PIN, and fingerprint.
The finger pad at the bottom center of the biometric unit offers ease-of-use for either right or left-handed enrollment.
The location of the finger pad is compliant with ADA standards.
The bioCLASS RWKLB575 read/write contactless smart card reader with keypad, LCD display, and fingerprint biometric verification.
LCD display provides feedback on user finger placement and defines custom menu keys.
Fingerprint templates are stored on the iCLASS card and not in the reader, resulting in increased security, faster throughput, easier system management, lower costs for the biometric reader and reduced concerns over individual privacy.
HID's offerings encompass the industry's broadest range of open standard contactless smart card products, available from over 40,000 resellers worldwide.
Specifications:
- Reader Input Voltage: 9-12 VDC
- Current Range: 350 mA standby / 520 mA peak
- Cable distance to Host: 50 ft (15 m) max RS-232.
4000 ft (1216 m) max RS-485
- 18 Gauge Wire 300 ft (152 m) max Wiegand 22 Gauge Wire 125 ft (60 m) max Wiegand
- Op. Temperature: 32ºF - +113ºF (0ºC 45ºC)
- Open collector output: Sink 40 mA, source 1 mA. |
|
| ... products without technical information |
| |
| The TouchStrip Fingerprint Authentication Solution consists of a TouchStrip Fingerprint Sensor (TCS3) and the Digital ID Hardware Engine (TCD42). This solution has been optimized for use in portable storage applications, conveniently enabling strong data protection. Alternative solutions require matching software to be installed on any machine where the drive is attached. Including the Digital ID Engine inside the drive enables full plug-and-play portability to any machine or OS, and insures that all authentication actions are fully protected from hacking attempts. |
|
|
|
