Brass Fitting
- Push to connect
- Brass pipe
- Compression type
Product Specifications
- Temperature Range -40 ° F to 325° F
- Pressure 250 Psi nominal / 400 Psi Max
- Shape Material Forged SAE CA377 Brass
|
|
|
|
|
|
PRIME double compression (Double ferrule) tube fittings provide a leak proof, torque free joints in all instrumentation & process tubing connections which will withstand high pressure, Impulse, Vacuum, Vibration and temperature. These features eliminate costly, hazardous leaks and provide highest safety and maintenance free tubing joints.
All action in the fittings move axially, i.e. Tube is not twisted during assembly. Since no torque is transmitted from the fittings to the tubing, there is no initial strain, which might weaken the tubing. Each part in the fitting assembly is machined to most exacting dimensional tolerance on CNC machines. Total quality management is practiced throughout the manufacturing process as per ISO standard to achieve best quality joints at all tubing end connections. PRIME tube fitting assembly consist of four precision machined components namely body, nut, front ferrule and back ferrule. All you need to do is to insert the tube and tighten the nut by 1 ¼ turn from finger tight position. This action forces both front & back ferrule to move forward between nut and body, Back ferrule is driven against the taper rare of the front ferrule and swaged radially inward on the tube & thus holding the tube against vibration and mechanical pull due to pressure. Back ferrule also lift the front ferrule out to form a full faced seal on the taper surface of the body. Front ferrule also moves forward against the taper portion of the fitting body and due to wedging action forces inward, gripping and subsequently sealing the front edge tightly on to the tubing.
|
|
Macron produce a comprehensive range of hose fittings in aluminium, gunmetal and other alloys to British, American and other international standards. They can be produced to a customers' specifications in a variety of materials and finishes including polishing, anodising and chrome plating.
-Delivery hose couplings
- Branchpipes and nozzles
- Blank caps and plugs
- Adaptors
- Collection heads and manifolds
- Breechings
- Suction hose couplings and wrenches
- Suction strainers
- Standpipes and hydrant keys
|
|
- Stainless steel pipe
- Diameters 22 to 100 mm (3/4'' to 4'')
- Quick connection, easy to install
- Efficient flow, no leaks
- 10 years guarantee
|
|
|
|
|
|
For Connecting Pneumatic Conveying Tube & Pipe
- Easy to install - All sizes stocked
- Galvanized or stainless steel shells available
- Precision cut inner sleeves and gaskets
- Thick 1/8" black neoprene gaskets standard
- White, silicone & Viton® gaskets available
- Thick stiffener bars provide added strength
- Copper anti-static strips included
- Grade 5 full thread bolts won't strip or break
- Requires only 3/4" tools to install
- Replacement gaskets available
- Gasket protectors available upon request
- Lengths - 2 bolt 4", 3 bolt 6", 4 bolt 8", 5 bolt 10"
Neoprene - Our standard black gasket for Lorenz Couplings is perfect for most dry bulk conveying applications. Resists rotting, checking and cracking from exposure to ozone.
Temperature range (-40° to +200° F) (-40° to 100° C).
White Nitrile - Excellent gasket for all types of conveying applications. Especially in the food industry. A high quality FDA approved compound ( -40° to 100° C).
Silicone - For use in higher temperature applications. Silicone is odourless, tasteless, non-toxic and noncorrosive. Available for all Lorenz products (-60° to 450° F) ( -50° to 230° C).
Viton® - Please consult factory for specific details regarding this product.
|
|
Pipes and components made of steel, longitudinally welded. Diameter from 60 up to 800 mm.
Material: mild steel, primed or galvanized and stainless steel (st/st). Wall-thickness from 1 up to 3 mm.
Pressed segments with small radius for bulk good handling and pressed bends (with good flow characteristics) with a radius twice as large as diameter (up to 400 mm) for exhaust air/dust extraction plants.
|
|
Top Line BioPharm products are designed and built to meet the most stringent requirements of ultra-pure processing, including the ASME BPE 2002 specifications for dimension, surface finish and tolerance.
- Type 316L stainless steel
- Clamp or weld end connections
- Pin stamping of heat numbers and stainless steel grades
- High quality electropolishing or other finishes to suit your needs
Every Biopharm product is subjected to rigorous quality control inspections, then capped and shrink-wrapped to ensure safe storage and shipping.
|
|
The Pargrip Fittings are ideally suited for use in corrosive environments and chemical applications. The fitting design yields a leak-tight connection and requires no special tools to assemble. The connection is achieved by merely inserting the tubing into the fitting assembly and tightening the nut.
FEATURES:
* PFA body manufactured from virgin High Purity materials. Benefit is less surface particulates resulting in cleaner operation.
* Design reduces assembly time, and costs.
* Less downtime with leak tight seal.
* Numerous configurations, including Redi-flare, reduce system complexity and cost.
SPECIFICATIONS:
Materials of Construction:
* Wetted Surfaces - PFA, PTFE
* Non Wetted Surfaces - PVDF, PFA, ETFE
|
|
|
|
|
|
The Grinnell grooved mechanical products range offers a complete & dependable way of executing the mechanical engineering installations in a structure.This applies not only to fire protection systems,but also to heating,air conditioning & ventilation installations.They are found wherever reliable operation is the key factor, even in power stations & other demanding construction projects.Our service also includes the assistance of specialists to offer guidance on the optimum use of these products.
The Grooved Method
Grinnell couplings and grooved-end fittings are universally used for joining grooved end pipe in a wide variety of piping systems.They are designed to provide a self-centering joint which accommodates the application of pressure, vacuum & other external forces, while limiting the burdensome need for special supports, expansion joints etc.
Flexible and Rigid Couplings
Flexible couplings provide designed in clearances between the housing key sections & the pipe grooves to permit both angular and longitudinal movement of the pipe.Rigid Couplings provide a rigid, locked-in pipe connection. Rigidity is attained simply; it is built-in.The Rigid System is based on a technologically advanced housing design that conforms to and grips the pipe.Couplings are available in painted & galvanized finish.
Range of fittings
Grinnell grooved fittings are available through 600mm/24" nominal pipe size in a variety of styles.These fittings are designed to provide minimum pressure drop & uniform strength. Depending on style and size, fittings are provided in various materials including malleable iron,ductile iron,stainless steel,forged steel or segmentally welded steel.
|
|
|
Autoclave Engineers medium pressure and high pressure fittings use the coned-and-threaded connection. This metal to metal connection features orifice sizes to match the high flow characteristics of this series. Autoclave's fittings and tubing are used as fluid handling components for the chemical/petrochemical, research, and oil and gas industries and have different ranges capable of operating to 150,000 psi (10,000 bar) and range from 1/4" to 1 1/2" tube sizes.
|
|
Fittings with bush EO2 + machines EOMAT ECO/UNI
Description:
Fitting with bush high pressure guaranteed without escapes and simple and reliable machines of assembly
Advantages:
*Raccord with bush EO2:
- with seal elastomer for a total absence of escapes
- very simplified assembly (loss of the impossible bush, mechanical stop unit)
- unlimited assemblies, disassemblings (possibility of changing the seal)
- high resistor with corrosion (500H with white rust
*Machines of assembly EOKARRYMAT and EOMAT ECO/UNI
- simple and reliable
- portable and autonomous (EOKARRYMAT)
- tubes of 6 with stainless and steel 42mm
- economic (2 X faster than a manual assembly) "
Applications:
Fittings with bush EO2 associated with the machines with assembly EOKARRYMAT and EOMAT ECO/UNI are used successfully in a multitude of industries where fluids are conveyed under pressure
|
|
- Working pressures up to 14.000 bar / 200,000 psi.
- Large orifices at rated pressures.
- Excelent flow capacity performance.
- Safety quaranteed by use of wheep holes.
- High quality stainless steel.
- Suitable for fluids and gases.
WE ARE LOOKING FOR A DISTRIBUTOR IN ITALY. Please contact us if you are interested!
|
|
MPI Fittings are designed to operate at pressures in the range of 5,000 to 15,000 psi.
|
|
While others were thinking about large fittings, Clippard was thinking big about smaller fittings. Smaller valves and cylinders created the need for smaller fittings. Clippard was the first to develop ports utilizing the 10-32 thread. This thread has become an industry standard in the marketplace.
Clippard precision fittings will save you time, space, and money when designing versatile, productive, trouble free, pneumatic circuits. Our endless variety of fittings insure that you find just the right fit when plumbing pneumatic circuits or assemblies. These fittings are small in size but large in performance, allowing for streamlining of pneumatic assemblies and eliminating the need for larger, more expensive, cumbersome fittings.
|
|
Fittings: The range of fittings for steel pipes, for PE pipes and threaded fittings covers all the needs of Industrial and Plumbing Industries.
TOF PE - Brass fittings for Polietilene pipes
TOF/T GAS : Reached T for PE with derivation fi lettata female Gas
|
|
Features
• Available with choice of NPT/BSPT/BSP/SAE/ISO pipe threads, weld end and hose end fittings.
• Wide range of sizes, combinations and configurations.
• Manufactured in wide range of material like Stainless Steel, Steel, Brass, Aluminum, Titanium, Hastalloy, Monel and other special alloys.
• Straight items are made from fine quality extruded bars, all shaped items are made from close grain forgings.
• Size range from 1/8” to ¾”. Bigger sizes are available on request.
• All threads are capped to avoid damages
|
|
Dog bones should prevent a sliding or moving of the piping system in each direction. They serve furthermore for compensation of the reaction forces of compensators such as sliding sockets and push-fit fittings. The dog bone has to be dimensioned for all appearing forces:
Dog bones which have not been determined should be chosen in a way so as to make use of direction alterations in the course of the piping system for the absorption of the length alterations. As dog bones, edges of fittings sockets or special dog bone fittings are suitable. Swinging clips are not appropriate to be used as dog bones or the clamping of the pipes.
|
|
BULK precision pipe fittings are manufactured in a wide range of configurations
Size range from 1/8" to 1"
Construction from bar stock or forging materials
Threads meet requirements of ANSI B1.20.1, DIN 2999, BSP and ISO 7/1
Male and female threads are protected to ensure their integrity
MATERIALS
BULK precision pipe fittings are available as standard in 316 Stainless Steel.
We can also supply other materials including Brass, Monel, Hastelloy, Inconel, Titanium,...
PRESSURE RATING
Working pressures are calculated in accordance to ANSI code for pressure piping B 31.1 and showed in the table "general info".
Female pipe end ratings are lower than male pipe end ratings for a given size because the inner and outer diameters of female threads are larger than male pipe threads.
|
|
Style 38 Couplings
Proven by years of service on all kinds of pipe, Dresser Style 38 couplings provide flexible, leakproof connections that last the life of the pipe. No costly threading, beveling, exact pipe fitting or alignment is required. The resilient Dresser gaskets absorb vibration and pipe movement and permit curves to be laid with straight pipe lengths. Installation is safe and sure. There's no hazard to workmen or delays due to weather. Dresser Style 38
couplings are available from 1/2" ID to over 400" OD.
NOTE: Commonly used sizes are listed in the tables, but couplings can be
furnished for practically any size or special condition.
|
|
Properties:
Design ==> Screw-in fitting
Supplementary design information ==> French series
Construction ==> T shaped
Connection 1 ==> BSPT conical outer thread
Seal type==> thread seal
Connection 2 ==> metric cylindrical outer thread
Seal type ==> 24° inner cone
Connection 3 ==> metric cylindrical outer thread
Seal type ==> 24° inner cone
Delivery form ==> Socket with union nut and cutting ring
Material ==> Steel
Surface protection ==> electro galvanised, yellow chromized
|
|
|
Safety Lock TYPE: Automatic safety coupler designed to prevent accidental disconnects from the plug. The plug must be pushed further into the coupler body while the sleeve is pulled back in order to disconnect. Typical uses include weld and cut operations, diving, lift systems, air breathing equipment and any application where unintentional disconnecting would create a safety issue.
|
|
|
Air and vacuum plumbing for all EOAT and automation projects. Also includes vacuum generators sized for single cups to entire tools.
|
|
Pipe Adapters
Pipe Caps and Plugs
Pipe Couplings
Pipe Crosses
Pipe Elbows
Pipe Nipples
Pipe Reducers
Pipe Tees
|
|
MATERIAL: A234-WPB. A420-WPL6. A403-WP304L. A403-WP316. A403-WP316L.
Bending Radius®: R=3D, 4D, 5D………..
Bending Angle (θ): Degree15,20,45,60,90,135,180and also could manufacture according the angles given by the clients.
Straight Length (L): The length between two ends general from 300mm-1500mm, and also can product according to the clients’ requirement to product.
Outer Diameter(D) D≤1220mm
Wall Thickness(T) T≤120mm
End Bevel according to the bevel of welding pipe fittings construction
|
|
Female Hose Couplings, Page 203-204
Type M (suitable for self-assembly, reusable)
Type M-NR (non-reusable)
Reverse Side Special Types + Accessories:
Fittings and clamps for barrel pump hoses, spare seals, special washer NYD, box spanner EW 15/25, double head wrench
|
|
As demonstrated by our product certifications (AENOR, AFNOR, Kiwa, etc.), Cepex offers the highest-level guarantee for all its PVC Fittings for pressurized fluid handling applications. The extensive range of sizes and combinations we offer will accommodate any system design. The dimensions of our fittings comply with UNE-EN 1452-3, UNE-EN 1452-3, DIN 8063, and NF 54016/54029 standards, while many of our products meet other standards as well, including British, ASTM and Thai.
|
|
|
|
|
|
The U-PVC range is a system of products complete of: fittings for solvent welding, threaded connection and manual or automatic valves for use in the construction of process and service lines to convey industrial fluids at maximum operating temperatures of 60°C.
The entire range is produced using U-PVC resins compliant with the standards EN 1452 and ISO 4422 and in observance of the requirements of DIN 8063 and EN ISO 15493 for the use of plastic pipes in industrial processes.
Among the main properties and features of the U-PVC range the following can be noted:
Good chemical resistance: U-PVC resins guarantee excellent chemical resistance with regard to most acids and alkalis, aliphatic hydrocarbons and saline solutions. U-PVC resins are also totally compatible for handling food grade fluids, treated and untreated drinking water, as well as demineralised water according to current national and international standards.
Good thermal stability: Mostly in the intermediate temperature range between 20°C and 50°C, U-PVC finds its ideal application in industrial and water supplies, guaranteeing optimal performance in terms of mechanical resistance, good rigidity, low coefficients of thermal expansion and optimal safety factors in service.
Lifetime: U-PVC resins feature is an high value in the material strength (Minimum Required Strength MRS ≥ 25.0 Mpa at 20°C) and an extremely extended lifetime.
|
|
Mechanical Fittings
Fittings for Solvent Cementing
Fuseable Fittings
COOL-FIT
Double Containment
Multilayer Fittings
|
|
|
|
