Flap discs
Flap Discs are used for:
Intermediate and finishing of welds.
Deburring, rust removal and snagging.
Suitable for almost all ferrous & non-ferrous materials
Excellent for surface finishing
Flap Disc specifications:
A/O Flap Discs - Coated with Aluminium Oxide.
Z/A Flap Discs - Coated with Zirconia Alumina.
S/C Flap Discs - Coated with Silicon Carbide.
CGW Flap discs specification and uses:
A/O - Alloy steel and low-alloy steel
Z/A - High-alloy, stainless and heat treated steel. High tensile non ferrous metals
S/C - Marble, Stone, Glass & non Ferrous metals
CGW Flap Discs sizes:
100mm X 16mm (4" x 5/8")
115mm X 22mm (4-1/2" x 7/8")
125mm X 22mm (5" x 7/8")
150mm X 22mm (6" x 7/8")
180mm X 22mm (7" x 7/8")
CGW Types of Flap Discs:
T-27 - Used when working on flat grinding surfaces. Most efficient when used at a 0-15 degree angle.
T-29 - Conical type has an angle excellent for contour and edge work. Best at more dramatic angle of 15 to 25 degrees.
The types are available in 2 densities: Regular and XL.
The XL has approximatly 60% more material then the regular
Z/A - Zirconia Alumina coated, for high alloyed steel, stainless steel and heat-treated steel.
Used for blending and finishing in one operation, CGW flap discs replace the traditional T-27 depressed centre discs and fibre discs. Suitable for:
Grinding and finishing of welds
Decurring, rust removal and snagging
Excellent for surface finishing
|
|
ABI's Flap Discs are created by overlapping coated abrasive flaps and adhering them firmly to a back-up plate. This design provides a cooler running, longer lasting disc. And because new layers of abrasive are constantly being exposed, a very consistent finish is provided during the life of the disc. These discs are specifically recommended for high stock removal on stainless steel, carbon steel, aluminum, and most alloys. They offer many times the life of conventional resin fiber discs.
Characteristics:
- Cool running
- Fast cutting
- Non-loading
- Durable
- Consistent finish
- Long Lasting Zirconium
- Also available with threaded center
Applications:
- Weld grinding
- Surface Preparation
- Blending
- Cleaning
- Deburring
Tools:
- Right Angle Grinder
- Portable Grinder
- Power Tools
- Hand tools
|
|
|
|
|
|
siastrip
sia Fibral can now offer you two types of siastrip disc; we have the siastrip and the siastrip plus. These products are designed for cleaning and stripping the work piece, doing so without excessive stock removal, thus leaving a clean manageable surface to work on. The open structure of our siastrip products make them ideal for many applications and assist in its resistance to loading.
Series 6300 siastrip
Our standard siastrip incorporates an extra coarse silicon carbide grit bonded to rigid open fibres and is black in colour. This product is recommended for stripping paint; it is especially good in the ART sector for removing paint from car bodywork made from carbon steel.
Series 6300 siastrip plus*
The siastrip plus is the red siastrip disc and is used on Innox steel for removing blueing from tig welds. Like the black siastrip it is also recommended for use in the ART sector, but for paint removal on aluminium panels. Both siastrip products are available in the following disc forms: spindle mounted, Type 27 fibreglass backed, siafix and mandrel mounted.
|
|
|
Carborundum coated abrasive flap discs are engineered for light stock removal, blending and finishing all in one application. Using a right angle grinder, they grind like a depressed center wheel and finish like a fibre disc – helping you reduce process time and lower your total grinding costs, and without the need for any special tools. Ideal for metal grinding and polishing, especially for weld bead grinding on fine carbon and stainless steel.
|
|
PSA Discs And Rolls E-weight Silicon Carbide / Waterproof Abrasive Paper
(Black Colour)
DESCRIPTION :
PSA (Self adhesive) E -wt Silicon Carbide in disc GRIT No : P60 ~ P800
FEATURES: Silicon Carbide Grain
- C & D -wt. High quality paper
- Resin on Resin bond
- High quality oil bond paper
BENEFITS: Sharp cut
- Very fine finish
- Resists heat w/ great grain adheshion
-Long lifetime resists all moisture
- High strength paper
APPLICATIONS
- For Wet & Dry sanding
- Lacquers & Paint
- Body filler
- Glass
-Metal
- Plastic
|
|
|
POLIFAN® Flap Discs combine the 2-step process of rough grinding with a hard wheel and finishing with a fiber disc. One-step POLIFAN® Flap discs are aggressive, and capable of extremely high removal rates. They grind quietly and comfortably for enhanced user comfort. They leave a superior surface finish, and can save you time and money.
|
|
The performance of the KLINGSPOR abrasive mop disc, with its fan-shaped radial arrangement of the grinding flaps, far exceeds that of other abrasive products.
- even surface finish over tool's full service life
- high stock removal efficiency per unit of time
- long service life
- low set-up time
- smooth running characteristics
|
|
