MULTILYZER is a digital display flue gas analysis computer with state-ofthe-
art processor technology and convincing, compact design. Measured parameters: O2, COH2, flue gas temperature, combustion air
temperature, draft, pressure, differential pressure.
Options: CO20,000, NO, SO2 Calculated parameters: CO absolute,
CO2, NOx, lambda, eta efficiency, flue gas losses, dew point, temperature
difference. Options: Solid fuel calorific value EB, 15 minutes mean value for solid fuel measurement, eta efficiency condensing systems |
|
In order to permit the measurement and the continuous control of smokes generated by the combustion of natural gas, fuel oil, coal or garbage, Fuji Electric has developed a complete line of gas analysers allowing to adapt all industrial facilities to the standards and regulations limiting the disposals of pollutants in the atmosphere.
|
|
Applications: for controls and the complete analyzes of the industrial and domestic boilers, you will be able to store the series of measurement and to exploit them on PC.
Answers reference frame QUALIGAZ
2 cells O2 and CO
2 optional cells NO (Nox), NO2, SO2 with the choice.
O2, CO2, CO, CO of smoke, ambient CO Peak, NO, NO2, Nox, SO2. Room temperature, of smoke, Delta T ECS.
T Departure and T return
Differential pressure, Delta P
Excess of air, Losses, Output
Index of opacity
Current of ionization
Sealing of the gas network
5 preprogrammed fuels: natural gas, heavy fuel, domestic fuel, butane, propane.
5 other fuels can be programmed on request.
Impact printer integrated with standard paper (not thermics).
Memory size of 250 series of measurement.
Possibility of recording and of printing the indices of opacity.
Comparison between O2, CO2 and excess of air (Lambda)
Integrated room temperature, of smoke and differential T.
Detection and localization of the gas leaks.
Manual switch or automatic of protection of the cell CO.
Indicator of wear of the state of the cells.
Food: refillable battery or sector 230 Vac.
Delivered in a case, with note of use and certificate of calibration. |
|
Model CEA-9001 Flue Gas Analyzer & PEM-9002 Portable Emissions Monitor
The CEA-9001 is a digital, hand-held, flue gas analyzer featuring state-of-the-art microprocessor technology.
Ideally suited for inspecting and servicing small and medium sized heater installations, it is used for safety-relevant technical inspections of CO emission concentrations in gas combustion plants.
The CEA-9001 offers storage of 100 complete blocks of measurement data which can be printed directly via an IR printer or processed through an appropriate PC program.
Optional upgrades are available for up to three measurement cells -- O2, CO, and NO -- which allows for CO measurement with H2 compensation, waste gas temperature, O2 / CO2 content, and combustion air temperature measurement.
The CEA-9001 is available with a light weight yet rugged carrying case. |
|
LAND has a range of portable gas analysers for testing, checking and monitoring combustion processes for operating efficiency; and analyzing pollutant gas emissions for environmental compliance.
The range comprises lightweight, simple-to-use portable gas analysers with facilities aimed at a wide range of applications. Up to 9 gas measurement are available on a single analyser. There are a wide range of options available, including a data acquisition system - plus the ability to self-configure the analyzer to exactly meet plant and process requirements.
|
|
Measuring parameters:
O2, CO / H2, (NO, SO2 and / or CO-high optional), waste gas temperature, ambient temperature, draft or balance pressure.
NOTE: NO2 measurements are not possible.
Computed values:
CO2, CO non-diluted, Lambda, pressure and temperature difference, degree of efficiency (Eta), waste gas losses (qA), NOx, dew point, and Eta combustion value
This lightweight design incorporates many features including:
Powerful storage battery; approximately 30 hours of operation with activated display illumination
Illuminated display showing four simultaneous measuring values in a selectable display combination
Optional upgrades for up to five measuring cells: O2, CO / H2, CO-high, NO, SO2
Integrated printer for plain paper - measuring data can be printed immediately |
|
708 Combustion Efficiency Analyzer
1. Combustion Efficiency Analyzer
• Measure 02 and CO
• Calculate CO2, efficiency, excess air and ratio.
• Will work with high efficiency furnaces, hot water
heaters, and other combustible gas appliances.
2. CO Analyzer
3. Differential Thermometer
709 Combustion Efficiency Analyzer w/ Differential Digital Manometer (0.001 inH20)
1. Combustion Efficiency Analyzer
• Measure 02 and CO
• Calculate CO2, efficiency, excess air and ratio.
• Will work with high efficiency furnaces, hot water
heaters, and other combustible gas appliances.
2. Differential Digital Manometer
3. CO Analyzer
4. Differential Thermometer
712 Flue Gas Analyzer
1. Combustion Efficiency Analyzer
• Measure 02 and CO
• Calculate CO2, efficiency, excess air and ratio.
2. Combustible Gas Detector
3. CO Analyzer
• Measure 0-10,000 ppm CO
4. Differential Thermometer
5. Differential Digital Manometer
714
1. Combustion Efficiency Analyzer
• Measure 02, CO, and NO
• Calculate CO2, NOX, efficiency, excess and air ratio
2. NO & NOX Analyzer
3. CO Analyzer
4. Differential Thermometer
5. Differential Digital Manometer
|
|
The FLAMCHECK portable combustion analyser system enables simultaneous quick and accurate measurements of the various chemical parameters bound to combustion with regard to industrial installations such as: Refineries; Steel industries; Power plants…
The gas sample is taken up through a probe and passed through a condensate trap and a solid particle filter, thereby avoiding any trace of humidity and dust.
The clean & dry sample is then directed to three electrochemical sensors allowing simultaneous measurement of the Oxygen (O2), the Nitrogen Monoxide (NO) and the Carbon Monoxide (CO) concentrations.
Advantages:
• Robust industrial design for daily use in harsh environments.
• High reliability of the measurements thanks to its automatic zero calibration (the time period between calibrations can be programmed).
• Automatic Condensate Recovery and draining
Enables optimum protection of the measuring cells.
• Automatic Protection of the measuring cells when highly concentrated or unusually high temperature samples are present.
• Data display on a large and interactive backlit screen for a user-friendly and simultaneous display of all parameters. |
|
Available for zone 1, ATEX
|
|
COMTEC® 6000 is a totally new and unique InSitu Oxygen & COe (Combustibles) flue gas and process gas analyser. The innovative combustibles sensor pioneered and developed by ENOTEC (patent pending), combines with its world-proven "leak-proof" Zirconia Cell technology to produce the worlds first InSitu O2 & COe analyser.
Both measuring cells, (O2 & COe), are actually located inside the process measuring actual real-time values without the need for sampling, conditioning and expensive hybrid systems. The COMTEC® 6000 probe simply installs directly inside the duct for direct & continuous dual readings of Oxygen & COe present. COMTEC® 6000 can easily be installed as standalone instrument or as a retrofit upgrade to an existing system. It's designed to be maintenance free, with minimal calibration requirements, and completely user-friendly operation.
|
|
| Reliable measurement of ppm combustibles (CO + H2) or carbon monoxide (CO) together with oxygen, allows the user to determine and maintain the optimal O2 set point for the process. This results in improved product throughput, increased safety, longer equipment life, lower emissions and maximized fuel efficiency. |
|
| AMETEK Thermox offers three styles of direct-mount flue gas oxygen analyzer - all are easily serviced without removing the analyzer from the flange. Insitu – average response, to 1250°F (677°C). Convective – average response, to 2600°F (1537°C). Close-coupled extractive – very fast response to 3200°F (1760°C). |
|
A complete range of flue gas oxygen analysers for all applications
Genesis is a range of flue gas oxygen analysers developed specifically for combustion analysis and control applications. Unrivalled flexibility and ease-of-use enables the Genesis oxygen analyser systems range to meet all process requirements.
The range of Oxygen Analysers for General Purpose Applications includes in-situ measurement probes for a wide range of flue gas temperatures (0 - 1250 °C / 32 - 2282 °F), local and remote control units, and an automatic calibration unit.
The 'stand-alone system' is the world's first truly, This oxygen analyser also carries TÜV approval.
|
|
