Agilent function generator / arbitrary waveform generators give you 10 standard waveforms plus the ability to create arbitrary waveforms.
15, 20, 80 or 500 MHz bandwidth
1.25 GSa/s sample clock (N6030A)
Pulse generation with variable edge time (33220A, 33250A)
DDS technology
12, 14, 15-bit resolution
Built-in modulation capabilities
Free IntuiLink connectivity software
|
|
|
|
|
|
The 4079 is a versatile high performance dual channel function / arbitrary waveform generator with the largest arbitrary memory depth in its class. The generator combines the ability to produce nearly any conceivable arbitrary waveform with accuracy and precision and a DDS architecture offering easy to use conventional function generator capabilities. Arbitrary waveforms have 14 bit amplitude resolution, 125 MSa/s sample rate and up to 4 million points of length. Waveforms can be output in continuous, triggered, gated or burst modes. The instrument can be remotely controlled via GPIB or RS232 using SCPI-compliant commands.
Extensive features such as waveform summing, internal or external AM, FM and FSK modulation along with versatile sweep capabilities and variable edge pulse generation make this generator suitable for a wide range of applications including electronic design, sensor simulation and functional test.
Features & Benefits:
* 14-bit, 125 MSa/s, 4 M point Arbitrary Waveform Generator
* 50 MHz Sine / 50 MHz Square waveforms
* Predefined Pulse, Ramp, Triangle, Noise, Sin (X)/X, Exponential and Gaussian waveforms
* Both channels offer full functionality. All wave form parameters such as frequency, amplitude and offset can be set independently
* Synchronize both output signals to the same clock signal (external or internal) and precisely adjust the phase relationship between the two signals
* Economical baseband I/Q signal source
* Saves cost and bench space
* AM, FM and FSK modulation
* 10 mVpp to 10 Vpp with 1 mVpp settable amplitude resolution
* Large graphical LCD shows a detailed output waveform representation
* Fully programmable markers
* Fully protected output
* Closed case calibration
* Arbitrary waveform editing software included
* SCPI compliant command set
* GPIB and RS-232 Interfaces (standard)
|
|
Agilent function generator / arbitrary waveform generators give you 10 standard waveforms plus the ability to create arbitrary waveforms.
15, 20, 80 or 500 MHz bandwidth
1.25 GSa/s sample clock (N6030A)
Pulse generation with variable edge time (33220A, 33250A)
DDS technology
12, 14, 15-bit resolution
Built-in modulation capabilities
Free IntuiLink connectivity software
|
|
|
|
|
|
The 4075 is a versatile high performance function/arbitrary waveform generator with the largest arbitrary memory depth in its class. The generator combines the ability to produce nearly any conceivable arbitrary waveform with accuracy and precision and a DDS architecture offering easy to use conventional function generator capabilities. Arbitrary waveforms have 14 bit amplitude resolution, 100 MSa/s sample rate and up to 400,000 points length. Waveforms can be output in continuous, triggered, gated or burst modes. The instrument can be remotely controlled using SCPI-compliant commands via RS232.
Extensive features such as internal or external AM, FM and FSK modulation along with versatile sweep capabilities and variable edge pulse generation make this generator suitable for a wide range of applications including electronic design, sensor simulation and functional test.
Features & Benefits:
* 14-bit, 100 MSa/s, 400 k point Arbitrary Waveform Generator
* 25 MHz Sine / 25 MHz Square waveforms
* Predefined Pulse, Ramp, Triangle, Noise, Sin (X)/X, Exponential and Gaussian waveforms
* AM, FM and FSK modulation
* 10 mVpp to 10 Vpp with 1 mVpp settable amplitude resolution
* Large graphical LCD shows a detailed output waveform representation
* Fully programmable markers
* Fully protected output
* Closed case calibration
* Arbitrary waveform editing software included
* SCPI compliant command set
|
|
|
|
|
|
Model 4086AWG is a laboratory grade synthesized function generator with arbitrary capability. Direct digital synthesis (DDS) techniques are used to create stable, accurate output signals for all 27 built-in standard and complex (arbitrary) waveforms as well as custom arbitrary waveforms. The 4086AWG produces high purity, low distortion sine waves up to 80 MHz, square waves up to 40 MHz and provides extensive analog modulation capabilities including AM, FM, FSK, PSK, pulse modulation, burst mode and linear/logarithmic sweep combined with multiple trigger modes. The included intuitive Windows Software lets users create and edit custom arbitrary waveforms and download them with a single click to the instrument’s non volatile memory. Unmatched affordability and high performance make the 4086AWG a perfect fit for many applications in Electronic Test and Design, Sensor Simulation and Education and Training.
# Clean and stable output of very small signals down to the 1mV–10mV range (50 ohm)
# Support of internal and external modulation sources as well as internal, external and gated trigger sources
# Create arbitrary waveforms with 10 bit vertical resolution, 16k memory depth and a sample rate of 200 MHz
# Seamless import of waveforms from any Tektronix® TDS1000, TDS2000, TPS2000 and TDS3000 series digital storage oscilloscope. Easily recreate waveforms originating from the DSO’s display or internal memory.
# Fully programmable via the standard RS232 interface using SCPI compatible commands.
# 100 MHz Universal Counter with frequency measurement and totalize function
|
|
|
|
|
|
The 4076 is a versatile high performance function / arbitrary waveform generator with the largest arbitrary memory depth in its class. The generator combines the ability to produce nearly any conceivable arbitrary waveform with accuracy and precision and a DDS architecture offering easy to use conventional function generator capabilities. Arbitrary waveforms have 14 bit amplitude resolution, 125 MSa/s sample rate and up to 4 million points of length. Waveforms can be output in continuous, triggered, gated or burst modes. The instrument can be remotely controlled via GPIB or RS232 using SCPI-compliant commands.
Extensive features such as waveform summing, internal or external AM, FM and FSK modulation along with versatile sweep capabilities and variable edge pulse generation make this generator suitable for a wide range of applications including electronic design, sensor simulation and functional test.
Features & Benefits:
* 14-bit, 125 MSa/s, 4 M point Arbitrary Waveform Generator
* 50 MHz Sine / 50 MHz Square waveforms
* Predefined Pulse, Ramp, Triangle, Noise, Sin (X)/X, Exponential and Gaussian waveforms
* AM, FM and FSK modulation
* 10 mVpp to 10 Vpp with 1 mVpp settable amplitude resolution
* Large graphical LCD shows a detailed output waveform representation
* Fully programmable markers
* Fully protected output
* Closed case calibration
* Arbitrary waveform editing software included
* SCPI compliant command set
* GPIB and RS-232 Interfaces (standard)
|
|
|
|
|
|
The V350 is a four-channel VME-module analog/digital function generator that generates arbitrary waveshapes synchronized with logic-level outputs, as might be used in control systems or radar simulation, or other COTS applications.
Each V350 channel generates one 12-bit analog waveform and up to four digital outputs by scanning sequential data points stored in user-loadable memory. Outputs are processed by digital-to-analog converters, smoothing filters, and output amplifiers.
Output stage multiplexing allows flexible configuration, and channels may operate independently or may be synchronized within a module or across modules.
Control and waveform generation operate at full 40-MHz rate or programmed sub-multiples. An option allows waveform generation synchronous to an external trigger without the jitter resulting from quantization to the local clock.
Each channel has 1 Mword of waveform memory controlled through a 512-block command table that includes Play, Delay, Wait, and Stop commands, conditional jump, and flag control.
Self-test and Demo modes allow quick evaluation and verification.
Features Include:
* 4 analog + digital waveform generators
* Command-table driven architecture
* 1 Mword memory per channel
* Full 40-MHz operation
* Synchronous or independent channel operation
* Self-test and demo modes
* Conformal coated, wide temperature range
* Zero-jitter trigger option
|
|
|
|
|
|
Arbitrary Waveform Function Generator Model 625A
The BNC Model 625A (SG-100A/Telulex) represents a major breakthrough in price/performance for signal generation and signal measurements and analysis. This versatile device allows the engineer to access a broad range of operating modes such as arbitrary waveform, pulse, word/data integration, function, VCO, AM, FM, SSB, FSK, and burst.
The BNC 625A is much more than a a signal generator: Never before has so much versatility, capability, and performance been packed into a single-low cost instrument. Its architecture is based on the latest advances in DSP and DDS technology which not only ensures calibrated and drift free performance, but also gives the engineer signal measurement and analysis functions such as voltage/power measurement and DTMF detection.
The BNC 625A delivers clean, fully synthesized, DC to 21.5 MHz modulated or unmodulated waveforms with ) 0.01 Hz frequency resolution and 1mV and 0.1 dBm amplitude resolution. User friendly features include a large, easy-to read LCD display which allows the user to see all modulation parameters simultaneously. A full numeric keypad and encoder provides direct editing of each parameter, without confusing sub-menus.
Areas of application include: medicine, education, communications, photonics, circuit design, power systems, and consumer electronics.
|
|
|
|
|
|
Waveform Generation and Aquisition Modules
•Range of Waveform Generators and a Digitizer Module
•70Ms/sec Digitizer
•lOOMs/sec Arbitrary Waveform Generator
•3 Channel Function Generator to 10MHz
•Occupy Single 3U PXI Slot
•VISA and Kernel Support For PXI Environment
•Complies with PXI and CompactPCI Specifications
The Pickering range of PXI instruments includes waveform generators suitable for producing waveforms for the emulation of sensors or the stimulation of external systems.
The 41 -610 is a Dual Arbitrary Waveform Generator with clock rates up to lOOMsamples/sec and 14-bit converter resolution. Low timing skew between the channels makes it ideal for applications that require two high quality signals with closely matched timing requirements. Waveforms can be created from the embedded waveform library or imported as files from external software tools.
As well as waveform generation Pickering's instrument range includes a Digitizer Module suitable for the capture of analog signals for digital analysis. The 41-320 is a dual channel 14-bit digitizer with a maximum sample rate of 70MHz and can be used with common mode or single-ended input signals.
|
|
|
|
|
|
The B K Precision Model 4017B DDS Sweep/Function Generator is a versatile signal source which combines several functions into one unit including waveform generator, pulse generation (through variable symmetry), frequency sweep and frequency counter.
The heart of the function generator is a DDS based system that produces precision timing for sine, square, or triangle wave generation with frequencies between 0.01 Hz and 10 MHz. A continuously variable offset allows the output to be injected directly into circuits at the correct bias level.
The versatility and capabilities of the 4017B allows for a vast number of applications in both analog and digital electronics fields including Design Engineering, Manufacturing, Servicing and Education. The 4017B has the ability to output a wide range of frequencies that encompasses sub-audible, audio, ultrasonic, and RF applications.
# Features: 2x16 LCD Display area
# Clean output waveforms
# "Intelligent Encoder" frequency control knob
# Linear and log sweeps
# Output level displayed on the LCD
# CMOS/TTL Outputs
# Adjustable DC offset
# RS232 Interface
|
|
|
|
|
|
The 4078 is a versatile high performance dual channel function/arbitrary waveform generator with the largest arbitrary memory depth in its class. The generator combines the ability to produce nearly any conceivable arbitrary waveform with accuracy and precision and a DDS architecture offering easy to use conventional function generator capabilities. Arbitrary waveforms have 14 bit amplitude resolution, 100 MSa/s sample rate and up to 400,000 points length. Waveforms can be output in continuous, triggered, gated or burst modes. The instrument can be remotely controlled using SCPI compliant commands via RS232.
Extensive features such as internal or external AM, FM and FSK modulation along with versatile sweep capabilities and variable edge pulse generation make this generator suitable for a wide range of applications including electronic design, sensor simulation, functional test or generation of I/Q modulated signals.
Features & Benefits:
* 14-bit, 100 MSa/s, 400 k point Arbitrary Waveform Generator
* 25 MHz Sine / 25 MHz Square waveforms
* Both channels offer full functionality. All wave form parameters such as frequency, amplitude and offset can be set independently
* Synchronize both output signals to the same clock signal (external or internal) and precisely adjust the phase relationship between the two signals
* Economical baseband I/Q signal source
* Saves cost and bench space
* 10 mVpp to 10 Vpp with 1 mVpp settable amplitude resolution
* Large graphical LCD shows a detailed output waveform representation
* Fully programmable markers
* Arbitrary waveform editing software included
* SCPI compliant command set
|
|
Model#4011A
MSRP $315.00 0.5 Hz to 5 MHz
Sine, Square, Triangle, Pulse, & Ramp output
Coarse and Fine tuning
4 digit LED display
Variable duty cycle
Variable DC offset
Variable amplitude output plus 20dB attenuator
20Vpp output into open circuit (10Vpp into 50 Ohms)
|
|
Function Generator ( MODEL: FG15)
New FG15, 15MHz Function Generator can generator extremely clean and low
distortion waveform output . It comes with 90MHz TTL output , optional 2GHz
frequency counter etc . The unique design is to make the rotary menu driven
pop up and down functions for easy operation . Please refer to how pure the
waveform is as the attached files.
5MHz Function Generator ( MODEL: FG 52)
0.05Hz ~ 5MHz Function Generator
Linear/Log Sweep Function
Duty Cycle Control
Invert Function
Auto Range Auto Gatetime Counter
0.001Hz Counter Resolution
MODEL: FG 32 (6 Functions, 6 Ranges with counter)
1. Six waveform functions - Sine, Triangle, Square, Ramp +/- Pulse.
2. Frequency Range 0.5Hz ~ 3MHz
3. 5 digit autorange counter LED display
4. Internal/External counter function.
5. Linear/Log sweep. Sweep rate 10mS ~ 5S.
6. External counter trigger level control.
7. VCF input 0 ~ +/- 10V Voltrage control frequency to 1000:
8. Amplitude : 20V p-p (open);10V p-p (50 Ohm load).
|
|
|
The performance of a low distortion analog source and the precision of direct digital synthesis (DDS) is combined in the DS360. With less than 0.001 % total harmonic distortion (THD), 25 ppm frequency accuracy, and a broad range of features including sweeps and bursts, the DS360 is the ideal source for audio frequency applications.
|
|
VXI Technology is one of the leading suppliers worldwide of modular test solutions, offering a broad selection of instruments capable of meeting widely varying customer needs and applications. We develop high-performance instrumentation with a focus on density, modularity and price/performance.
All of our products come with industry standard drivers. These include driver source code and executable soft front panels for interactive control with the instruments.
VXI Technology provides the following types of instruments:
1. Single function, single-slot VXIbus modules
2. Multi-function instruments based on our VMIP™ platform
3. VMEbus instrumentation
|
|
Complex signals have been pre-programmed (ROM) on the GX 1010 and can be accessed as and when necessary. Up to 5 additional signals can be loaded (in RAM) from digital interfaces - RS232 or IEEE.
# Frequencies from 0.1mHz to 10MHz
# Signals: Sine, square, triangle, TTL, pulse,
ramp, noise, arbitrary signals etc.
# Digital display, 20-character LCD screen, 4 lines
# Output level - 5mV to 20 VDC
# Wobble (Ext, Int, Lin or Log), modulation (AM, FM,
FSK)
# Programmable RS232, IEEE, creation of specific signals by SX-GENE software
# Power supply: 198-264V or 99-132V
# Safety: IEC 61010-1, Cat.I, 50V
The SX-GENE software extends the potential applications of the GX 1010 by exploiting all its abitrary functionalities:
# parameter setting from a PC
# storage and transmission of the configurations to the GX 1010
# importation of signals from the GX 1010 and from OX 8000 oscilloscopes
# graphical, mathematical and bitmap processing of the wave forms
|
|
The GP1616H function generator is a programmable instrument capable of generating predefined Sine, Square, Triangle, Ramp, Haversine, Haver triangle and Pulse waveforms as well as a programmable DC output. The firmware is customized to be fully compatible with the Hewlett Packard 8116A GPIB command set. Software test procedures using the original HP8116A instrument require no code modification when upgrading to the GP1616H.
|
|
|
Function Generators are basic tools for any laboratory. The basic features and functions are common to most function generators that are available on the market, except Tabor offers the highest end of products with truly analog signals reaching frequencies to 20MHz. Tabor also offers Pulse/Function Generators combo, in which most standard Function Generator features are preserved and some pulse capabilities are added.
|
|
Function Generators
AFG3000 Series Arbitrary/Function Generators
The AFG3000 Arbitrary/Function Generator Series, with its large color display and intuitive user interface, is both easy to learn and easy to use. Operation is just as intuitive as Tektronix oscilloscopes, speeding design and time to market. Dual channel models allow a completely independent selection of waveforms and frequencies and represent a big advantage in versatility and cost. The front panel memory USB connectivity makes it easy to save and transfer waveforms and settings.
|
|
|
|
|
|
Smaller than a paperback, the T346 outperforms rackmount instruments costing far more. It features four output channels capable of generating standard and arbitrary waveforms from microHz to 32 MHz, and four additional internal channels usable as modulation and summing sources. Channels can also be pulse/PWM and Gaussian noise sources, and can be summed with or modulate one another in any combination. Modulations include AM, FM, PM, and PWM. The T344 version is a four channel ARB without modulations.
The T344 and T346 have evolved from the budget-priced 2 MHz T340 waveform generator, and the parallel V340-series VME modules.
Additional Waveform Generators:
T340 Embedded sine wave generator
http://www.highlandtechnology.com/DSS/T340DS.html
T344 Waveform generator
http://www.highlandtechnology.com/DSS/T344DS.html
V340 VME sine wave PWM/pulse generator
http://www.highlandtechnology.com/DSS/V340DS.html
V346 VME complex waveform generator
http://www.highlandtechnology.com/DSS/V346DS.html
V350 VME analog and digital waveform generator
http://www.highlandtechnology.com/DSS/V350DS.html
V370 VME arbitrary waveform generator
http://www.highlandtechnology.com/DSS/V370DS.html
V375 VME arbitrary waveform generator
http://www.highlandtechnology.com/DSS/V375DS.html
|
|
|
|
|
|
The V375 is a versatile VME four-channel arbitrary waveform generator. The module architecture was designed in cooperation with major aircraft engine and power systems manufacturers to provide the features needed for accurate simulation of real-world sensor inputs.
The V375 is ideal for:
* Simulation of sensor signals from complex rotating machines
* Generation of pure and distorted polyphase AC waveforms, with all waveshape parameters (frequency, amplitude, phase, distortion components) smoothly variable in real time
* Generation of complex pulse trains with realtime control of relative pulse positions and amplitudes
* Shake table, servo, or actuator drive
The V375 builds on its predecessor, the Model V370, by extending the output bandwidth to 300 kHz and adding four inputs for user waveforms to sum into the channel outputs. A new burst mode allows software or external input to trigger generation of one or more waveform cycles.
Features:
* Four independent DDS frequency sources allow smooth variation of waveform scan rates without requiring table reloads
* Four versatile, memory-table-driven waveform generators scan up to 65,536 discrete points per waveform at up to 15 MHz point step rate
* 16-bit amplitude resolution; 32-bit frequency resolution
* Programmable waveform jump and triggered burst capability
* Channels may be synchronized within a module or across multiple modules
* Programmable lowpass filters are provided to smooth discrete sample points
* Onboard microprocessor performs macro commands: Fourier synthesis, pulse train generation, sweeping, and test functions
More Waveform Generators:
http://www.highlandtechnology.com/Pages/prodind2.html#Anchor-Arb
|
|
|
|
|
|
* Pattern generator with programmable levels
* 32 bit data width at 40 MS/s
* 32 Bit 66 MHz PCI interface available
* PCI Express x1 interface available
* High and low level programmable to -2 V up to +10 V
* Level individually for each 4 bit programmable
* Outputs can be individually disabled
* Differntial outputs in hardware
* Capable of driving 110 ohm termination
* Up to 4 GSample memory
* Synchronisation to multi-board system possible
* Edge/pulse width/delay trigger
* Synchronization option available for up to 16 cards
* Options: ABA mode, Multiple Recording/Replay, Gated Sampling/Replay, BaseXIO
The M2i.72xx pattern generator series gives the user the possibility to generate digital data with a wide range of output levels. For every 4 bit the LOW and HIGH levels can be programmed from -2.0 V up to +10.0 V. Even at high speeds you are not limited concerning the maximum output swing. This enables the user to drive devices of nearly any logic family, like ECL, PECL, TTL, LVDS, LVTTL, CMOS or LVCMOS. The potentially necessary differential signals are generated in hardware, so that only one data bit is used for each pair of differential signals.
All outputs can be separately disabled allowing the easy connection with digital acquisition boards and the adaption to a wide range of test setups. The internal standard synchronisation bus allows synchronisation of several M2i.xxxx boards. Therefore the M2i.72xx board could be used as an enlargement to any digital or analog board.
|
|
|
|
|
|
* 14 bit arbitrary waveform generator
* 4 synchronous channels with seperate D/A
* Maximum output rate 20 MS/s on 4 channels
* 32 Bit 66 MHz PCI interface available
* PCI Express x1 interface available
* Output up to ±3 V in 50 Ohm
* Amplifier module with ±10 V output level as an option
* Programmable Offset and Amplitude
* Software SPEasyGenerator included
* Up to 4 GSample memory
* Synchronisation to multi-board system possible
The M2i.60xx series offer 8 different versions of arbitrary waveform generators for the PCI bus. With these boards it is possible to generate free definable waveforms on several channels synchronously. There are up to four channels on one board with a maximum sampling rates of 125 MS/s. The internal standard Syncbus allows the setup of synchronous multi channel systems with higher channel numbers. It is also possible to combine the arbitrary waveform generator with other boards of the M2i product family like analogue or digital acquisition boards.
With the up to 2 GSample large on-board memory long waveforms could be generated even with high sampling rates. The memory could also be used as a FIFO buffer to make continuously data transfer from PC memory or hard disk.
|
|
|
|
|
|
* 14 bit arbitrary waveform generator
* 2 synchronous channels with seperate D/A
* Maximum output rate 125 MS/s on 2 channels
* Output up to ±3 V in 50 Ohm
* Amplifier module with ±10 V output level as an option
* Programmable Offset and Amplitude
* Up to 256 MSample memory
* Continuous FIFO mode
* 32 Bit CompactPCI 6U interface
* Compatible with 3,3V and 5V PCI I/O-Voltage
The MC.60xx series offer 8 different versions of arbitrary waveform generators for the CompactPCI bus. With these boards it is possible to generate free definable waveforms on several channels synchronously. There are up to four channels on one board with a maximum sampling rate of 125 MS/s. The internal standard Sync-bus allows the setup of synchronous multi channel systems with higher channel numbers. It is also possible to combine the arbitrary waveform generator with other boards of the MC product family like analogue or digital acquisition boards. With the up to 256 MSample large on-board memory long waveforms could be generated even with high sampling rates. The memory could also be used as a FIFO buffer to make continuously data transfer from PC memory or hard disk.
|
|
|
|
|
|
* 14 bit arbitrary waveform generator
* Maximum output rate 125 MS/s on one channel
* Output up to ±3 V in 50 Ohm
* Amplifier module with ±10 V output level as an option
* Programmable Offset and Amplitude
* Up to 64 MSample memory
* Continuous FIFO mode
* 32 Bit PXI / CompactPCI 3U interface
* Software SPEasyGenerator included
The MX.60xx series offers 4 different versions of arbitrary waveform generators for the CompactPCI bus. With these boards it is possible to generate free definable waveforms on several channels synchronously. There are one or two channels on one board with a maximum sampling rate of 125 MS/s. The internal standard Sync-bus allows the setup of synchronous multi channel systems with higher channel numbers. It is also possible to combine the arbitrary waveform generator with other boards of the MX product family like analogue or digital acquisition boards. With the up to 64 MSample large on-board memory long waveform could be generated even with high sampling rates. The memory could be used also as a FIFO buffer to make continuous data transfer from PC memory or hard disk.
|
|
|
|
|
|
* 14 bit arbitrary waveform generator
* Maximum output rate 125 MS/s on one channel
* 32 Bit 66 MHz PCI interface available
* PCI Express x1 interface available
* Output up to ±3 V in 50 Ohm
* Amplifier module with ±10 V output level as an option
* Programmable Offset and Amplitude
* Software SPEasyGenerator included
* Up to 4 GSample memory
* Synchronisation to multi-board system possible
The M2i.60xx series offer 8 different versions of arbitrary waveform generators for the PCI bus. With these boards it is possible to generate free definable waveforms on several channels synchronously. There are up to four channels on one board with a maximum sampling rates of 125 MS/s. The internal standard Syncbus allows the setup of synchronous multi channel systems with higher channel numbers. It is also possible to combine the arbitrary waveform generator with other boards of the M2i product family like analogue or digital acquisition boards.
With the up to 2 GSample large on-board memory long waveforms could be generated even with high sampling rates. The memory could also be used as a FIFO buffer to make continuously data transfer from PC memory or hard disk.
|
|
|
The Function Generator is a full-featured, 30 MHz instrument that uses an innovative Direct Digital Synthesis (DDS) architecture. It generates many standard waveforms with excellent frequency resolution (1 µHz), and has versatile modulation capabilities including AM, FM, Burst, PM and frequency sweeps. It also generates arbitrary waveforms with a fast 40 Msample/s update rate.
|
|
|
|
|
|
The GX1110 is a high performance, single-channel PXI arbitrary waveform generator that offers function generator and arbitrary waveform generator functionality within one instrument. Built-in waveforms are available for use with both the DDS or AWG modes of operation and include Sine, Triangle, Ramp, Noise, Gaussian pulse and Sinx/x. A flexible sequencer is also available as part of the AWG's architecture, supporting the generation of complex waveforms.
The GX1200/1201 is a single-channel PXI-based Arbitrary Waveform Generator. The GX1200/1201 is a high performance waveform generator that combines many powerful functions in one small package.
The GX1200/1201 is a single-channel PXI-based Arbitrary Waveform Generator. The GX1200/1201 is a high performance waveform generator that combines many powerful functions in one small package.
The GC1300 is a single-channel PCI-based Arbitrary Waveform Generator. It is a high performance waveform generator that combines many powerful functions in one small package. Supplied free with the instrument is Arbconnection software, which is used for controlling the GC1300 and for generating, editing and downloading waveforms from a remote computer.
|
|
|
Model 5061 represents the company’s next generation of products in the field of function, pulse and arbitrary waveform generators. This instrument is superior and far more versatile than any existing equivalent weather it is an analog or digital product. As a waveform source, this model can replace analog generators in almost every application. The Instrument combines high-frequency performance, versatility and compact size in a boxed format. Featuring signal output in the range of 1mHz to 25MHz and 14-bit vertical DAC resolution and up to 1M arbitrary waveform buffer, these instruments exhibit performance and provide solutions to the most demanding test stimulus challenge.
|
|
|
|
|
|
Arbitrary Waveform Generators
Arbitrary waveform generators offer a degree of versatility that few other instruments can match. In addition to creating standard waveforms, they can generate "real world" signals with all the glitches, drift, noise and other anomalies that a device-under-test will encounter when it leaves the lab or manufacturing floor.
With their ability to produce all the types of waveforms that you can imagine, these mixed signal generator instruments embrace applications that include serial data communication simulation, wireless network stress testing, disk drive testing and much more. Key capabilities include:
* Analog, digital and mixed signal generation
* Up to 4 analog outputs, 28 digital outputs, and 4 variable level marker outputs
* Industry-leading performance: up to 20 GS/s sample rate; up to 5.8 GHz bandwidth
* Up to 14-bit vertical resolution
* Real-time sequencing control to create infinite waveform loops, jumps, patterns and conditional branches
* Integrated PC, large color display, touch screen, removable hard drive, CD/DVD drive, USB ports, Ethernet and GPIB, providing flexibility to enhance productivity.
|
|
|
|
