CNG Series
Twin Tower Natural Gas Dryers
CNG Series twin tower purification systems are completely self-contained, fully automatic, heat reactivated, closed-loop blower purge desiccant dryers. Located at the gas inlet of the booster compressor, they are designed to remove water vapor from Compressed Natural Gas. Using molecular sieve as the drying media, these systems will continuously dry CNG down to a pressure dew point as low as -100°F with residual moisture levels as low as 0.04 lbs. per mmscf.
Specifically engineered for large flow (>200 scfm) heavy-duty NGV fleet refueling applications.
Specially formulated molecular sieve desiccant for minimal odorant fading and low-pressure drop.
Full-ported, poppet type non-lubricated valves for reliable operation and long life.
Down-flow drying results in less fluidization & longer desiccant life.
Closed-loop convection regeneration-no gas lost to purge and prolonged desiccant life.
|
|
|
A philosophy of quality manufacturing and innovative design has made Kemp a leader in engineered solutions for air, gas and liquid drying/separation. Let us put our 130 years of engineering and manufacturing experience to work for your engineered application.
|
|
|
|
|
|
P u r g a s complete purification series
In order to make natural gas suitable for utilisation as fuel in motor vehicles, it is essential to remove suspended solid particles and to ensure that the gas is dry (i.e. that it contains no water)! On the one hand this ensures reliable operation of the vehicles by preventing clogging and corrosion of vital vehicle components such as the fuel system and the fuel tank.
On the other hand, natural gas fuel filling stations are not subject to disturbances, for example at compressor intakes or due to freezing at the fuel pumps, so that availability is ensured around the clock.
Meet the reqirements of ISO 15403:2000(E). http://www.iso.org
ZANDER offers system solutions from 16 up to 350 bar. Capacity 35m³/h up to 2500 m³/h.
Manufactured by the specifications ISO 9001 and ISO 14000, the design of the delivered absorbers and filters is technically free from oil and grease, for applications involving technical gases of the fluid group 1 according to the pressurised equipment directive (DRG 97/23/EC). This ZANDER system solution dependably fulfils the standard for natural gas quality according to ISO 15403:2000(E) as well as compliance with the European directives for explosion protection according to ATEX (94/9/EG)
|
|
Natural gas processing plants purify natural gas before it is supplied to the market.
The components extracted are either recycled (ethane, propane, LPG) or disposed of (nitrogen).
|
|
|
|
|
|
As Gas Chromatograph users will probably confirm, little has changed in the past decades in the way hydrogen gas is used in the laboratory. Now that picture is set to change, thanks to a remarkable multi-disciplinary gas generator manufactured by Parker Balston. Their new paradigm solution for generating hydrogen in laboratories is so easy to use that it could potentially save thousands of Euros a year in expensive downtime and installation costs.
Four different models have been upgraded to the 100, 165, 260 and 510 ml/min units producing high purity hydrogen, 99.9999% at up to 6.89 bar. Special features include an advanced PEM electrochemical cell protection system with microprocessor controls, a unique water hydration circulation purification system. This is also complimented by USB capability with software options for remote monitoring and control, blue intensity back lighted display for simple operator use with touch screen visuals for system status checks, Automatic water fill options, and data logging performance controls for preventative maintenance with reporting tools for use in regulated environments where system validations are required.
These generators will allow GC (Gas Chromatograph) users to supply, control, and automate all hydrogen gas supplies. A single generator can support up to as many as 13 instruments with high purity hydrogen.
Other applications include fuel gases for total hydrocarbon analyzers, supply gases for hydrogenation reactors, hydrogen for pilot scale fuel cells assays and hydrogen for collision reaction gases.
Each generator is available as standard with a two-year warranty emphasizing the quality and reliability
Parker Balston is the worldwide leader in separation and filtration technologies, and offers a broad range of analytical gas generators to meet your specific analytical instrument requirements. All products are backed by a fully staffed field sales and service organization.
|
|
|
The combination of these technologies produces a continuous on-demand supply of pure nitrogen. Typical applications include nebulizer gases, curtain gases, source gases, chemical and solvent evaporation, instrument purge and supply, evaporative light scattering detector use and sparging.
|
|
|
The Parker Balston NitroSource Lab nitrogen generator can produce up to 500 lpm of pure LC/MS grade nitrogen at pressures up to 10 bar. The generator is engineered to transform standard compressed air into a safe regulated supply of nitrogen with minimal operator attention. Pressure flow rates and purities are specifically designed to match the stringent requirements of all the latest LC/MS instruments. Typical applications include LC/MS, LC/MS/MS, nebuliser gases for APCI and ESI, ELSD, Turbo Vaps and chemical solvent evaporation. The Nitrosource Lab technology has been tried and tested by all the major LC/MS manufactures.
|
|
|
|
|
|
‘Plug and Play’ Nitrogen Generator for LC/MS
The Parker Balston® NitroFlow Lab is a self contained generator that produces up to 32 lpm of pure LC/MS grade nitrogen at pressures up to 8 bar. It produces nitrogen by utilizing a combination of compressors, filtration, and membrane separation technologies. High and low pressure compressors carefully matched to hollow fibre membranes separate the clean air into a concentrated nitrogen stream.
The combination of these technologies produces a continuous on-demand supply of pure nitrogen. Typical applications include LC/MS/MS nebulizer gases for APCI and ESI, ELSD, Turbo Vaps and chemical solvent evaporation. The NitroFlow Lab has been tried and tested by all the major LC/MS manufactures.
The unique combination of the dual compressor generator ensures that the NitroFlow Lab has several unique technical advantages over all other existing LC/MS Nitrogen Generators.
Nitrogen is produced at low pressure and then compressed to 8 bar. This ensures minimal maintenance of the system with no compressed air filter replacements or condensate. The compressor life is guaranteed under the Parker Balston warranty for 8000 continuous running hours, the longest currently available on the market.
Parker Balston is the worldwide leader in separation and filtration technologies, and offers a broad range of analytical gas generators to meet your specific analytical instrument requirements. All products are backed by a fully staffed field sales and service organization.
|
|
|
|
|
|
Parker Balston® SOURCE LCMS-5000 Series is now available for Applied BioSystems MDS Sciex API-LC/MS users
The Parker Balston® SOURCE-LCMS-5000 is a visually integrated and functionally modular LC/MS gas generation system which produces high purity nitrogen, zero air and exhaust pump gases for all Applied Biosystems – MDS Sciex LC/MS/MS instruments.
It produces nitrogen, zero air and pump exhaust air by utilizing a combination of a compressor with filtration, catalysts and membrane separation technologies. An integrated low-maintenance compressed air supply is filtered by high efficiency coalescing filters removing all contaminants down to 0.01 micron. Hollow fiber membranes subsequently divide the clean air into a concentrated nitrogen stream. The zero air is produced by catalytic oxidation which converts the hydrocarbons. A passive hollow-fiber dehydration membrane is used to create the exhaust pump gas.
The integrated Scroll compressor is ‘whisper’ quite at only 48 dBA and is supplied as standard with a 10,000 hour / 3 year warranty. Low maintenance and reliable this offers the best compressor warranty currently available on the market.
Parker Balston is the worldwide leader in separation and filtration technologies, and offers a broad range of analytical gas generators to meet your specific analytical instrument requirements. All products are backed by a fully staffed field sales and service organization.
|
|
Besides the standard plants, on request IGS Italia can design and build highly complex plants, with systems installed inside ISO containers, if so required with high-pressure cylinder filling, or else, plan and control the entire gas generation and distribution systems in the customer's facility.
Customized plants can be skid mounted, thus giving full system mobility.
|
|
• Turnkey PSA onsite oxygen generator plants especially designed for on-site continuous production of oxygen
• Mobile, compact, stationnary or shelter units "all-in-on" and ready for operation
• Designed for the most extreme conditions (very high or low temperature, very high or low altitude, dust atmospheres, etc.)
• Oxygen output purity, flow and pressure are stable and certified
• CE marked
• Compliance with european standards
• Various capacities are available
• Three ranges of oxygen generators :
Oxystar 99 : high purity 99.5% oxygen generator
Premium : highly efficient oxygen generator, purity 95% +/- 1%
Orlane : high flow and cost-effective oxygen generator, purity 93% +/- 3%
• Many innovative monitoring options are available including SMS alarming system, touch screen panel, internet remote monitoring, etc.
|
|
At present, the demands for generators of endogas and exogas regard 15% of our supplies.
The major part of the plants are requested with atmospheres on a nitrogen-methanol base. The steadily increasing use of atmospheres on a methane base is to be considered an important fact.
These atmospheres can only be applied in cases of wide tolerances and for specific productions. The current experimentation indicates that there will not be great changes in the future as far as the technical aspect is concerned.
|
|
|
|
|
|
The modular design of the OXYSWING® Medical Oxygen Concentrators allows an unlimited flexibility in the selection and lay-out of a medical oxygen supply system. After installation the end user has even the possibility to adapt his generator to changed oxygen supply conditions by simply varying the number of PSA modules of the unit.
Certified Quality.
Also in terms of quality the OXYSWING® Medical Oxygen Concentrators offer a new dimension: besides the manufacturing to the quality standards of both ISO 9001:2000 and ISO 13485:2003, OXYSWING® Medical Oxygen Concentrators are also certified to the 93/42/CE directive for medical devices, which makes them fully suitable for any healthcare application.
Reliable, Convenient & Simple.
· Process piping, valves and air treatment of each supplied concentrator already sized for the maximum possible number of PSA modules;
· Standard process piping and valve bodies made of stainless steel;
· Components from first-class international suppliers with proven durability even under harsh operating conditions and available throughout the world;
· Standard oxygen analyzer with zirconium-oxide measuring cell:
maximum measuring reliability
no annual measuring cell renewal required
no yearly calibration required
· Optional electronic flow meter installed inside the metal cabinet;
· Optional CO2 analyzer;
· Optional telemetry for remote monitoring and control of the oxygen generator
· Robust and simple design for minimum maintenance requirements;
· No skilled personnel needed for system modification at the installation site in case of changed oxygen supply conditions
|
|
• Industrial units to produce oxygen on site by oxygen concentrator FLOXY, delivered turnkey
• Specially designed for continuous operation
• Purity, flow and pressure output stable and guaranteed.
• CE marked systems
• Several levels of concentration depending on the model chosen: 90, 93, 95, 99 and 99.5%.
• Different capacities available to meet all consumer profiles
• Many innovative options: SMS alarms, supervision by touchscreen panel and/or internet access, continuous recording, remote management, etc..
• Mobile, compact, stationary or shelter available
• Documentation according to engineering standards available upon request
• For medical applications (supply of medical gas piping systems in hospitals and clinics), please consult the product "generator / medical oxygen concentrator"
|
|
Distributed Energy Systems' StableFlow™ Hydrogen Control System is a breakthrough product allowing a power plant to actively control generator casing hydrogen purity, pressure and dew point.
StableFlow Hydrogen Control Systems integrate into your current hydrogen supply and automatically control pressure, purity and dew point. Actively controlling
hydrogen at optimum levels in your hydrogen cooled generator that will:
• Optimize Fuel Efficiency
• Maximize Generator Capacity
• Extend Generator Life
StableFlow Hydrogen Control Systems are designed for simple installation and do not require a generator outage.
|
|
|
WITT gas mixers are available as mechanical or electronic systems for different types of gases, capacity ranges and areas of application. The gas mixtures produced are either variable or pre-set. For local or remote monitoring and control extensive sensor technology and electronics are available. Gas mixers are also supplied with integrated analysers.
|
|
|
|
|
|
KOFLOC MFC-Gas Mixer (8500)
The KOFLOC MFC-Gas Mixer (8500) integrates 3 KOFLOC Gas Mass Flow Controller MODEL 8500 SERIES and a gas mixer in one convenient package. The result is a compact device that not only saves space and avoids clattering, but a unit with superior performance than a conventional system of separate mass flow controllers, a gas mixer and piping. The KOFLOC MFC-Gas Mixer (8500) is especially suited for burn control applications by greatly reducing flame flickering and stabilizing burn better than conventional setup.
FEATURES
- High-lift actuator for large flows
- Single 24 VDC power source
- Choice of RS232C or RS485 interface
- Standard totalizer function
- 14-bit converter for 4-1/2-digit display and operation
- Isolated thermal sensor for measuring inflammable gases
- Choice of SUS316L or SUS316 stainless steel
- Standard dimensions and fittings for easy replacement
- Free mounting position
- SV setting, plus 5 pattern settings
- Auto-zero function
- Wide selection of fittings, seals, wetted materials and communication interfaces
- Easy maintenance
APPLICATIONS
♦ Gas mixing
♦ Burn control
|
|
Gas Mixers
WITT gas mixers are available as mechanical or electronic systems for different types of gases, capacity ranges and areas of application. The gas mixtures produced are either variable or pre-set. For local or remote monitoring and control extensive sensor technology and electronics are available. Gas mixers are also supplied with integrated analysers. WITT are happy to design and build equipment to meet special requirements.
|
|
Proton Exchange Membrane Compact
Hydrogen Generators
- High purity (99.999+ %)
- Process pressure
- Minimizes hydrogen inventory
- No caustic electrolytes, asbestos free
- Reliable, compact, automatic control
Production rates: .5 - 1 Nm3/h (19 to 38 scf/h)
Distributed Energy Systems makes Proton Exchange Membrane (PEM) hydrogen generators the new standard for on-site hydrogen production. Related PEM products are already recognized as the technology of choice for automotive fuel cells. HOGEN® hydrogen generators are available for broad commercial use.
|
|
HOGEN GC hydrogen generators provide ultra-pure (99.9999%) pure hydrogen for a wide variety of laboratory and small scale industrial applications such as:
- Carrier gas for Gas Chromatographs (GCs)
- Fuel gas for flame ionization detectors (FID¹s) used with GCs
- Fuel gas for Trace Hydrocarbon Analyzers
- Hall detector reaction gas
- Plus hydrogen for other precision instruments and chemical research
|
|
|
The FuelGen(TM)hydrogen fuel generator system is the latest offering from Proton Energy Systems for vehicle fueling. The FuelGen system includes all of the components of Proton's commercial HOGEN H6M electrolyzer, housed in an outdoor rated enclosure. Enhanced system controls include an energy conservation mode for both the generator and chiller well suited to the intermittent hydrogen demand of the fueling scenario. The integrated DI water system, hydrogen quality monitoring, internal temperature control, and self contained automatic safety system make the FuelGen a turnkey, integrated electrolyzer package for high purity hydrogen fuel generation.
|
|
The PAC Chromatography application solution portfolio matches almost the entire spectrum of petroleum, petrochemical and natural gas analysis needs.
Beginning with the light end analysis of gas, naphtha and gasoline streams, PAC standard solutions progress up to and include the analysis of heavy streams such as crude oil and residual.
We also provide solutions for Environmental applications.
|
|
There are three hydrogen generator models in the HG2000 Series, offering outputs of 200 to 600 Nml/min and gas purity ratings in excess of 99.9995%. Thanks to their compact dimensions, these units can easily be positioned near the analysers they feed.
These generators are equipped with a microprocessor control system, a liquid crystal display to inform the operator of generator status in real time, and a membrane keyboard for setting main gas delivery parameters. HG2000 Series hydrogen generators are also equipped with an effective alarm system to warn the operator of any system malfunctions.
|
|
|
|
|
|
BENEFITS AND SAVINGS
- H2 production only on demand
- Ultra compact design
- Improved productivity and chromatography results
- Improved safety in the lab
- Extended column life
- Increased efficiency in the laboratory
- No caustic solutions required
- Recommanded by the major analytical instruments company
APPLICATION
Eliminate the high pressure H2 gas cylinders of the laboratory by generating a continuous source of pure H2 gas for the following applications:
- GC-FID, NPD, TCD, ELCD, HALL
- GC-Carrier gas
- THA
OPERATING MODE
These generators use the newest membrane technology for the electrolytic production of pure H2 gas. This technology was preferred over alternative hydrogen generating techniques because it is clean, requires less maintenance and there is no need to store chemicals to maintain operation. Hydrogen is produced by electrolysis of water through a polymer membrane. Only pure water, either distilled or deionised, is required to provide trouble free long term operation. A dessican t cartridge purifies the hydrogen.
Safety features :
The small contained volume(< 50 ml )makes the generator safe for operation in spaces where cylinder hydrogen is restricted. An auto shutt off procedure places the unit in standby in the event of an internal error, and selectable alarms allow the user to be informed whenever operating conditions vary from the set point.
|
|
TELEDYNE ENERGY SYSTEMS, INC. manufactures hydrogen generation systems designed for on-site, automatically controlled, ultra-pure hydrogen product gas generation. Delivery flows range from 1.1 nm3/hr (20 SLM) up to 56 nm3/hr (1,000 SLM) with 99.9998% purity. The generators also produce oxygen as a byproduct of the water electrolysis process.
The hydrogen generators are fully assembled, skid mounted and operationally tested prior to shipment to facilitate ease of installation and commissioning. System design can also be provided to include compression and storage solutions specific to your application.
TELEDYNE ENERGY SYSTEMS, INC. hydrogen generators are currently used in power plant, chemical plant, semiconductor, argon purification, metals processing, float glass, fiber optic, research laboratory, fuel cell testing, and hydrogen fueling applications throughout the world.
|
|
Pollution-free - full automatic clean generation-of-gas equipment.
Prolonged continuation operation is possible - Maintenance-free
Generation-of-gas equipment of the in-situ type which supplies the clean hydrogen gas which impurities do not mix by adoption of ion exchange membrane type water electrolysis.
application :
- For hydrogen addition of various chemical reactions
High purity gas for various burning.
- A marking pretreatment of IC and electronic products
- Metalworking, such as a false tooth and a jewelry craft
- Plastic melting processing
Fuel cell, other fuel
For functional water (hydrogen water) manufacture
|
|
|
Andritz VA TECH HYDRO has been producing generators and other electrical equipment since 1892. Well known under the repudated brand name "ELIN", VA TECH HYDRO generators are in operation all over the world. Generators with a capacity of more than 40,000 MVA are in service. Our own welding and machining facilities secure high quality and short delivery time.
|
|
Claind’s nitrogen generators satisfy all laboratory analysis and industrial process needs with very few exceptions.
The range includes compact generators with built-in oil-free compressors, medium and high pressure generators for industrial applications, and special generators for OEM applications.
Claind’s nitrogen generators are based on PSA (Pressure Swing Adsorption) technology for maximum reliability and gas quality. Claind has also patented the Fast Purity system, the most significant innovation in the world of PSA technology in recent years.
|
|
Hydrogen generator HG2000
There are three hydrogen generator models in the HG2000 Series, offering outputs of 200 to 600 Nl/min and gas purity ratings in excess of 99.9995%. Thanks to their compact dimensions, these units can easily be positioned near the analysers they feed.
These generators are equipped with a microprocessor control system, a liquid crystal display to inform the operator of generator status in real time, and a membrane keyboard for setting main gas delivery parameters. HG2000 Series hydrogen generators are also equipped with an effective alarm system to warn the operator of any system malfunctions.
|
|
Peak 99.9995% H2 Generator
Trusted technology that has been proven successful in our CFH Range of Hydrogen Generators has now been incorporated into the design for our new Peak Hydrogen Generators.
Safety Features such as a Self- Check for internal leaks on Power- Up, Dual Safety in the form of pressure control and a mechanical pressure switch as well as forced air ventilation eradicate the risk of Hydrogen escaping into atmosphere.
The Hydrogen Generators also benefit of an automatic water loading pump, which loads water automatically from an external tank, allowing for easier and less frequent re-fills of de- ionised water.
The new smaller design of this generator range safes valuable space in your laboratory.
|
|
|
|
